Dunlop FILL&GO Operating Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
BY DUNLOP TECH
Simply remain mobile
GB
Operating manual
for the tire mobility kit & electrical air pump
AUTOMATIC SYSTEM/DIRECT CONNECTION
30

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FILL&GO and is the answer not in the manual?

Questions and answers

Related Manuals for Dunlop FILL&GO

Summary of Contents for Dunlop FILL&GO

  • Page 1 BY DUNLOP TECH Simply remain mobile Operating manual for the tire mobility kit & electrical air pump AUTOMATIC SYSTEM/DIRECT CONNECTION...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Scope of delivery Page 32 Technical data Page 32 Basic safety information Page 33 Important terms and symbols Page 33 Intended use Page 34 Storage and shelf life Page 35 Disposal of sealant Page 35 Disposal of electrical air pump Page 36 Repair of electrical air pump Page 36...

  • Page 3: Scope Of Delivery

    SCOPE OF DELIVERY The FILL & GO tire mobility kit contains an electric pump with power cable (12 V) and fill hose, a bottle with tire sealant, various adapters and an instruction manual. TECHNICAL DATA Electrical air pump Sealant bottle Input voltage: 12 Volt (V) Depending on the version of the Current consumption: max.

  • Page 4: Basic Safety Information

    BASIC SAFETY INFORMATION ► NOTE: Read the entire operating manual incl. all safety and warning notes through carefully before use. WARNING: Failure to comply with the following information and instructions may result in property damage, electric shock, fire, serious injury and/or danger to life. This operating manual must also be passed on when the mobility system is handed over to third parties.

  • Page 5: Intended Use

    WARNING: indicates a possible hazardous situation which could lead to death or severe injuries if it is not avoided. CAUTION: indicates a possible hazardous situation which could lead minor or moderate injuries if it is not avoided. ► NOTE: indicates information that is important but not connected to potentially dangerous situations.

  • Page 6: Storage And Shelf Life

    STORAGE AND SHELF LIFE CAUTION: The sealant retains its full functional ability within the given shelf life if the bottle is moved. If the bottle is stored in a vehicle that is driven regularly, the movement of the vehicle is sufficient. For this reason, we recommend keeping the tire mobility set in the vehicle.

  • Page 7: Disposal Of Electrical Air Pump

    DISPOSAL OF ELECTRICAL AIR PUMP The electrical air pump must be disposed of through the respective municipal collecting points. REPAIR OF ELECTRICAL AIR PUMP WARNING: The electrical air pump and the power cable cannot be repaired. If faulty, the equipment must be disposed of properly. Do not try to repair the air pump or the power cable yourself.
  • Page 8 > In the work area, the user is responsible to third parties for damage caused by use of the mobility system. > Never leave the equipment unattended as long as it is switched on, and heed the filling instructions for vehicle tires as well as for other objects to be filled. CAUTION: >...
  • Page 9 > Do not put the equipment into operation or stop its operation immediately and no longer use it if it is damaged. DANGER: > Pull the connection plug out when not in use, before any cleaning work or in the event of malfunctions, hazardous situations or damage to the power cable from the 12 V socket.

  • Page 10: First-Aid Measures

    FIRST-AID MEASURES If you should suffer any soiling, irritation, accidents or injuries in connection with the tire mobility system, please take the appropriate first-aid measures: > If clothing has become soiled and dampened with the sealant, take it off immediately. If complaints persist, consult a doctor.

  • Page 11: Description Fill & Go Tire Mobility System & Electrical Air Pump

    DESCRIPTION FILL & GO TIRE MOBILITY SYSTEM & ELECTRICAL AIR PUMP Electrical air pump 12 V power cable with 1a 12 V connection plug (in the stowage compartment on the underside of the equipment) On/off switch (ON/OFF) Manometer with air pressure display (in psi and bar) Valve button for discharging air Slot for sealant bottle Plug-in connection for sealant bottle or fill hose...

