GENESIS COUPE(BK) >2010 > G 2.0 DOHC > Automatic Transmission System > General
Information > Specifications
Specifications
Transmission type
Engine type
Gear ratio
Final gear ratio
Lubricants
Items
Transmission gear oil
1st
2nd
3rd
4th
5th
Reverse
A5SR1
Gasoline 2.0 TCI
3.827
2.368
1.519
1.000
0.834
2.613
3.909
Recommnend lubricant
APOLLOIL
ATF RED-1K
