Table of Contents

Advertisement

Quick Links

RG9O-EU39B
(영어 | 미국)
영
어
미
국
Genesis G70
OWneR's MAnUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G70 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Genesis G70

Summary of Contents for Genesis G70

  • Page 1 RG9O-EU39B (영어 | 미국) 영 어 미 국 Genesis G70 OWneR’s MAnUAL...
  • Page 2 This Owner’s Manual should be considered a part of the car and remain with it when it is sold for the use of the next owner. RESPONSIBILITY FOR MAINTENANCE The maintenance requirements for your new Genesis Branded OWNER’S INFORMATION Vehicle are found in Section 9. As the owner, it is your responsibility...
  • Page 3 This manual applies to all Genesis Branded Vehicle models and includes descriptions and explanations of optional as well as standard equipment.
  • Page 4 CAUTION: MODIFICATIONS TO YOUR GENESIS BRANDED VEHICLE Your Genesis Branded Vehicle should not be modified in any way. Such modifications may adversely affect the performance, safety or durability of your Genesis Branded Vehicle and may, in addition, violate conditions of the limited warranties covering the vehicle.
  • Page 5 SAFETY AND VEHICLE DAMAGE WARNING This manual includes information titled as DANGER, WARNING, CAUTION and NOTICE. These titles indicate the following: DANGER DANGER indicates a hazardous situation which, if not avoided, will result in death or serious injury. WARNING WARNING indicates a hazardous situation which, if not avoided, could result in death or serious injury.
  • Page 6 Introduction GENESIS BRANDED VEHICLE OWNER PRIVACY POLICY Your Genesis Branded Vehicle may be equipped with technologies and services that use information collected, generated, recorded or stored by the vehicle. Genesis Branded Vehicle has created a Vehicle Owner Privacy Policy to explain how these technologies and services collect use and share this information.
  • Page 7 Table of contents Introduction Vehicle Information, Consumer Information and Reporting Safety Defects Safety system Instrument cluster Convenience features Driving your vehicle Driver assistance system Emergency situations Maintenance Index...

  • Page 9: Table Of Contents

    1. Introduction Introduction ........................1-2 Genesis Customer Care....................1-3 Guide to Genesis Parts .....................1-4 How to use this manual....................1-7 Safety messages......................1-8 Fuel requirements ......................1-9 Vehicle modifications..................... 1-12 Vehicle break-in process....................1-13 Vehicle data collection and event data recorders ............1-14...

  • Page 10: Introduction

    Your Owner's Manual will introduce you to the features and operation of your new Genesis Branded Vehicle. To become familiar with your new Genesis Branded Vehicle, so that you can fully enjoy it, read this Owner's Manual carefully before driving your new vehicle.

  • Page 11: Genesis Customer Care

    Severe engine and transmission damage may result from the use of poor quality fuels and lubricants that do not meet Genesis Branded Vehicle specifications. You must always use high quality fuels and lubricants that meet the specifications listed in the "Recommended Lubricants And Capacities"...

  • Page 12: Guide To Genesis Parts

    Introduction GUIDE TO GENESIS PARTS 1. What are Genesis Parts? Genesis Parts are the same parts used by HYUNDAI Motor Company to manufacture vehicles. They are designed and tested for the optimum safety, performance, and reliability to our customers. Type A...
  • Page 13 Genesis Branded New Vehicle Limited Warranty or any other Genesis Branded Vehicle warranty. In addition, any damage to or failure of Genesis Part caused by the installation or failure of an imitation, counterfeit or used salvage part is not covered by any Genesis Branded Vehicle Warranty.
  • Page 14 3. How can you tell if you are purchasing Genesis Parts? Look for the Genesis Parts Logo on the package. Genesis Parts exported to the U.S. are packaged with labels written only in English. Genesis Parts are only sold through an authorized retailer of Genesis Branded products.

  • Page 15: How To Use This Manual

    HOW TO USE THIS MANUAL We want to help you get the greatest possible driving pleasure from your vehicle. Your Owner's Manual can assist you in many ways. We strongly recommend that you read the entire manual. In order to minimize the chance of death or injury, you must read the WARNING and CAUTION sections in the manual.

  • Page 16: Safety Messages

    Introduction SAFETY MESSAGES Your safety, and the safety of others are very important. This Owner's Manual provides you with many safety precautions and operating procedures. This information alerts you to potential hazards that may hurt you or others, and may damage your vehicle. Safety messages found on vehicle labels and in this manual describe these hazards and what to do to avoid or reduce the risks.

  • Page 17: Fuel Requirements

    To prevent damage to the engine and engine components, never add any fuel system cleaning agents to the fuel tank other than what has been specified. Consult an authorized retailer of Genesis Branded products for additional information. WARNING • Do not "top off" after the nozzle automatically shuts off when refueling.
  • Page 18 Flexible Fuel Vehicles. "E85" is not compatible with your vehicle. Use of "E85" may result in poor engine performance and damage to your vehicle's engine and fuel system. Genesis Branded Vehicle recommends that customers do not use fuel with an ethanol content exceeding 15 percent.
  • Page 19 Gasoline containing MMT Some gasoline contains harmful manganese-based fuel additives such as MMT (Methylcyclopentadienyl Manganese Tricarbonyl). Genesis Branded Vehicle does not recommend the use of gasoline containing MMT. This type of fuel can reduce vehicle performance and affect your emission control system.

  • Page 20: Vehicle Modifications

    NOTICE Some warning sounds (including welcome/good-bye sound, etc.) are generated from the interior speakers or amplifiers. If necessary, we recommend you to purchase Genesis Part to replace an interior speaker or amplifier. Any unauthorized product may cause a malfunction of the interior speakers or amplifiers.

  • Page 21: Vehicle Break-In Process

    VEHICLE BREAK-IN PROCESS • Do not race the engine. • While driving, avoid sudden acceleration. • Do not maintain a single speed for long periods of time, either fast or slow. Varying engine speed is needed to properly break-in the engine. •...

  • Page 22: Vehicle Data Collection And Event Data Recorders

    Introduction VEHICLE DATA COLLECTION AND EVENT DATA RECORDERS This vehicle is equipped with an event data recorder (EDR). The main purpose of an EDR is to record, in certain crash or near crash-like situations, such as an air bag deployment or hitting a road obstacle, data that will assist in understanding how a vehicle's systems performed.
  • Page 23 2. Vehicle Information, Consumer Information and Reporting Safety Defects Exterior Overview (Front View)..................2-2 Exterior Overview (Rear View)..................2-3 Interior Overview ......................2-4 Center Console Overview ....................2-5 Steering Wheel Control Overview .................. 2-7 Engine Compartment Overview..................2-8 Dimensions ........................2-10 Engine..........................

  • Page 24: Exterior Overview (Front View)

    Vehicle Information, Consumer Information and Reporting Safety Defects Exterior Overview (Front View) OIK013001L The actual shape may differ from the illustration. (1) Hood .........................5-54 (2) Headlight......................5-69,9-67 (3) Side repeater light ....................9-68 (4) Tires and wheels ......................9-38 (5) Side view mirror.......................5-43 (6) Sunroof ........................5-51 (7) Front windshield wiper blades ..............

  • Page 25: Exterior Overview (Rear View)

    Exterior Overview (Rear View) OIK013002L The actual shape may differ from the illustration. (1) Door ...........................5-21 (2) Fuel filler door......................5-65 (3) Rear combination light................... 9-68 (4) Reverse light ......................9-68 (5) Trunk........................5-55, 5-57 (6) Trunk open button....................5-59 (7) High mounted stop light ..................9-69 (8) Antenna ........................

  • Page 26: Interior Overview

    Vehicle Information, Consumer Information and Reporting Safety Defects Interior Overview OIK013003L The actual shape may differ from the illustration. (1) Inside door handle....................5-23 (2) Integrated memory system ..................5-28 (3) Side view mirror folding button................5-44 (4) Side view mirror control switch................5-43 (5) Central door lock switch ..................

  • Page 27: Center Console Overview

    Center Console Overview OIK013004N The actual shape may differ from the illustration. (1) Instrument cluster ..................... 4-2 (2) Driver's front airbag....................3-40 (3) Engine Start/Stop button..................6-5 (4) Hazard warning flasher button................. 8-2 (5) Infotainment system ....................5-110 (6) Automatic climate control system .................5-82 (7) Heated steering wheel button................
  • Page 28 Vehicle Information, Consumer Information and Reporting Safety Defects (21)Wireless charging system indicator ..............5-105 (22)Wireless charging system pad ................5-105...

  • Page 29: Steering Wheel Control Overview

    Steering Wheel Control Overview OIK013005N The actual shape may differ from the illustration. (1) Lighting control lever ....................5-69 (2) Wiper and washer control lever................5-79 (3) Voice recognition button ..................5-112 (4) Audio Remote control button................. 5-111 (5) Bluetooth® hands-free phone button ..............5-112 (6) Driving Assist buttons .....................

  • Page 30: Engine Compartment Overview

    Vehicle Information, Consumer Information and Reporting Safety Defects Engine Compartment Overview 2.5 T-GDi OIK013027 The actual engine compartment in the vehicle may differ from the illustration. (1) Fuse box ........................9-51 (2) Windshield washer fluid reservoir ................9-29 (3) Air cleaner ....................... 9-30 (4) Radiator cap ......................
  • Page 31 3.3 T-GDi OIK013029 The actual engine compartment in the vehicle may differ from the illustration. (1) Fuse box ........................9-51 (2) Windshield washer fluid reservoir ................9-29 (3) Air cleaner ........................9-30 (4) Radiator cap ......................9-27 (5) Engine coolant reservoir ..................9-25 (6) Engine oil filler cap ....................

  • Page 32: Dimensions

    Vehicle Information, Consumer Information and Reporting Safety Defects Dimensions Items in (mm) Overall length 184.45 (4,685) Overall width 72.83 (1,850) Overall height 55.12 (1,400) Front tread 225/40R19 62.83 (1,596) Rear tread 255/35R19 63.15 (1,604) Wheelbase 111.61 (2,835) Engine Displacement Bore x Stroke in. Engine Firing order No.

  • Page 33: Bulb Wattage

    Bulb Wattage Light bulb Bulb type Wattage Headlight High Turn signal light Front Parking light Side marker Daytime Running light (DRL) Puddle light Tail light Stop light/Turn signal light Reverse light Rear Side marker License plate light High mounted stop light Map lamp Room lamp Vanity mirror lamp...

  • Page 34: Tires And Wheels

    Vehicle Information, Consumer Information and Reporting Safety Defects Tires And Wheels Inflation pressure psi (kPa) Maximum Wheel nut Items Tire size Wheel size Normal load load OR over torque lbf·ft 100 mph (kgf·m, N ·m) Front Rear Front Rear 225/40R19 8.0J X 19 (250) (260)
  • Page 35 NOTICE • Ambient temperature affects tire pressure (about 1 psi (7 kPa) for every 12 °F (7° C) change). If colder temperatures are anticipated, it is permissible to increase cold tire inflation pressure by up to 3 psi (20 kPa) over the specification. If extreme temperature changes are expected, be sure to check and adjust tire pressure accordingly.

  • Page 36: Air Conditioning System

    Weight of volume Classification Refrigerant 20.1±0.9 oz. (570±25 g) R-1234yf Compressor lubricant 3.52±0.35 cu. in. (100±10 cc) Contact an authorized retailer of Genesis Branded products for more details. Vehicle Weight And Luggage Volume 2.5 T-GDi 3.3 T-GDi Items 4,850 4,993 Gross vehicle weight lbs.

  • Page 37: Recommended Lubricants And Capacities

    GS ATF SP-IV-RR Genesis/Hyundai genuine ATF SP-IV-RR or Automatic transmission fluid 9.72 US qt. (9.2 ℓ) other brands meeting the above specification approved by Genesis Customer Care 2.5 T-GDi 9.4 US qt. (8.9 ℓ) Mixture of antifreeze and Engine coolant 3.3 T-GDi 11.1 US qt.
  • Page 38 *5 To maintain the best braking performance and ABS/ESC performance, use genuine brake fluid that conform to specifications. *6 If the front/rear differential is submerged, visit an authorized retailer of Genesis Branded products to immediately replace the differential oil. *7 Be sure to inject oil for exclusive use of LSD when replacing Rear Differential Oil (if equipped with Limited Slip Differential).

  • Page 39: Recommended Sae Viscosity Number

    Recommended SAE viscosity number NOTICE • Always be sure to clean the area around any filler plug, drain plug, or dipstick before checking or draining any lubricant. This is especially important in dusty or sandy areas and when the vehicle is used on unpaved roads. Cleaning the plug and dipstick areas will prevent dirt and grit from entering the engine and other mechanisms that could be damaged.

  • Page 40: Vehicle Identification Number (Vin)

    Vehicle Information, Consumer Information and Reporting Safety Defects Vehicle Identification Vehicle Certification Number (VIN) Label Frame number OIK013021 The vehicle certification label attached on OIK013020 The vehicle identification number (VIN) is the driver's (or front passenger's) side the number used in registering your center pillar gives the vehicle vehicle and in all legal matters pertaining identification number (VIN).

  • Page 41: Tire Specification And Pressure Label

    Tire Specification And Engine Number Pressure Label 2.5 T-GDi OIK013028 OIK013026 3.3 T-GDi The tires supplied on your new vehicle are chosen to provide the best performance for normal driving. The tire label located on the driver's side center pillar gives the tire pressures recommended for your vehicle.

  • Page 42: Air Conditioner Compressor Label

    Vehicle Information, Consumer Information and Reporting Safety Defects Air Conditioner Refrigerant Label Compressor Label if equipped OIK053094N The refrigerant label provides information ORS011025L such as refrigerant type and amount. A compressor label informs you the type (R-1234yf) of compressor your vehicle is equipped with such as model, supplier part number, production number, refrigerant (1) and refrigerant oil (2).

  • Page 43: Open Source Software Notice

    Safety Administration of the U.S. Open source software information Department of Transportation. Your including the source code, copyright retailer of Genesis Branded products will notices and referred license terms may be help answer any questions you may have obtained on the website as you read this information.

  • Page 44: Reporting Safety Defects

    If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Genesis Customer Care. If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
  • Page 45 3. Safety system Important Safety Precautions..................3-2 Always wear your seat belt..................3-2 Restrain all children ..................... 3-2 Airbag hazards......................3-2 Driver distraction ......................3-2 Never drink or take drugs and drive ................3-3 Control your speed ...................... 3-3 Keep your vehicle in safe condition................3-3 Seats ..........................3-4 Safety precautions .......................
  • Page 46 Safety system Important Safety Driver distraction Driver distraction presents a serious and Precautions potentially deadly danger, especially for inexperienced drivers. Safety should be You will find many safety precautions and the primary concern when behind the recommendations throughout this wheel and drivers need to be aware of the section, and throughout this manual.
  • Page 47 Never drink or take drugs and drive Drinking alcohol or taking drugs can reduce your ability to respond to changing conditions and emergencies. Do not drink or take drugs and drive, and do not let your friends drink or take drugs and drive.
  • Page 48 Safety system Seats OIK033001N The actual shape may differ from the illustration. (1) Forward and backward (2) Seat cushion angle/height (3) Cushion extension (4) Seatback angle (5) Lumbar support (6) Seat back bolster (7) Front head restraints (8) Front seat warmer (9) Front air ventilation seat (10)Walk-in switch (passenger's side) (11) Rear seat warmer...
  • Page 49 Infotainment system Information • The information provided may differ depending on which functions are available on your vehicle. • The infotainment system may change after software updates. For more information, refer to the user's manual provided in the infotainment system and the quick reference guide.
  • Page 50 Safety system Front seats WARNING The front seat can be adjusted by using To reduce the risk of serious injury or the control switches located on the death from an inflating airbag: outside of the seat cushion. Before • Adjust the driver's seat as far to the rear driving, adjust the seat to the proper as possible while maintaining your position so that you can easily control the...
  • Page 51 Power seats - Seat adjustments CAUTION The driver's seat can be adjusted by using To prevent injury: the control switches located on the outside of the seat cushion. • Do not adjust your seat while wearing your seat belt. Moving the seat cushion WARNING forward may cause strong pressure on your abdomen.
  • Page 52 Safety system Seat cushion tilt/height adjustment Seat cushion extension adjustment (for driver's seat) if equipped OIK033006 Seat cushion tilt (1) OIK033004 To change the angle of the front part of To move the front part of the cushion the seat cushion: forward or rearward: 1.
  • Page 53 Seat bolster adjustment (for driver's seat) WARNING if equipped Do not adjust the passenger seat when a passenger is seated. Seatback pocket OIK033008 To adjust seat bolster: 1. Push the adjustment lever clockwise, the seatback bolster will be adjusted inward. Push the switch OIK033013 counterclockwise, the seatback bolster The seatback pocket is provided on the...
  • Page 54 Safety system - Never allow passengers to sit on top CAUTION of the folded down seatback while the vehicle is moving. This is not a Do not allow your hands or fingers to get proper seating position and no seat caught in the seat mechanisms while belts are available for use.
  • Page 55 3. Locate the seatbelt toward the 3. Return the rear seat belt to the proper outboard position before folding down position. the seatback to avoid the seatbelt system interfering with the seatback. Armrest OIK033069 OIK033016 4. Pull up the seatback folding lever, then The armrest is located in the center of the fold the seat toward the front of the rear seat.
  • Page 56 Safety system NOTICE To prevent damage, NEVER hit or pull on the head restraints. Front seat head restraints 2C_HeadrestRightPosition • Never adjust the head restraints position of the driver's seat when the vehicle is in motion. • Adjust the head restraints as close to the passenger's head as possible.
  • Page 57 NOTICE OIK033012 To reinstall the head restraint : OIK033124 1. Recline the seatback. If you recline the seatback towards the 2. Put the head restraint poles (2) into the front with the head restraints and seat holes while pressing the release button cushion raised, the head restraint may (1).
  • Page 58 Safety system Seat Warmers Adjusting the height up and down Seat warmers are provided to warm the seats during cold weather. During mild weather or under conditions where the operation of the seat warmer is not needed, keep the seat warmers OFF. WARNING The seat warmers can cause a SERIOUS BURN, even at low temperatures and...
  • Page 59 icon is pressed, the seat warmer is NOTICE controlled manually. To prevent damage to the seat warmers To use this feature, it can be enabled and seats: from the Settings menu in the infotainment system. • Never use a solvent such as paint thinner, benzene, alcohol or gasoline to Select: Setup >...
  • Page 60 If there is no change, have • You can also adjust the rear seat your vehicle inspected by an authorized warmers from the front seats. With the retailer of Genesis Branded products. engine running, select Climate > Rear Warmer in the infotainment system. OIK033056N...
  • Page 61 Front air ventilation seats Information The infotainment system may change after software updates. For more information, refer to the user's manual provided in the infotainment system and the quick reference guide. OIK033018N While the engine is running, touch the air ventilation icon to cool the driver's seat or front passenger's seat on the climate control information screen.
  • Page 62 Safety system Seat Belts • Do not use a seat belt if the webbing or hardware is damaged. This section describes how to use the seat • Do not latch the seat belt into the belts properly. It also describes some of buckles of other seats.
  • Page 63 Seat belt warning light If the seat belt is not fastened, when vehicle speed is above 12 mph (20 km/h), the warning light will blink and warning Driver's seat belt warning chime will sound for certain period of time (warning chime will sound in three Instrument cluster stages).
  • Page 64 Safety system • If the seat belt is unfastened while driving, the seat belt warning operates as follows depending on vehicle speed. - Under 12 mph (20 km/h): The corresponding seat belt warning light illuminates for about 70 seconds. - Over 12 mph (20 km/h): The corresponding seat belt warning light blinks and the warning chime sounds for about 35 seconds.
  • Page 65 To release your seat belt: • Position the lap portion of the seat belt as low as possible across your hips, not Press the release button (1) in the locking on your waist, so that it fits snugly. This buckle. allows your strong pelvic bones to absorb the force of the crash, reducing the chance of internal injuries.
  • Page 66 Safety system Rear center seat belt (3-point rear When the seat belt is fully extended from the retractor to allow the installation of a center seat belt) child restraint system, the seat belt if equipped operation changes to allow the belt to retract, but not to extend (Automatic Locking Retractor Type).
  • Page 67 The Emergency Fastening serviced, repaired or replaced by an Device System may be activated in authorized retailer of Genesis Branded certain crashes where the frontal or side products. collision(s) is severe enough, together • Do not hit the seat belt assemblies.
  • Page 68 If the warning light does not illuminate, stays illuminated or illuminates when the vehicle is being driven, have the pretensioner seat belts and/or SRS control module inspected by an authorized retailer of Genesis Branded products as soon as possible. 3-24...
  • Page 69 Additional seat belt safety Seat belt use and children precautions Infant and small children All 50 states have Child Restraint System Seat belt use during pregnancy laws which require children to travel in The seat belt should always be used approved Child Restraint System devices, during pregnancy.
  • Page 70 Restraint System in the rear seats. Always have the LATCH system inspected by Do not lie down your authorized retailer of Genesis Sitting in a reclined position when the Branded products after an accident. An vehicle is in motion can be dangerous.
  • Page 71 Any damaged parts should be seat. A child riding in the front passenger replaced as soon as possible by an seat can be forcefully struck by an authorized retailer of Genesis Branded inflating airbag resulting in SERIOUS products. INJURY or DEATH.
  • Page 72 "hooks" over a seatback, it may not provide adequate protection in an accident. • After an accident, have an authorized retailer of Genesis Branded products OIK033057 check the Child Restraint System, seat A rearward-facing Child Restraint System...
  • Page 73 and reduce the stress to the fragile neck height or weight limit allowed by your and spinal cord. Child Restraint System's manufacturer. All children under the age of one year Once your child outgrows the must always ride in a rearward-facing forward-facing Child Restraint System, Child Restraint System.
  • Page 74 Safety system WARNING CAUTION If the vehicle head restraint prevents A Child Restraint System in a closed proper installation of a Child Restraint vehicle can become very hot. To prevent System, the head restraint of the burns, check the seating surface and respective seating position shall be buckles before placing your child in the readjusted or entirely removed.
  • Page 75 If left and right outboard rear seating necessary, have your vehicle inspected positions. Their locations are shown in the by an authorized retailer of Genesis illustration. There are no LATCH anchors Branded products. provided for the center rear seating position.
  • Page 76 • Always have the LATCH system anchor. inspected by your authorized retailer of Child restraint hook holders are located Genesis Branded products after an on the rear of the seatbacks. accident. An accident can damage the LATCH system and may not properly secure the Child Restraint System.
  • Page 77 Automatic locking mode 3. Check that the Child Restraint System is securely attached to the seat by Since all passenger seat belts move freely pushing and pulling the seat under normal conditions and only lock forward-and-back and side-to-side. under extreme or emergency conditions (emergency locking mode), you must WARNING manually pull the seat belt all the way out...
  • Page 78 Safety system 2. Fasten the lap/shoulder belt latch into 4. Slowly allow the shoulder portion of the the buckle. Listen for the distinct "click" seat belt to retract and listen for an sound. audible "clicking" or "ratcheting" sound. This indicates that the retractor is in the "Automatic Locking"...
  • Page 79 If your Child Restraint System manufacturer instructs or recommends you to use a tether anchor with the lap/shoulder belt, refer to the "Installing a Child Restraint System (CRS)" section in this chapter. Information When the seat belt is allowed to retract to its fully stowed position, the retractor will automatically switch from the "Automatic Locking"...

