Summary of Contents for Hygiena EnSURE Touch
- Page 1 Manual...
-
Page 2: Chapter 1 | Quick Test
This instructional manual is intended to supplement various knowledge base articles, videos, and frequently asked questions found on www.help.hygiena.com. It’s a step-by-step guide to setting up your EnSURE Touch and shows you how to manage users, locations, plans, and results. Chapter 1 | Quick Test To get started, touch the Quick Test button from the Home screen. - Page 3 Retest app. When you perform a retest, the new test result is tied to the original test so that you can easily prove that corrective actions took place and that they were effective. Open the Retest app from the home screen. help.hygiena.com...
- Page 4 It will show you information such as the date, time, plan, and location of the failed test result. When you’re ready to retest, touch the Retest button. help.hygiena.com...
-
Page 5: Chapter 2 | Locations
To create, remove, or modify locations start at the home screen and touch the Locations icon. ➢ Adding Locations EnSURE Touch can hold thousands of locations. Follow the steps below to add a new one. Step One Touch the add (+) icon to create a new location. -
Page 6: Deleting A Location
Ch. 2 ➢ Deleting a Location Note : Deleting a location from your EnSURE Touch does not remove results associated with that location or any other location. Step One Touch the pencil icon to modify an existing location. Step Two... -
Page 7: Modifying A Location
Touch the pencil icon (as shown at in the image) to modify the location. Step Three You will be able to change the location’s name, device type and RLU limits. You’ll also be able to add or change any special instructions. help.hygiena.com... -
Page 8: Chapter 3 | Plans
To create, remove, or modify plans, start at the home screen and touch the Plans button. ➢ Adding a Plan EnSURE Touch can hold thousands of plans. Follow the steps below to add a new one. Step One Touch the add (+) icon... - Page 9 When it is time to run a scheduled Plan, you’ll see a red notification icon appear above the orange Plans icon on the home screen. help.hygiena.com...
- Page 10 Ch. 3 ➢ Deleting a Plan Note : Deleting a plan from your EnSURE Touch does not remove results associated with that plan or any other plan. Step One Touch the pencil icon (as shown at in the image) to modify an existing plan.
- Page 11 Touch the pencil icon (as shown at in the image) to begin modifying the plan. Step Three You will be able to change the plan name and plan type. You will also be able to add or modify a plan schedule. help.hygiena.com...
-
Page 12: Chapter 4 | Users
To create, remove or modify any users on the EnSURE Touch start at the Home screen and touch the Users icon. ➢ Creating a New User EnSURE Touch can hold hundreds of users. Follow the steps below to add a new one. Step One Touch on the plus (+) icon (as shown at in the image). -
Page 13: Deleting A User
Touch the pencil icon (as shown at in the image) to modify an existing user. Step Two Select the red remove icon (as shown at in the image)next to the name of the user you would like to remove from your device. help.hygiena.com... -
Page 14: Modifying A User
Select OK to continue and delete the user. ➢ Modifying a User Step One Touch the pencil icon (as shown at in the image) to modify an existing user. Step Two Select the pencil icon (as shown at in the image) to modify the user. help.hygiena.com... - Page 15 From here you can modify their username, change their role, and update their PIN. When you add a user on EnSURE Touch, it does not add a user to your SureTrend Cloud account. These are two different types of users. To add someone as a user on your SureTrend Cloud account, follow the steps here https://help.hygiena.com/...
-
Page 16: Chapter 5 | Results & Reports
Choose from a variety of pre-built reports to display instant trend analysis and reporting. In this section you will learn how to use the reporting and analysis features on the EnSURE Touch, and how to view and manage results on the meter. Note : You can find advanced reporting features and do more with results using SureTrend Cloud. -
Page 17: Trend Analysis
The Results screen will display all the results currently on your unit. You are able to filter by date, plan, and location. The table area below the filters will display a total count of all Pass, Caution, and Fail results based on the filters selected above. help.hygiena.com... -
Page 18: Chapter 6 | Customization
You are also able to enable or disable tests based on which Hygiena products you use in your facility. The following few pages will show you how to customize your EnSURE Touch and break down what each customization option means. -
Page 19: Product Selections
Customization. Step Two Touch Product Selections (as shown at in the image). To learn about test kits and products offered by Hygiena, visit our website at www.hygiena.com Step Three ATP Testing Enable ATP products you would like to appear in the Device Type drop-down field when performing testing. - Page 20 ➢ Simulation Customizations are optional. These settings may be changed any time without risk to your data. Step One Touch the Settings button from the Home screen. Next, touch Customization. Step Two Touch Simulation (as shown at in the image). help.hygiena.com...
- Page 21 Step Three Turning on Simulation Mode converts the RLU results from ATP testing on your EnSURE Touch so that they simulate the results you’d get if you were using another system. You can this feature on or off and select from a drop-down list of instruments you’d like to simulate.
- Page 22 Step Three Allow Multiple Instances This feature allows your EnSURE Touch to run multiple instances of a plan at the same time. This can be useful in situations where you have multiple areas of your facility that are the same, such as patient rooms in hospitals.
-
Page 23: Location Settings
For example you may have a large number of locations and want to group them based on the building they are in, or floor they are on, or type of surface they test. help.hygiena.com... -
Page 24: Test Settings
➢ Test Settings Customizations are optional. These settings may be changed any time without risk to your data. Step One Touch the Settings button from the Home screen. Next, touch Customization. Step Two Touch Tests (as shown at in the image). help.hygiena.com... - Page 25 #, or product. Personnel are not the same as Users! Users refer to the person who is logged into EnSURE Touch and performing the testing. Users can be Operators or Administrators. See Chapter 1 for more information.
-
Page 26: Chapter 7 | Settings
MAC address is a unique number used to identify a device such as a laptop, phone or EnSURE Touch. DHCP servers use the MAC address to identify devices and give fixed IP addresses. If your network environment requires your providing a MAC address, follow these instructions to find it. - Page 27 Ch. 7 ➢ Syncing the EnSURE Touch Note: It is always important to keep your EnSURE Touch connected to Wi-Fi. It ensures the device can sync results to SureTrend Cloud, minimizing the risks of data loss and enables you to keep your device up to date. We recommend you check for updates at least once a month.
- Page 28 (e.g. hotels). We do not currently support this method of connecting due to security risks to EnSURE Touch. You can manually configure RADIOUS authentication on your EnSURE Touch. Your results may vary as we have not tested with every RADIOUS solution available.
- Page 29 Ch. 7 ➢ From the Settings Button on the Home Screen Step One From the Home screen select the Settings icon. Step Two Select the Wi-Fi menu option. help.hygiena.com...
- Page 30 ➢ From the Notification area Step One Swipe down from the top of the screen. This can be done from almost any screen on EnSURE Touch. Step Two Press the Menu Option button in the upper right corner of the screen.
- Page 31 Turn on Wi-Fi if it is off. Select the wireless network to connect to. If you cannot find the wireless network to connect to in the list touch the Add (+) icon to manually add it. For more information, visit help.hygiena.com help.hygiena.com PRD_MAN_10_REVA_EnSURE-Touch...
