Please use the following instructions in conjunction with your vehicle's factory supplied
owners manual to properly install the Synergy
WARNING: To avoid any safety hazards, electrical malfunctions or
damage to the vehicle, it is important the following disconnection
and reconnection steps be followed step by step during installation.
Have the vehicle's manufacturer supplied owner's manual available.
1. Turn off vehicle and remove the key from the ignition.
2. Locate and access the vehicle's 12-volt battery, in accordance with your vehicle's
manufacturer supplied owner's manual.
Disconnect the vehicle's negative (-) cable from the battery by removing
3.
the attachment screw and lifting the cable off of the battery terminal.
4. Disconnect the vehicle's
the attachment screw and lifting the cable off of the battery terminal.
5. Connect the
harness to the
positive (+)
fasten the attachment screw. (The
power lead wiring harness is marked with a red colored end and is connected
to the 15 Amp fuse)
Synergy
®
Wiring Harness Installation
positive (+)
positive (+)
wire from the Synergy
positive (+)
battery terminal and then reconnect the vehicle's
positive (+)
cable to the
Pro-Plus Power Lead
Pro-Plus power lead wiring harness.
®
(+) Battery Cable
Synergy™ Power Lead
(-) Battery Cable
cable from the battery by removing
Pro-Plus power lead wiring
®
battery terminal. Be sure to securely
positive (+)
wire from the Synergy Pro-Plus
®
