Table of Contents

Advertisement

Quick Links

OWNER'S MANUAL
Operation
Maintenance
Specifications
All information in this Owner's Manual is current at the time
of publication. However, Genesis Branded Vehicle reserves
the right to make changes at any time so that our policy of
continual product improvement may be carried out.
This manual applies to all models of this vehicle and includes
descriptions and explanations of optional as well as standard
equipment.
As a result, you may find material in this manual that does not
apply to your specific vehicle.
Please note that some models are equipped with Right-Hand
Drive (RHD). The explanations and illustrations for some
operations in RHD models are opposite of those written in this
manual.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Electrified GV70 and is the answer not in the manual?

Questions and answers

Related Manuals for Genesis Electrified GV70

Summary of Contents for Genesis Electrified GV70

  • Page 1 Maintenance Specifications All information in this Owner’s Manual is current at the time of publication. However, Genesis Branded Vehicle reserves the right to make changes at any time so that our policy of continual product improvement may be carried out.
  • Page 2 CAUTION: MODIFICATIONS TO YOUR GENESIS BRANDED VEHICLE Your Genesis Branded Vehicle should not be modified in any way. Such modifications may adversely affect the performance, safety or durability of your Genesis Branded Vehicle and may, in addition, violate conditions of the limited warranties covering the vehicle.
  • Page 3 SAFETY AND VEHICLE DAMAGE WARNING This manual includes information titled as DANGER, WARNING, CAUTION and NOTICE. These titles indicate the following: DANGER DANGER indicates a hazardous situation which, if not avoided, will result in death or serious injury. WARNING WARNING indicates a hazardous situation which, if not avoided, could result in death or serious injury.

  • Page 5: Table Of Contents

    Table of contents Foreword/Starting your electric vehicle Vehicle information Safety system Instrument cluster Convenience features Driving your vehicle Driver assistance system Emergency situations Maintenance Index...

  • Page 6: Foreword/Starting Your Electric Vehicle

    1. Foreword/Starting your electric vehicle Electric vehicle ....................1-6 Electric vehicle ......................1-6 Characteristics of electric vehicles ................1-6 Battery Information ...................... 1-6 Main components of electric vehicle ............... 1-7 Main components of electric vehicle ................1-7 High voltage battery(lithium-ion battery) ..............1-7 High voltage battery warmer system................
  • Page 7 Driving electric vehicle ..................1-52 How to start the vehicle ..................... 1-52 How to shut off the vehicle ..................1-53 Virtual engine sound system ..................1-53 Distance to empty ...................... 1-54 Tips for improving distance to empty ............... 1-55 Energy information ....................1-56 Power/Charge Gauge ....................1-57 State of charge (SOC) gauge for high voltage battery ..........1-57 Warning and Indicator lights (related to electric vehicle) ........
  • Page 8 Copyright 2022 Genesis Brand Motor Company. All rights reserved. No part of this publication may be reproduced, stored in any retrieval system or transmitted in any form or by any means without the prior written permission of Genesis Brand Motor Company.
  • Page 9 Foreword/Starting your electric vehicle HOW TO USE THIS MANUAL We want to help you get the greatest possible driving pleasure from your vehicle. Your Owner’s Manual can assist you in many ways. We strongly recommend that you read the entire manual. In order to minimize the chance of death or injury, you must read the WARNING and CAUTION sections in the manual.
  • Page 10 RETURNING USED VEHICLES (FOR EUROPE) Genesis Branded Vehicle promotes an environmentally sound treatment for end of life vehicles and offers to take back your Genesis Branded Vehicle end of life vehicles in accordance with the European Union (EU) End of Life Vehicles Directive.

  • Page 11: Electric Vehicle

    Foreword/Starting your electric vehicle ELECTRIC VEHICLE Electric vehicle Information An electric vehicle is driven using a What does regenerative braking do? battery and an electric motor. While It uses an electric motor when decelerating general vehicles use an internal and braking and transforms kinetic combustion engine and gasoline as fuel, energy to electrical energy in order to electric vehicles use electrical energy...

  • Page 12: Main Components Of Electric Vehicle

    • VCU: Control the various controls on contact an authorized retailer of the vehicle. Genesis Branded products. • Motor: Uses electrical energy stored inside the high voltage battery to drive High voltage battery the vehicle (functions like an engine in (lithium-ion battery) a standard vehicle).

  • Page 13: High Voltage Battery Warmer System

    • Using the V2L function may reduce we recommend that you contact the mileage due to the use of high an authorized retailer of Genesis voltage battery energy, and repeated Branded products for inspection and use of the V2L function may cause maintenance.

