FusionServer Pro 1288H V5 Server
V100R005
User Guide
Issue
13
Date
2020-06-05
HUAWEI TECHNOLOGIES CO., LTD.

Advertisement

Table of Contents
loading

Related Manuals for Huawei FusionServer Pro 1288H V5

Summary of Contents for Huawei FusionServer Pro 1288H V5

  • Page 1 FusionServer Pro 1288H V5 Server V100R005 User Guide Issue Date 2020-06-05 HUAWEI TECHNOLOGIES CO., LTD.
  • Page 2 Notice The purchased products, services and features are stipulated by the contract made between Huawei and the customer. All or part of the products, services and features described in this document may not be within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information, and recommendations in this document are provided "AS IS"...

  • Page 3: About This Document

    FusionServer Pro 1288H V5 Server User Guide About This Document About This Document Purpose This document describes the 1288H V5 in terms of its appearance, functions, structure, installation and removal procedures, basic configuration, OS installation methods, parts replacement, and troubleshooting.
  • Page 4 FusionServer Pro 1288H V5 Server User Guide About This Document Symbol Description Supplements the important information in the main text. NOTE is used to address information not related to personal injury, equipment damage, and environment deterioration. Change History Issue Date...

  • Page 5: Table Of Contents

    FusionServer Pro 1288H V5 Server User Guide Contents Contents About This Document........................ ii 1 Overview............................1 1.1 Overview....................................1 1.2 Physical Structure..................................2 1.3 Logical Structure..................................3 2 Hardware Description......................5 2.1 Front Panel....................................5 2.1.1 Appearance.................................... 5 2.1.2 Indicators and Buttons............................... 6 2.1.3 Ports.......................................
  • Page 6 FusionServer Pro 1288H V5 Server User Guide Contents 2.7.3 PCIe Slot Description................................ 33 2.8 PSUs......................................34 2.9 Fans......................................35 2.10 Boards..................................... 36 2.10.1 Mainboard..................................37 2.10.2 Drive Backplane................................39 3 Product Specifications......................41 3.1 Technical Specifications..............................41 3.2 Environmental Specifications............................46 3.3 Physical Specifications.................................
  • Page 7 FusionServer Pro 1288H V5 Server User Guide Contents 7.2.6.7 Connecting a Serial Cable............................78 7.2.6.8 Connecting PSU Cables..............................79 7.2.6.8.1 Connecting the AC PSU Cable..........................79 7.2.6.8.2 Connecting DC PSU Cables............................. 81 7.2.6.9 Checking Cable Connections............................82 7.3 Power-On and Power-Off..............................82 7.3.1 Power-On Procedure................................
  • Page 8 FusionServer Pro 1288H V5 Server User Guide Contents 9.5.2 Disabling VMD................................. 120 9.6 Accessing the BIOS................................121 9.6.1 Accessing the BIOS (V3XX or Earlier)........................121 9.6.2 Accessing the BIOS (V6XX or Later)......................... 123 9.7 Clearing Data from a Storage Device..........................125 10 More Information......................128 10.1 Technical Support................................

  • Page 9: Overview

    1.2 Physical Structure 1.3 Logical Structure 1.1 Overview Huawei FusionServer Pro 1288H V5 (1288H V5) is a new-generation 1U 2-socket rack server designed for Internet, Internet Data Center (IDC), cloud computing, enterprise, and telecom applications. The 1288H V5 is ideal for IT core services, cloud computing, high-performance computing, distributed storage, big data processing, enterprise or telecom applications, and other complex workloads.

  • Page 10: Physical Structure

    FusionServer Pro 1288H V5 Server User Guide 1 Overview Figure 1-1 1288H V5 (with 8 drives) 1.2 Physical Structure Figure 1-2 Physical structure of a 1288H V5 with 8 x 2.5" drives (example) PSUs Chassis Fan module brackets Fan modules...

  • Page 11: Logical Structure

    FusionServer Pro 1288H V5 Server User Guide 1 Overview DVD drive Indicator board VGA board Heat sinks Processors Memory modules TPM/TCM Screw-in RAID controller card Mainboard FlexIO card PCIe riser module 1 PCIe riser module 2 1.3 Logical Structure Figure 1-3 1288H V5 logical structure ®...
  • Page 12 FusionServer Pro 1288H V5 Server User Guide 1 Overview ● The LBG-2 Platform Controller Hub (PCH) supports: – Two 10GE optical LOM ports or two 10GE electrical LOM ports – Two GE electrical LOM ports ● The server uses Hi1710 management chip and supports a video graphic array (VGA) port, a management network port, and a debug serial port.

  • Page 13: Hardware Description

    FusionServer Pro 1288H V5 Server User Guide 2 Hardware Description Hardware Description 2.1 Front Panel 2.2 Rear Panel 2.3 Processor 2.4 Memory 2.5 Storage 2.6 Network 2.7 I/O Expansion 2.8 PSUs 2.9 Fans 2.10 Boards 2.1 Front Panel 2.1.1 Appearance ●...

  • Page 14: Indicators And Buttons

    FusionServer Pro 1288H V5 Server User Guide 2 Hardware Description ● 8 x 2.5" drive configuration Figure 2-2 Front view Drives (Optional) Built-in DVD drive Slide-out label plate (with an SN label) ● 10 x 2.5" drive configuration Figure 2-3 Front view...
  • Page 15 FusionServer Pro 1288H V5 Server User Guide 2 Hardware Description Fault diagnosis LED Health status indicator LOM port 1 connection LOM port 2 connection status indicator status indicator LOM port 3 connection LOM port 4 connection status indicator status indicator...
  • Page 16 FusionServer Pro 1288H V5 Server User Guide 2 Hardware Description Health status indicator LOM port connection status indicator UID button/indicator Indicator and Button Description Table 2-1 Indicators and buttons on the front panel Silkscreen Indicator/ Description Button Fault ● ---: The device is operating normally.
  • Page 17 FusionServer Pro 1288H V5 Server User Guide 2 Hardware Description Silkscreen Indicator/ Description Button UID button/ The UID button/indicator helps identify and indicator locate a device. UID indicator: ● Off: The device is not being located. ● Blinking blue: The device has been located and is distinguished from other devices that have also been located.

  • Page 18: Ports

    FusionServer Pro 1288H V5 Server User Guide 2 Hardware Description Silkscreen Indicator/ Description Button LOM port Each indicator shows the connection status of connection an Ethernet LOM port. status ● Off: The network port is not in use or has indicator failed.

