Preparing Cameras without Sensor Cover Glass
Alvium, Manta, Prosilica GT
1. Terms used in this document
Term
Circular protection foil
Cover glass
lbf-in
Nm
PCB
PCBA
Extended Format housing
Large Format housing
Protection glass
RCG
TCG
2. Scope
RCG and TCG cameras must be handled with utmost care to avoid damage to the image sensor. Follow the
instructions in this document to properly prepare RCG or TCG cameras for operation.
3. Safety notes
3.1. Electrostatic discharge (ESD)
Electrostatic charge builds up in the body when walking on carpeted floor. This can discharge when
touching metal objects like a door handle. Such ESD can damage electronic devices, especially when tools
or hands get in contact with connectors. We recommend measures to avoid damage by ESD:
• Unpacking: Remove the camera from its anti-static packaging only when your body is grounded.
• Workplace: Use a static-safe workplace with static-dissipative mat and air ionization.
• Wrist strap: Wear a static-dissipative wrist strap to ground your body.
• Clothing: Wear ESD-protective clothing. Keep components away from your body and clothing. Even if
you are wearing a wrist strap, your body is grounded but your clothes are not.
3.2. Sensor damage
Follow the instructions thoroughly to avoid damage to sensor and camera. Work in a dust-free environment
(class 100 or better) with humidity according to ESD requirements.
OTE
Description
Adhesive tape to protect the lens mount against dirt
Glass layer on top of the sensor surface, removed for RCG and TCG cameras
Inch-Pounds, unit for maximum torque, based on the British imperial units system
(1 lbf-in = 0.113 Nm)
Newton meter, unit for maximum torque; based on the metrical system (1 Nm = 8.85 lbf-in)
Printed circuit board
Printed circuit board assembly as a set of multiple PCBs
Extended-sized housing, such as for Prosilica GT1910, GT1660, and GT2300
Large-sized housing, such as for Prosilica GT4905, GT4907, and GT6600
Clear "filter" in the camera mount assembly
Removed Cover Glass sensor option
Taped Cover Glass sensor option
Page 1 of 18
V3.0.1
2022-Sep-27
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Allied Vision Alvium
Summary of Contents for Allied Vision Alvium
- Page 1 PPLICATION Preparing Cameras without Sensor Cover Glass V3.0.1 Alvium, Manta, Prosilica GT 2022-Sep-27 1. Terms used in this document Term Description Circular protection foil Adhesive tape to protect the lens mount against dirt Cover glass Glass layer on top of the sensor surface, removed for RCG and TCG cameras...
-
Page 2: Warranty Conditions
Sensor Cover Glass 4. Warranty conditions Allied Vision warranty does not cover any damage to the sensor as soon as the cover glass or the circular protection foil is removed. TCG and RCG cameras have the standard warranty on the electronics, but... - Page 3 For details, see your camera’s user guide. 2. Mount your optics according to the manual of the lens manufacturer and the Alvium user guide. Without compensation, cameras could be focused to infinity after the sensor cover glass has been removed.
- Page 4 Preparing Cameras without Sensor Cover Glass 7. Instructions for Alvium bare board cameras – TCG At delivery, sensors of TCG cameras are protected by the cover glass fixed by adhesive tapes. This section instructs on removing these tapes and the cover glass. Note that you must mount bare board cameras into housings immediately after the TCG has been removed.
- Page 5 Preparing Cameras without Sensor Cover Glass Tape Glass Sensor Bare pixel surface Tape Figure 2: Sensor with TCG (schematic view) 1. Place the camera on your work bench, with the sensor side facing up. 2. Place the magnifying glass above the camera, with sufficient space to access the TCG and the adhesive tapes with tools.
- Page 6 Preparing Cameras without Sensor Cover Glass 9. With the pliers, grip the detached corner of tape and slowly pull it off the cover glass and off the sensor baseplate. Pliers Figure 5: Pliers pulling the adhesive tape off the sensor (schematic view) 10.
