February 8, 2018
2018 RLX: TQI and New Model Service Information
Supersedes 17-043, dated November 2, 2017, to revise the information highlighted in yellow.
AFFECTED VEHICLES
Year
Model
2018
RLX
REVISION SUMMARY
In NEW MODEL SERVICE INFORMATION, we added 2 topics: 3. Shift by Wire and 4. Shift Override.
INTRODUCTION
This bulletin covers the total quality inspection (TQI) of the 2018 RLX. It includes these procedures:
1.
Remove the Exterior Protective Coatings
2.
Install the Fuses
3.
Remove the Interior Protective Coverings
4.
Install the Floor Mats
5.
Check the Battery
6.
Install the Body Plugs
7.
Install the Front License Plate Holder
8.
Clean the Rear License Plate Area, and
Install the Mounting Hardware
9.
Set the Tire Pressures
To do a TQI on the navigation system, be sure to complete S/B 17-044, 2018 RLX: TQI of the Navigation System.
This bulletin also includes this new model service information:
1.
10-Speed Automatic Transmission
2.
Traffic Jam Assist (TJA)
CLIENT INFORMATION:
and training to correctly and safely maintain your vehicle. These procedures should not be attempted by "do-it-yourselfers," and you should not
assume this bulletin applies to your vehicle, or that your vehicle has the condition described. To determine whether this information applies,
contact an authorized Acura automobile dealer.
© 2018 American Honda Motor Co., Inc. – All Rights Reserved
Service Bulletin
Trim Level
With Technology Package
The information in this bulletin is intended for use only by skilled technicians who have the proper tools, equipment,
10.
Initialize the TPMS
11.
Do the PCM Idle Learn Procedure
12.
Install the SBW Shifter Cover
13.
Check/Refresh the SiriusXM
Service (Except in Alaska and Hawaii)
14.
Check the ACC, LKAS, Forward Collision
Warning/Collision Mitigation Braking System
Lane Departure Warning/Road Departure
Mitigation Indicators
15.
Check the Head-Up Warning (HUW) Indicator
16.
Check Voice System Interaction
®
17.
Check Bluetooth
3.
Shift by Wire (SBW)
4.
Shift Override
17-043
08212 Version 2
®
Radio Dealer Demo
®
HandsFreeLink
(HFL)
Page 1 of 13
™
,
Advertisement
Related Manuals for Acura RLX 2018
Summary of Contents for Acura RLX 2018
- Page 1 These procedures should not be attempted by “do-it-yourselfers,” and you should not assume this bulletin applies to your vehicle, or that your vehicle has the condition described. To determine whether this information applies, contact an authorized Acura automobile dealer. Page 1 of 13...
- Page 2 CLAIM INFORMATION Reimbursement Time: 1.4 hours NOTE: This time includes the TQI of the navigation system. TQI PROCEDURES Before Starting Review these items: Perfect Delivery documents, especially the information on battery maintenance and tire pressures TQI checklist in the maintenance journal Make sure you record the TQI on the appropriate pages of the maintenance journal.
- Page 3 1. When the indicator blinks, touch the keyless access remote to the ENGINE START/STOP button. The indicator will switch from blinking to steady when communication is complete. 2. Start the engine by pressing the ENGINE START/STOP button while applying the brake pedal. You must start the engine within 10 seconds of touching the remote to the button.
- Page 4 There are several protective coverings on the interior trim pieces and some areas of the carpet. Carefully remove all of them with clean hands to avoid soiling any surfaces. If any of the interior is dirty, clean it with mild soap or an Acura cleaning product such as Leather &...
- Page 5 Install the Floor Mats Install the floor mats where they belong. Place the driver’s and front passenger’s floor mat eyelets over the anchors on the floor, then turn the knobs clockwise to the lock position. Do the same for the rear seat floor mats. The anchors for those mats are under the front seats.
- Page 6 Test the battery with the ED-18 battery tester using S/B 88-016, Battery Testing and Replacement. Make sure the ED-18 has the latest software installed before using it. See S/B 09-027, ED-18 Battery Tester Update Information. If the test results show GR8 DIAGNOSTIC NEEDED, you must charge the battery with the GR8 battery diagnostic station.
- Page 7 Vehicle Exterior (Vehicle Lowered to Half-Height) Install the Front License Plate Holder If state regulations require the use of a front license plate, install the front license plate holder as shown using the three self-tapping bolts. The four short bolts are for attaching the license plate. The two long bolts and two self-tapping screws are for installing the rear license plate.
- Page 8 Clean the Rear License Plate Area, and Install the Mounting Hardware Remove the masking tape that covers the two bolt holes. Using 3M General Purpose Adhesive Cleaner (3M #051135-08984) and a clean shop towel, carefully remove any tape residue. Then, install the two long bolts and two self-tapping screws as shown.
- Page 9 Under-Hood (Engine Idling) Do the PCM Idle Learn Procedure To ensure a steady engine idle, do the PCM idle learn procedure as follows after installing the No. 15 BACKUP RADIO (10 A) and No. 16 BACKUP (10 A) fuses: 1. Start the engine with the transmission in Park, and make sure all electrical items (A/C, audio-navigation unit, rear window defogger, lights, etc.) are turned off.
- Page 10 ™ Check the ACC, LKAS, Forward Collision Warning/Collision Mitigation Braking System , Lane Departure Warning/Road Departure Mitigation Indicators When you first turn the ignition to ON, these indicators should come on for a few seconds and then go off: ACC (Adaptive Cruise Control [with Low Speed Follow]) ...
- Page 11 Check Voice System Interaction Audio System and ODMD 1. Press and release the Talk button. 2. When you hear the voice portal prompt, wait for the beep and say “Audio.” 3. After your command is accepted, wait for the beep and say “SXM.” 4.
- Page 12 Auto Park Mode As a convenience feature, the transmission automatically shifts into Park when you turn the ignition to OFF or when all of these conditions are met: The vehicle is stopped. The driver’s seat belt is unbuckled. ...
- Page 13 3. Touch the remote to the POWER button, and press the Neutral button with your foot off the brake pedal. The red indicators on either side of the Neutral button will start to blink and will keep blinking for 5 seconds. Even after they stop blinking, the transmission is in Neutral and will stay there indefinitely.