  • Page 19: Rear Panel

    FusionServer Pro 1288H V5 Server User Guide 2 Hardware Description ● 10 x 2.5" drive configuration Figure 2-9 Ports on the front panel USB 3.0 port Port Description Table 2-2 Ports on the front panel Port Type Note Description Quantity...

  • Page 20: Appearance

    FusionServer Pro 1288H V5 Server User Guide 2 Hardware Description 2.2.1 Appearance Figure 2-10 Rear view PCIe slot 1 PCIe slot 2 PCIe slot 3 (Optional) FlexIO card PSU 1 PSU 2 2.2.2 Indicators Indicator Positions Figure 2-11 Indicators on the rear panel...
  • Page 21 FusionServer Pro 1288H V5 Server User Guide 2 Hardware Description Data transmission status Connection status indicator for a GE indicator for a GE electrical port electrical port Data transmission status Connection status indicator for the indicator for the management network...

  • Page 22: Ports

    FusionServer Pro 1288H V5 Server User Guide 2 Hardware Description Indicator Description Connection status ● Off: The network port is not connected. indicator for a GE ● Steady green: The network port is properly electrical port connected. Data transmission ● Off: No data is being transmitted on the port.
  • Page 23 FusionServer Pro 1288H V5 Server User Guide 2 Hardware Description (Optional) 10GE optical (Optional) 10GE optical port (LOM port 1) port (LOM port 2) (Optional) 10GE electrical (Optional) 10GE electrical port (LOM port 1) port (LOM port 2) VGA port...
  • Page 24 FusionServer Pro 1288H V5 Server User Guide 2 Hardware Description Port Type Quantity Description Management 1000BASE-T Used for server management. network port NOTE The management network port is a GE port that supports 100 Mbit/s and 1000 Mbit/s auto- negotiation.

  • Page 25: Processor

    If only one processor is required, install it in socket CPU1. ● The same model of processors must be used in a server. ● Contact your local Huawei sales representative or use the Intelligent Computing Compatibility Checker to determine the components to be used.

  • Page 26: Memory

    FusionServer Pro 1288H V5 Server User Guide 2 Hardware Description Figure 2-13 Processor positions 2.4 Memory 2.4.1 Memory Identifier You can determine the memory module properties based on the label attached to the memory module. Figure 2-14 Memory identifier Issue 13 (2020-06-05)

  • Page 27: Memory Subsystem Architecture

    FusionServer Pro 1288H V5 Server User Guide 2 Hardware Description callout Description Definition Capacity of the memory ● 8 GB module ● 16 GB ● 32 GB ● 64 GB ● 128 GB Number of ranks of the ● 1R: single-rank memory module ●...

  • Page 28: Memory Compatibility

    FusionServer Pro 1288H V5 Server User Guide 2 Hardware Description Memory Channel Memory Slot C (primary) DIMM020(C) DIMM021(I) D (primary) DIMM030(D) DIMM031(J) E (primary) DIMM040(E) DIMM041(K) F (primary) DIMM050(F) DIMM051(L) CPU 2 A (primary) DIMM100(A) DIMM101(G) B (primary) DIMM110(B) DIMM111(H)
  • Page 29 Maximum operating speed of a DIMM ● The DDR4 DIMMs of different types (RDIMM and LRDIMM) and specifications (capacity, bit width, rank, and height) cannot be used together. ● Contact your local Huawei sales representative or use the Intelligent Computing Compatibility Checker to determine the components to be used.

  • Page 30: Memory Installation Guidelines

    FusionServer Pro 1288H V5 Server User Guide 2 Hardware Description Table 2-7 DDR4 memory specifications Parameter Specifications Maximum capacity per DDR4 DIMM (GB) Rated speed (MT/s) 2933 Operating voltage (V) Maximum number of DDR4 DIMMs in a server Maximum DDR4 memory capacity of the server...

  • Page 31: Memory Installation Positions

    FusionServer Pro 1288H V5 Server User Guide 2 Hardware Description (channels 1 and 2, or channels 1, 2, and 3). The DIMMs installed must be identical in size and organization. ▪ For a multi-processor configuration, each processor must have a valid memory mirroring configuration.

  • Page 32: Memory Protection Technologies

    FusionServer Pro 1288H V5 Server User Guide 2 Hardware Description Figure 2-16 DDR4 memory installation guidelines (1 processor) Figure 2-17 DDR4 memory installation guidelines (2 processors) 2.4.6 Memory Protection Technologies The following memory protection technologies are supported: ● ● Full mirroring ●...

  • Page 33: Storage

    FusionServer Pro 1288H V5 Server User Guide 2 Hardware Description ● Faulty DIMM isolation ● Memory thermal throttling ● Memory address parity protection ● Memory demand/patrol scrubbing ● Device tagging ● Data scrambling ● Adaptive double device data correction (ADDDC) ●...

  • Page 34: Drive Numbering

    PCH supports only SATA drives. ● b: The drives can be managed only by the SP460C-M (Broadcom SAS3516) RAID controller card. ● Contact your local Huawei sales representative or use the Intelligent Computing Compatibility Checker to determine the components to be used.
  • Page 35 FusionServer Pro 1288H V5 Server User Guide 2 Hardware Description Table 2-9 Description of SAS/SATA drive indicators Activity Indicator Fault Indicator Description (Green) (Yellow) Steady on The drive is in position. Blinking at 4 Hz Data is being read or written normally, or data on the primary drive is being rebuilt.

  • Page 36: Raid Controller Card

    The NVMe drive is faulty. 2.5.4 RAID Controller Card The RAID controller card supports RAID configuration, RAID level migration, and drive roaming. ● Contact your local Huawei sales representative or use the Intelligent Computing Compatibility Checker to determine the components to be used. ●...
  • Page 37 FusionServer Pro 1288H V5 Server User Guide 2 Hardware Description ● Contact your local Huawei sales representative or use the Intelligent Computing Compatibility Checker to determine the components to be used. Table 2-12 FlexIO cards supported by the 1288H V5 (example)
  • Page 38 FusionServer Pro 1288H V5 Server User Guide 2 Hardware Description Figure 2-25 SM233 network port indicators ● SM251 with two 56G IB optical ports Figure 2-26 SM251 network port indicators ● SM252 with one 56G IB optical port Figure 2-27 SM252 network port indicators ●...

