Using Your VP-12N 1:12 + 3 UXGA / CAT5 Distributor

Table 1: Front and Rear Panel Features of the VP-12N 1:12 + 3 UXGA/CAT5 Distributor

# Feature
1 POWER Switch
2 INPUT HD15F Connector
3 OUT HD15F Connectors
4 OUT RJ-45 Connectors
5 Power Connector with FUSE

Table 2: Underside Features of the VP-12N 1:12 + 3 UXGA / CAT5 Distributor

# Feature
1 BLUE Trimmer
2 GREEN Trimmer
3 RED Trimmer
4 ID BIT CONTROL Switch Slide to the left to set to ON
5 Using Your VP-12N 1:12 + 3 UXGA / CAT5 Distributor
This section describes how to connect the VP-12N 1:12 + 3 UXGA / CAT5
Distributor.
The example in Figure 3 illustrates how to output a computer graphics signal
from a computer to up to 12 local monitors, as well as how to transmit it over
UTP cabling to 3 TP-120 XGA Line Receiver units.
To connect the VP-12N and up to 3 TP-120 XGA Line Receiver units, do the
following:
1. Connect a computer graphics source (for example, a computer) to the
INPUT HD15F connector.
2. Connect the OUTPUT HD15F connectors to up to 12 acceptors (for
example, Local Display 1 to Local Display 12).
3. Ensure that the ID BIT switch on the underside of the VP-12N is set to
ON (by sliding it to the left). This would enable a notebook or laptop (if
connected instead of a computer) to output a VGA signal to an external
VGA monitor.
1 Using a UTP cable with CAT5 connectors at both ends (the PINOUT is defined in Table 3 and Figure 4)
2 For example, on the TP-120 XGA Line Receiver. Refer to the separate user manual: PT-110, WP-110, PT-120, TP-120,
which can be downloaded from the Internet at this URL: http://www.kramerelectronics.com
3 Insert a screwdriver into the small hole and carefully rotate it to adjust the level
4 The default. Enabling the notebook or laptop to output a VGA signal to an external VGA monitor
4
Function
Illuminated switch for turning the unit ON or OFF
Connect to the computer graphics (UXGA) source
Connect to the computer graphics (UXGA) acceptors (from 1 to 12)
1
Connect to the LINE IN RJ-45 connector
AC connector enabling power supply to the unit
Function
Adjusts the blue level
Adjusts the green level
Adjusts the red level
2
(from 1 to 3)
3
3
3
4
; to the right to set to OFF
