2016 RLX Sport Hybrid: TQI and New Model Service Information
Supersedes 15-025, dated May 20, 2015, to revise the information highlighted in yellow
REVISION SUMMARY
Under Fluids, the oil was changed to Full Synthetic Engine Oil, P/N 08798-9073.
AFFECTED VEHICLES
Year
Model
2016
RLX Sport Hybrid
INTRODUCTION
This bulletin covers the total quality inspection (TQI) of the 2016 RLX Sport Hybrid. It includes these procedures:
1.
Fuel the Vehicle
2.
Remove the Exterior Protective Coatings
3.
Install the Fuses
4.
Remove the Interior Protective Coverings
5.
Install the Floor Mats
6.
Check the 12-Volt Battery
7.
Install the Body Plugs
8.
Install the Front License Plate Holder
9.
Clean the Rear License Plate Area and Install
the Mounting Hardware
10.
Install the Front Splash Guards (If Equipped)
11.
Set the Tire Pressures
12.
Initialize the Tire Pressure Monitoring System
(TPMS)
To do the TQI of the navigation system, be sure to complete Service Bulletin 15-026, 2016 RLX Sport Hybrid: TQI of the
Navigation System.
CLIENT INFORMATION:
training to correctly and safely maintain your vehicle. These procedures should not be attempted by "do-it-yourselfers," and you should not assume
this bulletin applies to your vehicle, or that your vehicle has the condition described. To determine whether this information applies, contact an
authorized Acura automobile dealer.
© 2015 American Honda Motor Co., Inc. – All Rights Reserved
Service Bulletin
Trim Level
With Technology Package
With Advance Package
The information in this bulletin is intended for use only by skilled technicians who have the proper tools, equipment, and
13.
Check the Tire Repair Kit
14.
Do the Idle Learn Procedure
15.
Charge the High-Voltage Battery
16.
Install the Electronic Gear Selector Cover
17.
Initialize the Audio-Navigation Unit Anti-Theft
Function and Set the AM/FM Audio Unit Presets
18.
Check/Refresh the XM Satellite Radio Dealer Demo
Service (Except in Alaska and Hawaii)
19.
Check the ACC, LKAS, LDW, FCW, and CMBS
Indicators (If Equipped)
20.
Check the Head-Up Display (HUD)
21.
Check the Voice System Interaction
22.
Check Bluetooth
®
23.
Check the Moonroof One-Touch Feature
15-025
06115 Version 2
HandsFreeLink
®
(HFL)
Page 1 of 22

Advertisement

loading
Need help?

Need help?

Do you have a question about the RLX Sport Hybrid 2016 and is the answer not in the manual?