  • Page 39: I/O Expansion

    FusionServer Pro 1288H V5 Server User Guide 2 Hardware Description Port Type Indicator Description 10GE electrical Transmission rate ● Off: The data transmission rate is port indicator 10/100 Mbit/s. ● Steady green: The data transmission rate is 10 Gbit/s. ● Steady yellow: The data transmission rate is 1 Gbit/s.

  • Page 40: Pcie Cards

    User Guide 2 Hardware Description 2.7.1 PCIe Cards PCIe cards provide ease of expandability and connection. ● Contact your local Huawei sales representative or use the Intelligent Computing Compatibility Checker to determine the components to be used. 2.7.2 PCIe Slots...

  • Page 41: Pcie Slot Description

    FusionServer Pro 1288H V5 Server User Guide 2 Hardware Description PCIe Riser Modules Figure 2-30 PCIe riser modules 2.7.3 PCIe Slot Description The PCIe slots mapping to a vacant CPU socket are unavailable. Issue 13 (2020-06-05) Copyright © Huawei Technologies Co., Ltd.

  • Page 42: Psus

    FusionServer Pro 1288H V5 Server User Guide 2 Hardware Description Table 2-14 PCIe slot description PCIe PCIe Conne Port Root Device Slot Slot Stand ctor Width Port (B/D/ Size ards Width (B/D/ RAID CPU 1 PCIe Port1C 17/02/ contro 00/0...

  • Page 43: Fans

    The PSUs are protected against short circuit. Double-pole fuse is provided for the PSUs with dual input live wires. ● Contact your local Huawei sales representative or use the Intelligent Computing Compatibility Checker to determine the components to be used.

  • Page 44: Boards

    FusionServer Pro 1288H V5 Server User Guide 2 Hardware Description Figure 2-32 Fan module positions 2.10 Boards Issue 13 (2020-06-05) Copyright © Huawei Technologies Co., Ltd.

  • Page 45: Mainboard

    FusionServer Pro 1288H V5 Server User Guide 2 Hardware Description 2.10.1 Mainboard Figure 2-33 1288H V5 mainboard USB 3.0 port (USB 3.0 UID indicator (D6020) CONN/J169) Serial port Management network port GE electrical port GE electrical port VGA connector (VGA...
  • Page 46 FusionServer Pro 1288H V5 Server User Guide 2 Hardware Description 10GE optical port (10GE VROC key port (J130) PORT1/J131) or 10GE electrical port (10GE PORT1/J100) PCIe riser 1 slots SATA signal connector 2 (corresponding to CPU 1/ (SATA2/J71) J108) SATA signal connector 1...

  • Page 47: Drive Backplane

    FusionServer Pro 1288H V5 Server User Guide 2 Hardware Description ● a: "10GE optical port" corresponds to the mainboard integrated with two 10GE optical ports and two GE electrical ports. "10GE electrical port" corresponds to the mainboard integrated with two 10GE and two GE electrical ports.
  • Page 48 FusionServer Pro 1288H V5 Server User Guide 2 Hardware Description Power connector (HDD mini-SAS HD connector POWER/J24) (PORT A/J28) Backplane signal cable connector (HDD_BP/J1) ● 10 x 2.5" drive backplane 1 Figure 2-36 10 x 2.5" drive backplane 1 (BOM 03024KYL)

  • Page 49: Product Specifications

    FusionServer Pro 1288H V5 Server User Guide 3 Product Specifications Product Specifications 3.1 Technical Specifications 3.2 Environmental Specifications 3.3 Physical Specifications 3.1 Technical Specifications Table 3-1 Technical specifications Category Specifications Form factor 1U rack server Chipset ® ® Intel C621/Intel...
  • Page 50 FusionServer Pro 1288H V5 Server User Guide 3 Product Specifications Category Specifications Memory Supports 24 memory modules of the following types: ● Up to 24 DDR4 memory modules ● Max. 2933 MT/s memory speed ● RDIMM and LRDIMM support ● The DDR4 memory modules of different types...
  • Page 51 FusionServer Pro 1288H V5 Server User Guide 3 Product Specifications Category Specifications Storage Supports a variety of drive configurations. For details, 2.5.1 Drive Configurations. ● Supports two M.2 SSDs. – M.2 SSDs are supported only when the server is configured with an Avago SAS3004iMR RAID controller card.
  • Page 52 PCIe cards. For details, see 2.7.2 PCIe Slots 2.7.3 PCIe Slot Description. ● Support Huawei proprietary PCIe SSD cards to bolster I/O performance for applications such as searching, caching, and download services. ● Supports GPU cards. NOTE The preceding information is for reference only. Use the...
  • Page 53 FusionServer Pro 1288H V5 Server User Guide 3 Product Specifications Category Specifications Ports Supports a variety of ports. ● Ports on the front panel: – One USB 2.0 port – One USB 3.0 port – One DB15 VGA port NOTE For the server that uses 10 x 2.5"...

  • Page 54: Environmental Specifications

    FusionServer Pro 1288H V5 Server User Guide 3 Product Specifications 3.2 Environmental Specifications Table 3-2 Environmental specifications Category Specifications Temperature ● Operating temperature: 5°C to 45°C (41°F to 113°F) (ASHRAE Classes A2 to A4 compliant) ● Storage temperature (≤ 72 hours): –40°C to +65°C (–40°F to +149°F)

  • Page 55: Physical Specifications

    FusionServer Pro 1288H V5 Server User Guide 3 Product Specifications Category Specifications Particle contaminant ● The equipment room environment meets the requirements of ISO 14664-1 Class 8. ● There is no explosive, conductive, magnetic, or corrosive dust in the equipment room.
  • Page 56 – Cabinet width: 482.6 mm (19 in.) – Cabinet depth ≥ 1000 mm (39.37 in.) ● Requirements for guide rail installation: – L-shaped guide rails: apply only to Huawei cabinets. – Static rail kit: applies to cabinets with a distance of 543.5 mm to 848.5 mm (21.40 in.

  • Page 57: Software And Hardware Compatibility

    FusionServer Pro 1288H V5 Server User Guide 4 Software and Hardware Compatibility Software and Hardware Compatibility Use the Intelligent Computing Compatibility Checker to obtain information about the operating systems and hardware supported. NO TICE Do not use incompatible components. Otherwise, the server may fail to work properly.