  • Page 13: Instructions For The Use Of Fill & Go In The Event Of A Flat Tire

    INSTRUCTIONS FOR THE USE OF FILL & GO IN THE EVENT OF A FLAT TIRE You will find the respective photo illustration on pages 3–4 (see fold-out page, front). ► NOTE: Read the entire operating manual incl. all safety and warning notes through carefully before use.
  • Page 14 a combustion engine outdoors and in areas with sufficient ventilation (e.g. in garages with the doors open). There is a choking hazard due to vehicle exhaust fumes when the engine is running. With the FILL & GO mobility set you can carry out temporary repairs to punctures of a size of around 6 mm in the tread and tire shoulder (Fig.
  • Page 15 Remove the speed limit sticker (max. 80 km/h; max. 50 mph) on the base of the bottle (Fig. 4a) and stick it in a clearly visible place on the dashboard (Fig. 4b). Take the fill hose and insert it into the plug-in connection on the bottle (Fig. 5). Slide the bottle with the yellow plug-in connection facing downwards into the slot provi- ded on the electrical air pump until it latches into place and you hear it “click„...
  • Page 16 Connect the 12 V power cable of the electrical air pump to the 12 V socket or the cigarette lighter (Fig. 8a) and ensure the power supply, depending on your vehicle (drive) (see vehicle manual if applicable). To go easy on the vehicle battery, we recommend starting the engine of vehicles with a com- bustion engine (Fig.
  • Page 17 DANGER: > The pumping process must be terminated at the latest when the maximum pressure according to the vehicle manufacturer has been reached. > The electrical air pump should not work for more than 10 minutes in constant operation. We recommend allowing it to cool for approx. 30 minutes before using it again. >...
  • Page 18 WARNING: Note that for safety reasons you may not drive faster than 80 km/h (50 mph) with a tire that has undergone temporary repair. Then drive for approx. 10 minutes with the vehicle to distribute the sealant in the tire and thus seal the tire from the inside.
  • Page 19 WARNING: Please note that you must not drive more than approx. 300 km (approx. 190 miles) with the provisionally repaired tire. After use, the sealant bottle can be disposed of with domestic waste, it should not remain in the vehicle. The electrical air pump can be used frequently and should be stowed safely in the vehicle again.

  • Page 20: Instructions On Inflating A Tire Without Damage

    INSTRUCTIONS ON INFLATING A TIRE WITHOUT DAMAGE You will find the respective photo illustration on pages 269–270 (see fold-out page, back). You can also use the electrical air pump to increase the air pressure in the tire without this being damaged. ►...
  • Page 21 DANGER: Please note that the electrical air pump may only be used on vehicles with a combustion engine outdoors and in areas with sufficient ventilation (e.g. in garages with the doors open). There is a choking hazard due to vehicle exhaust fumes when the engine is running.
  • Page 22 To go easy on the vehicle battery, we recommend starting the engine of vehicles with a com- bustion engine (Fig. E) – ensure sufficient ventilation. For vehicles with an electrical motor, we recommend switch other electrical equipment off during operation of the electrical air pump. DANGER: The electrical air pump should not be operated unattended.

  • Page 23: Instructions On Inflating Inflatable Products

    Check the tire pattern for any peculiarities and remove the electrical air pump hose carefully from the tire valve and unplug the 12 V connection plug from the 12 V socket. Stow the electrical air pump in the vehicle again in such as way that it is secured and can be accessed again if necessary.
  • Page 24 Before you start inflating, find out the maximum permissible air pressure of the object to be filled. DANGER: Always observe the information provided by the respective manufacturer. Overfilling can lead to the object bursting and the user becoming injured. In order to use the electrical air pump you require a 12 V socket or a 12 V cigarette lighter – both of which you will find inside your vehicle.
  • Page 25 underside of the electrical air pump (Fig. B). Choose the suitable adapter, depending on the object to be filled. The inflation of large-volume inflatable objects can be speeded up by combining two adapters. For this purpose, the pointed adapter is inserted into the tube-like adapter and locked by one eighth of a turn (Fig.
  • Page 26 DANGER: The electrical air pump should not be operated unattended. Children under 16 years of age must not use the electrical air pump unattended. Start the electrical air pump by setting the on/off switch to ON (Fig. F). Constantly observe the fill pressure and the air volume.
