- Page 1 EVO88-M Dual-8” Active Line-Array System User Manual...
-
Page 2: Table Of Contents
TABLE OF CONTENTS WARNINGS AND SAFETY GUIDELINES ............3 WARRANTY ......................4 DECLARATION OF CONFORMITY ..............4 OVERVIEW ......................5 DESCRIPTION .....................5 DSP/AMP POWER MODULE ................6 DSP CONTROLS ....................7 SYSTEM CONFIGURATIONS ................8 MINIMUM ARRAY CURVATURE ...............9 MEDIUM ARRAY CURVATURE ............... 10 MAXIMUM ARRAY CURVATURE ..............11 RIGGING AND INSTALLATION ............... -
Page 3: Warnings And Safety Guidelines
• No user serviceable parts inside. • Only use accessories tested and approved by IDEA and supplied by the manufacturer or an authorized dealer. • Installations, rigging and suspension operations must be done by qualified personnel. -
Page 4: Warranty
WARRANTY • All IDEA products are guaranteed against any manufacturing defect for a period of 5 years from date of purchase for acoustical parts and 2 years from date of purchase for electronic devices. • The guarantee excludes damage from incorrect use of the product. -
Page 5: Overview
PA systems, with a coherent, natural sound within the coverage area and superior power delivery in its category EVO88-M is an active line-array element that features a 1,2 kW Class-D Powersoft power module. One unit of self-powered EVO88-M feeds one passive EVO88-P , integrating a straightforward active system that optimises costs, setup and logistics. -
Page 6: Dsp/Amp Power Module
Visual indicator for active preset number Array configuration preloaded presets and setups EVO88-M internal DSP feature 4 preloaded presets to fit most common internal angulation splay and array length configurations. Refere to page 8 of this document for more detailed information about systems configuration and preset... -
Page 7: Dsp Controls
1.2 kW Class-D amp and DSP application, a medium-sized as factory ready with turn-key power module by Powersoft so EVO88-M system can be easily split solutions for TEOd8 driven amps as one EVO88-M element can power into smaller clusters for mobile and... -
Page 8: System Configurations
MINIMUM (<30° Recommended Internal Splay Angulation Sum) MEDIUM (30-60° Recommended Internal Splay Angulation Sum) MAXIMUM (>60° Recommended Internal Splay Angulation Sum) EASE FOCUS Prediction Software EVO88-M Ease Focus GLL files are available for download from the product’s page as well as from the Downloads repository section. -
Page 9: Minimum Array Curvature
HF energy on the acoustical axis Standalone DSP processors for IDEA Active Line-Array of the Array, achieving greater HF energy over greater systems like EVO88, and included in IDEA System-Amplifier distances (improving “throw”) but narrowing down the DSP Solutions. -
Page 10: Medium Array Curvature
Recommended Internal Splay Angulation Sum This is the most useful level of vertical coverage for the These presets are found as standard in the EVO88-M most typical flown Line-Array applications and it will ensure integrated DSP and can be directly selected from the back balanced coverage and SPL within the listening area for the pannel interface as shown in Section of this document. -
Page 11: Maximum Array Curvature
Standalone DSP processors for IDEA Active Line-Array summing of the HF energy. This kind of angling is found in systems like EVO88 and included in IDEA System-Amplifier Arrays with a small box count or in larger arrays that are DSP Solutions. -
Page 12: Rigging And Installation
Suspension of this product should be implemented by qualified professionals following safe rigging practices and local regulations. Designed, engineered and manufactured by IDEA in Cedeira (Galicia) Made in Spain PRODUCT OF EUROPE to 10 internal angulation options in 1° steps are available and dedicated stow positions for a precise and quick deployment of the array. -
Page 13: Recommended System Suspension Procedure
RECOMMENDED SYSTEM SUSPENSION PROCEDURE Set the transport Unlock the bottom cart with the EVO88 EVO88 element from elements in the desired the transport cart and position and lock the proceed to suspend wheel for a secure setup. the system up to a comfortable position for next step. -
Page 14: Configuration Example
CONFIGURATION EXAMPLE 8 x EVO88 System 8 x EVO88 Sustem AC 32A* 70-cm 70-cm Balanced Balanced 70-cm 70-cm AC 32A* audio signal* audio signal* PowerCON PowerCON Links Links Links Links INPUT A INPUT B INPUT C INPUT D AES/EBU A AES/EBU B Ch. -
Page 15: Technical Data
Nominal Impedance: Refer to the owner's manuals for 16 Ohm rigging instructions, system Recommended Amp Power: INPUT components and suspension 600/1200 W hardware intended for this product. Designed, engineered and manufactured by IDEA in Cedeira (Galicia) LINK PRODUCT OF EUROPE... -
Page 16: Accessories
ACCESSORIES RF-600 is a dedicated rigging frame allows for quick, easy and secure deployment of EVO88 arrays in flown setups. The rigging frame has been design to seamlessly fit and lock with EVO88 integrated rigging hardware. Dimmensions: 90 x 653 x 628 mm Net Weight: 21.5 Kg Max. - Page 17 For updated information regarding IDEA products, refer to our website support section: www.ideaproaudio.com/resources IDEA is always in pursuit of better performance, greater reliability and design features; technical specifications and minor finish details may vary without notice in order to improve our products.