  • Page 80: Airbag - Supplemental Restraint System

    Safety system Airbag - Supplemental Restraint System OIK033088 The actual airbags in the vehicle may differ from the illustration. (1) Driver's front airbag (2) Passenger's front airbag (3) Side airbag/rear side airbag (4) Curtain airbag (5) Driver's knee airbag (6) Front center side airbag Your vehicle is equipped with an Advanced Supplemental Airbag System for the driver's and front passenger's seats.
  • Page 81 WARNING AIRBAG SAFETY PRECAUTIONS • ALWAYS use seat belts and Child Restraint Systems - every trip, every time, everyone! Even with airbags, you can be seriously injured or killed in a collision if you are improperly belted or not wearing your seat belt when the airbag inflates. •...

  • Page 82: Srs Components

    Safety system SRS components OIK033089N The SRS consists of the following components: (1) Driver's front airbag module (2) Passenger's front airbag module (3) Front center side airbag module (4) Front/rear side airbag modules (5) Curtain airbag modules (6) Retractor pretensioner (7) Airbag warning light (8) SRS control module (SRSCM)/Rollover sensor (9) Front impact sensors...
  • Page 83 (15)Emergency Fastening Device Information Front Passenger's airbag OFF indicator is located on the overhead console. 3-39...

  • Page 84: Where Are The Airbags

    Safety system Where are the airbags? crash pad below the steering wheel, and the passenger's side front panel pad above the glove box. Driver's and passenger's front The airbag locations are embossed with airbags the letters, "AIRBAG". Driver's front airbag The purpose of the SRS is to provide the vehicle's driver and front passenger with additional supplemental protection that...
  • Page 85 • Hold the steering wheel at the 9 o'clock Front center side airbag (Driver's seat) and 3 o'clock positions, to minimize the risk of injuries to your hands and arms. • Do not allow the front passenger to place their feet or legs on the dashboard.
  • Page 86 • If the seat or seat cover is damaged, The curtain airbags are not designed to have your vehicle serviced by an deploy in all side impact or rollover authorized retailer of Genesis Branded situations. products. 3-42...

  • Page 87: How Does The Airbags System Operate

    If necessary, have the 3 minutes after the engine is turned off. airbag inspected by an authorized • Airbags inflate in the event of certain retailer of Genesis Branded products. frontal or side collisions to help protect the occupants from serious physical injury.
  • Page 88 Safety system • The front airbags completely inflate WARNING and deflate in an instant. It is virtually impossible for you to see the airbags To reduce the risk of serious injury or inflate during an accident. It is much death from an inflating airbag: more likely that you simply see the •...

  • Page 89: What To Expect After An Airbag Inflates

    • Always wash exposed skin areas thoroughly with cold water and mild soap. • Have an authorized retailer of Genesis ODN8039080L Branded products replace the airbag After complete inflation, the airbag immediately after deployment. Airbags immediately starts deflating, enabling the are designed to be used only once.

  • Page 90: Srs Warning Light

    If this is the Have authorized retailer of Genesis case, wash and rinse with cold water Branded products inspect the SRS as immediately and seek medical attention if soon as possible if any of these conditions the symptoms persist.
  • Page 91 Main components of the Occupant wearing the seat belt properly for the Classification System most effective protection by the airbag and the seat belt. • A detection device located within the front passenger seat cushion. The OCS may not function properly if the passenger takes actions which can affect •...
  • Page 92 Safety system Condition and operation in the front passenger Occupant Classification System Indicator/Warning Light Devices Condition Detected by the "PASSENGER SRS Warning Front Passenger Occupant Classification System AIR BAG OFF" Light Airbag Indicator Light Adult Activated Infant or Child Restraint System Deactivated with 12 months old *3*4...
  • Page 93 • NEVER place your feet on the front WARNING passenger seatback. Riding in an improper position or placing weight on the front passenger's seat when it is unoccupied by a passenger adversely affects the OCS. To reduce the risk of serious injury or death: •...
  • Page 94 • When changing or replacing the seat or seat cover, use original items only. The OCS has been developed based on using original Genesis Branded products seats only. Altering or changing the authentic parts may result in system malfunction and increase risk of injury when in collision.
  • Page 95 Proper seated position for OCS NOTICE The "PASSENGER AIR BAG OFF" indicator generally illuminates for about 4 seconds after the Start/Stop button is in the ON or START position. But, if the Start/Stop button is pressed to the ON or START position within 3 minutes after the vehicle is turned OFF, the indicator does not illuminate.

  • Page 96: Why Didn't My Airbag Go Off In A Collision

    • Press the Engine Start/Stop button to the OFF or ACC position and wait for 3 minutes, when the vehicle is being towed to prevent inadvertent airbag deployment. • Have all airbag repairs conducted by an authorized retailer of Genesis Branded products. 3-52...
  • Page 97 OIK033073_8L [A] SRS control module/Rollover sensor [B] Front impact sensor [C] Side impact sensor (Pressure) [D] Side impact sensor (Acceleration): B-pillar [E] Side impact sensor (Acceleration): C-pillar 3-53...
  • Page 98 Safety system Airbag inflation conditions Although the driver's and front passenger's airbags are designed to Front airbags inflate in frontal collisions, they also may inflate in other types of collisions if the front impact sensors detect a sufficient impact. Side and curtain airbags and the front center side airbag are designed to inflate in side impact collisions, but they may inflate in other collisions if the side...
  • Page 99 In an angled collision, the force of impact may direct the occupants in a direction where the airbags would not be able to provide any additional benefit, and thus the sensors may not deploy any airbags. OIK033079 Front airbags are not designed to inflate in rear collisions, because occupants are moved backward by the force of the impact.

  • Page 100: Srs Care

    SRS care • Always have inflated airbags replaced The SRS is virtually maintenance-free and by an authorized retailer of Genesis there are no parts you can safely service Branded products. by yourself. If the SRS airbag warning •...

  • Page 101: Additional Safety Precautions

    Modifications to accommodate disabilities. If you require modification to your vehicle to accommodate a disability, contact the Genesis Customer Care at 844-340-9741. Adding equipment to or modifying your airbag equipped vehicle If you modify your vehicle by changing...
  • Page 103 4. Instrument cluster Instrument Cluster......................4-2 Instrument cluster control...................4-3 Gauges and meters......................4-4 Transmission shift indicator ..................4-8 Warning and indicator lights..................4-8 Cluster display messages..................4-20 Cluster Display (Type A) ....................4-25 Cluster display control....................4-25 View modes........................ 4-25 Option menu ......................4-28 Cluster Display (Type B) ....................4-30 Cluster display control....................4-30 View modes.........................4-31 Trip computer......................4-33...

  • Page 104: Instrument Cluster

    Instrument cluster Instrument Cluster 8-inch OIK043001N 12.3-inch 3D OIK043003N The actual cluster in the vehicle may differ from the illustration. For more information, refer to the "Gauges and meters" section in this chapter. (1) Tachometer (2) Speedometer (3) Fuel gauge (4) Engine coolant temperature gauge (5) Warning and indicator lights (6) Cluster display...

  • Page 105: Instrument Cluster Control

    Instrument cluster control Type A Instrument panel illumination OIK040074L Type B OIK043005 When the vehicle's parking lights or headlights are on, press the illumination control switch to adjust the brightness of the instrument panel illumination. When pressing the illumination control switch, the interior switch illumination intensity is also adjusted.

  • Page 106: Gauges And Meters

    Instrument cluster Gauges and meters Tachometer 8-inch Speedometer 8-inch (MPH, km/h) OIK043475 12.3-inch 3D OJX1049060L 12.3-inch 3D (MPH, km/h) OIK040007 The tachometer indicates the approximate number of engine revolutions per minute (RPM). OIK043073L Use the tachometer to select the correct The speedometer indicates the speed of shift points and to prevent lugging and/or the vehicle and is calibrated in kilometers...
  • Page 107 Engine coolant temperature gauge Information (for 12.3-inch 3D cluster) OIK043009N OIK040080L This gauge indicates the temperature of For 8-inch instrument cluster, you can the engine coolant when the Engine check the engine coolant temperature in Start/Stop button is in the ON position. the Utility view on the cluster.
  • Page 108 Instrument cluster This gauge indicates the approximate 12.3-inch 3D amount of fuel remaining in the fuel tank. Information • The fuel tank capacity is given in chapter 2. • The fuel gauge is supplemented by a low fuel warning light, which will illuminate when the fuel tank is nearly empty.
  • Page 109 Odometer 12.3-inch 3D 8-inch OIK043043E • The distance to empty is the estimated OIK043466E distance the vehicle can be driven with 12.3-inch 3D the remaining fuel. • If the estimated distance is below 1 mi. (1 km), the trip computer will display "---"...

  • Page 110: Transmission Shift Indicator

    • The airbag warning light will remain illuminated if there is a malfunction with the Safety Restraint System (SRS) airbag operation. If this occurs, have your vehicle inspected by an authorized retailer of Genesis Branded products.
  • Page 111 If this occurs, have your vehicle inspected indicates the brake fluid level in the by an authorized retailer of Genesis reservoir is low. Branded products. If the brake fluid level in the reservoir is...
  • Page 112 If this occurs, have your vehicle inspected WL_BreakWarningLamp by an authorized retailer of Genesis When the ABS warning and Parking Brake Branded products as soon as possible. warning lights are on simultaneously, it...
  • Page 113 If the belt is adjusted properly, there may your vehicle inspected by an authorized be a problem in the electrical charging retailer of Genesis Branded products as system. soon as possible. Continued driving If this occurs, have your vehicle inspected...
  • Page 114 If this occurs, have your vehicle inspected by an authorized retailer of Genesis Branded products as soon as possible. 4-12...
  • Page 115 EPB. radar blocked If this occurs, have your vehicle • Blind-Spot Collision-Avoidance Assist inspected by an authorized retailer of malfunction Genesis Branded products. • Blind-Spot Collision-Avoidance Assist radar blocked Information • LED headlight malfunction The Electronic Parking Brake (EPB) • High Beam Assist malfunction warning light may illuminate when the •...
  • Page 116 TPMS. operating. If this occurs, have your vehicle inspected For more information, refer to the by an authorized retailer of Genesis "Forward Collision-Avoidance Assist Branded products as soon as possible. (FCA) (Sensor Fusion)" section in chapter For more information, refer to the "Tire Pressure Monitoring System (TPMS)"...
  • Page 117 Lane Safety is set, For more information, refer to the "Lane have your vehicle inspected by an Following Assist (LFA)" section in chapter authorized retailer of Genesis Branded products. This indicator light blinks: • Green: When Lane Keeping Assist is operating.
  • Page 118 Whenever there is a malfunction with the AWD system. If this occurs, have your vehicle inspected by an authorized retailer of Genesis Branded products. btn_WPDE-201 This warning light is to warn the driver the For more information, refer to the "All road may be icy.
  • Page 119 Electronic Stability Control (ESC) vehicle cannot detect the smart key. OFF indicator light If this occurs, have your vehicle inspected by an authorized retailer of Genesis Branded products. This indicator light blinks: btn_WAE-208 Whenever there is a malfunction with the This indicator light illuminates: immobilizer system.
  • Page 120 For more information, refer to the "High If any of these conditions occur, have Beam Assist (HBA)" section in chapter 5. your vehicle inspected by an authorized retailer of Genesis Branded products. AUTO HOLD indicator light High beam indicator light btn_WTL-207...
  • Page 121 If the yellow indicator light remains on after the front view camera has been uncovered or unblocked, have your vehicle inspected by an authorized retailer of Genesis Branded products. For more information, refer to the "Intelligent Speed Limit Assist (ISLA)" section in chapter 7.

  • Page 122: Cluster Display Messages

    Instrument cluster ECO Mode Indicator Light CUSTOM mode indicator light if equipped if equipped OIK043465 OIK043462 This indicator light illuminates This indicator light illuminates When you select "CUSTOM" mode as When you select "ECO" mode as drive drive mode. mode. For more information, refer to the "Drive For more information, refer to the "Drive Mode Integrated Control System"...
  • Page 123 If the warning message appears each have your vehicle inspected by an time you press the Engine Start/Stop authorized retailer of Genesis Branded button, have your vehicle inspected by an products. authorized retailer of Genesis Branded products.
  • Page 124 Instrument cluster Door, Hood, trunk open indicator Low tire pressure OIK043017 This warning appears if any door or hood OIK080024L This warning message appears if the tire or trunk is left open. The warning will pressure is low. The corresponding tire on indicate which door is open in the display.
  • Page 125 Low fuel Information This message appears if the fuel tank is The infotainment system may change almost out of fuel. after software updates. For more When this message appears, the low fuel information, refer to the user's manual level warning light in the cluster will come provided in the infotainment system and the quick reference guide.
  • Page 126 Check haptic steering wheel system This message appears if there is a problem with the haptic steering wheel system. have your vehicle inspected by an authorized retailer of Genesis Branded products. Check headlight if equipped This message appears if the headlights are not operating properly.

  • Page 127: Cluster Display (Type A)

    Cluster Display (Type A) Cluster display control OIK043021 The cluster display modes can be changed by using the control switches. Switch Operation Function Press MODE button for changing View modes UP, DOWN switch for changing items in Utility view and Option Scroll menu Press...
  • Page 128 Instrument cluster Drive Info Driving Assist view OIK043047N OIK040040N Trip distance, total driving time, average The status of Smart Cruise Control, Lane fuel economy, instant fuel economy Following Assist, Highway Driving Assist, appear. etc. appears when Driving Assist view is The information is combined for each selected.
  • Page 129 Accumulated Info Speed Limit Warning if equipped OIK043049N Accumulated Trip distance, total driving OIK073108N time, average fuel economy, instant fuel The driver can monitor the information economy appear. provided from Intelligent Speed Limit The information is accumulated starting Assist. from the last reset. For more information, refer to the To reset manually, press the OK switch on "Intelligent Speed Limit Assist (ISLA)"...

  • Page 130: Option Menu

    Instrument cluster Engine Temperature WARNING if equipped To avoid driver distractions, do not adjust the setting while driving the vehicle which may lead to an accident. Option menu Press the OK switch to enter Option menu. WARNING To avoid driver distractions, do not adjust OIK040080L the setting while driving which may lead Engine coolant temperature gauge...
  • Page 131 Service Messages Driver Assistance Settings OIK040067L OIK040065L When Service Messages menu is When Driver Assistance Settings menu is selected, press the OK switch on the selected, press the OK switch on the steering wheel to check vehicle warning steering wheel. The "Driver Assistance" messages.

  • Page 132: Cluster Display (Type B)

    Instrument cluster Cluster Display (Type B) if equipped Cluster display control OIK043021 The cluster display modes can be changed by using the control switches. Switch Function MODE button for changing modes MOVE switch for changing items SELECT/RESET button for setting or resetting the selected item 4-30...

  • Page 133: View Modes

    View modes View modes Symbol Explanation Sport (Sedan, if • This mode displays information related to engine. equipped) • This mode displays driving information such as the tripmeter, fuel economy, etc. Trip Computer • This mode displays digital speedometer. For more information, refer to the "Trip computer" section in this chapter.
  • Page 134 Instrument cluster Sport mode Driving Assist mode OIK043072N This mode displays information related to OIK040040N The status of Smart Cruise Control, Lane your engine such as engine oil Following Assist, Highway Driving Assist, temperature(1), current torque(2) and etc. appears when Driving Assist view is turbo boost pressure(3).

  • Page 135: Trip Computer

    Trip computer Warning mode The trip computer is a microcomputer-controlled driver information system that displays information related to driving. Information Some driving information stored in the trip computer (for example Average Vehicle Speed) resets if the battery is disconnected. OIK050227L This warning light informs the driver the following situations.
  • Page 136 Instrument cluster Accumulated Info OIK053005 To change the trip mode, toggle the " OIK043049N Accumulated trip distance, total driving " switch on the steering wheel. time, average fuel economy, instant fuel economy appear. Since Refueling The information is accumulated starting from the last reset.

  • Page 137: Instrument Cluster (For 12.3-Inch 3D Cluster)

    Digital Speedometer Recommendations to optimize the 3D effect ORG3040031N OIK047151N • Adjust the height of the seat and Digital speedometer display shows the steering wheel so that the instrument speed of the vehicle. cluster and camera module can be seen at a glance.
  • Page 138 Instrument cluster - Light from outside, sunlight or Information infrared LED light of the camera is reflected on the glasses or • When your face gets too close or far to sunglasses the instrument cluster, or the camera on the instrument cluster is blocked by - The driver turns or lowers his/her the steering wheel or other objects, the head so that the face or an eye is...
  • Page 139 • Do not apply any impact on the surface WARNING of the instrument cluster, interior view camera or around the area of the • You should not use the 3D cluster if you interior view camera. If interior view or any of your family members or camera is damaged, the system may relatives has a history of epilepsy, not operate properly.

