EVO88-P
Dual-8" Passive Line-Array system
QuickStart Guide
EVO88-P is a professional line-array system that can serve as a
portable or installed FOH solution for medium to large venues
and as ancillary side/down fill for lager PA systems, with a
coherent, natural sound within the coverage area and superior
power delivery in its category
The HF assembly mounts a 3" compression driver and an IDEA
proprietary Hi-Q waveguide allowing for minimum vertical gap
between array elements providing optimum element coupling
and reducing artifacts and DSP adjustments while providing
optimum directivity control. For LMF section, EVO88-P mounts
dual very high-performance 8" woofers.
The active version EVO88-M features a 1,2 kW Class-D
Powersoft power module. One unit of self-powered EVO88-M
feeds one passive EVO88-P, integrating a straightforward active
system that optimises costs, setup and logistics.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EVO88-P and is the answer not in the manual?

Questions and answers

Related Manuals for Idea EVO88-P

Summary of Contents for Idea EVO88-P

  • Page 1 EVO88-P Dual-8” Passive Line-Array system QuickStart Guide EVO88-P is a professional line-array system that can serve as a portable or installed FOH solution for medium to large venues and as ancillary side/down fill for lager PA systems, with a coherent, natural sound within the coverage area and superior power delivery in its category The HF assembly mounts a 3”...
  • Page 2 15/18 mm Birch Plywood Grille 1.5 mm perforated weatherised steel with protective foam Finish Durable IDEA proprietary Aquaforce High Resistance paint coating process Rigging Hardware High-resistance, coated steel integrated 4-point rigging hardware 10 angulation points (0˚-10˚ internal splay angles in 1˚steps) 624 x 223 x 499 mm (24.6 x 8.8 x 19.6 in)
  • Page 3 • IDEA declines any responsibility from misuse that may result in malfunction or damage of the equipment. WARRANTY • All IDEA products are guaranteed against any manufacturing defect for a period of 5 years from date of purchase for acoustical parts and 2 years from date of purchase for electronic devices.
  • Page 4 For further information scan the QR Code or refer to the following web address: www.ideaproaudio.com/product-detail/evo88-p IDEA is always in pursuit of better performance, greater reliability and design features. Technical specifications and minor finish details may vary without notice in order to improve our products.
