MOD - 6270
STEP 5
5.1 Locate Center Rail (D) into the corresponding brackets inside of Headboard (A) and
Footboard (B).
5.2 Insert and secure the Center Rail Support (F) to the Center Rail (D) & Side Rail (C) using
hardware parts Wood Screw (2).
D
2. WOOD SCREW M3.5 x 16mm x 8pcs
STEP 6
6.1 Locate Center Rail (D) into the corresponding brackets inside of Headboard (A) and
Footboard (B) using hardware parts Wood Screw (1).
D
x 2
1. WOOD SCREW M4 x 20mm x 2pcs
A
C
x 2
B
Screw Driver
A
1
Screw Driver
D
D
B
A
F
C
2
A
F
04 of 05