  • Page 140: Vehicle (Infotainment System)

    Instrument cluster Vehicle (infotainment Setting your vehicle 1. Press the SETUP button on the main System) keyboard. OIK043027N OIK043028 Vehicle Settings in the infotainment 2. Select Vehicle and change the setting system provides user options for a variety of the features. of settings including door lock/unlock features, convenience features, driver assistance settings, etc.
  • Page 141 5. Convenience features Accessing Your Vehicle ....................5-5 Smart key........................5-5 Immobilizer system..................... 5-11 Genesis Digital Key ......................5-12 Digital Key (Smartphone) ...................5-12 Digital Key (Card Key)....................5-17 Used Vehicle/Digital Key Maintenance..............5-20 Limitations of the System...................5-21 Door Locks ........................5-21 Operating door locks from outside the vehicle ............5-21 Operating door locks from inside the vehicle............
  • Page 142 Power sunshade ......................5-51 Tilt open/close ......................5-52 Slide open/close ......................5-52 Automatic reversal .....................5-52 Resetting the sunroof....................5-53 Sunroof open warning ....................5-54 Hood ..........................5-54 Opening the hood...................... 5-54 Closing the hood ......................5-55 Non-Powered Trunk ......................5-55 Opening the trunk ......................5-55 Closing the trunk ....................... 5-56 Emergency trunk safety release................
  • Page 143 5. Convenience features Headlight delay function ....................5-71 Interior button lights....................5-71 Daytime Running Light (DRL) ................... 5-72 Headlight moisture removal function ..............5-72 Welcome system......................5-72 Puddle light ........................ 5-73 High Beam Assist (HBA) ....................5-74 High Beam Assist setting................... 5-74 High Beam Assist operation..................
  • Page 144 Recirculating air when entering a tunnel ..............5-98 Sunroof inside air recirculation ................5-99 Scheduled Ventilation ....................5-99 Warmer/ventilation based on climate settings (for driver's seat) ......5-100 Climate Touch Screen Haptics ................5-100 Storage Compartment....................5-100 Center console storage.....................5-101 Glove box ........................5-101 Sunglass holder ......................5-101 Interior Features......................

  • Page 145: Accessing Your Vehicle

    - Setup > Vehicle > Lights > Welcome Mirror/Light > Enable on Door Unlock OIK053306 Your Genesis Branded Vehicle uses a - The infotainment system may smart key, which you can use to lock or change after software updates. For...
  • Page 146 Convenience features 2. Put your hand in the door handle or WARNING press the Door Unlock button (2) on the smart key. Do not leave the smart key in your vehicle with unsupervised children. Unattended 3. The driver's door will unlock. children could press the Engine 4.
  • Page 147 • To prevent unintentional door lock or Information unlock: • If you press the front passenger outside Press the lock button on the smart key door handle with the smart key in your and immediately press the unlock possession, all the doors will unlock. button along with the lock button for more than 4 seconds.
  • Page 148 Convenience features Using panic alarm Starting the vehicle Press and hold the Panic button (4) for You can start the vehicle without inserting more than one second. The horn sounds the key. and hazard warning lights blink for about For more information, refer to the "Engine 30 seconds.
  • Page 149 Genesis Branded products or tow the • Always have the smart key with you vehicle, if necessary. when leaving the vehicle. If the smart key is left near the vehicle, the vehicle battery may be discharged.
  • Page 150 If the smart key does not operate normally, you can lock or unlock the driver's door by using the mechanical key. 1. Press the Genesis text section of the Mechanical key to remove the case. OIK053325 4. Reinstall smart key cover in the reverse order of removal.

  • Page 151: Immobilizer System

    If the system repeatedly does not recognize the coding of the key, contact an authorized retailer of Genesis Branded products. Do not attempt to alter this system or add other devices to it. Electrical problems could result that may make your vehicle inoperable.

  • Page 152: Genesis Digital Key

    Digital Key (Smartphone) Information Information • Genesis digital keys are only available This device complies with Part 15 of the on smartphone that support digital key FCC rules. Operation is subject to the functions, and digital key functions of...
  • Page 153 2. After selecting Digital Key > Set Up Digital Key from the Genesis Digital Key App in the smartphone, register the digital key according to the guidance in the smartphone screen.
  • Page 154 [B] NFC Antenna delete the digital key (smartphone) Apple iPhone before re-registering. An active Digital Key can be shared through the Genesis Digital Key App with a different smartphone. • During the digital key saving process, the process may cancel when:...
  • Page 155 Locking/Unlocking the doors Information • If the driver places the digital key • The location of the NFC Antenna on the (smartphone) NFC antenna to the smartphone may vary by phone model, driver's or passenger's door handle so please contact the smartphone authentication pad for more than 2 manufacturer for details.
  • Page 156 Convenience features Deleting all registered digital key Information (smartphone) If a shared digital key (smartphone) is used for the first time, the activating time may take longer. • Place the shared digital key (smartphone) on the door handle authentication pad until the vehicle door lock/unlock activates.

  • Page 157: Digital Key (Card Key)

    OIK053002 [A] Vehicle authentication pad (Wireless charging vehicle cannot be deleted individually. pad) • Even though Genesis Digital Key App is 1. Have both of your smart keys with you deleted from the smartphone, the in the vehicle. digital key saved in the smartphone is 2.
  • Page 158 Convenience features Using the digital key (card key) Starting the vehicle The driver can lock or unlock the door by After placing your registered digital key placing the card key on the outside door (card key) on the vehicle authentication handle, and the vehicle can be started by pad (wireless charging pad), depress the placing the card key on the vehicle...
  • Page 159 Deleting your digital key (card key) • Long-time exposure to high temperature may cause the digital key (card key) to malfunction. Be careful not to expose the digital key (card key) to direct sunlight or high temperature. • Leaving the digital key (card key) on the in-vehicle authentication pad (wireless charging pad) while driving may cause the digital key (card key) to...

  • Page 160: Used Vehicle/Digital Key Maintenance

    Genesis Customer Care system profile menu. Center. • The personalization function works only...

  • Page 161: Limitations Of The System

    Genesis Digital Key app. Mechanical key Limitations of the System • Genesis Digital Key App on the smartphone and card key may not work - Smartphone battery or the vehicle battery is discharged. - NFC or Bluetooth is turned off on the smartphone settings.
  • Page 162 Convenience features Unlock NOTICE Do not apply excessive force on the door and door handle. It may damage the door and door handle. Information When the keyhole freezes and does not open, lightly tap or indirectly warm (for example, hand temperature) the keyhole. OIKSB053282 Put your hand in the front outside door handle while carrying the smart key with...

  • Page 163: Operating Door Locks From Inside The Vehicle

    Operating door locks from Information inside the vehicle If a power door lock ever fails to function while you are in the vehicle try one or With the door lock button more of the following techniques to exit: • Operate the door unlock feature repeatedly (both electronic and manual) while simultaneously pulling on the door handle.
  • Page 164 Convenience features With the central door lock switch WARNING Driver's door Do not leave the elderly, children or animals unattended in your vehicle. An enclosed vehicle can become extremely hot, causing death or serious injury to the elderly, unattended children or animals who cannot escape from the vehicle.

  • Page 165: Impact Sensing Door Unlock System

    Impact sensing door unlock Child-protector rear door system locks All doors are automatically unlocked if equipped when an impact causes the airbags to deploy. Speed sensing door lock system All doors are automatically locked when the vehicle exceeds 9 mph (15 km/h). Automatic door lock and unlock features OIK053204N...

  • Page 166: Theft-Alarm System

    Convenience features Theft-alarm System Information This system helps to protect your vehicle • Do not lock the doors until all and valuables. The horn sounds and the passengers have left the vehicle. If the hazard warning lights blink continuously remaining passenger leaves the vehicle if any of the following occur: when the system is armed, the alarm will be activated.

  • Page 167: Rear Occupant Alert (Roa)

    Rear Occupant Alert System operation (ROA) Alert Rear Occupant Alert is provided to help prevent the driver from leaving the vehicle with the rear passenger left in the vehicle. System setting To use Rear Occupant Alert, it must be enabled from the Settings menu in the infotainment system.

  • Page 168: Integrated Memory System

    Information • If the battery is disconnected, the memory settings will be erased. • If integrated memory system does not operate normally, have the system inspected by an authorized retailer of Genesis Branded products. 5-28...

  • Page 169: Resetting The System

    While resetting integrated memory Information system • If you press the SET button or the 1. Resetting starts with a notification corresponding button which the setting sound. is being recalled, the setting will 2. The driver's seat and seatback is temporarily deactivate.

  • Page 170: Seat Easy Access

    Convenience features Seat easy access • You can set the Seat Easy Access function from the Settings menu in the Seat easy access will move the driver's infotainment system. Select: seat and steering wheel automatically as - Driver seat follows: Setup >...

  • Page 171: Steering Wheel

    Instrument cluster warning operation, have the system checked by lights may illuminate or the steering an authorized retailer of Genesis Branded effort may be high. If these symptoms products. occur, drive the vehicle to a safe location as soon as possible.
  • Page 172 If the adjustment is still not possible after resetting the steering wheel power adjustment, have the system Power adjustment inspected by an authorized retailer of Genesis Branded products. if equipped OIK053009 5-32...

  • Page 173: Horn

    Horn • Automatic temperature control The heated steering wheel starts to automatically control the steering wheel temperature after being manually turned ON. - When HIGH is manually selected: The heated steering wheel automatically changes to the LOW position after 30 minutes. You can turn off the heated steering wheel by touching the icon to the OFF position.

  • Page 174: Mirrors

    Convenience features Mirrors Information The infotainment system may change after software updates. For more Inside rearview mirror information, refer to the user's manual Before driving your vehicle, check to see provided in the infotainment system and that your inside rearview mirror is the quick reference guide.
  • Page 175 Electrochromic mirror (ECM) if equipped OIK053370N (1) HomeLink Channel 1 (2) HomeLink Channel 2 OIK053074 (3) HomeLink Channel 3 [A] Sensor (4) Garage Door Opener Status Indicator: Some vehicles come equipped with an Closing or Closed electrochromic mirror that helps control (5) HomeLink Operation Indicator glare while driving at night or under low (6) Garage Door Opener Status Indicator:...
  • Page 176 Convenience features Integrated HomeLink® Wireless Control 1. Programming HomeLink® System The following steps show how to program The HomeLink® Wireless Control System HomeLink. If you have any questions or provides a convenient way to replace up are having difficulty programming your to three handheld radio-frequency HomeLink buttons, refer to the HomeLink transmitters used to activate compatible...
  • Page 177 3. Press the Engine Start/Stop button to 5. Press and release the HomeLink button the ACC (Accessory) position for you are programming and observe the programming of HomeLink. indicator light. • If the indicator light remains solid 2) Programming a New HomeLink® green, your device should operate when the HomeLink button is pressed.
  • Page 178 Convenience features 8.Return to the vehicle and firmly press, 1. In your vehicle, press and hold the hold for two seconds and release, the programmed HomeLink button for 2 HomeLink button up to three times in a seconds, then release. Confirm that the row slowly.
  • Page 179 2. Operating HomeLink® 6.Your Two-Way Communication programming is now complete. 1) Operating HomeLink® Information If your garage door opener has Two-Way Communication functionality, it is possible for HomeLink to stop functioning the garage door shortly after initial programming, IF the Two-Way Communication Programming wasn't properly completed.
  • Page 180 Convenience features • If the indicator (6) appears solid Green, it indicates that the last activated device was "open" properly. 3. Erasing HomeLink® Buttons 1) Erasing and Reprogramming a Single HomeLink® Button: 1. Press and hold the desired HomeLink button you want to re-program. DO NOT release the button.
  • Page 181 FCC (Htats-Unis) et ISED (Canada) 3. Release the buttons once the HomeLink indicator light (7) changes to Cet appareil est conforme aux règlements Green and flashes rapidly. de la FCC, section 15, et au CNR-210 4. Now all three HomeLink buttons (1), (2) d'Innovation, Sciences et and (3) are cleared of any Dhveloppement économique Canada.
  • Page 182 Convenience features HomeLink 5 Programing Flow Chart OIK053376N 5-42...

  • Page 183: Side View Mirrors

    Side view mirrors the vehicle to a warm place and allow the ice to melt. • Do not clean the mirror with harsh abrasives, fuel or other petroleum based cleaning products. Adjusting the side view mirrors OIK053316 Your vehicle is equipped with both left-hand and right-hand side view mirrors.
  • Page 184 Convenience features Infotainment system setting Folding the side view mirrors • Enable on door unlock if equipped If Setup > Vehicle > Lights > Welcome Manual type Mirror/Light > Enable on Door Unlock is selected from the Settings menu in the infotainment system, - The mirror will fold or unfold when the door is locked or unlocked by the...

  • Page 185: Reverse Parking Aid

    Reverse parking aid Reverse parking aid user settings mode if equipped You may change the angle of the side view mirror if it is difficult to see the rear view with the basic downward mirror angle provided when reversing. When the vehicle is first delivered, the set downward angle of the left and right side view mirror are different to ensure driver visibility.

  • Page 186: Windows

    Convenience features Windows OIK053354N (1) Driver's door power window switch (2) Front passenger's door power window switch (3) Rear door (left) power window switch (4) Rear door (right) power window switch (5) Window opening and closing (6) Automatic power window (7) Power window lock switch 5-46...

  • Page 187: Power Windows

    Power windows Window opening and closing The Engine Start/Stop button must be in the ON position to be able to raise or lower the windows. Each door has a Power Window switch to control that door's window. The driver has a Power Window Lock button which can block the operation of rear passenger windows.
  • Page 188 If the power windows do not operate second detent. properly after resetting, have the system inspected by an authorized retailer of Genesis Branded products. WARNING WARNING Make sure body parts or other objects are safely out of the way before closing the...

  • Page 189: Remote Window Opening Function

    Remote window opening • Note that the front passenger control is still able to operate the front passenger function window, and that the driver master control can still operate all the power if equipped windows. System settings NOTICE • To prevent possible damage to the power window system, do not open or close two windows or more at the same time.
  • Page 190 Convenience features Window opening NOTICE You can still control the window Do not leave the windows down when movement with the vehicle turned off by leaving the vehicle to prevent theft or pressing the Door Lock button (1) or the damage from water entering the vehicle.

  • Page 191: Wide Sunroof

    Wide Sunroof Power sunshade if equipped If your vehicle is equipped with a sunroof, you can slide or tilt your sunroof with the sunroof switch located on the overhead console. OIK053200N Use the power sunshade to block direct sunlight coming through the sunroof glass.

  • Page 192: Tilt Open/Close

    Convenience features Tilt open/close • Push the sunroof switch forward or rearward to the second detent position. The power sunshade and sunroof glass operate automatically (auto slide feature). To stop the sunroof movement at any point, push the sunroof switch in any direction. Automatic reversal OIK053298N •...

  • Page 193: Resetting The Sunroof

    In some circumstances resetting the NOTICE sunroof operation may need to be performed. Some instances where • Do not continue to push the sunroof resetting the sunroof may be required switch after the sunroof is fully opened, include: closed, or tilted. Damage to the sunroof motor may occur or may cause the •...

  • Page 194: Sunroof Open Warning

    Convenience features Hood Sunroof open warning Opening the hood 1. Park the vehicle and set the parking brake. 2. Pull the release lever to unlatch the hood. The hood should pop open slightly. OIK043018 If the driver turns off the engine when the sunroof is not fully closed, the warning chime will sound for several seconds and the sunroof open warning will appear on...

  • Page 195: Closing The Hood

    Non-Powered Trunk Closing the hood 1. Before closing the hood, check in and if equipped around the engine compartment to ensure the following: Opening the trunk • Any tools or other loose objects are removed from the engine room area 1.

  • Page 196: Closing The Trunk

    Convenience features • Use the trunk release button. WARNING Inside Your vehicle should be kept locked and keys should be kept out of the reach of children. Parents should teach their children about the dangers of playing in the trunk. Emergency trunk safety release OIK053023...

  • Page 197: Power Trunk

    Power Trunk protected occupant space but is a part of the vehicle's crush zone. if equipped • Your vehicle should be kept locked and the smart key should be kept out of the reach of children. Parents should teach Power trunk operating their children about the dangers of conditions playing in trunks.
  • Page 198 This must be done by an authorized retailer of • Be careful where there is an incline, as Genesis Branded products. the trunk lid may drop slightly when it is stopped before it fully opens. • Do not operate the power trunk under the following conditions.

  • Page 199: Operating The Power Trunk

    Operating the power trunk Power trunk open button (Outside the power trunk) Power trunk open (Smart key) OIK053022 When the trunk is closed, press the power OIK053076L trunk open button to open the trunk. When the trunk is closed, press the power If the vehicle is locked, press the power trunk open button for 1 second.
  • Page 200 Convenience features Power trunk close button (Inside the Switching the power trunk from power trunk) manual to automatic If you apply over a certain amount of power manually when the trunk is opened, the power trunk system detects the direction and closes or opens automatically.

  • Page 201: Setting The Power Trunk

    If the power trunk does not operate properly after the above procedure, have Setting the power trunk the system inspected by an authorized retailer of Genesis Branded products. Power Trunk Opening Height To adjust the Power Trunk Opening Emergency trunk safety Height, select Setup >...

  • Page 202: Smart Trunk

    Convenience features Smart Trunk 1. Fold the rear seats using the seatback folding lever (1). if equipped OIK053029 2. Open the trunk using the Emergency OIK053030 On a vehicle equipped with a smart key, Trunk Safety Release lever. the trunk can be opened with hands-free WARNING activation using the smart trunk system.

  • Page 203: Deactivating Smart Trunk

    2. Detect and Alert Information The smart trunk detecting area extends The smart trunk will NOT operate when: about 20-40 in. (50-100 cm) behind the vehicle. If you are positioned in the • Any door is open, or all doors are closed detecting area and are carrying the but not locked smart key, the hazard warning lights...

  • Page 204: Detecting Area

    Convenience features Make sure to be aware of how to • The alert stops once the smart key is deactivate the smart trunk function for moved outside of the detecting area emergency situations. within the 3 second period. Information Information •...

  • Page 205: Fuel Filler Door

    Fuel Filler Door Closing the fuel filler door 1. To install the fuel tank cap, turn it clockwise until it "clicks" one time. Opening the fuel filler door 2. Close the fuel filler door until it is 1. Turn the engine off. latched securely.

  • Page 206: Emergency Fuel Filler Door Release

    Genesis cap or the equivalent (of the • When refueling, always shift the gear to genuine part) specified for your vehicle. the P (Park) position, set the parking...

  • Page 207: Head-Up Display (Hud)

    Head-Up Display (HUD) Information if equipped The infotainment system may change after software updates. For more information, refer to the user's manual provided in the infotainment system and the quick reference guide. Head-Up Display information OIKSB053034N The Head-Up Display is an optional feature that allows the driver to view information projected onto a transparent screen while still keeping your eyes safely...

  • Page 208: Precautions While Using The Head-Up Display

    Convenience features Precautions while using the WARNING Head-Up Display The warning information of Blind-Spot • It may sometimes be difficult to read Collision Warning on the Head-Up Display information on the Head-Up Display in are supplemental. Do not solely depend the following situations.

  • Page 209: Exterior Lights

    Exterior Lights NOTICE • Do not cover or spill anything on the Lighting control sensor (1) located at the upper end of the windshield glass. To operate the lights, turn the knob at the • Do not clean the sensor using a window end of the control lever to one of the cleaner, the cleanser may leave a light following positions:...

  • Page 210: High Beam Operation

    Convenience features To flash the high beam headlight, pull the Information lever towards you, then release the lever. The high beams will remain ON as long as The Engine Start/Stop button must be in you hold the lever towards you. the ON position to turn on the headlight.

  • Page 211: Battery Saver Function

    Battery saver function Information The purpose of this feature is to help The infotainment system may change prevent the battery from being after software updates. For more discharged. The system automatically information, refer to the user's manual turns off the parking light when the driver provided in the infotainment system and turns the vehicle off and opens the the quick reference guide.

