July 24, 2015

2016 RLX: TQI Information

Supersedes 15-014, dated February 17, 2015, to revise the information highlighted in yellow.

AFFECTED VEHICLES

Year

Model

2016

RLX

REVISION SUMMARY

Under CLAIM INFORMATION, revised the flat rate time to 1.5 hours.

INTRODUCTION

This bulletin covers the total quality inspection (TQI) of the 2016 RLX. It includes these procedures:

Remove the Exterior Protective Coatings

Install the Fuses

Remove the Interior Protective Coverings

Install the Floor Mats

Check the Battery

Install the Body Plugs

Install the Front License Plate Holder

Clean the Rear License Plate Area and Install

the Mounting Hardware

Set the Tire Pressures

To do a TQI on the navigation system, be sure to complete S/B 15-008, 2016 RLX: TQI of the Navigation System.

CLAIM INFORMATION

Flat Rate Time: 1.5 hours

NOTE: This flat rate time includes the TQI of the navigation system, if equipped.

CLIENT INFORMATION:

training to correctly and safely maintain your vehicle. These procedures should not be attempted by "do-it-yourselfers," and you should not assume

this bulletin applies to your vehicle, or that your vehicle has the condition described. To determine whether this information applies, contact an

authorized Acura automobile dealer.

Service Bulletin

Trim Level

With Navigation

With Navigation and AcuraWatch Plus Package

With Technology Package

With Advance Package

The information in this bulletin is intended for use only by skilled technicians who have the proper tools, equipment, and

10.

Initialize the Tire Pressure Monitoring System

(TPMS)

11.

Do the Idle Learn Procedure

12.

Install the Shift Lock Release Cover

13.

Initialize the Audio-Navigation Unit Anti-Theft

Function and Set the AM/FM Audio Unit Presets

14.

Check/Refresh the XM Satellite Radio Dealer Demo

Service (Except in Alaska and Hawaii)

15.

Check the ACC, LKAS, LDW, FCW, and CMBS

Indicators (If Equipped)

16.

Check the Head-Up Warning (HUW) Indicator

17.

Check Voice System Interaction

18.

Check Bluetooth

15-014

01430 Version 2

HandsFreeLink

(HFL)

Page 1 of 11

Need help?

Do you have a question about the RLX 2016 and is the answer not in the manual?

Questions and answers

Summary of Contents for Acura RLX 2016

Page 1 These procedures should not be attempted by “do-it-yourselfers,” and you should not assume this bulletin applies to your vehicle, or that your vehicle has the condition described. To determine whether this information applies, contact an authorized Acura automobile dealer. Page 1 of 11...
Page 2 TQI PROCEDURES Before Starting Review these items: • Perfect Delivery documents, especially the information on battery maintenance and tire pressures • TQI checklist in the maintenance journal Make sure you record the TQI on the appropriate pages of the maintenance journal. The TQI is not done until this bulletin and the TQI checklist are both complete.
Page 3 2. When the indicator blinks, touch the keyless remote to the ENGINE START/STOP button. NOTE: The indicator will switch from blinking to steady when communication is complete. 3. Start the engine by pressing the ENGINE START/STOP button while applying the brake pedal. You must start the engine within 10 seconds of touching the remote to the button.
Page 4 There are several protective coverings on the interior trim pieces and some areas of the carpet. Carefully remove all of them with clean hands to avoid soiling any surfaces. If any of the interior is dirty, clean it with mild soap or an Acura cleaning product such as Leather &...
Page 5 Install the Floor Mats Install the floor mats in the appropriate positions. Place the driver’s and front passenger’s floor mat eyelets over the anchors on the floor, then turn the knobs clockwise to the lock position. Do the same for the rear seat floor mats. The anchors for those mats are under the front seats.
Page 6 Vehicle Exterior (Vehicle Raised to Full Height) Install the Body Plugs Install the four body plugs as shown. If they are not installed, the vehicle could make a wind noise that is hard to troubleshoot. Page 6 of 11...
Page 7 Vehicle Exterior (Vehicle Lowered to Half-Height) Install the Front License Plate Holder If state regulations require the use of a front license plate, install the front license plate holder using the three self- tapping screws. The remaining four self-tapping screws are for attaching the plate. Page 7 of 11...
Page 8 Clean the Rear License Plate Area and Install the Mounting Hardware Remove the masking tape covering the two bolt holes. Using 3M General Purpose Adhesive Cleaner (3M #051135- 08984) and a clean shop towel, carefully remove any tape residue. Then install the mounting hardware as shown. Vehicle Exterior (Vehicle Lowered to Ground) Set the Tire Pressures To prevent flat spots during vehicle shipping and storage, the tires are inflated to over 40 psi.
Page 9 Under-Hood (Engine Idling) Do the Idle Learn Procedure To ensure a steady engine idle, do the idle learn procedure as follows after installing the No. 15 BACKUP RADIO (10 A) and No. 16 BACKUP (10 A) fuses: 1. Make sure all electrical items (A/C, audio unit, rear window defogger, lights, etc.) are turned off. 2.
Page 10 Check the ACC, LKAS, LDW, FCW, and CMBS Indicators (If Equipped) When you first set the power mode to ON, these indicators should come on for a few seconds and then go off: • ACC (Adaptive Cruise Control [with low speed follow]) •...
Page 11 Check Voice System Interaction Audio System and On Demand Multi-Use Display (ODMD) 1. Press and release the Talk button. 2. After the beep, say “XM channel 122.” You should see XM channel 122 on the ODMD. Climate Control System 1. Select AUTO to turn on the climate control system. 2.
