4.3Repair 4.4Disposal 5. Installation and operation guide 1. Description 2. Pair to Sundirect Smart control system 3. Dismiss the connection between receiver and remote control 4. Installation manual for PE-Plus Series 5. Installation manual for IC-Plus|GD-Plus|MD-Plus Series 6. Electric power connection 6.
(Article Number: Receiver01) on the backside of the panel. It needs to be used in conjunction with the Sundirect control system - Smart 1.0 or Smart 1.0Pro (NOT included in the box) - in order to meet the Ecodesign legislation of the EU/EC Directive 2009/125/EC.
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR INJURY: 1. Product related safety warnings • Sundirect infrared heaters operate at a surface temperature of around 95°C when wall mounted. Do NOT touch the heater when switched on. • Prolonged contact may cause injuries or burns.
Please note that the heater may discolour with use. This is due to airborne pollution and is not a fault. If you wish to add a picture print to your heater please contact a Sundirect dealer. Do not cover your heater with a picture foil and do not paint or print the heater yourself. This might cause...
Sundirect dealer. 3. Repair Repairs must be carried out by authorized Sundirect dealers or by Sundirect directly. If you attempt to alter the product or to proceed with any repairs yourself it will void your warranty.
Heating status signal light (red light) “P” button Power switch 2.Pairing to Sundirect Smart control system Step1: Plug your heater to an electrical outlet, switch the Power switch of Receiver01 on, double press the “P” button and the “Pair signal light” will start to flash and is ready for pairing.
Page 8
We highly recommend having the panel installed by a qualified electrician or installer authorized by Sundirect. If you wish to mount the above panels on the ceiling, please contact your Sundirect dealer to purchase the right ceiling bracket. For PE380-Plus, you need the bracket BC005, and for the other models, you will need BC004.
Page 9
(not supplied). Please make sure the wall/ceiling is safe to mount. We highly recommend to have the panel installed by a qualified electrician or installer authorized by Sundirect. Please note that GD-Plus/MD-Plus series are designed only for wall mounting, don’t mount them on the ceiling.
Do not connect a heater that is damaged in any way to the power network. Before installation, make sure that the heater, cable and plug are completely free from damages. When in doubt contact your local Sundirect dealer for assistance. 6. Technical specifications: Panels covered by these instructions are listed in the table below.
The warranty covers the repair or replacement of the heater only and Sundirect shall not be liable for any other occurring costs such as installation cost or any other consequential losses however incurred.
Page 12
Information requirement for the electric local space heaters Models: PE-Plus/IC-Plus/GD-Plus/MD-Plus + Smart1.0/Smart1.0 Pro Item Symbol Value Unit Item Unit Type of heat input, for electric storage local Heat output space heaters only(Select one) manual heat charge control, with Nominal heat output Pnom 0.27-1.1...
Page 13
Serial Number of this Sundirect infrared heater is Sundirect Technology Ltd. Unit 1203, 12/F, Sam Cheong Building 216-220 Des Voeux Road Central Hong Kong / China Sundirect Logistics Europe Hofbauer GmbH Zimmeterweg 4, 6020 Innsbruck Austria / Europe info@sundirect-heater.com www.sundirect-heater.com...
Page 14
3. Reparatie Afval 5. Installatie en bedieningshandleiding 1. Beschrijving 2. Verbinden met het Sundirect Smart control systeem 3. Verbreken van de verbinding tussen de ontvanger en bediening 4. Installatie handleiding voor PE-Plus series 5. Installatie handleiding voor IC-Plus|GD-Plus|MD-Plus Series 6. Elektrische aansluiting 6.
Page 15
1. Kennisgeving aan koper Bedankt voor de aanschaf van dit Sundirect infraroodpaneel. We hopen dat u geniet van deze innovatieve technologie en dat dit product een aangename sfeer in uw huis zal brengen. Lees deze instructies aandachtig door en bewaar het voor toekomstig gebruik. Als u deze instructies niet naleeft, vervalt uw garantie.
Page 16
3. Veiligheidsinstructies OM HET RISICO OP BRAND, ELEKTRISCHE SCHOK OF LETSEL TE VERMINDEREN: 1. Productgerelateerde veiligheidswaarschuwingen Sundirect-infraroodpanelen werken bij wandmontage met een oppervlaktetemperatuur van • ongeveer 95°C. Raak het paneel NIET aan wanneer deze is ingeschakeld.. • Langdurig contact kan verwondingen of brandwonden veroorzaken..
Page 17
Houd er rekening mee dat de heater door gebruik kan verkleuren. Dit komt door luchtvervuiling en is geen fout. Neem contact op met een Sundirect dealer als u een fotoprint wilt toevoegen aan uw paneel. Dek uw paneel niet af met fotofolie en beschilder of bedruk de kachel niet zelf. Hierdoor kan het...
Page 18
3. Reparatie Reparaties dienen te worden uitgevoerd door geautoriseerde Sundirect dealers of rechtstreeks door Sundirect. Als u probeert het product te wijzigen of zelf reparaties uit te voeren, vervalt uw garantie. Weggooien Sundirect infraroodstralers zijn elektrische apparaten en dus elektrisch afval. Gooi het infraroodpaneel aan het einde van zijn levensduur weg in overeenstemming met de lokale regelgeving met betrekking tot elektrisch afval.
Page 19
Verwarming aan (rood light) “P” Programma knop Aan/uit schakelaar 2. Koppeling met het Sundirect smart systeem Steek de stekker van het infrarood paneel in een stopcontact, zet de Power-schakelaar van Receiver01 aan, druk twee keer op de “P”-knop en het “koppelstatus signaal licht” begint te knipperen en is klaar om te verbinden.
Page 20
Wij raden ten zeerste aan om het paneel te laten installeren door een gekwalificeerde elektricien of door Sundirect geautoriseerde installateur. Houd er rekening mee dat de GD-Plus/MD-Plus-serie alleen is ontworpen voor wandmontage, monteer ze niet aan het plafond.
Page 21
Sluit een verwarming die op enige wijze beschadigd is niet aan op het elektriciteitsnet. Zorg er voor de installatie voor dat het paneel, kabel en stekker volledig vrij zijn van beschadigingen. Neem bij twijfel contact op met uw plaatselijke Sundirect-dealer voor hulp. 6. Technische specificaties: De panelen die onder deze instructies vallen, staan in de onderstaande tabel.
Page 22
Sundirect-dealer en stuur het paneel samen met het aankoopbewijs terug. De garantie dekt alleen de reparatie of vervanging van het infrarood paneel en Sundirect is niet aansprakelijk voor eventuele andere kosten zoals installatiekosten of andere gevolgschade, hoe dan ook ontstaan.
Page 23
Informatievereiste voor de elektrische toestellen voor lokale ruimteverwarming Models: PE-Plus/IC-Plus/GD-Plus/MD-Plus + Smart1.0/Smart1.0 Pro Item Symbol Value Unit Item Unit Type of heat input, for electric storage local Heat output space heaters only(Select one) manual heat charge control, with Nominal heat output Pnom 0.27-1.1...
Page 24
Serial Number of this Sundirect infrared heater is Sundirect Technology Ltd. Unit 1203, 12/F, Sam Cheong Building 216-220 Des Voeux Road Central Hong Kong / China Sundirect Logistics Europe Hofbauer GmbH Zimmeterweg 4, 6020 Innsbruck Austria / Europe info@sundirect-heater.com www.sundirect-heater.com...
