PCB Piezotronics IMI SENSORS EX615A42 Installation And Operating Manual page 6

Model Number
EX615A42
Performance
Sensitivity(± 5 %)
Measurement Range
Frequency Range(± 5 %)
Frequency Range(± 10 %)
Resonant Frequency
Non-Linearity(<200 g pk)
Transverse Sensitivity
Environmental
Overload Limit(Shock)
Temperature Range
Temperature Response
Temperature Response
Temperature Response
Base Strain Sensitivity
Enclosure Rating
Electrical
Capacitance(Pin to Pin)
Capacitance(with integral cable)
Insulation Resistance(at 500F)
Insulation Resistance(at room temp)
Electrical Isolation(Case)
Physical
Sensing Element
Sensing Geometry
Housing Material
Sealing
Size (Height x Length x Width) .89 in x 1.58 in x 1.58 in
Weight(without cable)
Mounting
Cable Length
Cable Termination
Cable Type Armored 3-wire, low-noise PTFE
Mounting Torque
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without notice.
®
ICP is a registered trademark of PCB Group, Inc.
HIGH TEMPERATURE INDUSTRIAL ACCELEROMETER
ENGLISH
100 pC/g 10.2 pC/(m/s²)
+/-200 g pk +/-2000 m/s² pk
5 kHz
6 kHz
>20 kHz >20 kHz
± 1 %
<5 %
1000 g pk 9800 m/s² pk
-65 to +500 °F -54 to +260 °C
See Graph See Graph
+.03 %/°F +.06 %/°C
See Graph See Graph
0.003 g/µε 0.03 (m/s²)/µε
IP68
11,100 pF 11,100 pF
35 pF/ft 115 pF/m
7
≥ 10 Ohm ≥ 10
9
≥ 10 Ohm ≥ 10
8
>10 Ohm >10
Ceramic Ceramic
Shear Shear
Stainless Steel Stainless Steel
Welded Hermetic Welded Hermetic
23 mm x 40 mm x 40 mm
6.7 oz 190 gm
Through Holes (4) Through Holes (4)
10 ft
Pigtail Pigtail
Armored 3-wire, low-noise PTFE
cable
11 ft-lb 15 Nm
SI
[2]
Optional versions have identical specifications and accessories as listed for the standard
model except where noted below. More than one option may be used.
5 kHz [3]
6 kHz
[1]
± 1 % [4]
<5 % [5]
[1]
[1]
IP68
NOTES:
[1]
[1]Typical.
[2]Conversion Factor 1g = 9.81 m/s².
7
Ohm
[3]1Hz = 60 cpm (cycles per minute).
9
Ohm [4]Zero-based, least-squares, straight line method.
8
[5]Transverse sensitivity is typically ≤ 3%.
Ohm
[1]
3 m
cable
SUPPLIED ACCESSORIES:
Model 081C108 Mounting Screw, 1/4-28x1, Inconel (2)
Model ICS-1 NIST-traceable single-axis amplitude response calibration from 600 cpm (10 Hz) to
upper 5% frequency (3)
Entered: LK
Date: 10/21/2015 Date: 10/21/2015 Date: 10/21/2015 Date: 10/21/2015
3425 Walden Avenue, Depew, NY 14043
OPTIONAL VERSIONS
Engineer: PL Sales: WDC Approved: NJF
Phone: 800-959-4464
Fax: 716-684-3823
E-Mail: imi@pcb.com
Revision: NR
ECN #: 43970
Spec Number:
58202
