3. Module dimensions and pin description

3.1 Module size package

Fig.1 Schematic diagram of the radar module structure

3. 2. Pin description

Interface
Pins
1
2
3
Interface 1
4
5
6
Description
Typical
5V
5.0V
GND
RX
TX
S1
3.3V/0V
S2
3.3V/0V
Description
Power supply input positive
Ground
Serial port reception
Serial port transfer