  • Page 58: Safety Instructions

    Take protective measures if a Class A product is used in residential areas as it is likely to cause radio interference. Personal Safety ● Only personnel certified or authorized by Huawei are allowed to install the hardware. ● Stop any operation that may cause personal injury or equipment damage, report the problem to a project supervisor immediately, and take protective measures.
  • Page 59 FusionServer Pro 1288H V5 Server User Guide 5 Safety Instructions Figure 5-1 Protective clothing ● Before touching a device, ensure that you are wearing ESD clothing and ESD gloves (or wrist strap), and remove any conductive objects (such as watches and jewelry).
  • Page 60 FusionServer Pro 1288H V5 Server User Guide 5 Safety Instructions Figure 5-3 Wearing an ESD wrist strap ● Exercise caution when using tools that could cause personal injury. ● If the installation position of the device is above shoulder height, use a stacker to lift it.

  • Page 61: Maintenance And Warranty

    FusionServer Pro 1288H V5 Server User Guide 5 Safety Instructions ● If the original packaging is unavailable, package heavy, bulky parts (such as chassis and blades) and fragile parts (such as PCIe GPUs and SSDs) separately. Intelligent Computing Compatibility Checker to obtain information abut the components supported by a node or server.

  • Page 62: Esd

    FusionServer Pro 1288H V5 Server User Guide 6 ESD 6.1 ESD Prevention 6.2 Grounding Methods for ESD Prevention 6.1 ESD Prevention The static electricity released by the human body or conductors may damage the mainboard or other electrostatic-sensitive devices. The damage caused by static electricity will shorten the service time of the devices.

  • Page 63: Grounding Methods For Esd Prevention

    FusionServer Pro 1288H V5 Server User Guide 6 ESD 6.2 Grounding Methods for ESD Prevention Use one or more of the following grounding methods when handling or installing electrostatic-sensitive devices: ● Use an ESD wrist strap that connects to a grounded work area or computer chassis through a ground cable.

  • Page 64: Installation And Configuration

    FusionServer Pro 1288H V5 Server User Guide 7 Installation and Configuration Installation and Configuration 7.1 Installation Environment Requirements 7.2 Hardware Installation 7.3 Power-On and Power-Off 7.4 Initial Configuration 7.1 Installation Environment Requirements 7.1.1 Space and Airflow Requirements To allow for servicing and adequate airflow, observe the following space and airflow requirements: ●...

  • Page 65: Temperature And Humidity Requirements

    FusionServer Pro 1288H V5 Server User Guide 7 Installation and Configuration Figure 7-1 Direction of heat dissipation 7.1.2 Temperature and Humidity Requirements To ensure continued safe and reliable equipment operation, install or position the system in a well-ventilated, climate-controlled environment.

  • Page 66: Hardware Installation

    FusionServer Pro 1288H V5 Server User Guide 7 Installation and Configuration 7.2 Hardware Installation 7.2.1 Installation Overview Installation Process Figure 7-2 Installation process Precautions ● Properly ground the server before installation to avoid damage to electronic components from electrostatic discharge. Improper grounding may cause electrostatic discharge.

  • Page 67: Unpacking The Server

    Before installing and configuring a server, you need to install all optional parts required, such as extra CPUs, drives, and PCIe cards. Procedure Step 1 Install the optional parts for the 1288H V5. For details, see FusionServer Pro 1288H V5 Server V100R005 Maintenance and Service Guide. ----End 7.2.4 Installing Server Guide Rails Issue 13 (2020-06-05) Copyright ©...

  • Page 68: Installing L-Shaped Guide Rails

    FusionServer Pro 1288H V5 Server User Guide 7 Installation and Configuration 7.2.4.1 Installing L-Shaped Guide Rails L-shaped guide rails are designed for Huawei cabinets only. The 1288H V5 servers are not stackable onto L-shaped guide rails. Procedure Step 1 Install floating nuts.
  • Page 69 FusionServer Pro 1288H V5 Server User Guide 7 Installation and Configuration Figure 7-4 Installing a floating nut Install the other floating nut in the same way. Step 2 Install the L-shaped guide rails. Position a guide rail horizontally in contact with the mounting bars in the cabinet.

  • Page 70: Installing The Static Rail Kit

    FusionServer Pro 1288H V5 Server User Guide 7 Installation and Configuration 7.2.4.2 Installing the Static Rail Kit The static rail kit applies to cabinets with a distance of 543.5 mm to 848.5 mm (21.40 in. to 33.41 in.) between the front and rear mounting bars.

  • Page 71: Installing A 1288H V5

    FusionServer Pro 1288H V5 Server User Guide 7 Installation and Configuration Step 3 Align the front end of the rail with the hole on the front column of the cabinet, push the rail horizontally, and insert the rail into the hole on the column from the side.
  • Page 72 FusionServer Pro 1288H V5 Server User Guide 7 Installation and Configuration Procedure Step 1 Install the server. NO TICE At least two people are required to move the device. Otherwise, personal injury or device damage may occur. Lift the server, place it on guide rails, and slide it into the chassis. At least two people are required to move the server.

  • Page 73: Installing The Server On The Ball Bearing Rail Kit

    FusionServer Pro 1288H V5 Server User Guide 7 Installation and Configuration 7.2.5.2 Installing the Server on the Ball Bearing Rail Kit Before installing the server, ensure that the ball bearing rail kit is properly installed. For details, see 7.2.4.3 Installing the Ball Bearing Rail Kit.
  • Page 74 FusionServer Pro 1288H V5 Server User Guide 7 Installation and Configuration Figure 7-10 Installing the server on inner rails Press the release buttons on both sides and push the server into the rails. See (1) and (2) in Figure 7-11.
  • Page 75 FusionServer Pro 1288H V5 Server User Guide 7 Installation and Configuration Figure 7-11 Installing the server Tighten the captive screws on the mounting ears to secure the server. Figure 7-12 Securing the server Step 2 Install a cable management arm (CMA).
  • Page 76 FusionServer Pro 1288H V5 Server User Guide 7 Installation and Configuration Insert the nail heads on the inner left rail into the holes on the inner support lever of the CMA, and pull the CMA in the arrow direction. See (3) in Figure 7-13.

  • Page 77: Connecting External Cables

    FusionServer Pro 1288H V5 Server User Guide 7 Installation and Configuration 7.2.6 Connecting External Cables 7.2.6.1 Cabling Guidelines Basic Guidelines NO TICE Do not block the air exhaust vents of power supply units (PSUs) when you lay out cables. Otherwise, heat dissipation of the server may be affected.

