Makita 3711 Instruction Manual
Hide thumbs
Also See for 3711:
- Instruction manual (67 pages) ,
- Instruction manual (48 pages) ,
- Instruction manual (13 pages)
Table of Contents
Advertisement
Quick Links
Trimmer
EN
Affleureuse
FR
Einhandfräse
DE
Rifilatore
IT
Kantenfrees
NL
Recortadora
ES
Tupia
PT
Overfræser
DA
Κουρευτικό περιθωρίων
EL
Şekil verme testeresi
TR
3711
INSTRUCTION MANUAL
MANUEL D'INSTRUCTIONS
BETRIEBSANLEITUNG
ISTRUZIONI PER L'USO
GEBRUIKSAANWIJZING
MANUAL DE
INSTRUCCIONES
MANUAL DE INSTRUÇÕES
BRUGSANVISNING
ΕΓΧΕΙΡΙΔΙΟ ΟΔΗΓΙΩΝ
KULLANMA KILAVUZU
7
12
18
24
30
36
42
47
52
58
Advertisement
Table of Contents
Related Manuals for Makita 3711
Summary of Contents for Makita 3711
- Page 1 Trimmer INSTRUCTION MANUAL Affleureuse MANUEL D’INSTRUCTIONS Einhandfräse BETRIEBSANLEITUNG Rifilatore ISTRUZIONI PER L’USO Kantenfrees GEBRUIKSAANWIJZING MANUAL DE Recortadora INSTRUCCIONES Tupia MANUAL DE INSTRUÇÕES Overfræser BRUGSANVISNING Κουρευτικό περιθωρίων ΕΓΧΕΙΡΙΔΙΟ ΟΔΗΓΙΩΝ Şekil verme testeresi KULLANMA KILAVUZU 3711...
- Page 2 Fig.1 Fig.5 Fig.6 Fig.2 Fig.7 Fig.3 Fig.8 Fig.4...
- Page 3 Fig.9 Fig.13 Fig.10 Fig.14 Fig.11 Fig.15 Fig.12...
- Page 4 Fig.20 Fig.16 Fig.21 Fig.17 θ θ Fig.22 Fig.18 Fig.23 Fig.19...
- Page 5 Fig.24 Fig.28 Fig.25 Fig.29 Fig.26 Fig.30 Fig.27 Fig.31...
- Page 6 Fig.32 Fig.33...
-
Page 7: Specifications
ENGLISH (Original instructions) SPECIFICATIONS Model: 3711 Collet chuck capacity 6.35 mm (1/4″) or 6.0 mm No load speed 32,000 min Overall height 211 mm Net weight 1.5 kg Safety class • Due to our continuing program of research and development, the specifications herein are subject to change without notice. -
Page 8: Save All Warnings And Instruc- Tions For Future Reference
Save all warnings and instruc- FUNCTIONAL tions for future reference. DESCRIPTION The term "power tool" in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool. CAUTION: Always be sure that the tool is Trimmer safety warnings switched off and unplugged before adjusting or checking function on the tool. -