  • Page 212: Daytime Running Light (Drl)

    If moisture is The infotainment system may change not removed, have your vehicle inspected after software updates. For more by an authorized retailer of Genesis information, refer to the user's manual Branded products. provided in the infotainment system and the quick reference guide.

  • Page 213: Puddle Light

    Interior lamp Escort light When the interior lamp switch is in the When the Engine Start/Stop button is in the OFF position and the driver's door is position and all doors (and trunk) are opened, the puddle light will turn on for closed and locked, the room lamp will 30 seconds.

  • Page 214: High Beam Assist (Hba)

    Convenience features High Beam Assist (HBA) High Beam Assist setting OIK053217N OIK053313 With the Engine Start/Stop button in the High Beam Assist automatically controls ON position, select Setup > Vehicle > the headlights between high beam and Lights > High Beam Assist from the low beam depending on the detected Settings menu to turn on High Beam ambient light, such as an oncoming...

  • Page 215: High Beam Assist Operation

    (HBA) system" warning message will (headlight/parking/off), High Beam appear and warning light will Assist will turn off and the illuminate on the instrument cluster. Have corresponding light will turn on. your vehicle inspected by an authorized retailer of Genesis Branded products. 5-75...
  • Page 216 Convenience features Limitations of High Beam Assist WARNING High Beam Assist may not work properly • At times, High Beam Assist may not in the following situations: work properly High Beam Assist is for • Light from an oncoming or front vehicle your convenience only.

  • Page 217: Interior Lights

    Interior Lights Door lamp ( The front or rear room lamps come on when the front or rear doors are opened. WARNING When doors are unlocked by the smart Do not use the interior lights when driving key, the front and rear lamps come on for in the dark.

  • Page 218: Vanity Mirror Lamp

    Convenience features Foot lamp NOTICE Do not leave the lamp switches on for an extended period of time when the engine is turned off. Vanity mirror lamp OIK053043N The foot lamp turns on when a door is open and turns off when the door is closed.

  • Page 219: Wipers And Washers

    Wipers And Washers • MIST: For a single wiping cycle, push the lever downward and release. The wipers operate continuously if the lever is held in this position. Information If there is heavy accumulation of snow or ice on the windshield, defrost the windshield for about 10 minutes, or until the snow and/or ice is removed before using the windshield wipers to ensure...

  • Page 220: Front Windshield Washers

    Convenience features Front windshield washers WARNING To avoid personal injury from the windshield wipers, when the engine is running and the windshield wiper switch is placed in the AUTO mode: • Do not touch the upper end of the windshield glass facing the rain sensor. •...
  • Page 221 WARNING When the outside temperature is below freezing, ALWAYS warm the windshield using the defroster to help prevent the washer fluid from freezing on the windshield and obscuring your vision which could result in an accident and serious injury or death. NOTICE •...

  • Page 222: Automatic Climate Control System

    Convenience features Automatic Climate Control System OIK053220N The switch arrangements may vary depending on which functions are applicable to your vehicle. (1) Driver's temperature control (2) Passenger's temperature control (3) AUTO (automatic control) (4) OFF (system off) (5) Front windshield defroster (6) Mode selection (7) Fan speed control (8) A/C (air conditioning)

  • Page 223: Automatic Temperature Control Mode

    Automatic temperature Driver side/Passenger side control mode The Automatic Climate Control System is controlled by setting the desired temperature. 1. Press the AUTO button. OIK053083 To turn the automatic operation off, select any function of the following: • Mode selection button •...

  • Page 224: Manual Temperature Control Mode

    Convenience features 7. Press the AUTO button to convert to full Information automatic control of the system. The climate control system settings will be maintained, even when the vehicle is turned OFF. However, the climate control system settings will be initialized when the battery has been discharged, or when the cables have been disconnected In this case, adjust the climate control...
  • Page 225 Air flow direction OIK053048 Symbol Operation Direction Air flow is directed toward the upper body. B, D, F Air flow is directed toward the upper body and face. A, B, D, F Air flow is directed toward the upper body and floor. B, C, D, E, F 5-85...
  • Page 226 Convenience features Symbol Operation Direction Air flow is directed toward the upper body, face and floor. A, B, C, D, E, F Most of the air flow is directed to the floor, with a small amount of the air being directed to the windshield and side A, C, D, E, F window defrosters.
  • Page 227 Front windshield defroster Rear seat OIK053086 OIK053085 The instrument panel vent air flow can be directed up/down or left/right using the Defrost-level (A, D) vent adjustment lever. Press the button, and the indicator light The air flow can also be CLOSED using the on the button will illuminate and the vent adjustment lever.
  • Page 228 Convenience features SYNC Air intake control OIK053087 OIK053319 The air intake control button is used to Adjusting the driver and passenger side select either Fresh mode (outside air) or temperature equally Recirculation mode (cabin air). Touch the SYNC icon to adjust the driver Recirculation mode and passenger side temperature equally.
  • Page 229 Fan speed control Information Front seat Operating the system primarily in Fresh mode is recommended. Use Recirculation mode temporarily only when needed. Prolonged operation of the heater in Recirculation mode and without the air conditioning ON can cause fogging of the windshield. In addition, prolonged use of the air conditioning ON in Recirculation mode may result in excessively dry, dehumidified air in the...

  • Page 230: System Operation

    Convenience features System operation OFF mode Cooling/Ventilation 1. Select the Face Level mode. 2. Set the air intake control to fresh or recirculation mode. 3. Set the temperature control to the desired position. 4. Set the fan speed control to the desired speed.
  • Page 231 Air conditioning system operation tips Air conditioning Your Genesis Branded Vehicle air • If the vehicle has been parked in direct conditioning system is filled with sunlight during hot weather, open the R-1234yf refrigerant. windows for a short time to let the hot air inside the vehicle escape.

  • Page 232: System Maintenance

    Therefore, if abnormal operation is found, have the system inspected by an authorized retailer of Genesis Branded products. NOTICE It is important that the correct type and amount of oil and refrigerant is used.
  • Page 233 WARNING Vehicles equipped with R-1234yf Ęę Since the refrigerant is mildly flammable and operated at high pressure, the air 2C_RefrigerantLabel conditioning system should only be Each symbols and specification on the air serviced by trained and certified conditioning refrigerant label is technicians.

  • Page 234: Windshield Defrosting And Defogging

    Convenience features Windshield Defrosting To defog inside windshield And Defogging WARNING Windshield heating Do not use the position during cooling operation in extremely humid weather. The difference between the temperature of the outside air and that of the windshield could cause the outer surface OIK053053 of the windshield to fog up, causing loss 1.

  • Page 235: Defogging Logic

    Check to make sure the air intake control is in Fresh mode. If the air intake control indicator light is illuminated, press the button once to enable Fresh mode (indicator light OFF). If the position is selected, lower fan speed is adjusted to a higher fan speed. Defogging logic To reduce the probability of fogging up OIK053093N...

  • Page 236: Climate Control Additional Features

    Convenience features Climate Control Operating conditions The Air conditioning auto-drying feature Additional Features operates under the following conditions: • The vehicle is turned off after operating Information the air conditioner for a certain period. The infotainment system may change • The battery level is sufficient and the after software updates.

  • Page 237: Auto Defogging System

    Auto defogging system Turning the Auto Defogging System ON or OFF Climate control system Press the front windshield defroster button for 3 seconds when the Engine Start/Stop button is in the ON position to turn the system on or off. Infotainment system Auto Defogging System can be turned on and off by selecting Setup >...

  • Page 238: Automatic Dehumidify

    Convenience features Automatic Dehumidify Turning Activate upon Washer Fluid Use ON or OFF if equipped To increase cabin air quality and reduce Climate control system windshield misting, recirculation mode To turn the Activate upon Washer Fluid switches off automatically after about 5 Use feature on or off, select Floor level to 30 minutes, depending on the outside ) mode, and then press the air intake...

  • Page 239: Sunroof Inside Air Recirculation

    Sunroof inside air • Activate upon Entering Tunnels: The vehicle's windows automatically close, recirculation and the climate control system switches to recirculation mode for if equipped When the sunroof is opened, fresh mode about 7 seconds before entering a will be automatically selected. At this tunnel.

  • Page 240: Warmer/Ventilation Based On Climate Settings (For Driver's Seat)

    Convenience features Storage Compartment Warmer/ventilation based on climate settings (for driver's seat) WARNING The temperature of the driver's seat Never store cigarette lighters, propane warmer, air ventilated seat and heated cylinders, or other flammable/explosive steering wheel is automatically controlled materials in the vehicle. These items may depending on the inside and outside catch fire and/or explode if the vehicle is temperature of the vehicle when the...

  • Page 241: Center Console Storage

    Center console storage Sunglass holder OIK053206N OIK053056 To open: To open: Press the button. Push and release the cover and the holder will slowly open. Place your sunglasses in the compartment door with the lenses Glove box facing out. To close: Push back into position.

  • Page 242: Interior Features

    Convenience features Interior Features WARNING Keep cans or bottles out of direct sun light Cup holder and do not put them in a hot vehicle. It may explode. Front NOTICE • Keep your drinks sealed while driving to prevent spilling your drink. If liquid spills, it may get into the vehicle's electrical/electronic system and damage electrical/electronic parts.

  • Page 243: Sunvisor

    Sunvisor Power outlet OIK053351 OIK053060 To use the sunvisor, pull it downward. The power outlet is designed to provide power for mobile telephones or other To use the sunvisor to block the sun from devices designed to operate with vehicle the side window, pull it downward, electrical systems.

  • Page 244: Usb Charger

    Convenience features electronic systems or devices used in Rear your vehicle. • Push the plug in as far as it goes. If good contact is not made, the plug may overheat and the fuse may be damaged or blown. • Plug in battery equipped electrical/electronic devices with reverse current protection.

  • Page 245: Wireless Smartphone Charging System

    USB charger or check whether your smartphone supports the connected devices. Contact an the Qi technology. authorized retailer of Genesis Branded products for more information on The wireless charging process starts accessories for vehicles. when you put a Qi-enabled smartphone on the wireless charging with the screen •...
  • Page 246 Convenience features 3. Turn on the wireless charging function NOTICE in the infotainment system. • The wireless smartphone charging • Select Setup > Vehicle > system may not support certain Convenience > Wireless Charging smartphones, which are not verified for System For Mobile Devices the Qi specification ( ).

  • Page 247: Clock

    • Some magnetic items like credit cards, Information phone cards or rail tickets may be damaged if left with the smartphone This device complies with Part 15 of the during the charging process. FCC rules. • When any smartphone without a Operation is subject to the following three wireless charging function or a metallic conditions:...

  • Page 248: Coat Hook

    Convenience features Coat hook Floor mat anchor(s) Always use the Floor Mat Anchors to Type A attach the front floor mats to the vehicle. The anchors on the front floor carpet keep the floor mats from sliding forward. WARNING Do not overlay additional mats or liners over the floor mats.

  • Page 249: Luggage Net Holder

    DO NOT use the luggage net pedal operation, Genesis Branded Vehicle when the strap has visible signs of wear recommends that the Genesis floor mat or damage. designed for use in your vehicle be • Use the luggage net to keep only light installed.

  • Page 250: Infotainment System

    USB port or the connected interior parts because they may cause devices. Contact an authorized retailer damage or discoloration. of Genesis Branded products for more information on accessories for vehicles. USB Port • The use of non-genuine parts may damage the USB port and infotainment system.

  • Page 251: Steering Wheel Remote Controls

    SEEK/PRESET ( ) (2) Information If the SEEK/PRESET switch is pressed up The signals which the antenna can or down and held for 0.8 second or more, transmit and receive varies depending on it will function in the following modes: the vehicle option.

  • Page 252: Infotainment System

    Convenience features Infotainment system Bluetooth® Wireless Technology OIK053068 For more information, refer to the OIK053070 separately supplied infotainment system manual. Voice recognition OIK053095N (1) Call/Answer/Call end button (2) Microphone For more information, refer to the separately supplied infotainment system manual. OIK053072 For more information, refer to the CAUTION...

  • Page 253: Lexicon Premium Sound System

    Lexicon premium sound system if equipped CAUTION Lexicon premium sound system is equipped with door speaker grills made of stainless steel. The grill surface can be heated when the vehicle is exposed to hot weather for a long period of time. Keep away from the speaker grill when it is hot.
  • Page 255 6. Driving your vehicle Before Driving ........................6-3 Before entering the vehicle..................6-4 Before starting ......................6-4 Engine Start/Stop Button....................6-5 Engine Stop/Start button positions ................6-6 Starting the engine ...................... 6-7 Turning off the engine ....................6-8 Remote start.........................6-9 Vehicle Auto-Shut Off .....................6-9 Operating Conditions ....................6-9 Deactivating Conditions....................6-9 System Operation ......................
  • Page 256 Prerequisite for activation ..................6-42 Launch Control activation ..................6-42 Limited use of Launch Control ................. 6-43 Coasting......................... 6-44 Coasting setting ......................6-44 Coasting operating conditions ................. 6-44 Coasting release conditions ..................6-45 Drive Mode Integrated Control System ..............6-46 Drive mode ........................

  • Page 257: Before Driving

    If you hear a change in the sound of the exhaust or drive over something that strikes the underneath side of the vehicle, have the exhaust system inspected as soon as possible by an authorized retailer of Genesis Branded products. Do not run the engine in an enclosed area.

  • Page 258: Before Entering The Vehicle

    Driving your vehicle • Check that any items you are carrying WARNING are stored properly or fastened down securely. CALIFORNIA PROPOSITION 65 WARNING Engine exhaust and a wide variety of WARNING automobile components including components found in the interior To reduce the risk of SERIOUS INJURY or furnishings in a vehicle, contain or emit DEATH, take the following precautions: harmful chemicals known to the State of...

  • Page 259: Engine Start/Stop Button

    Engine Start/Stop Button WARNING • NEVER press the Engine Start/Stop button while the vehicle is in motion except in an emergency. This may result in the vehicle turning off and loss of power assist for the steering and brake systems. This may lead to loss of directional control and braking function, which could cause an accident.

  • Page 260: Engine Stop/Start Button Positions

    Driving your vehicle Engine Stop/Start button positions Button Position Action Notes To turn off the engine, press the If the steering wheel is not locked Engine Start/Stop button with the properly when you open the vehicle shifted to P (Park). driver's door, the warning chime will sound.

  • Page 261: Starting The Engine

    Starting the engine Starting the engine 1. Always carry the smart key with you. WARNING 2. Make sure the parking brake is applied. • Always wear appropriate shoes when 3. Make sure the gear is shifted to P (Park) operating your vehicle. Unsuitable by pressing the P button.

  • Page 262: Turning Off The Engine

    Driving your vehicle Emergency starting NOTICE To prevent damage to the vehicle: • If the engine stalls while you are in motion, do not attempt to shift the gear to the P (Park) position. If traffic and road conditions permit, you may put the gear in N (Neutral) while the vehicle is still moving and press the Engine Start/Stop button in...

  • Page 263: Remote Start

    Vehicle Auto-Shut Off Remote start if equipped If your vehicle is parked and the engine is left on for a long period of time, the engine will turn off automatically to help reduce fuel consumption and prevent accidents caused by carbon dioxide poisoning.

  • Page 264: System Operation

    Driving your vehicle System Operation 2C_AutoShutOffInfo When all the conditions are satisfied, the Vehicle Auto-Shut Off operates and turns the engine off automatically after 60 minutes. A timer appears on the instrument cluster 30 minutes before vehicle shut off. Resetting cluster timer To reset the cluster timer, do one of following: •...

  • Page 265: Automatic Transmission

    Automatic Transmission OIK063088 [A] UNLOCK button [B] P button [C] Shift lever When you move the shift lever, depress the brake pedal while pressing the UNLOCK button. 6-11...

  • Page 266: Automatic Transmission Operation

    Driving your vehicle P (Park) Automatic transmission operation Always come to a complete stop before shifting into P (Park). The automatic transmission has eight forward speeds and one reverse speed. The individual speeds are selected automatically in the D (Drive) position. WARNING To reduce the risk of serious injury or death:...
  • Page 267 N (Neutral) • When the driver's door is opened with the gear in N (Neutral) and the vehicle is The wheels and transmission are not turned off. engaged. In situations the gear must be in P (Park), always check if the gear is shifted to P (Park) by checking the cluster.
  • Page 268 Driving your vehicle WARNING • Do not shift into gear unless your foot is firmly on the brake pedal. Use the P (Park) position to idle a vehicle for an extended period of time. The wheels and the transmission are not engaged. While parking the vehicle with the engine running, depress the brake pedal or apply the parking brake.
  • Page 269 When the battery is discharged R (Reverse) to D (Drive) You cannot shift gears, when the battery is discharged. In emergencies, do the following to shift the gear to N (Neutral) on a level ground. 1. Connect the battery cables from another vehicle or from another battery to the jump-starting terminals inside the engine compartment.

  • Page 270: Cluster Display Messages (Cluster)

    Shift Immediately have your vehicle inspected the gear to P (Park), apply the parking by an authorized retailer of Genesis brake, and press the Engine Start/Stop Branded products. button to the OFF position. Take the Key with you when leaving the vehicle.
  • Page 271 Shifting conditions not met. Reduce Shift to P after stopping speed, then shift 2C_ShiftToPAfterStoppingInfo This message appears when the gear is OIK063010E shifted to P (Park) while the vehicle is This message appears when engine rpm moving. is too high, or when driving speed is too fast to shift the gear.
  • Page 272 P button. display when there is problem with the P RELEASE button. Immediately have your vehicle inspected by an authorized retailer of Genesis have your vehicle inspected by an Branded products. authorized retailer of Genesis Branded products.
  • Page 273 Auto shift to P engaged NEUTRAL engaged OIK063015L OIK060017L The message appears on the cluster display when the gear shifts to P (Park) The message appears on the cluster automatically. display when the N (Neutral) position is engaged. Example of gear shifting to P (Park) automatically: Transmission overheated warning When the driver's door is opened with the...

  • Page 274: Paddle Shifter (Manual Shift Mode)

    • If the above message is continuously of the following: displayed, have your vehicle inspected by an authorized retailer of Genesis - Pull the [+] paddle shifter for more Branded products. than one second.
  • Page 275 RPMs are outside travel lanes. of the allowable range. • Genesis Branded Vehicle recommends • Do not drive with your foot resting on you to follow all posted speed limits. the brake pedal. Even light, but...

  • Page 276: Braking System

    Driving your vehicle Braking System WARNING Take the following precautions: Power-Assist Brakes • Do not drive with your foot resting on the brake pedal. This will create Your vehicle has power-assisted brakes abnormal high brake temperatures, that adjust automatically through normal excessive brake lining and pad wear, usage.

  • Page 277: High Performance Brake

    • If the vehicle has continuous vibration or shudder in the steering wheel while Applying the parking brake braking, have your vehicle be checked by an authorized retailer of Genesis Branded products. WARNING Frequent speeding and braking may deform components and worn the disc brake causing vibration when braking.
  • Page 278 1. Ensure seat belts are fastened and checked by an authorized retailer of the doors, hood and trunk are closed. Genesis Branded products. 2. With the engine running, depress the brake pedal and shift out of P (Park) to R (Reverse), D (Drive) or Manual shift mode.
  • Page 279 EPB has been appears. released, have the system checked by an authorized retailer of Genesis • If the driver's seat belt is unfastened Branded products. and the engine hood or trunk is opened, a warning sounds and a message •...
  • Page 280 Driving your vehicle AUTO HOLD turning Off! Press brake • NEVER allow anyone who is unfamiliar pedal with the vehicle to touch the EPB switch. If EPB is released unintentionally, serious injury may occur. • Only release EPB when you are seated inside the vehicle with your foot firmly on the brake pedal.
  • Page 281 EPB may have malfunctioned. the ON position. If this occurs, have the system checked This light will be illuminated when the by an authorized retailer of Genesis parking brake is applied with the Engine Branded products. Stop/Start button in the START or ON The EPB warning light may illuminate position.