  • Page 78: Connecting Mouse, Keyboard And Vga Cables

    FusionServer Pro 1288H V5 Server User Guide 7 Installation and Configuration ● Place the connectors of all service data cables at the bottom of the cabinet so that the connectors are difficult to reach. 7.2.6.2 Connecting Mouse, Keyboard and VGA Cables The front and rear panels of the server provide DB15 VGA ports but no standard PS/2 port for a keyboard or mouse.
  • Page 79 FusionServer Pro 1288H V5 Server User Guide 7 Installation and Configuration Procedure Step 1 Determine the model of the new network cable. ● Shielded cables are recommended. According to the result of the EMC test, if a non-shielded cable is used, the system cannot respond to the ESD.

  • Page 80: Connecting A Cable To An Optical Port

    FusionServer Pro 1288H V5 Server User Guide 7 Installation and Configuration Figure 7-15 Connecting a network cable Step 6 Connect the new network cable to the peer network port. ● Connect the other cable connector to the peer device based on the network plan.
  • Page 81 FusionServer Pro 1288H V5 Server User Guide 7 Installation and Configuration You are advised to arrange cables in the same way as existing cables. Ensure that cables are routed neatly and undamaged. ● Separate optical cables or SFP+ cables from power cables and signal cables when laying out the cables.
  • Page 82 FusionServer Pro 1288H V5 Server User Guide 7 Installation and Configuration Figure 7-16 Connecting an optical cable ● When you use an SFP+ cable: Remove the SFP+ cable to be replaced. Gently push the power connector inwards and pull the latch out to remove the SFP+ cable.

  • Page 83: Connecting An Ib Cable

    FusionServer Pro 1288H V5 Server User Guide 7 Installation and Configuration Connect the new SFP+ cable. Remove the dust-proof cap on the port, and insert the cable connector into the port. When you hear a "click" and the cable cannot be pulled out, the connector is secured.
  • Page 84 FusionServer Pro 1288H V5 Server User Guide 7 Installation and Configuration Step 2 Number the new cable. ● The number of the new cable must be the same as that of the old one. ● Use the same type of labels for the optical cable.
  • Page 85 FusionServer Pro 1288H V5 Server User Guide 7 Installation and Configuration Figure 7-19 Removing a cable (for an IB NIC with two 56 Gbit/s ports as an example) Connect the new cable. Remove the dust-proof cap on the port, and insert the cable connector into the port.

  • Page 86: Connecting A Usb Device

    FusionServer Pro 1288H V5 Server User Guide 7 Installation and Configuration Power on the device. If the LOM indicator is green, the cable is properly connected. Step 6 Bind the new optical cable. Bind the new optical cable in the same way as the existing optical cables. You can also remove all existing cable ties and bind all optical cables again if necessary.

  • Page 87: Connecting Psu Cables

    FusionServer Pro 1288H V5 Server User Guide 7 Installation and Configuration Procedure Step 1 Connect the serial cable. Figure 7-22 Connecting a serial cable ----End 7.2.6.8 Connecting PSU Cables 7.2.6.8.1 Connecting the AC PSU Cable Before connecting power cables, ensure that the server has been correctly installed.
  • Page 88 FusionServer Pro 1288H V5 Server User Guide 7 Installation and Configuration Figure 7-23 Connecting the cable Step 3 Secure the power cable using a velcro strap. Figure 7-24 Securing the cable Issue 13 (2020-06-05) Copyright © Huawei Technologies Co., Ltd.

  • Page 89: Connecting Dc Psu Cables

    FusionServer Pro 1288H V5 Server User Guide 7 Installation and Configuration Step 4 Connect the other end of the power cable to the AC PDU in the cabinet. The AC PDU is fastened horizontally in the rear of the cabinet. Connect the power cable to the socket on the PDU according to the plan.

  • Page 90: Checking Cable Connections

    FusionServer Pro 1288H V5 Server User Guide 7 Installation and Configuration Step 3 Connect the other end of the power cable to the DC PDU in the cabinet. The DC PDU is fastened horizontally in the rear of the cabinet. Connect the power cable to the socket on the PDU according to the plan.

  • Page 91: Power-On Procedure

    FusionServer Pro 1288H V5 Server User Guide 7 Installation and Configuration 7.3.1 Power-On Procedure NO TICE ● Before powering on a server, ensure that the PSUs are switched off, all cables are connected correctly, and the power supply voltage meets service requirements.

  • Page 92: Power-Off Procedure

    FusionServer Pro 1288H V5 Server User Guide 7 Installation and Configuration On the KVM screen, click on the toolbar. iii. Select Power On. A dialog box is displayed. Click Yes. 7.3.2 Power-Off Procedure ● Powering off a server will interrupt all services and programs running on it. Therefore, before powering off a server, ensure that all services and programs have been stopped or migrated to other servers.

  • Page 93: Initial Configuration

    FusionServer Pro 1288H V5 Server User Guide 7 Installation and Configuration ▪ To power off the server forcibly, run the ipmcset -d powerstate -v 2 command. Type y or Y and press Enter. ● Use the Remote Virtual Console. Log in to the Remote Virtual Console.

  • Page 94: Configuration Overview

    FusionServer Pro 1288H V5 Server User Guide 7 Installation and Configuration 7.4.2 Configuration Overview Configuration Process Figure 7-26 Initial configuration process Table 7-5 Process description Step Description Change the initial ● Initial password of the default iBMC user passwords. ● Initial iBMC U-Boot password Check the server.

  • Page 95: Changing Initial Passwords

    FusionServer Pro 1288H V5 Server User Guide 7 Installation and Configuration Step Description Upgrade the system. Upgrade software or firmware, and install or update drivers to the latest versions. Documents ● Configure the iBMC. The configuration method varies depending on the iBMC version.
  • Page 96 FusionServer Pro 1288H V5 Server User Guide 7 Installation and Configuration Step 2 On the iBMC WebUI, choose Configuration > Local Users. The Local Users page is displayed. Figure 7-27 Local Users page Step 3 Click on the right of the user whose password is to be changed.

  • Page 97: Changing The Initial U-Boot Password

    FusionServer Pro 1288H V5 Server User Guide 7 Installation and Configuration The password must meet the following requirements: ● Contain 8 to 20 characters. ● Contain at least one space or one of the following special characters: `~!@#$%^&*()-_=+\|[{}];:'",<.>/? ● Contain at least two types of the following characters:...

