EW-7811Un V2
User Manual
08-2022 / V1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EW-7811Un V2 and is the answer not in the manual?

Questions and answers

Thomas Kelly
June 22, 2025

what is the power draw of the EW-7811Un V2

0

Related Manuals for Edimax EW-7811Un V2

Summary of Contents for Edimax EW-7811Un V2

  • Page 1 EW-7811Un V2 User Manual 08-2022 / V1.0...

  • Page 2: Table Of Contents

    Contents Product Information ........1 I-1. Package Contents ..........1 I-2. Hardware Overview ..........1 I-3. LED Status ............1 I-4. Supported System ..........1 Windows Plug-and-Play Installation ..... 2 II-2. Plug-and-Play ............2 II-3. Select & Connect the Wi-Fi Network ....3 III.
  • Page 3 VI. Frequently Asked Question (FAQ) ....17 VII. More Information ........17 VIII. Safety Instructions ........18 IX. Simplified EU Declaration of Conformity ..18...

  • Page 4: Product Information

    LED Status Description Fast Flash Connected Slow Flash Not Connected No wireless activity I-4. Supported System Windows 7 / 8 .x / 10 / 11 macOS 10.9 ~ 10.15 Linux * Additional version information may be announced on the EDIMAX website.

  • Page 5: Windows Plug-And-Play Installation

    II. Windows Plug-and-Play Installation Insert Plug-and-Play Connect II-1. Insert the USB Adapter 1. Insert the USB adapter into the USB port and then switch on your computer. Never use force to insert the USB adapter. II-2. Plug-and-Play 1. The Network icon will be displayed on the bottom-right corner of the Windows taskbar if the Plug-and-Play function is supported.

  • Page 6: Ii-3. Select & Connect The Wi-Fi Network

    II-3. Select & Connect the Wi-Fi Network Select your Wi-Fi Network (SSID), click “Connect” and enter the password if it is required. 1. For Windows 11 users, click the Network icon and then click the right-arrow icon to show the existing Wi-Fi Network (SSID) and select the one you want to connect.
  • Page 7 2. For Windows 10 users, click the Network icon to show the ssexisting Wi-Fi Network (SSID) and select the one you want to connect. 3. Enter the password if it is required. 4. Establish the Wi-Fi connection and you can access the Internet when you see the Wi-Fi icon on the bottom-right corner of the Windows taskbar.

  • Page 8: Windows Driver Installation

    Never use force to insert the USB adapter. III-2. Download & Install the Driver 1. You can find the driver from the Edimax website. https://www.edimax.com/download If your computer can not access the Internet directly, please use an Internet-Enabled device instead.
  • Page 9 3. Click on the model number. Ensure the model number corresponds with your USB adapter. 4. Scroll down the web page and select the right OS version. Move the cursor to the “Download icon” and save the driver on the computer desktop or a location you prefer.
  • Page 10 6. Once the installation process starts, click “Next” to continue. 7. When the installation is completed, you will be asked to select whether you wish to restart your computer now or later. Select “Yes” and click “Finish” to continue. 8. Please make sure your computer has been restarted before you go to next step.

  • Page 11: Iii-3. Connect To A Wi-Fi Network

    III-3. Connect to a Wi-Fi Network 1. After you restart your computer, the Network icon will be displayed on the bottom-right corner of the Windows taskbar. (Refer to VI. FAQ->Q2 ) Notice that the Network icon might be different depending on your Operating System version.
  • Page 12 4. Enter the password if it is required. 5. Establish the Wi-Fi connection and you can access the Internet when you see the Wi-Fi icon on the bottom-right corner of the Windows taskbar.