  • Page 282: Auto Hold

    Driving your vehicle Auto Hold Auto Hold helps maintain the vehicle in a standstill even though the brake pedal is not depressed after the driver brings the vehicle to a complete stop by depressing the brake pedal. Information The Auto Hold On or Off setting is maintained when the vehicle is turned off.
  • Page 283 2. Press the AUTO HOLD switch. If the AUTO HOLD indicator changes to The AUTO HOLD indicator will turn off. yellow, Auto Hold is not working properly. Contact an authorized retailer of Genesis WARNING Branded products. To prevent, unexpected and sudden...

  • Page 284: Anti-Lock Brake System (Abs)

    Driving your vehicle AUTO HOLD turning Off! Press brake AUTO HOLD conditions not met. Close pedal door and hood. OIK060072L OIK060067L When the conversion from Auto Hold to When you press the AUTO HOLD switch, if EPB is not working properly a warning will the driver's door and engine hood are not sound and a message will appear.
  • Page 285 If the light stays on, you may have a problem with your ABS. ABS is an electronic braking system that Contact an authorized retailer of Genesis helps prevent a braking skid. ABS allows Branded products as soon as possible.

  • Page 286: Electronic Stability Control (Esc)

    Driving your vehicle Electronic Stability Control ESC operation (ESC) ESC ON condition When the Engine Start/Stop button is in the ON position, ESC and the ESC OFF indicator lights illuminate for about three seconds. After both lights go off, ESC is enabled.
  • Page 287 The ESC OFF indicator light and/or illuminates, have your vehicle checked by message "Traction & Stability Control an authorized retailer of Genesis Branded disabled" illuminates and a warning products as soon as possible. chime sounds. In this state, both the...

  • Page 288: Vehicle Stability Management (Vsm)

    Driving your vehicle Vehicle Stability Management NOTICE (VSM) Driving with wheels and tires with Vehicle Stability Management is a different sizes may cause the ESC system function of the Electronic Stability to malfunction. Before replacing tires, Control (ESC) system. It helps the vehicle make sure all four tires and wheels are the stay stable when accelerating or braking same size.

  • Page 289: Hill-Start Assist Control (Hac)

    VSM system. When only for about 5 seconds. the warning light illuminates, have your vehicle checked by an authorized retailer of Genesis Branded products as soon as Information possible. • Hill-Start Assist Control does not operate when the gear is shifted to P (Park) or N (Neutral).

  • Page 290: Brake Assistant System (Bas)

    If the braking action does not return to km/h). normal, stop as soon as it is safe to do so and call an authorized retailer of Genesis • The brake pedal is depressed over a Branded products for assistance. certain conditions.

  • Page 291: All Wheel Drive (Awd)

    All Wheel Drive (AWD) NOTICE if equipped • Do not drive in water if the water level is All Wheel Drive (AWD) delivers engine higher than the bottom of the vehicle. power to front and rear wheels for • Check your brake condition once you maximum traction.
  • Page 292 Driving your vehicle Driving on snow-covered or icy roads NOTICE • Start off slowly by applying the When the vehicle is stuck in snow, sand or accelerator pedal gently. mud, place a nonslip material under the • Use snow tires or tire chains. drive wheels to provide traction OR slowly •...

  • Page 293: Emergency Precautions

    Driving through water Emergency precautions • Try to avoid driving in deep standing water. It may stall your engine and clog Tires your exhaust pipes. When replacing tires, be sure to equip all • Do not change gear while driving in four tires with the same size, type, tread water.
  • Page 294 Whenever the AWD ( ) warning light • Never engage the parking brake while illuminates, have your vehicle inspected running the engine on a car lift. This by an authorized retailer of Genesis may damage the AWD system. Branded products as soon as possible. Dynamometer testing An AWD vehicle must be tested on a special four wheel chassis dynamometer.

  • Page 295: Limited Slip Differential

    OIK060073L the Rear Differential (for LSD) oil Check Electronic Suspension changed by an authorized retailer of Genesis Branded products. When Electronic Control Suspension is not working properly, this warning • Be sure to inject oil for exclusive use of message will appear on the cluster LSD when replacing Rear Differential display.

  • Page 296: Launch Control

    Driving your vehicle Launch Control 4. Depress the brake pedal firmly with your left foot, while depressing the accelerator pedal down fully with your if equipped right foot. Then, the engine RPM will The Launch Control system controls the reach an optimized level. vehicle to help reduce wheel spin or slip on a hard acceleration from a standing The message "Launch Control Ready"...

  • Page 297: Limited Use Of Launch Control

    Limited use of Launch Control Information Transmission temperature too high. Launch Control is available again after Launch control not available cooling down by driving the vehicle for at least 3 minutes. CAUTION • Launch Control system is intended for use at a closed race track and not intended for use on public roads.

  • Page 298: Coasting

    Driving your vehicle Coasting Coasting operating conditions if equipped The Coasting function will operate when When certain conditions are met, the the accelerator pedal is depressed and engine is automatically decoupled from released under the following conditions. the transmission while gear remains in D •...

  • Page 299: Coasting Release Conditions

    Coasting release conditions NOTICE The Coasting function will be • If the accelerator pedal is pressed automatically released when the quickly for accelerating with the following conditions are met. Coasting function in operation, • COMFORT, SPORT, or SPORT+ mode is acceleration may occur after the selected for driving mode engagement of the clutch inside the...

  • Page 300: Drive Mode Integrated Control System

    Driving your vehicle Drive Mode Integrated - Engine noise may be louder at some automatic transmission shifts as Control System down-shift requires pressing down more on the accelerator. Drive mode may be selected according to The above situations are normal the driver's preference or road condition.
  • Page 301 • When SPORT mode is activated: Information - The engine RPM will tend to remain SPORT+ mode applied to vehicle raised over a certain length of time equipped with ESC. even after releasing the accelerator - Upshifts are delayed when accelerating CUSTOM mode Information...

  • Page 302: Vehicle Characteristic

    Driving your vehicle Vehicle characteristic The characteristic of each component varies according to which drive mode is selected. DRIVE MODE Component COMFORT Mode SPORT Mode SPORT+ Mode Power train COMFORT SPORT SPORT+ Engine & Driving Launch Control Steering COMFORT SPORT SPORT+ SPORT Chassis...

  • Page 303: Active Air Flap

    Start the vehicle after performing the necessary work like foreign matter removal and waiting 10 minutes. If the pop-up remains up, contact an authorized retailer of Genesis Branded products. CAUTION • Regardless of the pop-up, if the air flaps aren't in the same position, stop the vehicle and wait for 10 minutes and start the vehicle and inspect the air flap.

  • Page 304: Special Driving Conditions

    Driving your vehicle Special Driving Rocking the vehicle If it is necessary to rock the vehicle to free Conditions it from snow, sand, or mud, first turn the steering wheel right and left to clear the area around your front wheels. Then, shift Hazardous driving conditions back and forth between R (Reverse) and a When hazardous driving elements are...

  • Page 305: Smooth Cornering

    Driving in the rain NOTICE Rain and wet roads can make driving If you are still stuck after rocking the dangerous. Here are a few things to vehicle a few times, have your vehicle consider when driving in the rain or on pulled out by a tow vehicle to avoid slick pavement: engine overheating, possible damage to...

  • Page 306: Driving In Flooded Areas

    Driving your vehicle Winter Driving Driving in flooded areas Avoid driving through flooded areas The severe weather conditions of winter unless you are sure the water is no higher quickly wear out tires and cause other than the bottom of the wheel hub. Drive problems.
  • Page 307 Snow tires WARNING Snow tires should be equivalent in size and type to the vehicle's standard tires. Otherwise, the safety and handling of your vehicle may be adversely affected. Use snow tires when road temperature is below 45 °F (7 °C). Refer to the below chart, and mount the recommended snow tire for your vehicle.
  • Page 308 Driving your vehicle Summer tires Tire chains if equipped • Summer tires are used to maximize the driving performance on dry roads. • If the temperature is below 44.6 °F (7 °C) or you are driving on snowy or icy roads, the summer tires lose their brake performance and traction as the tire grip weakens significantly.

  • Page 309: Winter Precautions

    Winter temperatures affect battery performance. Inspect the battery and cables, as specified in chapter 9. The battery charging level can be checked by an authorized retailer of Genesis Branded products or in a service station. 6-55...
  • Page 310 2. When you are not sure block the rear wheels in advance, so the about a type of winter weight oil, consult vehicle may not roll. Then, release the an authorized retailer of Genesis Branded parking brake. products. Do not let ice and snow accumulate...

  • Page 311: Trailer Towing

    Trailer Towing Drive your vehicle when water vapor condenses and accumulates inside the exhaust pipes We do not recommend using this vehicle for trailer towing. When the vehicle is stopped for a long time in winter while the engine is running, WARNING water vapor may condense and accumulate inside the exhaust pipes.

  • Page 312: Vehicle Load Limit

    Driving your vehicle Vehicle Load Limit GAWR (Gross Axle Weight Rating) This is the maximum allowable Two labels on your driver's door sill weight that can be carried by a single show how much weight your vehicle axle (front or rear). These numbers was designed to carry: the Tire and are shown on the Certification Label.

  • Page 313: The Loading Information Label

    The Loading Information Type D Label Type A OIK059166N Type E OIK057176N Type B OIK057174N The label located on the driver's door sill gives the original tire size, cold tire OIK059165N pressures recommended for your Type C vehicle, the number of people that can be in your vehicle and vehicle capacity weight.
  • Page 314 Driving your vehicle Seating capacity 4.The resulting figure equals the available amount of cargo and Total : 5 persons (Front seat : 2 luggage load capacity. For persons, Rear seat : 3 persons) example, if the "XXX" amount Seating capacity is the maximum equals 1400 lbs.
  • Page 315 Example 1 ≥ Maximum Passenger Weight Cargo Weight Load (1400 (1100 lbs.) (150 lbs. × 2 = 300 lbs.) lbs.) (499 kg) (68 kg × 2 = 136 kg) (635 kg) Example 2 ≥ Maximum Passenger Weight Cargo Weight Load (1400 (650 lbs.) (150 lbs.
  • Page 316 Driving your vehicle Certification label handling and braking ability, and cause an accident. • Do not overload your vehicle. Overloading your vehicle can cause heat buildup in your vehicle's tires and possible tire failure, increased stopping distances and poor vehicle handling-all of which may result in a collision.
  • Page 317 7. Driver assistance system Driver Assistance System Notice ................... 7-3 Forward Collision-Avoidance Assist (FCA) (Sensor Fusion) ......... 7-3 Forward Collision-Avoidance Assist settings............. 7-5 Forward Collision-Avoidance Assist operation............7-7 Forward Collision-Avoidance Assist malfunction and limitations......7-11 Lane Keeping Assist (LKA)....................7-18 Lane Keeping Assist settings..................7-18 Lane Keeping Assist operation...................7-19 Lane Keeping Assist malfunction and limitations ............
  • Page 318 Navigation-based Smart Cruise Control (NSCC)............7-66 Navigation-based Smart Cruise Control settings ............ 7-67 Navigation-based Smart Cruise Control operation ..........7-67 Limitations of Navigation-based Smart Cruise Control ......... 7-68 Lane Following Assist (LFA)....................7-71 Lane Following Assist settings .................. 7-72 Lane Following Assist operation ................7-72 Lane Following Assist malfunction and limitations ..........

  • Page 319: Driver Assistance System Notice

    Driver Assistance System Forward Notice Collision-Avoidance Assist (FCA) (Sensor Information Fusion) Due to infotainment software versions, the description of each function of the driver assistance system may differ from Basic function the owner's manual. OIK073001 Forward Collision-Avoidance Assist helps detect a vehicle, a powered two-wheeler, a pedestrian, or a cyclist ahead on the road and may warn you of a possible collision with a warning message on the...
  • Page 320 • If the detecting sensors have been replaced or repaired, have your vehicle inspected by an authorized retailer of Genesis Branded products. • Never install any accessories or stickers on the front windshield, or tint the front windshield.

  • Page 321: Forward Collision-Avoidance Assist (Fca) (Sensor Fusion)

    Genesis Branded products. • If Forward Safety is selected, Forward • Use only genuine Genesis parts to Collision-Avoidance Assist will warn the repair or replace a damaged front radar driver with a warning message, an cover.
  • Page 322 Driver assistance system CAUTION Information The setting for Forward Safety includes When the engine is restarted, Forward Basic function, Junction Turning, and Safety Warning Timing maintains the last Direct Oncoming. setting. Forward Safety Warning Timing Warning Methods OIK073006N OIK073007N With the engine on, select Setup > The Warning Methods can be set with the Vehicle >...

  • Page 323: Forward Collision-Avoidance Assist Operation

    • If a vehicle or powered two-wheeler is Information detected in front, the function will operate when your vehicle speed is • If you change the Warning Methods, about 6-124 mph (10-200 km/h). the Warning Methods of other Driver assistance systems may change. •...
  • Page 324 Driver assistance system Collision Warning WARNING • The operating speed range may be limited depending on the state of the vehicle in front or the surroundings. • During night driving, detection of powered two-wheelers may degrade and Forward Collision-Avoidance Assist may not operate properly or be temporarily limited.
  • Page 325 Collision Warning • The function will operate when your vehicle speed is about 6-19 mph (10-30 km/h) and the oncoming vehicle, powered two-wheeler speed is about 19-44 mph (30-70 km/h). Stopping vehicle and ending brake control OIK070007L To warn the driver of a collision, the "Collision Warning"...
  • Page 326 Driver assistance system • The function will operate when your Information vehicle speed is about 19-80 mph (30-130 km/h) and the oncoming When a collision warning is being issued vehicle or powered two-wheeler speed or emergency braking is being engaged, is above 6 mph (10 km/h).

  • Page 327: Forward Collision-Avoidance Assist Malfunction And Limitations

    Assist warning and collision mitigation Forward Safety system" warning are possible depending on the message will appear, and the detectable distance. warning lights will illuminate on the instrument cluster. Have your vehicle inspected by an authorized retailer of Genesis Branded products. 7-11...
  • Page 328 (snow, rain, or foreign material) is removed (including trailer, carrier, etc., from the rear bumper), have your vehicle inspected by an authorized retailer of Genesis Branded products. WARNING • Even though the warning message or warning light does not appear on the...
  • Page 329 • Driving in vast areas where there are • The field of view of the front view camera is obstructed by sun glare few vehicles or structures (for example, desert, meadow, suburb, etc.) • Street light or light from an oncoming traffic is reflected on the wet road •...
  • Page 330 Driver assistance system • The adverse road conditions cause excessive vehicle vibrations while driving • Your vehicle height is low or high due to heavy loads, abnormal tire pressure, etc. • Driving through a narrow road where trees or grass are overgrown •...
  • Page 331 • Driving on an inclined road When driving on a curve, you must maintain a safe braking distance, and if necessary, depress the brake pedal to reduce your driving speed in order to maintain a safe distance. 2C_FCADrivingOnInclinedLoad 2C_FCADrivingOnCurveLoad_3 2C_FCADrivingOnInclinedLoad_2 2C_FCADrivingOnCurveLoad_4 Forward Collision-Avoidance Assist may detect a vehicle, powered...
  • Page 332 Driver assistance system cyclist in front of you while driving the vehicle changes lanes abruptly. In uphill or downhill, adversely affecting this case, you must maintain a safe the performance of the sensors. braking distance, and if necessary, steer your vehicle and depress the This may result in unnecessary warning, brake pedal to reduce your driving braking assist or no warning, braking...
  • Page 333 • Detecting vehicle • Forward Collision-Avoidance Assist may not operate for about 15 seconds after the vehicle is started, or the front view camera is initialized. Information This device complies with Part 15 of the FCC rules. Operation is subject to the following three conditions: 2C_FCADetectingVehicle If the vehicle in front of you has cargo...

  • Page 334: Lane Keeping Assist (Lka)

    Driver assistance system Lane Keeping Assist (LKA) Lane Keeping Assist settings While driving over a certain speed, Lane Lane Safety Keeping Assist helps detect lane markings (or road edges) and may warn you if your vehicle leaves the lane without using the turn signal and may assist with steering to help prevent your vehicle departing from its travel lane.

  • Page 335: Lane Keeping Assist Operation

    Warning Methods Information • If you change the Warning Methods, the Warning Methods of other Driver assistance systems may change. • The Warning Volume and Haptic Warning cannot be turned off at the same time. When one of the warning is turned off the other is activated.
  • Page 336 Driver assistance system Warning and control steering wheel will make adjustments to help keep vehicle inside the lane. Lane Keeping Assist will warn and help control the vehicle with Lane Departure • Lane Keeping Assist will operate when Warning and Lane Keeping Assist. your vehicle speed is about 0-120 mph (60-200 km/h).

  • Page 337: Lane Keeping Assist Malfunction And Limitations

    If this occurs, have your vehicle inspected OIK073086 by an authorized retailer of Genesis Lane detected Branded products. Lane Keeping Assist disabled OIK073020 • The images and colors in the cluster...
  • Page 338 Genesis Branded products. • There are road markings, such as zigzag lanes, crosswalk markings and road WARNING signs •...

  • Page 339: Blind-Spot Collision-Avoidance Assist (Bca)

    Blind-Spot • Refer to the "Lane Keeping Assist malfunction and limitations" if the lane Collision-Avoidance is not detected properly. Assist (BCA) • When you are towing a trailer or another vehicle, turn off Lane Keeping Assist for safety reasons. Blind-Spot Collision-Avoidance Assist helps detect approaching vehicles in the •...
  • Page 340 Blind-Spot Genesis Branded products. Collision-Avoidance Assist judges that • Use only genuine Genesis parts to there is a collision risk with an repair the rear bumper where the rear approaching vehicle in the blind spot, it corner radar is located.

  • Page 341: Blind-Spot Collision-Avoidance Assist Settings

    • Do not apply license plate frame or objects, such as a bumper sticker, film or a bumper guard near the rear corner radar. • Blind-Spot Collision-Avoidance Assist may not work properly if the bumper has been replaced, or the surroundings of the rear corner radar have been damaged or paint has been applied.

  • Page 342: Blind-Spot Collision-Avoidance Assist Operation

    Driver assistance system Blind-Spot Warning Methods Collision-Avoidance Assist operation Collision warning OIK073007N The Warning Methods can be set with the engine on. • Warning Volume: Select Setup > Vehicle > Driver Assistance > Warning Methods > Warning Volume from the OIK073207 To warn the driver a vehicle is detected, Settings menu in the infotainment...
  • Page 343 Collision-avoidance assist (while WARNING parallel parking exit) • The detecting range of the rear corner radar is determined by a standard road width, therefore, on a narrow road, Blind-Spot Collision-Avoidance Assist may detect other vehicles two lanes over and warn you. In contrast, on a wide road, Blind-Spot Collision-Avoidance Assist may not be able to detect a vehicle driving in the...
  • Page 344 Driver assistance system • Driver should maintain control of the • Brake control will end after the vehicle is stopped by emergency braking for vehicle at all times. Do not depend on about 2 seconds. Blind-Spot Collision-Avoidance Assist. Maintain a safe braking distance, and if WARNING necessary, depress the brake pedal to reduce driving speed or to stop the...

  • Page 345: Blind-Spot Collision-Avoidance Assist Malfunction And Limitations

    If Blind-Spot Collision-Avoidance Assist does not operate properly after it is removed, have your vehicle inspected by an authorized retailer of Genesis Branded products. OIK073279L When the side view mirror warning light is not working properly, the "Check side view mirror warning light"...
  • Page 346 Driver assistance system Limitations of Blind-Spot WARNING Collision-Avoidance Assist • Even though the warning message Blind-Spot Collision-Avoidance Assist does not appear on the instrument may not operate properly, or it may cluster, Blind-Spot Collision-Avoidance operate unexpectedly under the Assist may not properly operate. following circumstances: •...
  • Page 347 • A trailer, carrier or other attachment is WARNING installed around the rear corner radar • Driving on a curved road • The bumper around the rear corner radar is covered with objects, such as a bumper sticker, bumper guard, bike rack, etc.
  • Page 348 Driver assistance system • Driving on an inclined road • Driving where the heights of the lanes are different OIK073210 Blind-Spot Collision-Avoidance Assist OIK073212L may not operate properly when driving Blind-Spot Collision-Avoidance Assist on a slope. The function may not detect may not operate properly when driving the vehicle in the next lane or may where the heights of the lanes are...

