Wireless Remote Control

pecification:

Function:

16 Channel wireless remote control

Frequency:

433.92MHz

Battery:

3V CR2032 Lithium Cell Battery

verview:

Compact 16 channels hand held remote control with the ability to control your lighting system

wirelessly.

With 4 sets of ON/OFF button, 1 set of group ON/OFF function and a slide switch to select 4

channels.

LYCT-505

Version 2.

Table of Contents

Need help?

Do you have a question about the LYCT-505 and is the answer not in the manual?

Page 1 Wireless Remote Control LYCT-505 pecification: Function: 16 Channel wireless remote control Group ON/OFF Function Frequency: 433.92MHz Battery: 3V CR2032 Lithium Cell Battery verview: Compact 16 channels hand held remote control with the ability to control your lighting system wirelessly. With 4 sets of ON/OFF button, 1 set of group ON/OFF function and a slide switch to select 4 channels.
Page 2 aring: Hand held remote control can memorize unlimited receivers into the 16 channels. Pairing using LEARNING MODE: 1. First choose the desired receiver(s) that you wish to control. 2. Press the ‘Learn’ button once (LED will flash), this will now enter learning mode. 3.
Page 3 peration: If you wish to use more than 4 memories, the I / II / III / IV slide switch at the bottom of the remote control must be used. Each channel can store up to 4 memories. Slide Switch. Slide switch allows the remote control to transmit up to 16 commands.
Page 4 attery Replacement: 3V CR2032 lithium battery is included. When the battery voltage is low, the transmission range will be reduced accordingly. Slide down battery cover and with a screw driver push out the battery. Replace with a new battery then slide up the battery cover. roubleshoot: Problem: The LED on remote control does not light up.