  • Page 98: Checking The Server

    FusionServer Pro 1288H V5 Server User Guide 7 Installation and Configuration Step 6 Switch to the interface for changing the U-Boot password. passwd The command output is as follows: Enter old password: Step 7 Enter the old password. The command output is as follows: Enter new password: Step 8 Enter a new password.
  • Page 99 FusionServer Pro 1288H V5 Server User Guide 7 Installation and Configuration Figure 7-29 Check process Procedure Step 1 Determine the hardware status by observing the indicators on the front panel. For details, see 2.1.2 Indicators and Buttons. Step 2 Log in to the iBMC WebUI.

  • Page 100: Setting The Ibmc Ip Address

    FusionServer Pro 1288H V5 Server User Guide 7 Installation and Configuration For details, see FusionServer Pro Rack Server Upgrade Guide. Step 4 Query health status. On the menu bar, choose Information. In the navigation tree, choose Overview to query the health status.

  • Page 101: Configuring Raid

    RAID controller cards. ● The configuration method varies depending on the RAID controller card model. For details, see Huawei V5 Server RAID Controller Card User Guide. 7.4.7 Configuring the BIOS Scenarios This section describes how to configure the BIOS of the server.

  • Page 102: Accessing The Bios

    FusionServer Pro 1288H V5 Server User Guide 7 Installation and Configuration Process Figure 7-32 Process for configuring the BIOS 7.4.7.1 Accessing the BIOS Procedure Step 1 Restart the server, and enter the BIOS. For details, see 9.6 Accessing the BIOS.

  • Page 103: Setting Pxe For A Nic

    FusionServer Pro 1288H V5 Server User Guide 7 Installation and Configuration ● The default boot mode is UEFI. ● For some OSs, if the capacity of the drive or RAID array for installing the OS is greater than 2 TB, use the UEFI boot mode. For details, see the release notes of the OS.

  • Page 104: Setting The Bios Password

    FusionServer Pro 1288H V5 Server User Guide 7 Installation and Configuration Step 3 Select the network port to be configured and press Enter. The dialog box for setting the network port is displayed. Step 4 Select Enabled and press Enter.

  • Page 105: Selecting A Language

    FusionServer Pro 1288H V5 Server User Guide 7 Installation and Configuration 7.4.7.5 Selecting a Language Procedure Step 1 On the BIOS main screen, choose Main. The Main screen is displayed. Step 2 Select Language and press Enter. The Language screen is displayed.

  • Page 106: Installing An Os

    FusionServer Pro 1288H V5 Server User Guide 7 Installation and Configuration Settings are saved and the BIOS is exited. The server automatically restarts for the settings to take effect. ----End 7.4.8 Installing an OS The 1288H V5 supports multiple types of OSs.
  • Page 107 FusionServer Pro 1288H V5 Server User Guide 7 Installation and Configuration The driver installation package and procedure vary depending on the operating system. Issue 13 (2020-06-05) Copyright © Huawei Technologies Co., Ltd.

  • Page 108: Troubleshooting

    If a fault occurs on a server, collect logs for fault diagnosis. ● Fault diagnosis Fault diagnosis rules and tools help Huawei technical support engineers and maintenance engineers to analyze and rectify faults according to alarms and hardware fault symptoms.

  • Page 109: Common Operations

    FusionServer Pro 1288H V5 Server User Guide 9 Common Operations Common Operations 9.1 Querying the iBMC IP Address 9.2 Logging In to the iBMC WebUI 9.3 Logging In to the Desktop of a Server 9.4 Logging In to the CLI 9.5 Managing VMD...

  • Page 110: Logging In To The Ibmc Webui

    FusionServer Pro 1288H V5 Server User Guide 9 Common Operations Step 3 Select iBMC Configuration and press Enter. The iBMC Configuration screen is displayed. Step 4 Check the IP address of the iBMC management network port. ----End 9.2 Logging In to the iBMC WebUI Scenarios Log in to the iBMC WebUI.
  • Page 111 FusionServer Pro 1288H V5 Server User Guide 9 Common Operations Browser Windows 10 64-bit Internet Explorer 11.0 JRE 1.8 U45 JRE 1.8 U144 Mozilla Firefox 39.0 to 54.0 Windows Server 2012 R2 Internet Explorer 11.0 JRE 1.8 U45 64-bit JRE 1.8 U144 Mozilla Firefox 39.0 to...
  • Page 112 FusionServer Pro 1288H V5 Server User Guide 9 Common Operations ● If the language of the browser you use to log in to the iBMC WebUI is not Chinese, English, or Japanese, upgrade the iBMC to V260 or later. Otherwise, the login page may fail to display.
  • Page 113 FusionServer Pro 1288H V5 Server User Guide 9 Common Operations Click Log In. After the login is successful, the Information page is displayed. The user name is displayed in the upper right corner. ▪ The system may display a message indicating incorrect username or password when you attempt to log in using Internet Explorer after the system is upgraded.

  • Page 114: Logging In To The Desktop Of A Server

    FusionServer Pro 1288H V5 Server User Guide 9 Common Operations Click Log In. After the login is successful, the Information page is displayed. The user name is displayed in the upper right corner. ----End 9.3 Logging In to the Desktop of a Server 9.3.1 Using the Remote Virtual Console...
  • Page 115 FusionServer Pro 1288H V5 Server User Guide 9 Common Operations Figure 9-2 Remote Console page Step 3 Click an Integrated Remote Console. ● Java Integrated Remote Console (Private): allows only one local user or VNC user to access and perform operations on the server through the iBMC.
  • Page 116 FusionServer Pro 1288H V5 Server User Guide 9 Common Operations Figure 9-3 Remote console (Java) Issue 13 (2020-06-05) Copyright © Huawei Technologies Co., Ltd.

  • Page 117: Using The Independent Remote Console

    FusionServer Pro 1288H V5 Server User Guide 9 Common Operations Figure 9-4 Remote console (HTML5) ----End 9.3.2 Using the Independent Remote Console Scenarios Log in to the desktop of a server using the Independent Remote Console. When the client OS and iBMC versions are compatible with the Independent Remote Console, the Independent Remote Console provides easier operations than the Remote Virtual Console.
  • Page 118 FusionServer Pro 1288H V5 Server User Guide 9 Common Operations Procedure Step 1 Configure an IP address for the client (PC) to enable communication between the client and the iBMC. The IP address configured and the iBMC management network port IP address must be on the same network segment.

  • Page 119: Ubuntu

    FusionServer Pro 1288H V5 Server User Guide 9 Common Operations Figure 9-6 Security warning Step 6 Click Yes. ● Click No to return to the login interface. ● Click Import CA to import the CA certificate (*.cer, *.crt, or *.pem). After the CA certificate is imported, the security risk dialog box will no longer be displayed.
  • Page 120 FusionServer Pro 1288H V5 Server User Guide 9 Common Operations Procedure Step 1 Configure an IP address for the client (PC) to enable communication between the client and the iBMC. The IP address configured and the iBMC management network port IP address must be on the same network segment.