  • Page 349: Safe Exit Warning (Sew)

    Safe Exit Warning (SEW) Information This device complies with Part 15 of the FCC rules. Operation is subject to the following three conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation.

  • Page 350: Safe Exit Warning Settings

    Driver assistance system Safe Exit Warning settings • Warning Volume: Select Setup > Vehicle > Driver Assistance > Warning Methods > Warning Volume from the Safe Exit Warning Settings menu in the infotainment system to change the warning volume. If you turn off the Warning Volume, for your safety, the function may warn you with a low volume.
  • Page 351 • The driver and passengers are responsible for accidents that occur while exiting the vehicle. Always check the surroundings before you exit the vehicle. • Never deliberately operate Safe Exit Warning. Doing so may lead to serious injury or death. •...

  • Page 352: Safe Exit Warning Malfunction And Limitations

    Radar blocked" If this occurs, have your vehicle inspected warning message will appear on the by an authorized retailer of Genesis instrument cluster. Branded products. Safe Exit Warning will operate properly when such foreign material or trailer, etc., is removed, and then the vehicle is restarted.

  • Page 353: Manual Speed Limit Assist (Msla)

    Manual Speed Limit CAUTION Assist (MSLA) Turn off Safe Exit Warning to install or remove a trailer, carrier, or another attachment. Turn on Safe Exit Warning when finished. Limitations of Safe Exit Warning Safe Exit Warning may not operate properly, or it may operate unexpectedly under the following circumstances: •...
  • Page 354 Driver assistance system 2. Push the + switch up or - switch down, Information and release it at the desired speed. • When the accelerator pedal is not Push the + switch up or - switch down depressed beyond the pressure point, and hold it.

  • Page 355: Intelligent Speed Limit Assist (Isla)

    Intelligent Speed Limit If you push the + switch up or - switch down, vehicle speed will be set to the Assist (ISLA) current speed on the instrument cluster. If you press the switch, vehicle speed if equipped will resume to the preset speed. Intelligent Speed Limit Assist uses information from the detected road signs Turning off Manual Speed Limit...

  • Page 356: Intelligent Speed Limit Assist Settings

    Driver assistance system Intelligent Speed Limit Assist WARNING settings For your safety, only change the Settings after parking the vehicle at a safe Speed Limit location. Information • Speed Limit Assist function operates based on the Offset setting added to the speed limit.
  • Page 357 Displaying speed limit Warning overspeed OIK073216N OIK073217N Speed limit information appears on the When driving at a speed higher than the instrument cluster. displayed speed limit, the speed limit is displayed in red. Information Changing set speed • If speed limit information of the road cannot be recognized, "---"...

  • Page 358: Intelligent Speed Limit Assist Malfunction And Limitations

    Genesis • If the speed limit of the road is under 20 Branded products. mph (30 km/h), the Changing set speed and Set speed auto change functions will not work.
  • Page 359 • The vehicle encounters illuminant road your vehicle inspected by an authorized signs retailer of Genesis Branded products. • Intelligent Speed Limit Assist incorrectly recognizes numbers or WARNING illustrations in the street signs or other signs as the speed limit •...
  • Page 360 Driver assistance system • Headlights are not used or the WARNING brightness of the headlights are weak at night or in the tunnel • Intelligent Speed Limit Assist is a supplemental function that helps the • Road signs are difficult to recognize driver to comply with the speed limit on due to the reflection of sunlight, street the road, and may not display the...

  • Page 361: Driver Attention Warning (Daw)

    Driver Attention Warning CAUTION (DAW) • Always keep the front view camera in good condition to maintain optimal performance of Driver Attention Basic function Warning. Driver Attention Warning monitors your • For more information on the driving pattern while driving. When the precautions of the front view camera, driver's attention level is below a certain refer to the "Forward...

  • Page 362: Driver Attention Warning Operation

    Driver assistance system Driver Attention Warning WARNING operation For your safety, only change the Settings after parking the vehicle at a safe Basic function location. The basic function of Driver Attention Warning is to warn the driver "Consider taking a break". CAUTION Taking a break •...

  • Page 363: Driver Attention Warning Malfunction And Limitations

    If generated, Leading Vehicle Departure this occurs, have your vehicle inspected Alert's warning message may not be by an authorized retailer of Genesis displayed and audible warning may not Branded products. be generated. • The driver has the responsibility to safely drive and control the vehicle.
  • Page 364 If Driver Leading vehicle departure alert function Attention Warning does not operate properly after it is removed, have your • When the vehicle cuts in vehicle inspected by an authorized retailer of Genesis Branded products. OIK073220 7-48...
  • Page 365 • When the vehicle ahead abruptly departures OIK073221 [A] Your vehicle [B] Front vehicle OIK073223 If a vehicle cuts in front of your vehicle, If the vehicle in front abruptly Leading Departure Alert may not departures, Leading Vehicle Departure operate properly. Alert may not operate properly.
  • Page 366 Driver assistance system • When in a parking lot WARNING Driver Attention Warning may not operate for about 15 seconds after the vehicle is started, or the front view camera is initialized. Information For more information on the precautions of the front view camera, refer to the OIK073225 "Forward Collision-Avoidance Assist If a vehicle parked in front drives away...

  • Page 367: Blind-Spot View Monitor (Bvm)

    Blind-Spot View Monitor Detecting sensor (BVM) if equipped Left side OIK073034L (1) Wide-side view camera (camera located at bottom of the mirror) (2) Wide-side view camera (camera located at bottom of the mirror) See the illustration above for the detailed OIK073169N location of the detecting sensors.

  • Page 368: Blind-Spot View Monitor Operation

    Genesis Brand products. WARNING • The image shown on the instrument cluster may differ from the actual distance of the object. Make sure to directly check the vehicle's surroundings for safety.

  • Page 369: Smart Cruise Control (Scc)

    Smart Cruise Control Smart Cruise Control settings (SCC) Smart Cruise Control Smart Cruise Control detects a vehicle ahead and helps maintain the distance from the vehicle ahead and the set speed. Overtaking Acceleration Assist When Smart Cruise Control judges you are attempting to overtake a vehicle in front, Smart Cruise Control helps with accelerating.

  • Page 370: Smart Cruise Control Operation

    Driver assistance system • Haptic Warning: Select Setup > • ESC (Electronic Stability Control) or Vehicle > Driver Assistance > Warning ABS (Anti-Lock Braking System) is on Methods > Haptic Warning from the Smart Cruise Control does not operate in Settings menu in the infotainment the following conditions.
  • Page 371 Setting vehicle distance • Regardless of the driving direction in your country, Overtaking Acceleration Assist will operate when the conditions are satisfied. When using the function in countries with different driving direction, always check the road conditions at all times. Turning on Smart Cruise Control OIK073036 Press the button repeatedly to cycle...
  • Page 372 Driver assistance system Increasing set speed Decreasing set speed OIK073037 OIK073038 • Push the + switch up and release it • Push the - switch down and release it immediately. The set speed will immediately. The set speed will increase by 1 mph (1 km/h) each time decrease by 1 mph (1 km/h) each time the switch is operated in this manner.
  • Page 373 Resuming Smart Cruise Control Information If your vehicle is equipped with Manual Speed Limit Assist, press and hold the Driving Assist ( ) button to turn off Smart Cruise Control. However Manual Speed Limit Assist will turn on. CAUTION Do not use the switches and buttons at OIK073040 the same time.
  • Page 374 Driver assistance system Temporarily canceled If you want to speed up temporarily without altering the set speed while Smart Cruise Control is operating, depress the accelerator pedal. While the accelerator pedal is depressed, the set speed, distance level and target distance will blink on the instrument cluster.
  • Page 375 In traffic situation Information If Smart Cruise Control is temporarily canceled while the vehicle is at a standstill with the function activated, EPB (Electronic Parking Brake) maybe applied. WARNING When Smart Cruise Control is temporarily canceled, distance with the front vehicle will not be maintained.
  • Page 376 Driver assistance system WARNING WARNING Always pay attention to vehicles or Take the following precautions when objects that may suddenly appear in front using Smart Cruise Control: of you, and if necessary, depress the • Smart Cruise Control does not brake pedal to reduce your driving speed substitute for proper and safe driving.

  • Page 377: Smart Cruise Control Malfunction And Limitations

    • If any other system’s warning message If this occurs, have your vehicle inspected appears or warning sound is generated, by an authorized retailer of Genesis Smart Cruise Control warning message Branded products. may not be displayed and warning sound may not be generated.
  • Page 378 Driver assistance system Smart Cruise Control will operate • The brightness changes suddenly, for properly when snow, rain or foreign example when entering or exiting a material is removed. tunnel • The brightness outside is low, and the WARNING headlights are not on or are not bright Even though the warning message does •...
  • Page 379 • Driving on a curved road • The vehicle in front is suddenly blocked by an obstacle • The vehicle in front suddenly changes lane or suddenly reduces speed • The vehicle in front is bent out of shape • The front vehicle’s speed is fast or slow •...
  • Page 380 Driver assistance system • Driving on an inclined road • Changing lanes 2C_FCADrivingOnInclinedLoad During uphill or downhill driving, the Smart Cruise Control may not detect a moving vehicle in your lane, and cause your vehicle to accelerate to the set speed.
  • Page 381 • Situations when detecting are limited - Animals and pedestrians Adjust your vehicle speed by depressing the brake pedal according to the road and driving conditions ahead. In the following cases, the vehicle in front cannot be detected by the sensor: - You are steering your vehicle - Driving on narrow or sharply curved roads...

  • Page 382: Navigation-Based Smart Cruise Control (Nscc)

    Driver assistance system Navigation-based Smart • Always look out for pedestrians when your vehicle is maintaining a distance Cruise Control (NSCC) with the vehicle ahead. if equipped Navigation-based Smart Cruise Control helps maintain appropriate speed depending on the road conditions by using information from the navigation system when driving on highways while Smart Cruise Control is operating.

  • Page 383: Navigation-Based Smart Cruise Control Settings

    Navigation-based Smart Navigation-based Smart Cruise Control display and control Cruise Control settings When Navigation-based Smart Cruise Control operates, it appears on the instrument cluster as follows: Navigation-based Smart Cruise Control standby If the operating conditions are satisfied, the white symbol will illuminate. OIK073104N With the engine on, select Setup >...

  • Page 384: Limitations Of Navigation-Based Smart Cruise Control

    Driver assistance system Limitations of WARNING Navigation-based Smart Cruise Control Navigation-based Smart Cruise Control may not operate properly under the following circumstances: • The navigation is not working properly • Map information is not transmitted due to infotainment system's abnormal operation •...
  • Page 385 • Driving on a road that is sharply curved • When there is a difference between the navigation route (main road) and the driving route (branch line), Highway Curve Zone Auto Slowdown function will operate based on the curve information on the main road. •...
  • Page 386 Driver assistance system • If the driver accelerates and releases WARNING the accelerator pedal while Navigation-based Smart Cruise Control • Navigation-based Smart Cruise Control is operating, the vehicle may not is not a substitute for safe driving decelerate sufficiently or may rapidly practices, but a convenience function.

  • Page 387: Lane Following Assist (Lfa)

    Lane Following Assist Information (LFA) This device complies with Part 15 of the FCC rules. Lane Following Assist helps detect lane Operation is subject to the following three markings and/or a vehicle ahead on the conditions: road, and helps center your vehicle in the lane.

  • Page 388: Lane Following Assist Settings

    Driver assistance system Lane Following Assist settings Lane Following Assist operation Warning Methods Turning Lane Following Assist On/Off OIK073007N The Warning Methods can be set with the engine on. OIK073016 With the engine on, shortly press the Lane • Warning Volume: Select Setup > Driving Assist ( ) button located on the Vehicle >...
  • Page 389 Warning and control First stage: Warning message Second stage: Warning message (red Lane Following Assist steering wheel) and audible warning OIK073090N If the vehicle ahead and/or both lane OTM070117N markings are detected and your vehicle If the driver still does not have their hands speed is below 120 mph (200 km/h), the on the steering wheel after the hands-off warning, the "Lane Following Assist (LFA)

  • Page 390: Lane Following Assist Malfunction And Limitations

    ( ) warning light will illuminate on the instrument cluster. If this occurs, have your vehicle inspected by an authorized retailer of Genesis Branded products. Limitations of Lane Following Assist For more information on Lane Following OIK070086 Assist limitations, refer to the "Lane...

  • Page 391: Highway Driving Assist (Hda)

    Highway Driving Assist Detecting sensor (HDA) if equipped Highway Driving Assist helps maintain a set distance and speed from the vehicle ahead while driving on a highway main section and helps center the vehicle in the lane. OIK073004L (1) Front view camera (2) Front radar See the illustration above for the detailed location of the detecting sensors.

  • Page 392: Highway Driving Assist Settings

    Information changed. Have your vehicle inspected • If you change the Warning Methods, by an authorized retailer of Genesis the Warning Methods of other Driver Branded products. Assistance systems may change. • If the engine is restarted, the •...

  • Page 393: Highway Driving Assist Operation

    Highway Driving Assist 2. Set speed operation 3. Lane Following Assist indicator 4. Whether there is a vehicle ahead and the selected headway Basic function 5. Whether the lane is detected or not Displaying operating status Information You can see the status of the Highway Driving Assist operation in the Driving •...
  • Page 394 Driver assistance system Restarting after stopping When Highway Driving Assist is operating, your vehicle will stop if the vehicle ahead of you stops. Also, if the vehicle ahead of you starts moving within 30 seconds after the stop, your vehicle will start as well.

  • Page 395: Highway Driving Assist Malfunction And Limitations

    (navigation information) and light will illuminate on the instrument surroundings. cluster. Have your vehicle inspected by an authorized retailer of Genesis Branded products WARNING • The driver is responsible for controlling the vehicle for safe driving. 7-79...
  • Page 396 Driver assistance system Limitations of Highway Driving • Lane Following Assist function may be temporarily disabled when the front Assist view camera cannot detect lanes Highway Driving Assist may not operate properly or the hands-off warning is on. properly, or it may not operate under the •...

  • Page 397: Rear View Monitor (Rvm)

    Rear View Monitor (RVM) Information if equipped This device complies with Part 15 of the FCC rules. Rear View Monitor displays the area behind your vehicle to help with safe Operation is subject to the following three parking. conditions: 1. This device may not cause harmful Detecting sensor interference, and 2.

  • Page 398: Rear View Monitor Settings

    Driver assistance system Rear View Monitor settings Camera settings Warning Methods OIK073273N You can change Rear View Monitor Display Contents by touching the setup OIK073007N icon ( ) on the screen while Rear View The Warning Methods can be set with the Monitor is operating, select Setup >...

  • Page 399: Rear View Monitor Operation

    Rear View Parking Lines Rear view OIK073237N OIK073238N If Rear View Parking Lines is selected, the Operating conditions rear view parking guide lines and rear top view guide lines appear on the Rear View • Shift the gear to R (Reverse), the rear Monitor screen.

  • Page 400: Rear View Monitor Malfunction And Limitations

    When Rear View Monitor is not working properly, or the screen flickers, or the camera image does not display properly, have your vehicle inspected by an authorized retailer of Genesis Branded products. OIK073239N Limitations of Rear View Monitor When you touch the...

  • Page 401: Surround View Monitor (Svm)

    Surround View Monitor Surround View Monitor settings (SVM) if equipped Warning Methods Surround View Monitor uses the wide view cameras and displays images around your vehicle through the infotainment system to help with safe parking. Detecting sensor OIK073007N The Warning Methods can be set with the engine on.
  • Page 402 Driver assistance system Rear View Parking Lines Camera settings When the Rear View Parking Lines is selected, parking guidance appears in the rear view. Information The horizontal guideline shows the distance of 1.6 ft. (0.5 m), 3.3 ft. (1 m) and 7.6 ft.

  • Page 403: Surround View Monitor Operation

    Operating conditions Surround View Monitor operation • The gear is shifted to N (Neutral) or D (Drive) from R (Reverse) and the vehicle speed is 6 mph (10 km/h) or less. Parking/View button • The Parking/View button (1) is pressed, while the gear is in N (Neutral) or D (Drive), and vehicle speed is 6 mph (10 km/h) or less.

  • Page 404: Surround View Monitor Malfunction And Limitations

    When Surround View Monitor is not working properly, or the screen flickers, or the camera image does not display properly, have your vehicle inspected by an authorized retailer of Genesis Branded products. OIK073267N Limitations of Surround View The rear view appears on the screen to Monitor assist in parking.

  • Page 405: Rear Cross-Traffic Collision-Avoidance Assist (Rcca)

    Rear Cross-Traffic • Surround View Monitor is designed to be used on a flat surface. Therefore, if Collision-Avoidance used on roads with different heights such as curbs and speed bumps, the Assist (RCCA) image in the screen may not look correct.

  • Page 406: Rear Cross-Traffic Collision-Avoidance Assist Settings

    Driver assistance system Detecting sensor WARNING When the engine is restarted, Rear Cross-Traffic Collision-Avoidance Assist will always turn on. However, if "Off" is selected after the engine is restarted, the driver should always be aware of the surroundings and drive safely. Warning Methods OIK073021 (1) Rear corner radar...

  • Page 407: Rear Cross-Traffic Collision-Avoidance Assist Operation

    Rear Cross-Traffic To warn the driver of an approaching vehicle from the rear left/right side of Collision-Avoidance Assist your vehicle, the warning light on the side operation view mirror will blink and a warning will appear on the instrument cluster. At the same time, an audible warning will sound Collision Warning and the steering wheel will vibrate.
  • Page 408 Driver assistance system Emergency Braking • The approaching vehicle is within about 5 ft. (1.5 m) from the left and right side of your vehicle • The speed of the vehicle approaching from the left and right is above 3 mph (5 km/h) •...
  • Page 409 • Brake control will end after the vehicle • Rear Cross-Traffic Collision-Avoidance is stopped by emergency braking for Assist does not operate in all situations about 2 seconds. or cannot avoid all collisions. • During emergency braking, braking • Rear Cross-Traffic Collision-Avoidance control by Rear Cross-Traffic Assist may warn the driver late or may Collision-Avoidance Assist will...

  • Page 410: Rear Cross-Traffic Collision-Avoidance Assist Malfunction And Limitations

    If Rear Cross-Traffic Collision-Avoidance Assist does not operate properly after it is removed, have your vehicle inspected by an authorized retailer of Genesis Branded products. OIK073279L When the side view mirror warning light is not working properly, the "Check side view mirror warning light"...
  • Page 411 WARNING Information • Even though the warning message For more information on the limitations of does not appear on the instrument the rear corner radar, refer to the cluster, Rear Cross-Traffic "Blind-Spot Collision-Avoidance Assist Collision-Avoidance Assist may not (BCA)" section in this chapter. operate properly.
  • Page 412 Driver assistance system • When the vehicle is on or near a slope (for example, a vehicle leaving beside your vehicle, a vehicle parking or pulling out in the rear area, a vehicle approaching your vehicle making a turn, etc.). If this occurs, the function may unnecessarily warn the driver and control the brake.
  • Page 413 • When the vehicle is parked rearward Information This device complies with Part 15 of the FCC rules. Operation is subject to the following three conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired 2C_RCCAParkRearward...

  • Page 414: Reverse Parking Distance Warning (Pdw)

    Driver assistance system Reverse Parking Distance • Warning Volume: Select Setup > Vehicle > Driver Assistance > Warning Warning (PDW) Methods > Warning Volume from the Settings menu in the infotainment if equipped system to change the warning volume. Reverse Parking Distance Warning uses If you turn off the Warning Volume, for the rear ultrasonic sensors to detect and your safety, the function may warn you...

  • Page 415: Reverse Parking Distance Warning Malfunction And Limitations

    If it still does not work properly, have your vehicle inspected by within 12 Beeps an authorized retailer of Genesis Branded in. (30 cm) continuously products. • The audible warning does not sound.
  • Page 416 - Water flows on the surface of the vehicle inspected by an authorized sensor retailer of Genesis Branded products. - Affected by another vehicle's sensors - The sensor is covered with snow or - Driving on uneven road, gravel roads...

