- Page 1 Grove - Fingerprint Sensor Release date： 9/20/2015 Version： Wiki: http://seeedstudio.com/wiki/Grove_-_Finger_Print_Sensor_V1.0 Bazaar: http://www.seeedstudio.com/depot/Grove-Fingerprint-Sensor-p-1424.html...
- Page 2 Document Revision History Revision Date Author Description Sep 21, 2015 Victor.He Create file...
-
Page 3: Table Of Contents
Contents Document Revision History · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 2 1. - Page 4 Disclaimer For physical injuries and possessions loss caused by those reasons which are not related to product quality, such as operating without following manual guide, natural disasters or force majeure, we take no responsibility for that. Under the supervision of Seeed Technology Inc., this manual has been compiled and published which covered the latest product description and specification.
-
Page 5: Introduction
1. Introduction The Finger Print Sensor is one optical fingerprint sensor which will make fingerprint detection and verification adding super simple. There’s a high powered DSP chip AS601 that does the image rendering, calculation, feature-finding and searching. You can also enroll new fingers directly - up to 162 finger prints can be stored in the onboard FLASH memory. -
Page 6: Specification
2. Specification Supply voltage 3.6~6.0 V Operating current(Max) 120 mA Fingerprint imaging time 1.0 S Match Mode: Compare Mode 1:1 Search Mode Storage capacity 162 templates False Acceptance Rate 0.001% (Security level 3) False Reject Rate 1.0% (Security level 3) Baud rate 9600, 19200, 28800, 38400, 57600bps (default is 57600) Interface... -
Page 7: Interface
3. Interface Pin number Name Type Function Description Positive Power Supply Input Terminal(Line color:Red) Serial data output, TTL logic levels(Line color: Yellow) Serial data input, TTL logic levels(Line color: White) Signal ground(Line color: Black) -
Page 8: Demonstration
4. Demonstration The Finger Print Sensor module is typically used in safes - there's a high powered DSP chip that does the image rendering, calculation, feature-finding and searching. Connect to any microcontroller or system with TTL serial, and send packets of data to take photos, detect prints, hash and search. - Page 9 Open the enroll code directly by the path: File -> Example ->FingerPrint->Enroll. Upload the code into Arduino. Please click here if you do not know how to upload. Startup Serial Tool and Select the ComNum and BuadRate used by the Arduino. ...
- Page 10 If your press is OK, you could see the following message. You will then have to repeat the process, to get a second clean print. Use the same finger! On success you will get notice.
- Page 11 If there's a problem such as a bad print or image, you'll have to do it again. Once you have the finger enrolled, it's a good idea to do a quick test to make sure it can be found in the database.
- Page 12 If it is not a finger in the database, this serial port will output nothing.
-
Page 13: Resource
5. Resource Finger Print Sensor Library File Finger Print Sensor Datasheet... - Page 14 Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: Seeed Studio 101020057...