  • Page 14: Ev Mode

    EV MODE If you select the ‘EV’ menu at the home screen you can enter EV mode. For detailed information, scan the QR code in a separately supplied simple manual. OJKEVQ012007L OJKEVQ012007L EV mode screen OJKEVQ012008L OJKEVQ012008L (1) Energy Information (4) Vehicle to Load (V2L) (2) Next Departure (5) EV Settings...

  • Page 15: Energy Information

    Foreword/Starting your electric vehicle Energy information Next departure OJKEVQ012009L OJKEVQ012009L OJKEVQ012011L OJKEVQ012011L Select ‘EV → Energy information’ on the Select ‘EV → Next departure time’ on the screen. screen. You can set the date and time of when to charge the battery, climate You can check battery information and control temperature, and other various energy consumption.

  • Page 16: Charging And Climate

    Charging and climate Departure time OJKEVQ012012L OJKEVQ012012L OJKEVQ012014L OJKEVQ012014L Select ‘EV → Scheduled charging and climate’ on the screen. Information Vehicle must be connected with the charging connector at the time pre- scheduled time for the scheduled charging. OJKEVQ012013L OJKEVQ012013L 1.
  • Page 17 Foreword/Starting your electric vehicle Off-peak time settings Target temperature settings OJKEVQ012016L OJKEVQ012016L OJKEVQ012017L OJKEVQ012017L 1. If selected, starts charging only on the 1. Set target temperature. designated off-peak time. If the target temperature (1) is set 2. Set the most inexpensive time to with the cable connected, the cabin complete charging.

  • Page 18: Vehicle To Load (V2L)

    Vehicle to load (V2L) Energy information Select ‘EV → Energy information’ on the V2L is the system provides AC power screen. using the high voltage battery for driving to operate several electronical products. You can check battery discharging level. How to connect Outdoor OJKEVQ012018L OJKEVQ012018L...
  • Page 19 Genesis Branded products. 5. Press the switch (1) to turn off the light (2) the the V2L will be off. You can...
  • Page 20 CAUTION • Be well-informed of the manual to prevent accidents. • The V2L discharging mode is blocked automatically in case of overheating. (When the discharging mode is blocked, check whether the V2L connector or power plug is contaminated, worn, corroded or broken or the home appliance capacity is over 16 A.
  • Page 21 Foreword/Starting your electric vehicle • If you use an electrical appliance • For various devices connected to that exceeds the maximum power an power outlet, use only products capacity that the vehicle can supply, that have obtained national the operation will stop and a warning safety certification.
  • Page 22 • Do not remodel or disassemble the WARNING V2L connector. There is a risk of fire, • Do not touch the V2L connector of electric shock or injury. the terminal of the vehicle charging inlet. • Do not put metal objects to the V2L connector or charging inlet.
  • Page 23 Foreword/Starting your electric vehicle LCD display messages ONE1Q011079L ONE1Q011079L OJKEVQ012074L OJKEVQ012074L V2L conditions not met If V2L is interrupted for any of the V2L has ended. Battery level has reached following reasons, a warning message is the set value/V2L finished. Defined charge displayed.

  • Page 24: Nearby Charging Stations

    Nearby charging stations EV settings OJKEVQ012025L OJKEVQ012025L OJKEVQ012027L OJKEVQ012027L Select ‘Nearby Stations’ on the screen. Select ‘EV → EV Settings’ on the screen. You can set the charging limit, charging current, battery conditioning mode and utility mode functions. Charging limit (Max. % Charge) OJKEVQ012026L OJKEVQ012026L Around the course, around the current...
  • Page 25 Foreword/Starting your electric vehicle Charging current Battery conditioning mode OJKEVQ012029L OJKEVQ012029L OJKEVQ012030L OJKEVQ012030L • You can adjust the charging You can select or deselect the Battery current for an AC charger. Select an conditioning mode. appropriate charging current. The Battery conditioning mode is •...
  • Page 26 Utility Mode System Activation When the system is activated: The high voltage battery is used instead of the 12 V auxiliary battery for operating • The ready ( ) indicator will turn the convenient features of the vehicle. off, and the utility ( ) indicator will When driving is not necessary such as illuminate on the cluster and the EPB...

  • Page 27: Charge Types For Electric Vehicle

    Foreword/Starting your electric vehicle CHARGE TYPES FOR ELECTRIC VEHICLE Charging Information • AC Charge: The electric vehicle is charged by plugging into a AC charger installed at your home or a public charging station. (For further details, refer to the ‘AC Charge’.) •...