  • Page 121: Macos

    FusionServer Pro 1288H V5 Server User Guide 9 Common Operations Figure 9-9 Security warning Step 8 Click Yes. ● Click No to return to the login interface. ● Click Import CA to import the CA certificate (*.cer, *.crt, or *.pem). After the CA certificate is imported, the security risk dialog box will no longer be displayed.
  • Page 122 FusionServer Pro 1288H V5 Server User Guide 9 Common Operations Procedure Step 1 Configure an IP address for the client (PC) to enable communication between the client and the iBMC. The IP address configured and the iBMC management network port IP address must be on the same network segment.

  • Page 123: Logging In To The Cli

    FusionServer Pro 1288H V5 Server User Guide 9 Common Operations Figure 9-12 Security warning Step 8 Click Yes. ● Click No to return to the login interface. ● Click Import CA to import the CA certificate (*.cer, *.crt, or *.pem). After the CA certificate is imported, the security risk dialog box will no longer be displayed.

  • Page 124: Logging In To The Cli Using Putty Over A Network Port

    FusionServer Pro 1288H V5 Server User Guide 9 Common Operations 9.4.1 Logging In to the CLI Using PuTTY over a Network Port Scenarios Use PuTTY to access a server over a local area network (LAN). ● You can obtain the PuTTY software from the chiark home page.
  • Page 125 FusionServer Pro 1288H V5 Server User Guide 9 Common Operations Figure 9-14 PuTTY Configuration Step 7 Set Close window on exit to Only on clean exit. Set Saved Sessions and click Save. You can double-click the saved record in Saved Sessions to log in to the server next time.

  • Page 126: Logging In To The Cli Using Putty Over A Serial Port

    FusionServer Pro 1288H V5 Server User Guide 9 Common Operations 9.4.2 Logging In to the CLI Using PuTTY over a Serial Port Scenarios Use PuTTY to log in to a server over a serial port when: ● You want to perform initial configuration of the server.
  • Page 127 FusionServer Pro 1288H V5 Server User Guide 9 Common Operations Figure 9-15 PuTTY Configuration Step 6 Set Close window on exit to Only on clean exit. Set Saved Sessions and click Save. You can double-click the saved record in Saved Sessions to log in to the server next time.

  • Page 128: Managing Vmd

    FusionServer Pro 1288H V5 Server User Guide 9 Common Operations 9.5 Managing VMD The Intel Volume Management Device (VMD) is a module integrated in the processor on the Purley platform. It is used for surprise hot plug, management, and error processing of SSDs.

  • Page 129: Accessing The Bios

    FusionServer Pro 1288H V5 Server User Guide 9 Common Operations Step 3 Select Socket Configuration and press Enter. Step 4 Select IIO Configuration and press Enter. Step 5 Select Intel(R) VMD Technology and press Enter. Step 6 Select Intel(R) VMD Config and press Enter.
  • Page 130 FusionServer Pro 1288H V5 Server User Guide 9 Common Operations Figure 9-16 BIOS startup screen ● To go to the BIOS front page, press F11 or F3. ● To boot from the network, press F12. Enter the password in the displayed dialog box.

  • Page 131: Accessing The Bios (V6Xx Or Later)

    FusionServer Pro 1288H V5 Server User Guide 9 Common Operations Figure 9-17 Entering the BIOS password Step 6 Enter the BIOS password. ● The default BIOS password is Admin@9000. ● Press F2 to alternate between the English (US), French, and Japanese keyboards.
  • Page 132 FusionServer Pro 1288H V5 Server User Guide 9 Common Operations The server is restarted. Step 5 During the restart, press Delete or F4 when the information shown in Figure 9-18 is displayed. Figure 9-18 BIOS startup screen ● To go to the Boot Manager screen, press F11 pr F3.

  • Page 133: Clearing Data From A Storage Device

    FusionServer Pro 1288H V5 Server User Guide 9 Common Operations Figure 9-19 Entering the BIOS password Step 6 Enter the BIOS password. ● The default BIOS password is Admin@9000. ● Press F2 to alternate between the English (US), French, and Japanese keyboards.
  • Page 134 FusionServer Pro 1288H V5 Server User Guide 9 Common Operations NO TICE The cleared data cannot be restored. Exercise caution when performing this operation. Procedure Before performing this operation, check that: ● The storage device is not in a RAID array with redundancy, and the server operating system is running properly.
  • Page 135 FusionServer Pro 1288H V5 Server User Guide 9 Common Operations Figure 9-21 Querying drive information Step 5 Write all 0s to the drive to be cleared. Drive letter Command: badblocks -swft 0 Example: badblocks -swft 0 /dev/sdb Figure 9-22 Clearing data (example) ●...

  • Page 136: More Information

    10 More Information More Information 10.1 Technical Support 10.2 Product Information 10.3 Product Configuration Resources 10.4 Maintenance Tools 10.1 Technical Support Huawei provides timely and efficient technical support through: ● Local branch offices ● Secondary technical support system ● Telephone technical support ●...

  • Page 137: Product Information

    – Send emails to support@huawei.com. Telecom carriers outside China: visit Global TAC Information. ● Contact the technical support personnel of your local Huawei office. 10.2 Product Information Table 10-1 provides common information about Huawei servers. Table 10-1 Product information Item...

  • Page 138: Product Configuration Resources

    CPU quantity, and DIMM quantity are specified. 10.4 Maintenance Tools Table 10-3 lists the software tools required for routine maintenance of Huawei servers. Table 10-3 Software tools for routine maintenance Tool Server Model and Software Description...
  • Page 139 FusionServer Pro 1288H V5 Server User Guide 10 More Information Tool Server Model and Software Description Version Smart Provisioning For details, see Smart Smart Provisioning installs Provisioning User Guide. OSs, configures RAID, and upgrades firmware. Download link: Smart Provisioning Issue 13 (2020-06-05)

  • Page 140: Software And Configuration Utilities

    11.1 iBMC 11.2 BIOS 11.1 iBMC Huawei intelligent Baseboard Management Controller (iBMC) is a Huawei proprietary intelligent system for remotely managing a server. The iBMC complies with IPMI 2.0 and SNMP standards and supports various functions, including KVM redirection, text console redirection, remote virtual media, and hardware monitoring and management.

