MOD-6233
Thank you for purchasing the MODWAY BED!
Before you start, here are some helpful advice:
1. We suggest you spend a short time reading through this leaflet and then follow the simple step instructions.
2. Owing to the size and weight of the bed, we recommend that it is assembled by two adults, on a carpeted or
padded area, in the room that it is intended for. Approx assembly time: 20 minutes.
3. Please do not use any tools other than those provided or recommended in these instructions.
4. Please do not throw away any of the packaging or the instruction until you have checked all the components and
hardware and the furniture is fully assembled. Please ensure that the packaging is disposed of in a safe
environmentally friendly way.
5. Assemble all components loosely until advised to tighten. Depending on use, it may be necessary to tighten the
components from time to time, so please save tools that have been provided.
6. Please keep all fitting out of reach of children.
Customer Service 609-256-9000 | www.modway.com
A
B
Components:
A
HEADBOARD
B
HB SUPPORT
C
BED FRAME
(DOES NOT INCLUDE
WITH THE PURCHASE)
1 PC
2 PCS
-
01 of 03
Advertisement
Related Manuals for modway MOD-6233
Summary of Contents for modway MOD-6233
- Page 1 MOD-6233 Thank you for purchasing the MODWAY BED! Before you start, here are some helpful advice: 1. We suggest you spend a short time reading through this leaflet and then follow the simple step instructions. 2. Owing to the size and weight of the bed, we recommend that it is assembled by two adults, on a carpeted or padded area, in the room that it is intended for.
- Page 2 1.2 Secure each HB support stand by using 2x JCBC Bolt [1] and 2x M6 Spring Washer [2] and 2x M6 Flat Washer [3]. Tighten with supplied Allen Key [4]. Repeat the same procedure to secure the other side. Note: Hardware may loosen over time. Periodically check that all connections are tight. Customer Service 609-256-9000 | www.modway.com 02 of 03...
- Page 3 3x M6 Flat Washer [3] for the thicker bed frame. Tighten with supplied Allen Key [4]. 2.3 Repeat the same procedure for each screw and each side of the bed frame. STEP 3 3.1 Assembly completed. Customer Service 609-256-9000 | www.modway.com 03 of 03...
- Page 4 MOD-6213 Thank you for purchasing the MODWAY BED! Before you start, here are some helpful advice: 1. We suggest you spend a short time reading through this leaflet and then follow the simple step instructions. 2. Owing to the size and weight of the bed, we recommend that it is assembled by two adults, on a carpeted or padded area, in the room that it is intended for.
- Page 5 JCBC BOLT M6 x 15mm 1 PC 4 PCS L BRACKET JCBB BOLT M8 x 50mm 8 PCS 2 PCS BARREL NUT ADJUSTABLE FOOT 3 PCS 3 PCS STEP 1 STEP 2 Customer Service 609-256-9000 | www.modway.com 02 of 06...
- Page 6 MOD-6213 Side Rail Holes STEP 3 Short Tab of L Bracket (13) Side Rail Holes STEP 4 Side Rail Holes STEP 5 Customer Service 609-256-9000 | www.modway.com 03 of 06...
- Page 7 MOD-6213 STEP 6 STEP 7 Customer Service 609-256-9000 | www.modway.com 04 of 06...
- Page 8 MOD-6213 STEP 8 STEP 9 3/13 STEP 10 3/13 7/13 11/13 Customer Service 609-256-9000 | www.modway.com 05 of 06...
- Page 9 MOD-6213 STEP 11 STEP 12 12.1 Assembly completed. Customer Service 609-256-9000 | www.modway.com 06 of 06...
