EVO24-P
Dual-12" Passive Large-Format Line-Array system
FEATURES
• Premium European High Efficiency custom-IDEA Transducers
• Proprietary High-Q 8-slot dual-driver waveguide assembly
• Multi-enclosure cabinet design
• Rugged and durable 15 mm Birch Plywood construction and finish
• 1.5 mm Aquaforce coated steel grille with internal protective foam
• Integrated Precision rigging system with 10 angulation points
• Integrated lateral bars for transport and setup
• Durable Aquarforce paint coating process
APPLICATIONS
• Main system for Touring and Rental Companies
• Very High SPL installed sound reinforcement
OVERVIEW
EVO24-P is a passive large-format touring line array system
specifically designed for professional sound reinforcement in big
events, large venues or open spaces for audiences from 5000 to
50000, in productions or events operated by rental companies or
pro-audio contractors.
EVO24-P is a 4-Way line-array element that features dual-12"
Neodymium LF woofers, 4 x 6.5" MF woofers in two sealed chambers
and 2 x 3" Neodymium compression drivers coupled to a proprietary -
design waveguide assembly.
QuickStart Guide
1
Advertisement
Related Manuals for Idea EVO24-P
Summary of Contents for Idea EVO24-P
- Page 1 • Main system for Touring and Rental Companies • Very High SPL installed sound reinforcement OVERVIEW EVO24-P is a passive large-format touring line array system specifically designed for professional sound reinforcement in big events, large venues or open spaces for audiences from 5000 to 50000, in productions or events operated by rental companies or pro-audio contractors.
- Page 2 15 mm Birch Plywood Grille 1.5 mm perforated weatherised steel with protective foam Finish Durable IDEA proprietary Aquaforce High Resistance paint coating process Rigging Hardware High-resistance, coated steel integrated 4-point rigging hardware 10 angulation points (0˚-10˚ internal splay angles in 1˚steps) Dimensions 1225 x 339 x 550 mm (48.2 x 13.3 x 21.7 in)
- Page 3 • IDEA declines any responsibility from misuse that may result in malfunction or damage of the equipment. WARRANTY • All IDEA products are guaranteed against any manufacturing defect for a period of 5 years from date of purchase for acoustical parts and 2 years from date of purchase for electronic devices.
- Page 4 For further information scan the QR Code or refer to the following web address: www.ideaproaudio.com/product-detail/evo24-p IDEA is always in pursuit of better performance, greater reliability and design features. Technical specifications and minor finish details may vary without notice in order to improve our products.