  • Page 141: Bios

    I/O and boot device, and finally boots the OS. The BIOS also provides the advanced configuration and power interface (ACPI) and hot swap. The Huawei Purley-based server is developed based on Insyde code base and uses a proprietary BIOS. It provides a variety of in-band and out-of-band configuration functions as well as high scalability, and supports customization.

  • Page 142: A Appendix

    A Appendix Appendix A.1 Product SN The serial number (SN) on the slide-out label plate uniquely identifies a device. The SN is required when you contact Huawei technical support. Figure A-1 SN example Table A-1 SN description Callout No. Description SN ID (two characters), which is 21.

  • Page 143: Operating Temperature Limitations

    FusionServer Pro 1288H V5 Server User Guide A Appendix Callout No. Description Year and month (two characters). ● The first character indicates the year. – Digits 1 to 9 indicate years 2001 to 2009, respectively. – Letters A to H indicate years 2010 to 2017, respectively.

  • Page 144: Nameplate

    FusionServer Pro 1288H V5 Server User Guide A Appendix Configuratio Max. 35°C (95°F) Max. 40°C (104°F) Max. 45°C (113°F) 8 x 2.5" drive ● All options Options not Options supported: configuration supported supported: ● Platinum 8153, ● Platinum Gold 8180/8168/8280...

  • Page 145: Ras Features

    FusionServer Pro 1288H V5 Server User Guide A Appendix A.4 RAS Features The server supports a variety of Reliability, Availability, and Serviceability (RAS) features. You can configure these features for better RAS. For details about how to configure RAS features, see...
  • Page 146 FusionServer Pro 1288H V5 Server User Guide A Appendix Module Feature Description Intel UPI Protocol Provides cyclic redundancy check Protection via CRC (CRC) protection for UPI packets to improve system reliability. System Core Disable for Fault Isolates a faulty CPU core during...

  • Page 147: Sensor List

    FusionServer Pro 1288H V5 Server User Guide A Appendix Module Feature Description BIOS-based Predictive The BIOS provides physical unit Failure Analysis (PFA) information for DIMM errors, and the OS traces and predicts errors, and isolates error memory pages. A.5 Sensor List...
  • Page 148 FusionServer Pro 1288H V5 Server User Guide A Appendix Sensor Description Component SYS 12V_1 Mainboard 12.0 V Mainboard voltage SYS 12V_2 Mainboard 12.0 V Mainboard voltage N VCore 1.8 V CPU voltage Mainboard N indicates the CPU number. The value is 1 or N DDR VDDQ 1.2 V DIMM voltage...
  • Page 149 FusionServer Pro 1288H V5 Server User Guide A Appendix Sensor Description Component N DDR VPP2 VPP_DEF voltage Mainboard N indicates the CPU number. The value is 1 or N F Speed Fan speed Fan module N indicates the fan N R Speed module number.
  • Page 150 FusionServer Pro 1288H V5 Server User Guide A Appendix Sensor Description Component N indicates the fan N R Status Fan status module number. The value ranges from 1 to 7. DIMM DIMM status DIMM N indicates the DIMM slot number.
  • Page 151 FusionServer Pro 1288H V5 Server User Guide A Appendix Sensor Description Component RAID PCIE ERR RAID controller card RAID controller card fault diagnosis health status RAID Card BBU LSI SAS3106 RAID BBU supercapacitor of controller card BBU RAID controller card...

  • Page 152: B Glossary

    FusionServer Pro 1288H V5 Server User Guide B Glossary Glossary B.1 A-E baseboard The BMC complies with the Intelligent Platform management Management Interface (IPMI). It collects, processes, controller (BMC) and stores sensor signals, and monitors the operating status of components. The BMC provides the hardware...

  • Page 153: F-J

    FusionServer Pro 1288H V5 Server User Guide B Glossary B.2 F-J Gigabit Ethernet An extension and enhancement of traditional shared (GE) media Ethernet standards. It is compatible with 10M and 100M Ethernet and complies with IEEE 802.3z standards. hot swap Replacing or adding components without stopping or shutting down the system.

  • Page 154: U-Z

    FusionServer Pro 1288H V5 Server User Guide B Glossary redundancy A mechanism that allows a backup device to automatically take over services from a faulty device to ensure uninterrupted running of the system. redundant array of A storage technology that combines multiple physical...

  • Page 155: C Acronyms And Abbreviations

    FusionServer Pro 1288H V5 Server User Guide C Acronyms and Abbreviations Acronyms and Abbreviations C.1 A-E alternating current Advanced Encryption Standard New Instruction Set Address Resolution Protocol Advanced Vector Extensions backup battery unit BIOS Basic Input/Output System baseboard management controller...

  • Page 156: F-J

    FusionServer Pro 1288H V5 Server User Guide C Acronyms and Abbreviations direct current DDR3 Double Data Rate 3 DDR4 Double Data Rate 4 DDDC double device data correction DEMT Dynamic Energy Management Technology DIMM dual in-line memory module DRAM dynamic random-access memory...

  • Page 157: K-O

    FusionServer Pro 1288H V5 Server User Guide C Acronyms and Abbreviations GPIO General Purpose Input/Output graphics processing unit high availability hard disk drive high-performance computing HTTP Hypertext Transfer Protocol HTTPS Hypertext Transfer Protocol Secure iBMC intelligent baseboard management controller Industry Canada...

  • Page 158: P-T

    FusionServer Pro 1288H V5 Server User Guide C Acronyms and Abbreviations Lucent connector LRDIMM load-reduced dual in-line memory module light emitting diode LAN on motherboard media access control module management controller next business day NC-SI Network Controller Sideband Interface C.4 P-T...
  • Page 159 FusionServer Pro 1288H V5 Server User Guide C Acronyms and Abbreviations RAID redundant array of independent disks reliability, availability and serviceability RDIMM registered dual in-line memory module REACH Registration Evaluation and Authorization of Chemicals RJ45 registered jack 45 RoHS Restriction of the Use of Certain Hazardous Substances...

  • Page 160: U-Z

    FusionServer Pro 1288H V5 Server User Guide C Acronyms and Abbreviations thermal design power TELNET Telecommunication Network Protocol Trusted Execution Technology TransFlash module TFTP Trivial File Transfer Protocol TCP offload engine trusted platform module C.5 U-Z UDIMM unbuffered dual in-line memory module...

This manual is also suitable for:

V100r005

Table of Contents
