PSTVS01 Installation Manual
Product Features
Model: PSTVS01
Product Weight: 2.65kg
TV Size Support: 37-70"
Maximum Load: 100lbs
Hardware List
Important: We are not responsible for any personal injury or product damage
due to mishandling, incorrect mounting, incorrect assembly or incorrect use of
this product.
Caution:
This TV Stand mount is intended for use with television that
does not exceed the maximum weight capacity designated. Using this mount with
products heavier than the maximum weight indicated may result in instability
causing possible injury.
Screw spare parts list
Description
No.
1
2
3
4
5
6
A
B
C
Specifications Model
Left arm
Left Connecting arm
Left Product base
Right arm
Right Connecting arm
Right Product base
M8x16mm Hexagonal screw
Ф8 washer
M8 Nut
D
E
F
G
H
I
Instruction of installation operation
1
Qty.
x1
Left base mount
x1
x1
x1
x1
A
x1
x8
x8
x8
M4X20mm Cross round screw
M6x20mm Cross round screw
M8x45mm Cross round screw
L5 plastic spacer
L10 plastic spacer
washer
Right base installation
B C
x4
x4
x4
x8
x8
x4
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Perlesmith PSTVS01
Summary of Contents for Perlesmith PSTVS01
- Page 1 PSTVS01 Installation Manual M4X20mm Cross round screw Product Features M6x20mm Cross round screw Model: PSTVS01 Product Weight: 2.65kg TV Size Support: 37-70" M8x45mm Cross round screw Maximum Load: 100lbs Hardware List L5 plastic spacer Important: We are not responsible for any personal injury or product damage...
