Classification and Regulatory Information
Response time
Warranty
*Subject to maintenance and service.
NOTE: At 25°C (77°F) ambient temperature the expected lifetime of the unit is at least 30,000 hrs. For
every 10°C (50°F) rise in temperature, the lifetime is reduced by half.
Using the GastroCH
The GastroCH ECK® Gastrolyzer® can be used with the GastroCHART™ software, which is a free
4
patient management software. GastroCHART™ software can be downloaded and installed from the
USB that comes with the GastroCH
port at the rear of the GastroCH
the software, ensure that the GastroCH
Double click the GastroCHART™ icon on the PC to start the programme. Refer to the GastroCHART™
manual for instructions on how to use the software.

Buttons

Breath test
Breath bag test
Next step
Previous step
Test quality
ECK® Gastrolyzer® with GastroCHART™
4
ECK® Gastrolyzer®. Place one end of the USB cable into the USB
4
ECK® and the other end to the USB port on the PC. Before starting
4
ECK® Gastrolyzer® is connected to the PC and switched on.
4
Class I ME equipment: (externally powered)
Type BF applied part
Method of sterilization (not suitable for sterilization)
Not suitable for use in an oxygen rich environment
Intended for continuous use
≤45 seconds
2 years*
Home
Settings
Log
Calibration
Service area
(PIN protected)
19
