- Page 1 INSTA LLATI ON MANUAL L.SPR.18D.C.M and L.SPR.18D.4.C.M DRW, DOUBLE TIRES, WDB 907 AND 4X4 MERCEDES BENZ SPRINTER 500 (2018-ONWARDS) DSC SYSTE M S.NL...
- Page 2 2 | INSTALLATION MANUAL | AUXILIARY AIR SUSPENSION | MERCEDES BENZ SPRINTER 500 L.SPR.18D.C.M (AND 4X4) (2018-ONWARDS) JULY 2021...
-
Page 3: Table Of Contents
Tube Connection and Disconnection, Cutting and Routing Bellow Inflation Spring Alignment 5.10 Maintenance 5.11 Check List Instructions for installation Special Model and 4x4 Epilogue 3 | INSTALLATION MANUAL | AUXILIARY AIR SUSPENSION | MERCEDES BENZ SPRINTER 500 L.SPR.18D.C.M (AND 4X4) (2018-ONWARDS) JULY 2021... -
Page 4: Foreword
DSC Nederland by post, fax or e-mail. Our e-mail address is: info@dscsystems.nl 4 | INSTALLATION MANUAL | AUXILIARY AIR SUSPENSION | MERCEDES BENZ SPRINTER 500 L.SPR.18D.C.M (AND 4X4) (2018-ONWARDS) JULY 2021... -
Page 5: Introduction
R I D E COM FO RT Air springs help to absorb shock loads from uneven road surfaces, therefore general ride quality is much improved. 5 | INSTALLATION MANUAL | AUXILIARY AIR SUSPENSION | MERCEDES BENZ SPRINTER 500 L.SPR.18D.C.M (AND 4X4) (2018-ONWARDS) JULY 2021... -
Page 6: Very Important Notes
PM85, July 2007 Safe recovery (and repair) of buses and coaches fitted with air suspension. The uniform resource locator (URL) for this document is: http://www.hse.gov.uk/PUBNS/pm85.pdf 6 | INSTALLATION MANUAL | AUXILIARY AIR SUSPENSION | MERCEDES BENZ SPRINTER 500 L.SPR.18D.C.M (AND 4X4) (2018-ONWARDS) JULY 2021... -
Page 7: Overview
DIN 9623-M6 Flange nut M6 * Right side not in the assembly drawing ** For 4x4: OP.LB.170-3.CPL (air bellow 170/3, 2 pcs) 7 | INSTALLATION MANUAL | AUXILIARY AIR SUSPENSION | MERCEDES BENZ SPRINTER 500 L.SPR.18D.C.M (AND 4X4) (2018-ONWARDS) JULY 2021... -
Page 8: Instructions For Installation
Lift the rear of the vehicle till there is working space of approximately 15 cm between bump stop and rear axle. 8 | INSTALLATION MANUAL | AUXILIARY AIR SUSPENSION | MERCEDES BENZ SPRINTER 500 L.SPR.18D.C.M (AND 4X4) (2018-ONWARDS) JULY 2021... -
Page 9: Bump Stop Removal And Fitting Of Upper And Lower Bracket
Tighten the sensor bracket and check the height of the headlights again. 9 | INSTALLATION MANUAL | AUXILIARY AIR SUSPENSION | MERCEDES BENZ SPRINTER 500 L.SPR.18D.C.M (AND 4X4) (2018-ONWARDS) JULY 2021... -
Page 10: Fitting Of Inflator Console
1.9 litre or 0.5 gallon at pressure EXT RA A special dashboard panel is available for OPTION 1, OPTION 2 and OPTION 3 10 | INSTALLATION MANUAL | AUXILIARY AIR SUSPENSION | MERCEDES BENZ SPRINTER 500 L.SPR.18D.C.M (AND 4X4) (2018-ONWARDS) JULY 2021... - Page 11 The photograph below shows all of the parts of Comfort Package ‘OPTION 2’ and ‘OPTION 3’. O P TI ON. 2 O PTI ON.3 11 | INSTALLATION MANUAL | AUXILIARY AIR SUSPENSION | MERCEDES BENZ SPRINTER 500 L.SPR.18D.C.M (AND 4X4) (2018-ONWARDS) JULY 2021...
-
Page 12: Tube Connection And Disconnection, Cutting And Routing
Do not use electrician’s side cutters. A dedicated tubing cutter Electrician’s Side Cutters RECOMMENDED NOT RECOMMENDED 12 | INSTALLATION MANUAL | AUXILIARY AIR SUSPENSION | MERCEDES BENZ SPRINTER 500 L.SPR.18D.C.M (AND 4X4) (2018-ONWARDS) JULY 2021... -
Page 13: Bellow Inflation
0.5 bar (7 psi) should be maintained at all times in order to avoid possible compression damage to the springs. 13 | INSTALLATION MANUAL | AUXILIARY AIR SUSPENSION | MERCEDES BENZ SPRINTER 500 L.SPR.18D.C.M (AND 4X4) (2018-ONWARDS) JULY 2021... -
Page 14: Spring Alignment
Check before and after the winter period the wax coating. Re-wax when necessarily 14 | INSTALLATION MANUAL | AUXILIARY AIR SUSPENSION | MERCEDES BENZ SPRINTER 500 L.SPR.18D.C.M (AND 4X4) (2018-ONWARDS) JULY 2021... -
Page 15: Check List
A wait of 24 hours is recommended in order to ensure that the vehicle has maintained its stance and that there are no air leaks present. 15 | INSTALLATION MANUAL | AUXILIARY AIR SUSPENSION | MERCEDES BENZ SPRINTER 500 L.SPR.18D.C.M (AND 4X4) (2018-ONWARDS) JULY 2021... -
Page 16: Instructions For Installation
6 INSTALLATION PICTURES 16 | INSTALLATION MANUAL | AUXILIARY AIR SUSPENSION | MERCEDES BENZ SPRINTER 500 L.SPR.18D.C.M (AND 4X4) (2018-ONWARDS) JULY 2021... - Page 17 17 | INSTALLATION MANUAL | AUXILIARY AIR SUSPENSION | MERCEDES BENZ SPRINTER 500 L.SPR.18D.C.M (AND 4X4) (2018-ONWARDS) JULY 2021...
- Page 18 CAUTION! - Before fully tightening the bolts that secure the air spring to the upper and lower brackets, set the vehicle at ride height (spring height approximately 13..14 cm) and ensure that the springs are correctly aligned. 18 | INSTALLATION MANUAL | AUXILIARY AIR SUSPENSION | MERCEDES BENZ SPRINTER 500 L.SPR.18D.C.M (AND 4X4) (2018-ONWARDS) JULY 2021...
-
Page 19: Special Model And 4X4
Now you can start at page 7 of this manual Be aware 4x4 uses 170/3, these are 3 steps air bellows 19 | INSTALLATION MANUAL | AUXILIARY AIR SUSPENSION | MERCEDES BENZ SPRINTER 500 L.SPR.18D.C.M (AND 4X4) (2018-ONWARDS) JULY 2021... -
Page 20: Epilogue
For general enquiries please contact one of our dealers. You can find them on our website. W W W.DS CSYST EMS.NL 20 | INSTALLATION MANUAL | AUXILIARY AIR SUSPENSION | MERCEDES BENZ SPRINTER 500 L.SPR.18D.C.M (AND 4X4) (2018-ONWARDS) JULY 2021... - Page 21 21 | INSTALLATION MANUAL | AUXILIARY AIR SUSPENSION | MERCEDES BENZ SPRINTER 500 L.SPR.18D.C.M (AND 4X4) (2018-ONWARDS) JULY 2021...