Questions and answers

Related Manuals for Acura RLX Sport Hybrid 2016

Summary of Contents for Acura RLX Sport Hybrid 2016

  • Page 1 These procedures should not be attempted by “do-it-yourselfers,” and you should not assume this bulletin applies to your vehicle, or that your vehicle has the condition described. To determine whether this information applies, contact an authorized Acura automobile dealer. Page 1 of 22...
  • Page 2 This bulletin also includes this new model service information: VIN Location Electronic Parking Brake Operation Rear Door Sun Shade Electronic Gear Selector Operation Electric Glove Box Fluids Capless Fueling System Shift Override CLAIM INFORMATION Flat Rate Time: 1.4 hours NOTE: This flat rate time includes the TQI of the navigation system. TQI PROCEDURES Before Starting Review these items:...
  • Page 3 Starting the Vehicle Without the Backup Fuse To prevent battery drain during vehicle shipping, the vehicle comes from the factory with the No. 16 BACKUP (10 A) fuse removed from the under-hood fuse/relay box. With it removed, the engine will not start when you apply the brake pedal and press the POWER button.
  • Page 4 Fuel the Vehicle Make sure the No. 16 BACKUP (10 A) fuse is installed before filling up the fuel tank. If the tank was filled without that fuse, turn the ignition to OFF and let the vehicle sit for 10 minutes. Install the fuse, then turn the ignition to ON. This will ensure accurate fuel gauge readings.
  • Page 5 There are several protective coverings on the interior trim pieces and some areas of the carpet. Carefully remove all of them with clean hands to avoid soiling any surfaces. If any of the interior is dirty, clean it with mild soap or an Acura cleaning product such as Leather &...
  • Page 6 Install the Floor Mats Install the floor mats in the appropriate positions. Place the driver’s and front passenger’s floor mat eyelets over the anchors on the floor, then turn the knobs clockwise to the lock position. Do the same for the rear seat floor mats. The anchors for those mats are on the floor under the front seats.
  • Page 7 Vehicle Exterior (Vehicle Raised to Full Height) Install the Body Plugs Install the four body plugs as shown. If they are not installed, the vehicle could make a wind noise that is hard to diagnose. Page 7 of 22...
  • Page 8 Vehicle Exterior (Vehicle Lowered to Half-Height) Install the Front License Plate Holder If state regulations require the use of a front license plate, install the front license plate holder using the three self- tapping screws. The remaining four self-tapping screws are for attaching the plate. Page 8 of 22...
  • Page 9 Clean the Rear License Plate Area and Install the Mounting Hardware Remove the masking tape covering the two bolt holes. Using 3M General Purpose Adhesive Cleaner (3M #051135- 08984) and a clean shop towel, carefully remove any tape residue. Then install the mounting hardware as shown. Install the Front Splash Guards (If Equipped) Install the front splash guards as follows: 1.
  • Page 10 3. Install the left front splash guard with one of the supplied self-tapping screws and the three self-tapping screws you removed in step 2 in the order shown. 4. Make sure there is no gap between the splash guard and the body. If there is, loosen the four self-tapping screws, hold the splash guard against the body, and tighten the screws.
  • Page 11 Check the Tire Repair Kit The tire repair kit is stored in the trunk. Check the expiration date in the upper left window. If it is close, replace the sealant. Under-Hood (Engine Idling) Do the Idle Learn Procedure To ensure a steady engine idle, do the idle learn procedure as follows after installing the No. 15 BACKUP RADIO (10 A) and No.
  • Page 12 Vehicle Interior Install the Electronic Gear Selector Cover Install the cover onto the electronic gear selector by gently pressing it into place. NOTE: The glove box will not open unless the No. 15 BACKUP RADIO (10 A) and No. 16 BACKUP (10A) fuses are installed or it is opened manually (see Electric Glove Box for details).
  • Page 13 Check the ACC, LKAS, LDW, FCW, and CMBS Indicators (If Equipped) When you first turn the ignition to ON, these indicators should come on for a few seconds and then go off: • ACC (Adaptive Cruise Control [with low speed follow]) •...
  • Page 14 Check the Head-Up Display (HUD) To turn on the HUD, press the HUD button to the left of the steering column. While sitting in the driver’s seat and looking straight out the windshield, check the arrow buttons on either side of the button. They should move the HUD image up and down.
  • Page 15 Check Voice System Interaction Audio System and On-Demand Multi-Use Display (ODMD) 1. Press and release the Talk button. 2. After the beep, say “XM channel 122.” You should see XM channel 122 on the ODMD. Climate Control System 1. Select AUTO to turn on the climate control system. 2.
  • Page 16 Check the Moonroof One-Touch Feature Make sure the moonroof one-touch feature works right: • When you firmly pull the moonroof switch backward and release it, the moonroof should fully open. • When you firmly push the switch forward and release it, the moonroof should fully close. •...
  • Page 17 Rear Door Sun Shade When you raise the rear door sun shade, a second part of the shade automatically opens to cover the quarter glass. They cannot be deployed separately. Electric Glove Box To open the glove box, press the electric glove box switch. If the battery is dead or if the backup fuse is removed, the actuator will not work and the glove box will not open.
  • Page 18 Capless Fueling System This vehicle does not come with a gas cap. A funnel is provided to allow manual fueling from a gas container. It is stored in the trunk luggage area. For more information, see the owner’s manual. Page 18 of 22...
  • Page 19 Electric Parking Brake Operation To manually apply: Gently and securely pull up the electric parking brake switch. The PARK indicator in the instrument panel comes on. To manually release: Press down on the brake pedal, then push down on the electric parking brake switch. The PARK indicator goes off. To automatically release: Gently press the accelerator pedal.
  • Page 20 The parking brake can be automatically released under these conditions: • The driver’s seat belt is buckled. • The engine is running. • The electronic gear selector is not set to Park or Neutral. Electronic Gear Selector Operation You select gears by either pressing or pulling up on each of the electronic gear selector buttons. Park, Neutral, and Drive are all activated by pressing down on the corresponding letter.
  • Page 21 Shift Override The transmission can be put into Neutral during transport mode (without backup fuses installed) by doing these steps: 1. Insert the key into the slot to the left of Drive, and push down. The red indicators on either side of the Park button will start to blink.
  • Page 22 3. Touch the remote to the POWER button, and press the Neutral button with your foot off the brake pedal. The red indicators on either side of the Neutral button will start to blink and will keep blinking for 5 seconds. Even after they go out, the transmission is in Neutral and will stay there indefinitely.