  • Page 417: Forward/Reverse Parking Distance Warning (Pdw)

    • If the Parking Distance Warning does not operate properly, have your vehicle inspected by an authorized retailer of Genesis Branded products. OIK073092 (1) Front ultrasonic sensors (2) Rear ultrasonic sensors Refer to the picture above for the detailed location of the detecting sensors.

  • Page 418: Forward/Reverse Parking Distance Warning Settings

    Driver assistance system Forward/Reverse Parking Forward/Reverse Parking Distance Warning settings Distance Warning operation Warning Methods Parking Safety button OIK073007N OIK073078 The Warning Methods can be set with the Press the Parking Safety ( ) button to engine on. turn on Forward/Reverse Parking Distance Warning.
  • Page 419 Forward Parking Distance Warning Warning Forward Parking Distance Warning will indicator Distance Warning operate when one of the condition is from object sound satisfied. Cluster Infotainment • The gear is shifted from R (Reverse) to D (Drive) with Reverse Parking Distance Warning on 12-24 in.

  • Page 420: Forward/Reverse Parking Distance Warning Malfunction And Limitations

    If it still does not work (30-60 cm) frequently properly, have your vehicle inspected by an authorized retailer of Genesis Branded products. • The audible warning does not sound. within 12 in. Beeps • The buzzer sounds intermittently.
  • Page 421 - Heavy rain or water spray is present vehicle inspected by an authorized - Water flows on the surface of the retailer of Genesis Branded products. sensor - Affected by another vehicle's sensors - The sensor is covered with snow or...

  • Page 422: Declaration Of Conformity

    • If the Parking Distance Warning does not operate properly, have your vehicle inspected by an authorized retailer of Genesis Branded products. OANATEL125 7-106...

  • Page 423: Rear Corner Radar

    Rear corner radar • For Canada The radio frequency components complies: • For USA OANATEL024 OANATEL126 7-107...
  • Page 424 Driver assistance system • For Canada OANATEL512 7-108...
  • Page 425 8. Emergency situations Hazard Warning Flasher ....................8-2 In Case Of An Emergency While Driving................ 8-2 If the engine stalls while driving ................. 8-2 If the engine stalls at a crossroad or crossing............8-2 If you have a flat tire while driving................8-3 If The Engine Will Not Start.....................8-3 Jump Starting ........................8-4 If The Engine Overheats....................8-6...

  • Page 426: Emergency Situations

    • Try to start the engine again. If your OIK083001 vehicle will not start, contact an The hazard warning flasher serves as a authorized retailer of Genesis Branded warning to other drivers to exercise products or seek other qualified extreme caution when approaching, assistance.

  • Page 427: If You Have A Flat Tire While Driving

    If you are on a If the vehicle still does not start, call an divided highway, do not park in the authorized retailer of Genesis Branded median area between the two traffic products for assistance. lanes.

  • Page 428: Jump Starting

    Emergency situations Jump Starting Jump starting can be dangerous if done incorrectly. Follow the jump starting Batteries contain sulfuric acid which is procedure in this section to avoid serious highly corrosive. Do not allow acid to injury or damage to your vehicle. If in contact your eyes, skin or clothing.
  • Page 429 6.Connect the jumper cables in the exact of Genesis Branded products. sequence shown in the illustration. First connect one jumper cable to the red, positive (+) jumper terminal of your...

  • Page 430: If The Engine Overheats

    Emergency situations If The Engine Overheats Disconnect the jumper cables in the exact reverse order you connected them: If your temperature gauge indicates 1. Disconnect the jumper cable from the overheating, you experience a loss of black, negative (-) chassis ground of power, or hear loud pinging or knocking, your vehicle (4).
  • Page 431 5. If engine coolant is leaking out, stop the CAUTION engine immediately and call the nearest authorized retailer of Genesis • Serious loss of coolant indicates a leak Branded products for assistance. in the cooling system and should be checked as soon as possible by an...

  • Page 432: Tire Pressure Monitoring System (Tpms)

    Emergency situations Tire Pressure Monitoring Check tire pressure System (TPMS) OIK080023L • You can check the tire pressure in the OIK083004 Utility view on the cluster. Refer to the "Cluster Display (Type A)", "Cluster Display (Type B)" section in chapter 4. •...

  • Page 433: Tire Pressure Monitoring System

    Genesis Branded products. your tires as soon as possible, and inflate them to the proper pressure. Driving on a 1. The Low Tire Pressure Telltale/ TPMS...

  • Page 434: Low Tire Pressure Warning Light

    Emergency situations Low tire pressure warning If you cannot reach a service station or if the tire cannot hold the newly added air, light replace the low pressure tire with the spare tire. The Low Tire Pressure Telltale will remain on and the TPMS Malfunction Indicator may blink for one minute and then remain illuminated until you have the low...

  • Page 435: Tpms (Tire Pressure Monitoring System) Malfunction Indicator

    NOTICE It is recommended that you do not use a puncture-repairing agent not approved by an authorized retailer of Genesis Branded products to repair and/or inflate a low pressure tire. Tire sealant not OIK083054...
  • Page 436 Emergency situations Always use a good quality tire pressure WARNING gauge to measure. Please note that a tire that is hot (from being driven) will have a This device complies with Part 15 of the higher pressure measurement than a tire FCC rules.

  • Page 437: If You Have A Flat Tire (With Spare Tire)

    If You Have A Flat Tire (with Spare Tire) if equipped WARNING Changing a tire can be dangerous. Follow the instructions in this section when changing a tire to reduce the risk of serious injury or death. OIK083048L Turn the winged hold down bolt counterclockwise to remove the spare CAUTION tire.

  • Page 438: Changing Tires

    Emergency situations Changing tires WARNING WARNING A vehicle can slip or roll off of a jack causing serious injury or death to you or those nearby. Take the following safety precautions: • Never place any portion of your body under a vehicle that is supported by a jack.
  • Page 439 4. Remove the wheel lug wrench, jack, 7. Place the jack at the designated jacking jack handle, and spare tire from the position under the frame closest to the vehicle. tire you are changing. The jacking positions are plates welded to the 5.
  • Page 440 After changing tires, have an they have metric threads to avoid authorized retailer of Genesis Branded damaging the studs and ensure the wheel products tighten the lug nuts to their is properly secured to the hub.
  • Page 441 When driving with the compact spare tire NOTICE mounted to your vehicle: To prevent damaging the compact spare • Check the tire pressure after installing tire and your vehicle: the compact spare tire. The compact spare tire should be inflated to 60 psi •...

  • Page 442: Jack Label

    Emergency situations Jack label OHYK065011 (1) Model Name (2) Maximum allowable load (3) When using the jack, set your parking brake. (4) When using the jack, stop the engine. (5) Do not get under a vehicle that is supported by a jack. (6) The designated locations under the frame (7) When supporting the vehicle, the base plate of jack must be vertical under the lifting point.

  • Page 443: If You Have A Flat Tire (With Tire Mobility Kit)

    Genesis or if a trailer is in use. Branded products or the equivalent The Tire Mobility Kit is not designed or...

  • Page 444: Notes On The Safe Use Of The Tire Mobility Kit

    0.16 inches (4 mm). Please contact the nearest retailer of Genesis Branded products if the tire cannot be made roadworthy with the Tire Mobility Kit. • Do not use the Tire Mobility Kit if a tire is severely damaged by driving run flat or with insufficient air pressure.

  • Page 445: Components Of The Tire Mobility Kit

    Components of the Tire Mobility Kit OIK083041 (1) Speed restriction label (2) Sealant bottle and label with speed restriction (3) Filling hose (4) Connectors and cable for the power outlet direct connection (5) Holder for the sealant bottle (6) Compressor (7) ON/OFF switch (8) Pressure gauge for displaying the tire inflation pressure (9) Button for reducing the tire inflation pressure...

  • Page 446: Using The Tire Mobility Kit When A Tire Is Flat

    Emergency situations 1. Shake the sealant bottle (2). WARNING Sealant • Keep out of reach of children. • Avoid contact with eyes. • Do not swallow. Using the Tire Mobility Kit When a tire is flat OIK083056 CAUTION 2. Connect the filling hose (3) to the sealant bottle (2) in the direction of (A) and connect the sealant bottle to the holder for the sealant bottle (5) in the...
  • Page 447 4. Unscrew the valve cap from the valve of 6. With the engine ON, switch on the the defective wheel and screw the compressor and let it run for about 5-7 filling hose (3) of the sealant bottle onto minutes to fill the sealant up to proper the valve.
  • Page 448 • Use of the TMK may be ineffectual for tire damage larger than about 0.16 inches (4 mm). Have you contact an authorized retailer of Genesis Branded products if the tire cannot be made roadworthy with the Tire Mobility Kit. OIK083043 12.Plug the compressor power cord into...

  • Page 449: How To Adjust Tire Pressure

    4. Adjust the tire inflation pressure to the WARNING recommended tire inflation. The tire inflation pressure must be With the engine running, proceed as inflated to the proper pressure, refer to follows. the "Tires And Wheels" section in chapter • To increase the inflation pressure : 2.

  • Page 450: Towing

    Wheel lift Towing transmission or the AWD system. OIK083045 (1) Dollies If emergency towing is necessary, contact an authorized retailer of Genesis Branded products or a commercial tow-truck service. Proper lifting and towing procedures are necessary to prevent damage to the vehicle.
  • Page 451 When towing your vehicle in an CAUTION emergency without wheel dollies: • Do not tow the vehicle with the rear 1. Release EPB before turning off the wheels on the ground as this may cause engine. damage to the vehicle. 2.

  • Page 452: Removable Towing Hook

    OIK083018L Rear OIK083017L Rear OIK083020 If towing is necessary, contact an authorized retailer of Genesis Branded OIK083019 products or a commercial tow-truck 2. Remove the hole cover by pressing the service. lower part of the cover on the bumper. If towing service is not available in an 3.
  • Page 453 • Use a towing cable or chain less than 16 CAUTION ft. (5 m) long. Attach a white or red cloth (about 12 in. (30 cm) width) in the The driver must be in the vehicle for middle of the cable or chain for easy steering and braking operations when the visibility.
  • Page 454 Emergency situations NOTICE To avoid damage to your vehicle and vehicle components when towing: • Always pull straight ahead when using the towing hooks. Do not pull from the side or at a vertical angle. • Do not use the towing hooks to pull a vehicle out of mud, sand or other conditions from which the vehicle cannot be driven out under its own...
  • Page 455 9. Maintenance Engine Compartment......................9-4 Maintenance Services .....................9-6 Owner's responsibility ....................9-6 Owner maintenance precautions ................9-6 Owner Maintenance ......................9-7 Owner maintenance schedule ..................9-7 Scheduled Maintenance Services ..................9-9 Normal maintenance schedule (For 2.5 T-GDi) ............9-11 Maintenance under severe usage conditions (For 2.5 T-GDi) ........ 9-14 Normal maintenance schedule (For 3.3 T-GDi) ............
  • Page 456 Checking the coolant level ..................9-25 Changing coolant ...................... 9-28 Brake Fluid........................9-28 Checking the brake fluid level .................. 9-28 Washer Fluid........................9-29 Checking the washer fluid level ................9-29 Air Cleaner ........................9-30 Filter replacement ..................... 9-30 Cabin Air Filter........................ 9-31 Filter inspection ......................
  • Page 457 9. Maintenance Low aspect ratio tires ....................9-50 Fuses..........................9-51 Instrument panel fuse replacement .................9-52 Engine compartment panel fuse replacement............9-53 Fuse/relay panel description..................9-54 Light Bulbs ........................9-66 Headlight, Parking light, Turn signal light, Daytime running light (DRL) replacement .............................9-67 Side repeater light replacement ................9-68 Puddle light replacement ..................

  • Page 458: Maintenance

    Maintenance Engine Compartment 2.5 T-GDi OIK013027 The actual engine compartment in the vehicle may differ from the illustration. (1) Fuse box (2) Windshield washer fluid reservoir (3) Air cleaner (4) Radiator cap (5) Engine coolant reservoir (6) Liquid-cooled intercooler coolant reservoir (7) Engine oil filler cap (8) Engine oil dipstick (9) Brake fluid reservoir...
  • Page 459 3.3 T-GDi OIK013029 The actual engine compartment in the vehicle may differ from the illustration. (1) Fuse box (2) Windshield washer fluid reservoir (3) Air cleaner (4) Radiator cap (5) Engine coolant reservoir (6) Engine oil filler cap (7) Engine oil dipstick (8) Brake fluid reservoir *Battery is in the trunk...

  • Page 460: Maintenance Services

    If you're unsure about any service Detailed warranty information is provided or maintenance procedure, have it done in your Owner's Handbook & Warranty by an authorized retailer of Genesis Information booklet. Branded products. Repairs and adjustments required as a result of improper maintenance or a lack of required maintenance are not covered.

  • Page 461: Owner Maintenance

    The following lists are vehicle checks and inspections that should be performed by the owner or an authorized retailer of WARNING Genesis Branded products at the frequencies indicated to help ensure safe, Performing maintenance work on a dependable operation of your vehicle.
  • Page 462 Maintenance While operating your vehicle: At least twice a year: (for example, every Spring and Autumn) • Note any changes in the sound of the exhaust or any smell of exhaust fumes • Check radiator, heater and air in the vehicle. conditioning hoses for leaks or damage.

  • Page 463: Scheduled Maintenance Services

    • Frequently driving under high speed or replacement interval. Have the rapid acceleration/deceleration engine oil and filter changed by an • Frequently driving in stop-and-go authorized retailer of Genesis condition Branded products. • Engine oil usage which is not - Oil Life Management System works...
  • Page 464 Then, select "Yes" when the message "Changed engine oil? Press [Yes] to reset the oil life." appears on the screen. - If there is no alert until the maximum maintenance interval, have your vehicle checked by an authorized retailer of Genesis Branded products. 9-10...

  • Page 465: Normal Maintenance Schedule (For 2.5 T-Gdi)

    Normal maintenance schedule (For 2.5 T-GDi) I : Inspect and if necessary, adjust, correct, clean or replace. R : Replace or change. Number of months or driving distance, whichever comes first Months 24 36 48 60 72 84 96 108 120 132 144 156 MAINTENANCE INTERVALS Miles×1,000...
  • Page 466 *2 If TOP TIER Detergent Gasoline is not available, one bottle of additive is recommended. Additives are available from your authorized retailer of Genesis Branded products along with information on how to use them. Do not mix other additives.
  • Page 467 If there are some important safety matters like fuel flow restriction, surging, loss of power, hard starting problem, etc. replace the fuel filter immediately regardless of maintenance schedule and consult an authorized retailer of Genesis Branded products for details. 9-13...

  • Page 468: Maintenance Under Severe Usage Conditions (For 2.5 T-Gdi)

    Maintenance Maintenance under severe usage conditions (For 2.5 T-GDi) The following items must be serviced more frequently on cars normally used under severe driving conditions. Refer to the chart below for the appropriate maintenance intervals. R : Replace I : Inspect and if necessary, adjust, correct, clean or replace. Maintenance Driving Maintenance item...
  • Page 469 *1 Requires <API SN PLUS (or above) Full synthetic> grade engine oil. If a lower grade engine oil (mineral oil including Semi-synthetic) is used, then the engine oil and engine oil filter must be replaced as indicated severe maintenance condition. Severe driving conditions A.

  • Page 470: Normal Maintenance Schedule (For 3.3 T-Gdi)

    Maintenance Normal maintenance schedule (For 3.3 T-GDi) I : Inspect and if necessary, adjust, correct, clean or replace. R : Replace or change. Number of months or driving distance, whichever comes first Months 96 108 120 MAINTENANCE INTERVALS Miles×1,000 Km×1,000 90 100 MAINTENANCE ITEM Engine oil and engine oil filter...
  • Page 471 *2 If TOP TIER Detergent Gasoline is not available, one bottle of additive is recommended. Additives are available from your authorized retailer of Genesis Branded products along with information on how to use them. Do not mix other additives.

  • Page 472: Maintenance Under Severe Usage Conditions (For 3.3 T-Gdi)

    If there are some important safety matters like fuel flow restriction, surging, loss of power, hard starting problem, etc. replace the fuel filter immediately regardless of maintenance schedule and consult an authorized retailer of Genesis Branded products for details. Maintenance under severe usage conditions (For 3.3 T-GDi) The following items must be serviced more frequently on cars normally used under severe driving conditions.
  • Page 473 Maintenance Driving Maintenance item Maintenance intervals operation condition Replace every 72,000 mi. Differential oil (front) (AWD) C, E, G, H, I, J (120,000 km) Without Replace every 72,000 mi. (120,000 km) Differential oil C, E, G, H, I, J (rear) Replace every 36,000 mi.

  • Page 474: Explanation Of Scheduled Maintenance Items

    Check the fuel lines, fuel hoses and Air cleaner filter connections for leakage and damage. Have an authorized retailer of Genesis Have the air cleaner filter replaced by an Branded products replace any damaged authorized retailer of Genesis Branded or leaking parts immediately.

  • Page 475: Cooling System

    Check the pads, the disc, and the rotor for any excessive wear-out. Inspect calipers Have the automatic transmission fluid for any fluid leakage. changed by an authorized retailer of Genesis Branded products according to the maintenance schedule. Exhaust pipe and muffler Visually inspect the exhaust pipes, Information...

  • Page 476: Drive Shafts And Boots

    Maintenance Engine Oil Drive shafts and boots Check the drive shafts, boots and clamps for cracks, deterioration, or damage. Checking the engine oil level Replace any damaged parts and, if necessary, repack the grease. Engine oil is used for lubricating, cooling, and operating various hydraulic components in the engine.

  • Page 477: Checking The Engine Oil And Filter

    3.3 T-GDi ORS092072N • (For 3.3 T-GDi) Have engine oil and filter changed by an authorized retailer of Genesis Branded products according to OIK093004 the Maintenance Schedule at the Use only the specified engine oil (Refer to beginning of this chapter.
  • Page 478 Maintenance • If the maintenance schedule to replace WARNING engine oil is exceeded, the engine oil performance may deteriorate and the CALIFORNIA PROPOSITION 65 WARNING engine condition may be affected. Engine oil contains chemicals known to Therefore, replace the engine oil the State of California to cause cancer, according to the maintenance birth defects and reproductive harm.

  • Page 479: Checking The Coolant Level

    Engine Liquid-cooled intercooler coolant/2.5 T-GDi Coolant/Liquid-cooled Intercooler Coolant The high-pressure cooling system has a reservoir filled with year-round antifreeze coolant. The reservoir is filled at the factory. Check the antifreeze protection and coolant level at least once a year, at the OIK093142 beginning of the winter season and Radiator/2.5 T-GDi...
  • Page 480 (deionized) water to bring the level to the MAX mark, but do not overfill. If frequent additions are required, see an authorized retailer of Genesis Branded products for a cooling system inspection. WARNING The electric motor for the cooling fan may...
  • Page 481 Liquid-cooled intercooler coolant WARNING Make sure the coolant cap is properly closed after refilling coolant. Otherwise the engine could be overheated while driving. 1. Check if the coolant cap label is straight in front. Engine compartment front view 2C_CheckCoolantCapLocked_2 Recommended coolant •...

  • Page 482: Changing Coolant

    -31 °F (-35 °C) and higher. Changing coolant Have the coolant changed by an authorized retailer of Genesis Branded products according to the Maintenance Schedule at the beginning of this chapter. OIK093145 Check the fluid level in the reservoir WARNING periodically.

  • Page 483: Washer Fluid

    Washer Fluid NOTICE • Do not allow brake fluid to contact the vehicle's body paint, as it will result in Checking the washer fluid paint damage. level • NEVER use brake fluid which has been exposed to open air for an extended time, as its quality cannot be guaranteed.

  • Page 484: Air Cleaner

    OIK093014 Do not attempt to wash or to rinse it, as water will damage the filter. If soiled, the air cleaner filter must be replaced. Visit an authorized retailer of Genesis Branded products to replace air cleaner filter. 9-30...

