Summary of Contents for Furniture of America Dutton CM-BK265
- Page 4 Ladder Rail...
- Page 5 Small L Shape Connection Bracket Big L Shape Connection Bracket...
- Page 7 Align the HB frames (#5) to the back posts and front posts. Insert bolts (#F) into each end and secure using the Allen wrench (#S). Align the right bookcase center panel (#8) to the right bookcase top panel (#6) and bottom panel (#7). Insert bolts into the side and bottom pre-drilled holes.
- Page 8 I. Insert wood dowels (#N) into each end of the right bookcase top panel (#6) and bottom panel (#7). II. Align the right bookcase left panel (#9) and right panel (#10) to the top and bottom panels. Insert into the wood dowels then insert bolts (#E) and secure using the Allen wrench (#S).
- Page 9 Align the nightstand top panel (#12) on top of the nightstand (#14). Insert bolts (#E) and secure using the Allen wrench (#S).
- Page 10 Align the desk (#15) to the nightstand top panel (#12) and the right bookcase top panel (#6). Insert bolts (#E) and secure using the Allen wrench (#S).
- Page 11 Align the right back post (#3) to the right bookcase left panel (#9) and right panel (#10). Insert bolts (#E) from within and secure.
- Page 13 Align the ladder steps (#24) to the ladder rails. Insert 10 bolts (#G) and secure using the Allen wrench (#S). Hook the ladder and insert 2 screws (#J). Secure using a Phillips screwdriver.
- Page 14 Insert screws (#I) into the slat ends and secure using the Phillips screwdriver.