- Page 7 Preparing Cameras without Sensor Cover Glass 8. Instructions for Manta cameras – RCG At delivery, sensors of RCG cameras are protected by the circular protection foil placed on the lens mount. This section instructs on removing the circular protection foil and mounting the lens. NOTICE Damage to the camera electronics and sensor •...
- Page 8 Preparing Cameras without Sensor Cover Glass 9. Instructions for Prosilica GT cameras – TCG At delivery, sensors of TCG cameras are protected by the cover glass fixed by adhesive tapes. This section instructs on removing these tapes and the cover glass, starting to disassemble the camera in order to get access to the sensor.
- Page 9 Preparing Cameras without Sensor Cover Glass The front assembly consists of the sensor unit (d) and the lens mount (e). The sensor unit must be kept in one piece to avoid damage to the sensor. Figure 10: Front assembly overview: sensor unit and lens mount NOTICE Damage to the sensor If you must reassemble the sensor unit, do not put the sensor surface down facing...
-
Page 10: Camera Top
Preparing Cameras without Sensor Cover Glass 9.2. Disassembling Prosilica GT Large Format housing cameras 1. Power off and unplug the camera. 2. Loosen and remove the four M2 x 10 socket head cap screws of the front assembly. Figure 13: Removing the four M2 x 10 socket head cap screws of the front assembly 3. - Page 11 Preparing Cameras without Sensor Cover Glass Continuing the disassembly • Keep the camera flipped open as described in step • The illustrations of the next action steps are schematics. The front assembly consists of the sensor unit (e) and the lens mount (f). Figure 15: Front assembly overview: sensor unit and lens mount 6.
- Page 12 Preparing Cameras without Sensor Cover Glass You have access to the sensor now. Sensor Figure 18: sensor unit and sensor 9. Continue with 9.3. Removing the taped cover glass on page 12. 9.3. Removing the taped cover glass Ease handling •...
- Page 13 Preparing Cameras without Sensor Cover Glass Tape Glass Sensor Bare pixel surface Tape Mount Figure 19: Sensor with TCG (schematic view) 1. Place the camera on your work bench, with the sensor side facing up. 2. Place the magnifying glass above the camera, with sufficient space to access the TCG and the adhesive tapes with tools.
- Page 14 Preparing Cameras without Sensor Cover Glass 9. With the pliers, grip the detached corner of the tape and slowly pull it off the cover glass and off the sensor baseplate. Pliers Figure 22: Pliers pulling the adhesive tape off the sensor (schematic view) 10.
- Page 15 Preparing Cameras without Sensor Cover Glass 9.4. Reassembling Prosilica GT Extended Format housing cameras 1. Position sensor unit and lens mount, so that markers (c) align. 2. Keeping screws (a) and spacers in place, fit the sensor unit (b) as a unit into the lens mount (d) Figure 24: Fitting the sensor unit into the lens mount 3.
- Page 16 Preparing Cameras without Sensor Cover Glass 9.5. Reassembling Prosilica GT Large Format housing cameras 1. Position sensor unit (a) and lens mount (c), so that markers (b) align. 2. Fit the sensor unit (a) into the lens mount (c). Figure 28: Fitting the sensor unit into the lens mount 3.
-
Page 17: Mounting The Lens
Preparing Cameras without Sensor Cover Glass 7. Insert and tighten the four M2 x 10 socket head cap screws at a maximum torque of 4 lbf-in (0.45 Nm). Figure 31: Inserting the four M2 x 10 socket head cap screws of the front assembly 9.6. -
Page 18: Copyright And Trademarks
All content is subject to change without notice. All trademarks, logos, and brands cited in this document are property and/or copyright material of their respective owners. Use of these trademarks, logos, and brands does not imply endorsement. Copyright © 2022 Allied Vision Technologies GmbH. All rights reserved. Page 18 of 18...