  • Page 485: Cabin Air Filter

    Cabin Air Filter 3. Pull out the cover while Pressing and holding the lock on the left side of the cover. Filter inspection The cabin air filter should be replaced according to the Maintenance Schedule. If the vehicle is operated in severely air-polluted cities or on dusty rough roads for a long period, it should be inspected more frequently and replaced sooner.

  • Page 486: Wiper Blades

    Maintenance Wiper Blades Blade replacement When the wipers no longer clean adequately, the blades may be worn or Blade inspection cracked, and require replacement. Contamination of either the windshield or NOTICE the wiper blades with foreign matter can reduce the effectiveness of the •...

  • Page 487: Battery

    Battery 3. Install a new wiper blade assembly in the reverse order of removal (3). WARNING To prevent SERIOUS INJURY or DEATH to you or bystanders, always follow these precautions when working near or handling the battery: OIK093021 4. With the engine on, turn the wiper switch to MIST/LOW/HIGH position to return the wipers to the bottom resting Always read and follow instructions...
  • Page 488 Maintenance WARNING CALIFORNIA PROPOSITION 65 WARNING Battery posts, terminals, and related accessories contain lead and lead compounds, chemicals known to the State of California to cause cancer, birth defects and reproductive harm. Batteries Keep batteries out of reach of children. also contain other chemicals known to the State of California to cause cancer.

  • Page 489: Battery Usage Recommendations

    Battery Usage WARNING Recommendations • Keep the battery securely mounted. • Keep the battery top clean and dry. • Keep the terminals and connections clean, tight, and coated with petroleum jelly or terminal grease. • Rinse any spilled electrolyte from the battery immediately with a solution of water and baking soda.

  • Page 490: Battery Capacity Label

    3. Unhook the positive clamp from the Alternatively you may connect a fully positive battery terminal. automatic regulated charger to the • Always use a Genuine Genesis Part engine compartment front jumper posts approved battery when you replace the or at the battery in the luggage battery.

  • Page 491: Reset Items

    • Fuel economy/Driving info/Since AGM battery serviced by an authorized refueling/Accumulated info (refer to retailer of Genesis Branded products. chapter 4) For charging your AGM battery, use • Integrated memory system (refer to only fully automatic battery chargers...

  • Page 492: Tires And Wheels

    Maintenance Tires and wheels Tire care For proper maintenance, safety, and WARNING maximum fuel economy, you must always maintain recommended tire Tire failure may cause loss of vehicle inflation pressures and stay within control resulting in an accident. To the load limits and weight reduce risk of SERIOUS INJURY or distribution recommended for your DEATH, take the following...

  • Page 493: Check Tire Inflation Pressure

    If a tire frequently needs refilling, have it checked by an If you overfill the tire, release air by authorized retailer of Genesis pushing on the metal stem in the Branded products. center of the tire valve. Recheck the tire pressure with the tire gauge.

  • Page 494: Tire Rotation

    Maintenance Tire rotation Information To equalize tread wear, Genesis The outside and inside of the Branded Vehicle recommends that unsymmetrical tire is distinguishable. the tires be rotated according to the When installing an unsymmetrical maintenance schedule or sooner if tire, be sure to install the side marked irregular wear develops.

  • Page 495: Tire Replacement

    • Tires degrade over time, even when they are not being used. Regardless of the remaining tread, Genesis Branded Vehicle recommends that tires be replaced after six (6) years of normal service. • Heat caused by hot climates or frequent high loading conditions can accelerate the aging process.

  • Page 496: Wheel Replacement

    Maintenance Tire traction Compact spare tire replacement Tire traction can be reduced if you if equipped A compact spare tire has a shorter drive on worn tires, tires that are tread life than a regular size tire. improperly inflated or on slippery Replace it when you can see the tread road surfaces.
  • Page 497 1. Manufacturer or brand name Example wheel size designation: Manufacturer or brand name is 8.0J X 18 shown. 8.0 - Rim width in inches. J - Rim contour designation. 2. Tire size designation 18 - Rim diameter in inches. A tire's sidewall is marked with a tire size designation.
  • Page 498 Genesis Branded Vehicle always use a tire that has the same recommends that tires designed load rating as the factory installed specifically for Genesis vehicles be tire. used. You may find the marking "GOE" (Genesis Original Equipment) 8. Uniform tire quality grading embossed on the tire sidewall.

  • Page 499: Tire Terminology And Definitions

    Tread wear Temperature - A, B & C The tread wear grade is a The temperature grades are A (the comparative rating based on the highest), B and C representing the wear rate of the tire when tested tire's resistance to the generation of under controlled conditions on a heat and its ability to dissipate heat specified government test course.
  • Page 500 Maintenance Accessory weight DOT markings This means the combined weight of A code molded into the sidewall of a optional accessories. Some examples tire signifying that the tire is in of optional accessories are automatic compliance with the U.S. Department transmission, power seats, and air of Transportation motor vehicle conditioning.
  • Page 501 Load index Passenger (P-Metric) tire An assigned number ranging from 1 to A tire used on passenger cars and 279 that corresponds to the load some light duty trucks and carrying capacity of a tire. multipurpose vehicles. Maximum inflation pressure The maximum air pressure to which a A layer of rubber-coated parallel cold tire may be inflated.

  • Page 502: All Season Tires

    Treadwear indicators Narrow bands, sometimes called All Season tires "wear bars", that show across the Genesis Branded Vehicle specifies all tread of a tire when only 1/16 inches season tires on some models to of tread remains. provide good performance for use all...

  • Page 503: Summer Tires

    Summer tires Radial-ply tires Genesis Branded Vehicle specifies Radial-ply tires provide improved summer tires on some models to tread life, road hazard resistance and provide superior performance on dry smoother high speed ride. The roads. Summer tire performance is radial-ply tires used on this vehicle...

  • Page 504: Maintenance

    • When there is an impact on a tire, inspect the tire condition. Or, you can contact an authorized retailer of Genesis Branded products. • Inspect the tire condition and pressure every 1,800 mi. (3,000 km) to prevent tire damage.

  • Page 505: Fuses

    If the replacement fuse blows, this indicates an electrical problem. Avoid using the system involved and immediately consult an authorized retailer of Genesis Branded products. WARNING 2C_FuseType_2 Multi type NEVER replace a fuse with anything but another fuse of the same rating.

  • Page 506: Instrument Panel Fuse Replacement

    If it fits loosely, consult an authorized Driver's side retailer of Genesis Branded products. In an emergency, if you do not have a spare fuse, use a fuse of the same rating...

  • Page 507: Engine Compartment Panel Fuse Replacement

    Blade type fuse Multi fuse/Midi fuse Multi type OIK093025 Cartridge type fuse OIK093027 Midi type OIK093026 OIK093028 If the multi fuse or midi fuse is blown, consult an authorized retailer of Genesis Branded products. 9-53...

  • Page 508: Fuse/Relay Panel Description

    Maintenance Fuse/relay panel description Instrument panel fuse panel OIK093029 Inside the fuse/relay box cover, you can find the fuse/relay label describing fuse/relay names and ratings. Information Not all fuse panel descriptions in this manual may be applicable to your vehicle; the information is accurate at the time of printing.
  • Page 509 OIK093013N Instrument panel fuse panel (Driver's side fuse panel) Fuse Fuse Name Circuit Protected Rating MULTI MEDIA1 Fuse - MULTIMEDIA 2/3 AIR BAG1 SRS Control Module, Passenger Occupant Detection Sensor Power Trunk Module, Driver/Passenger Power Side View Mirror, MODULE10 Driver Door Module, Driver IMS Control Module, Driver Air Lumbar Control Unit STOP LAMP IBU, Stop Lamp Switch...
  • Page 510 Maintenance Fuse Fuse Name Circuit Protected Rating MULTI MEDIA3 Surround View Monitor MULTI MEDIA2 A/V & Navigation Head Unit A/C Control Module, A/C Switch, Security Indicator, MEMORY1 Head-Up Display, Instrument Cluster E-SHIFTER1 Electronic ATM Shift Lever MODULE11 IAU, Multifunction Switch AIR BAG IND.
  • Page 511 Fuse Fuse Name Circuit Protected Rating Front Seat Warmer Control Module, Driver IMS Control Module, Front Air Ventilation Seat Control Module, A/C Control Module, MODULE5 A/C Switch, Electro Chromic Mirror, Rear Seat Warmer Control Module, AMP, Data Link Connector, Front Wireless Charger, A/V &...
  • Page 512 Maintenance Engine compartment fuse panel (Engine room junction block) Inside the fuse/relay box cover, you can find the fuse/relay label describing fuse/relay names and ratings. Information Not all fuse panel descriptions in this manual may be applicable to your vehicle; the information is accurate at the time of printing.
  • Page 513 Engine compartment fuse panel Fuse Fuse Name Circuit Protected Rating Alternator, Fuse - COOLING FAN2, Multi Fuse 1 - COOLING 225A FAN1, B+1, B+2, B+3, IG2, ECS1, ECS2 COOLING FAN2 100A [G6DP] Cooling Fan Controller START Start Relay COOLING FAN1 [G4KR] Cooling Fan Controller ICU Junction Block (Long Term Load Latch Relay, Fuse - STOP LAMP, MEMORY1, MULTIMEDIA 1/2/3, MODULE10)
  • Page 514 Maintenance Engine compartment fuse panel (PCB block) Fuse Name Fuse Rating Circuit Protected ESC3 ESC Module ECU3 ECU2 HORN Horn Relay WIPER1 Wiper Power Relay TCU2 P/N Relay, TCM Brake Vacuum Switch, E/R Junction Block (Vacuum Pump SENSOR4 Relay) TCU1 WIPER2 IBU, ECM [G6DP] Rear Sub Junction Block (Fuel Pump Relay)
  • Page 515 Relay Type Relay No. Relay Name MICRO Vacuum Pump Relay MICRO Blower Relay MICRO Start Relay MICRO E-CVVT Relay (G4KR) 9-61...
  • Page 516 Maintenance Trunk fuse panel (Rear sub junction block) OIK093155 Inside the fuse/relay box cover, you can find the fuse/relay label describing fuse/relay names and ratings. Information Not all fuse panel descriptions in this manual may be applicable to your vehicle; the information is accurate at the time of printing.
  • Page 517 OIK093055N Rear fuse panel Fuse Fuse Name Circuit Protected Rating ECS Unit POWER TRUNK Power Trunk Module FUEL PUMP Fuel Pump Relay HEATED Driver/Passenger Power Side View Mirror MIRROR AMP2 S/HEATER RR Rear Seat Warmer Control Module AMP1 Fuse - AMP2 IG1 Relay ICU Junction Block (Fuse - POWER OUTLET1, CHARGER1/2, MODULE6)
  • Page 518 Maintenance Trunk fuse panel (Battery junction block) OIK093153 Inside the fuse/relay box cover, you can find the fuse/relay label describing fuse/relay names and ratings. Information Not all fuse panel descriptions in this manual may be applicable to your vehicle; the information is accurate at the time of printing.
  • Page 519 Battery box fuse panel Fuse Fuse Name Circuit Protected Rating Rear Sub Junction Block 100A (ACC Relay, Fuse - B+2, REAR HEATED, FUEL PUMP, AMP1, IG1) Rear Sub Junction Block 100A (Fuse - B+1, ECS, S/HEATER RR, POWER TRUNK) E/R Junction Block (Fuse - START), START PCB Block (Fuse - ECU2, TCU1) Battery Sensor...

  • Page 520: Light Bulbs

    Maintenance Light Bulbs Information Consult an authorized retailer of Genesis Headlight desiccant (if equipped) Branded products to replace most vehicle This vehicle is equipped with desiccant to light bulbs. It is difficult to replace vehicle reduce fogging inside the headlight due light bulbs because other parts of the to moisture.

  • Page 521: Headlight, Parking Light, Turn Signal Light, Daytime Running Light (Drl) Replacement

    However, if the light goes out after flickering momentarily, or continues to flicker, have the system checked by an authorized retailer of Genesis Branded products. • The parking light may not turn on when the parking light switch is turned on,...

  • Page 522: Side Repeater Light Replacement

    If the LED light (1) does not operate, have (2) Stop/Turn signal light the system inspected by an authorized (3) Side marker retailer of Genesis Branded products. (4) Reverse light The LED lights cannot be replaced as a If the LED light does not operate, have the single unit because it is an integrated unit.

  • Page 523: High Mounted Stop Light Replacement

    Front lamps OIK093039 If the LED light (1) does not operate, have the system inspected by an authorized retailer of Genesis Branded products. The LED lights cannot be replaced as a OIK093040N Rear lamps single unit because it is an integrated unit.

  • Page 524: Appearance Care

    Pay special attention to the retailer of Genesis Branded products. removal of any accumulation of salt, dirt, The LED lights cannot be replaced as a mud, and other foreign materials. Make single unit because it is an integrated unit.
  • Page 525 Even prompt washing with plain water NOTICE may not completely remove all these deposits. A mild soap, safe for use on • Do not use strong soap, chemical painted surfaces, should be used. detergents or hot water, and do not wash the vehicle in direct sunlight or After washing, rinse the vehicle when the body of the vehicle is warm.
  • Page 526 Maintenance NOTICE NOTICE Matte paint finish vehicle (if equipped) • Wiping dust or dirt off the body with a dry cloth will scratch the finish. Automatic car wash which uses rotating brushes should not be used as this can • Do not use steel wool, abrasive damage the surface of your vehicle.
  • Page 527 Genesis Branded products. Thoroughly flush the vehicle underbody Take extreme care, as it is difficult to and wheel openings with lukewarm or restore the quality after the repair.
  • Page 528 By using the most advanced design and appears to be dry, it can still retain construction practices to combat moisture and promote corrosion. corrosion, Genesis Branded Vehicle High temperatures can also accelerate produces vehicles of the highest quality. corrosion of parts that are not properly However, this is only part of the job.

  • Page 529: Interior Care

    To help prevent corrosion Keep paint and trim in good condition Keep your vehicle clean Scratches or chips in the finish should be covered with "touch-up" paint as soon as The best way to prevent corrosion is to possible to reduce the possibility of keep your vehicle clean and free of corrosion.
  • Page 530 Maintenance Leather (if equipped) Cleaning the upholstery and interior trim • Features of seat leather - Leather is made from the outer skin Vehicle interior surfaces (if equipped) of an animal, which goes through a Remove dust and loose dirt from interior special process to be available for surfaces with a whisk broom or a vacuum use.
  • Page 531 - Chewing gum retailer of Genesis Branded products. Harden the gum with ice and remove gradually. • Handling prime napa leather Try to avoid excessive sunlight and heat exposure.

  • Page 532: Emission Control System

    This may result in damage inspected and maintained by an to the rear window defroster grid. authorized retailer of Genesis Branded products in accordance with the maintenance schedule in this manual. NOTICE...

  • Page 533: Crankcase Emission Control System

    Crankcase emission control Exhaust emission control system system The positive crankcase ventilation system The Exhaust Emission Control System is a is employed to prevent air pollution highly effective system which controls caused by blow-by gases being emitted exhaust emissions while maintaining from the crankcase.
  • Page 534 All inspections and WARNING adjustments must be made by an authorized retailer of Genesis Branded The exhaust system and catalytic system products. are very hot while the engine is running or • Avoid driving with an extremely low immediately after the engine is turned off.

  • Page 535: California Perchlorate Notice

    California Perchlorate Notice Perchlorate Material-special handling may apply, See: https://dtsc.ca.gov/perchlorate. Notice to California Vehicle Dismantlers: Perchlorate containing materials, such as air bag inflators, seatbelt pretensioners and keyless remote entry batteries, must be disposed of according to Title 22 California Code of Regulations Section 67384.10 (a).
  • Page 537 Index...
  • Page 538 Index Accessing your vehicle ........................5-5 Immobilizer system ........................5-11 Smart key .............................5-5 Active air flap ..........................6-49 Malfunction ..........................6-49 Air cleaner ..........................9-30 Filter replacement ........................9-30 Air conditioner compressor label .................... 2-20 Air conditioning system ......................2-14 Air Ventilation Seats ........................3-16 Airbag - Supplemental Restraint System ................
  • Page 539 Blind-Spot Collision-Avoidance Assist (BCA) ................7-23 Blind-Spot Collision-Avoidance Assist malfunction and limitations ........7-29 Blind-Spot Collision-Avoidance Assist operation ..............7-26 Blind-Spot Collision-Avoidance Assist settings ..............7-25 Blind-Spot View Monitor (BVM) ....................7-51 Blind-Spot View Monitor malfunction ..................7-52 Blind-Spot View Monitor operation ..................7-52 Blind-Spot View Monitor settings ....................
  • Page 540 Index Trip computer ........................... 4-33 View modes ..........................4-31 Coasting ............................. 6-44 Coasting operating conditions ....................6-44 Coasting release conditions ....................6-45 Coasting setting ........................6-44 Consumer Information ......................2-21 Declaration of conformity .......................7-106 Front radar ..........................7-106 Rear corner radar ........................7-107 Dimensions ..........................
  • Page 541 Remote start ..........................6-9 Starting the engine ........................6-7 Turning off the engine ........................ 6-8 Explanation of scheduled maintenance items ..............9-20 Air cleaner filter .........................9-20 Air conditioning refrigerant ...................... 9-22 Automatic transmission fluid ....................9-21 Brake discs, pads, calipers and rotors ..................9-21 Brake fluid ..........................9-21 Brake hoses and lines ........................9-21 Cooling system ..........................9-21...
  • Page 542 Digital Key (Card Key) ....................... 5-17 Digital Key (Smartphone) ......................5-12 Limitations of the System ......................5-21 Used Vehicle/Digital Key Maintenance .................. 5-20 Guide to Genesis Parts ......................... 1-4 Hazard warning flasher ......................8-2 Head-Up Display (HUD) ......................5-67 Head-Up Display information ....................5-67 Head-Up Display settings ......................5-67...
  • Page 543 Always wear your seat belt ......................3-2 Control your speed ........................3-3 Driver distraction ........................3-2 Keep your vehicle in safe condition ..................3-3 Never drink or take drugs and drive ..................3-3 Restrain all children ........................3-2 In case of an emergency while driving ..................8-2 If the engine stalls at a crossroad or crossing ................
  • Page 544 Index Trunk lamp ..........................5-78 Vanity mirror lamp ........................5-78 Interior overview ......................... 2-4 Introduction ..........................1-2 Jump starting ..........................8-4 Lane Following Assist (LFA) .......................7-71 Lane Following Assist malfunction and limitations ..............7-74 Lane Following Assist operation ....................7-72 Lane Following Assist settings ....................7-72 Lane Keeping Assist (LKA) ......................
  • Page 545 Emergency trunk safety release ....................5-56 Opening the trunk ........................5-55 Open Source Software Notice ....................2-21 Owner maintenance ........................9-7 Owner maintenance schedule ....................9-7 Power trunk ..........................5-57 Emergency trunk safety release ....................5-61 Operating the power trunk ...................... 5-59 Power trunk operating conditions ...................
  • Page 546 Index Seat belt restraint system ......................3-20 Seat belt safety precautions .....................3-18 Seat belt warning light ......................3-19 Seat Warmers ..........................3-14 Seats ............................. 3-4 Front seats ..........................3-6 Head restraint ..........................3-11 Rear seats ............................ 3-9 Safety precautions ........................3-5 Smart Cruise Control (SCC) .......................7-53 Smart Cruise Control malfunction and limitations ..............
  • Page 547 All Season tires ..........................9-48 Check tire inflation pressure ....................9-39 Low aspect ratio tires .......................9-50 Radial-ply tires ..........................9-49 Recommended cold tire inflation pressures ................9-38 Snow tires ..........................9-49 Summer tires ..........................9-49 Tire care .............................9-38 Tire maintenance ........................9-42 Tire replacement ........................9-41 Tire rotation ..........................9-40 Tire sidewall labeling ........................
  • Page 548 Index Windows ............................. 5-46 Power windows .........................5-47 Remote window opening function ..................5-49 Windshield defrosting and defogging ..................5-94 Defogging logic ........................5-95 Rear window defroster ......................5-95 To defog inside windshield ...................... 5-94 To defrost inside windshield ....................5-94 Winter driving ..........................

Table of Contents

Save PDF