  • Page 13: Macos Driver Installation

    Never use force to insert the USB adapter. IV-2. Download & Install the Driver 1. You can find the driver from the Edimax website. https://www.edimax.com/download If your MAC can not access the Internet directly, please use an Internet-Enabled device instead.
  • Page 14 3. Click on the model number. Ensure the model number corresponds with the USB adapter. 4. Scroll down the web page and select the right OS version. Move the cursor to the “Download icon” and save the driver on the computer desktop or a location you prefer.
  • Page 15 6. Move the cursor to the file you downloaded and double click to extract it. Copy the driver to the USB adapter first if you downloaded the driver on another Internet-Enabled device then insert the USB flash drive to the computer you will use the Wi-Fi USB adapter. 7.
  • Page 16 10. The screen displays important information, please read it carefully. Click “Continue” when you are ready. 11. To read the software license click “Read License” and then click “Agree” to confirm you agree to the terms. You must agree to the terms to continue installing the software.
  • Page 17 13. Click “Continue Installation” to install the driver. 14. Enter system administrator’s “Username” and “Password” and click and click “Install Software”. 15. The installation will take you a few minutes, once the installation is completed, click “Restart” to reboot your computer.

  • Page 18: Iv-3. Connect To A Wi-Fi Network

    IV-3. Connect to a Wi-Fi Network 1. After you restart the computer, you can see Wi-Fi USB adapter icon the top-right taskbar. Click the icon and then click “Turn USB-WiFi On” to activate the adapter. 2. After you turn on the USB WiFi, click the Wi-Fi USB adapter icon select “Join Other Network”.

  • Page 19: Advanced Feature

    V. Advanced Feature WPS (Wi-Fi Protected Setup) is a simple, alternative way to establish connections between WPS compatible devices when using the Wi-Fi Adapter on a Windows computer. When WPS is activated in the correct manner for two compatible devices, they will automatically connect to each other without a password required.
  • Page 20 “On”. Then the Network icon will be displayed on the Windows Taskbar. VII. More Information For more information, please visit our website with the following URL or scan the QR code: https://www.edimax.com/download Please search the model number to enter the referred page.
  • Page 21 IX. Simplified EU Declaration of Conformity Hereby, Edimax Technology declares that the radio equipment type, Wi-Fi USB Adapter, is in compliance with Directive 2014/53/EU, 2014/35/EU. The full text of the EU declaration of conformity is available at the following internet address: https://www.edimax.com/download/doc...
  • Page 22 COPYRIGHT Copyright  Edimax Technology Co., Ltd. all rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission from Edimax Technology Co., Ltd.
  • Page 23 Max. Transmit Power (dBm) 2412-2472 15.03 A simplified DoC shall be provided as follows: Article 10(9) Hereby, Edimax Technology Co., Ltd. declares that the radio equipment type N150 Wi-Fi Nano USB Adapter is in compliance with Directive 2014/53/EU The full text of the EU declaration of conformity is available at the following internet address: http://www.edimax.com/edimax/global/...
  • Page 24 The ETSI version of this device is intended for home and office use in Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Turkey, and United Kingdom. The ETSI version of this device is also authorized for use in EFTA member states: Iceland, Liechtenstein, Norway, and Switzerland.
  • Page 25 Canada Statement This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference; and (2) This device must accept any interference, including interference that may cause undesired operation of the device.
  • Page 26 EU Declaration of Conformity English: This equipment is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU, 2014/35/EU. Français: Cet équipement est conforme aux exigences essentielles et autres dispositions de la directive 2014/53/EU, 2014/35/EU. Čeština: Toto zařízení je v souladu se základními požadavky a ostatními příslušnými ustanoveními směrnic 2014/53/EU, 2014/35/EU.
  • Page 27 Declaration of Conformity We, Edimax Technology Co., Ltd., declare under our sole responsibility, that the equipment described below complies with the requirements of the European Radio Equipment directives. Equipment: N150 Wi-Fi Nano USB Adapter Model No.: EW-7811Un V2 The following European standards for essential requirements have been followed:...
  • Page 28 Declaration of Conformity We, Edimax Technology Co., Ltd., declare under our sole responsibility, that the equipment described below complies with the requirements of the United Kingdom Radio Equipment directives. Equipment: N150 Wi-Fi Nano USB Adapter Model No.: EW-7811Un V2 The following European standards for essential requirements have been followed: Radio Equipment Regulations 2017 (S.I.
