AML Oceanographic AML-3 LGR Quick Start Manual page 2

Connect With Sailfish¹
1. Install Sailfish on a Windows PC from
either:
- USB drive
- AMLoceanographic.com/software
You may be prompted to select
firewall settings during installation.
Ensure both boxes are selected before
continuing.
2. Ensure WiFi is enabled on your PC.
Note that connecting Sailfish to your
AML instrument will disconnect an
existing WiFi connection unless multiple
adapters are used.
3. Turn on instrument and start Sailfish.
4. If you have multiple WiFi adapters (such
as internal WiFi adapter and a USB Wifi
dongle), select the device you want to
use to connect with your AML
Instrument. Click Refresh.
5. Select the tile representing your AML
instrument and click Connect.
6. Sailfish will connect to the instrument
and the tile will display device
information.
Contact service@AMLoceanographic.com if you
have any difficulty locating or installing Sailfish.
For more info please visit AMLoceanographic.com or call +1 250 656 0771
LED Indicator Legend
Ready, GPS Locked
Ready, GPS Acquiring
Logging
Ready, Battery Low, GPS Locked
Ready, Battery Low, GPS Acquiring
Battery Low, Logging
Charging
Powering On/Off
Off & Fully Charged
Error
Take a Profile
1. Turn the instrument on. Wait for the LED
indicator to display Ready
water.
2. The instrument will detect 'in-water' and
will indicate Logging. Wait a few minutes
to allow the instrument to thermalize.
3. Lower the instrument to the required
depth, then retrieve. Reconnect with
Sailfish to download logged data.
4. Navigate to the Data Manager tab
to view and export the profile.
5. Turn the instrument off, rinse with fresh
water, then dry. Recharge if instrument
indicates Battery Low.
¹WiFi on 500 m only. Connect via USB for 6000 m.
²GPS on 500m only
³The instrument will still log data without a GPS lock.
²
³
²
³
. Immerse in
³
