MT30 Installation Guide - Smart Automation Button
Overview
The Cisco Meraki MT30 is a cloud managed Smart Button that is exceptionally simple to deploy and configure due to its integration into the Meraki dashboard
and the use of BLE technology. The MT family eliminates the complex and costly setups required by traditional solutions which removes the limitations of
placement of these sensors.
Product Overview
Physical Specifications
Dimensions
117.1x65.7x23.3mm (LxWxH)
•
Power
•
•
Operating Environment
•
•
•
•
Hardware
•
•
LED Indicators
1xAA Alkaline Battery
Permanent DC Power: 5V;2A USB-C (Sold separately)
Temperature: 0°C - 55°C(32F - 131F)
Relative Humidity: 0 - 95 % RH
Multicolor, multifunction status LED
Action Button
Reset button
USB-C Port
IP55 certified
1
Advertisement
Table of Contents
Related Manuals for Cisco MERAKI MT30
Summary of Contents for Cisco MERAKI MT30
- Page 1 Overview The Cisco Meraki MT30 is a cloud managed Smart Button that is exceptionally simple to deploy and configure due to its integration into the Meraki dashboard and the use of BLE technology. The MT family eliminates the complex and costly setups required by traditional solutions which removes the limitations of placement of these sensors.
- Page 2 • Flashing Amber - MT is running on a low battery. NOTE: To conserve battery life, the LEDs on the MT30 are not always on. Action Button Status Indicator The MT30 Smart Automation Button has 2 types of Action Trigger 1.
- Page 3 USB-C Port The MT30 sensors have a USB-C Port on the bottom that can be used to provide an alternate source of power using a compatible accessory. Package Contents...
- Page 4 Battery 1 AA Batteries Wall Mount Backplate 2x Mounting Screws Mounting equipment 2x Drywall anchors 1xMagnet Sponge 1xVHB Tape Pre-Installation Preparation You should complete the following steps before going on-site to perform an installation: Configure Your Network in the Dashboard The following is a brief overview of the steps required to add an MT10 to your network.
- Page 5 6. Enter device information and then select Done. Press Add another to claim a new device. List of Compatible Gateways: Wifi 5 Wave 2 APs - MR33, MR42, MR42E, MR52, MR53, MR53E, MR74 and MR84 MV2, MV12(W/NE), MV22(X), MV32, MV72(X) Wifi 6 APs - MR36, MR36H, MR44, MR45, MR46, MR46E, MR55, MR56, MR76, MR86 WARNING: Environmental sensors are only supported with second-generation MV cameras and compatible MR APs.
- Page 6 For a permanent installs, we recommend to use the included screws and drywall anchors to directly fix the mount plate on a flat surface. Once the mount plate is installed, the MT30 sensor can be mounted on the plate. Make sure the security screw(T6 torx) on the bottom of the sensor is fastened...
- Page 7 Peel and Stick Install For a less permanent install, there are two options provided...
- Page 8 Magnet - Stick the magnet on any surface and the mounting plate can be stuck to the Magnet. Once the mounting plate is on the desired surface, slide the MT30 sensor onto the plate and use the self retained Torx screw to secure the sensor.
