- Page 1 CEGONIA 8W 20W 30W Installation Manual SOLTECH Designs and Manufactures Advanced, Solar-Powered LED Technology.
- Page 2 CEGONIA 8W CEGONIA 20W CEGONIA 30W...
-
Page 3: Table Of Contents
Contents Introduction Luminous Distribution Battery Notes Installation and Wiring Compliance Mounting Accessories Installation Panel Angle 01 2 Remote Control Guide 0 1 4... -
Page 4: Introduction
01 Introduction Thank you for purchasing CEGONIA Urban Lighting Products. Please save these instructions. Read all of the instructions carefully Introduction before attempting to carry out any installation or wiring. Do not open or CEGONIA combine stylish design with hight efficiency. You can adjust both attempt to repair the product on your own, as it many cause serious the tilt angle and the azimuth to make sure the panel is in the optimal damage and would void the product warranty. - Page 5 CEGONIA 8W 16.8 inches 5.0 inches SOLAR PANEL: 3.9 Lbs SOLAR LAMP: 5.9 Lbs 13.8 inches BATTERY ASSEMBLY: 6.1 Lbs 6.0 inches 1.0 inches 7.5 inches 22.5 inches CEGONIA 20W 24.0 inches 11.0 inches SOLAR PANEL: 8.2 Lbs SOLAR LAMP: 12.1 Lbs 20.1 inches...
-
Page 6: Luminous Distribution
02 Luminous Distribution CEGONIA 8W Type III CEGONIA 20W Type III CEGONIA 30W Type III... -
Page 7: Battery Notes
03 Battery Notes 1. The LiFePO -battery-powered CEGONIA lights are visibly brighter Battery Status is indicated by the red/green indicator on the lighting than other outdoor solar lights, and their performance overall is fixture as follows: more reliable. - Red indicator (Charging) >... -
Page 8: Installation And Wiring Compliance
Electrical Codes. foundation are solid enough to withstand the lighting fixture(s). 2. The CEGONIA 8W, 20W and 30W models are intended for outdoor 5. Before installation, please ensure that the battery is fully charged. Install use only and should not be installed in an unventilated area, and shall during sunny days if possible. -
Page 9: Mounting Accessories
05 Mounting Accessories A. TRUNNION—Wall Mount 4.0 inches 6.8 inches 0.5 inches 0.5 inches 0.2 inches 5.1 inches A-a. STLSTE-08-WM (for CEGONIA 8W) A-b. STLSTE-20/30-WM (for CEGONIA 20W/30W) B. TRUNNION—Round 0.5 inches 0.5 inches 5.1 inches 5.1 inches Pole Size Pole Size 2.4 inches... - Page 10 06 Installation CEGONIA 8W Connect Connect ±45° 180° Component Kit B Component Kit A Connect Connect Loose screws of component kit B to adjust the angle of solar panel. ±45° 180° Loose screws of component kit A to rotate solar panel.
- Page 11 CEGONIA 20W 30W Connect Connect ±45° 270° Component Kit B Component Kit A Connect Loose screws of component kit B to adjust Connect the angle of solar panel. ±45° Loose screws of component kit A to rotate solar panel. 270° Connect Connect ±45°...
- Page 12 70° N 69° N 68° N 67° N 66° N 65° N 64° N 63° N 62° N 60° Alaska 61° N 60° N 49° N 48° N Washington 47° N 46° N Montana 45° N North Dakota Oregon 44° N Minne Idaho 43°...
-
Page 13: Panel Angle 01
07 Panel Angle The Solar charge in a battery pack won’t last forever, the off–grid system relies on stored daylight for autonomy. Angling your solar panels properly can boost the power intake of your lights. You want to angle your solar panels at a tilt equal to the area’s latitude. You can increase the tilt 15°... -
Page 14: 8 Remote Control Guide 0 1
08 Remote Control Guide 1. On/Off 2. Connect/Test 3. 40%~100% Motion 4. 20%~80% Motion Sensor Mode Sensor Mode (Default) 5. Night Owl Mode 6. Early Bird Mode 7. 100% Constant Mode 10. Timer Mode Disabled 8. 70% Constant Mode 9. 40% Constant Mode 12. - Page 15 5. Night Owl Mode 3. 40%~100% Motion Sensor Mode Changes as natural light decreases/increases (turns on at dusk); 70% Constant 40% brightness (turns on at dusk, turns off at dawn); brightness for 0.5 hour, 100% brightness for 3.5 hours, 70% brightness 100% brightness turns on for 2 minutes when motion is detected.
- Page 16 08 Remote Control Guide 7. 100% Constant Mode 8. 70% Constant Mode 100% brightness from dusk to dawn. 70% brightness from dusk to dawn. 9. 40% Constant Mode 40% brightness from dusk to dawn. 10. Timer Mode Disabled Press this button to turn off Timer Mode; settings revert back to before Timer Mode was last activated.
- Page 17 11. Timer Mode 4 Hours 12. Time Mode 8 Hours This is an additional mode which can work with any other modes. This is an additional mode which can work with any other modes. For example: press this button at any time after you turn on 70% For example: press this button at any time after you turn on 70% Con- Constant Mode.
- Page 18 CEGONIA products are covered by a 5 year limited warranty. SOLTECH urban light warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 5 years from date of purchase. To obtain warranty service please contact your local distributor or sales rep for further instruction.
- Page 20 SOLTECH Designs and Manufactures Advanced, Solar-Powered LED Technology.
