Solar Monitor
6. TFTP Boot-loader
The Solar Monitor supports remote software upgrade over the network via
TFTP (Trivial file transfer protocol)
Should there be a firmware update or the user wants to make specific
changes to the units and we have changed the software accordingly to the
customer needs the software can be remotely upgraded over the network.
7.
OID TABLE and MI-SNMP Manager software
OID table / number of services = 11
1.3.6.1.4.1.45501.1.3.1.0 = Relay 4 status (integer) 0 off / 1 on
1.3.6.1.4.1.45501.1.3.2.0 = Relay 5 status (integer) 0 off/1 on
1.3.6.1.4.1.45501.1.3.3.0 = Total Battery volts
1.3.6.1.4.1.45501.1.3.4.0 = Battery Charge Amps
1.3.6.1.4.1.45501.1.3.5.0 = Load amps
1.3.6.1.4.1.45501.1.3.6.0 = NOT USED
1.3.6.1.4.1.45501.1.3.7.0 = Temperature
1.3.6.1.4.1.45501.1.3.8.0 = Alarm status 0 off / 1 on
1.3.6.1.4.1.45501.1.3.9.0 = **Reserved / not used
1.3.6.1.4.1.45501.1.3.10.0 = Battery 1 (12V) value
1.3.6.1.4.1.45501.1.3.11.0 = Battery 2 (24v) value
1.3.6.1.4.1.45501.1.3.12.0 = Solar panel input Amps
-ISO
SNMP
Mi
11 |
P a g e