  • Page 28: Charging Types

    Charging types Category AC Charge DC Charge Portable Charge Charging OJKEVQ012086L OJKEVQ012087L OJKEVQ012086L Inlet (Vehicle) OJKEVQ012089L OJKEVQ012090L OJKEVQ012089L Charging OJKEVQ012073L OJKEVQ012092L OJKEVQ012073L Connector OJKEVQ012094L OJKEVQ012095L OJKEVQ012094L 1-23...
  • Page 29 Foreword/Starting your electric vehicle Category AC Charge DC Charge Portable Charge Charging Outlet OSQCEQ019005 ONX4EPHQ011019L ORG3EVQ011071 Use AC charger How to Use the DC charger at installed at home or Use household current Charge public charging stations public charging stations •...

  • Page 30: Charge Indicator Lamp For Electric Vehicle

    CHARGE INDICATOR LAMP FOR ELECTRIC VEHICLE When charging the high voltage battery, 1. Charging status the charge level can be checked from Lamp status Details outside the vehicle. Charging status Electric charging door High voltage battery level very low yellow High voltage battery level low green...

  • Page 31: Locking Charging Cable

    Foreword/Starting your electric vehicle Locking charging cable When the Charging Connector Is Locked Lock Do not Always while lock (if lock charging equipped) Before charging While charging Finished charging OJKEVQ012032L OJKEVQ012032L • ‘Always lock’ mode: You may select when the charging The connector locks when the connector can be locked and unlocked in charging connector is plugged into...

  • Page 32: Scheduled Charging

    When Connected Service application. you press the scheduled charging Refer to the Multimedia manual or deactivation button (2) for immediate the Genesis Connected Service for charging, the scheduled charge detailed information about setting setting is not completely deactivated. scheduled charging.
  • Page 33 Foreword/Starting your electric vehicle WARNING WARNING • Electromagnetic waves that are • Be careful not to touch the charging generated from the charger can connector, charging plug, and the seriously impact medical electric charging inlet when connecting devices such as an implantable the cable to the charger and the cardiac pacemaker.

  • Page 34: How To Check The Symbol On The Charging Label (For Europe)

    How to check the symbol on the CAUTION charging label (For Europe) • Always keep the charging connector and charging plug in clean and dry condition. Be sure to keep the charging cable in a condition where there is no water or moisture. •...

  • Page 35: Electric Charging Label

    Foreword/Starting your electric vehicle Electric charging label Precautions for AC and portable charger charging 1. After opening the charging door, check the charging symbol at the bottom of the warning label. 2. Check the charging connector symbol of the AC and Trickle charger cable. 3.

  • Page 36: Electric Charging Label Symbol Table

    Electric charging label symbol table AC and portable charger charging Type of Supply Type Voltage range Symbol Configuration accessory Vehicle connector and ≤480V RMS vehicle inlet DC charging Type of Supply Type Voltage range Symbol Configuration accessory 50 V to 500 V Vehicle 7P COMBO connector and...

  • Page 37: Disconnecting Charging Connector In Emergency

    Foreword/Starting your electric vehicle Disconnecting charging How to Connect AC Charger connector in emergency 1. Depress the brake pedal and apply the parking brake. 2. Turn OFF all switches, shift to P (Park), and turn OFF the vehicle. If charging is initiated without the gear in P (Park), the charging will start after the gear is automatically shifted to P (Park).
  • Page 38 5. Check if there is dust on the charging connector and charging inlet. 6. Hold the charging connector handle and connect it to the vehicle charging inlet. Push the connector all the way in. If the charging connector and charging terminal are not connected properly, this may cause a fire and charging may not start.
  • Page 39 Foreword/Starting your electric vehicle Checking Charging Status Information When charging the high voltage battery, • Even though charging is possible with the charge level can be checked from the Start/Stop button in the ON/START outside the vehicle. position, for your safety, start charging For more details, refer to ‘Charge when the Start/Stop button is in the Indicator Lamp for Electric Vehicle’...
  • Page 40 If the release button still does not work, we recommend to consult an authorized retailer of Genesis Branded products. 1-35...

  • Page 41: Dc Charge

    Foreword/Starting your electric vehicle DC charge How to Connect DC Charger 1. Depress the brake pedal and apply the parking brake. 2. Turn OFF all switches, shift to P (Park), and turn OFF the vehicle. OSQCEQ019005 OSQCEQ019005 You can charge at high speeds at public charging stations.
  • Page 42 5. Check whether there is dust or foreign Information substances inside the charging connector and charging inlet. To control the temperature of the high voltage battery while charging or when 6. Hold the charging connector handle the battery temperature is high, the and connect it to the vehicle charging air conditioning is used to cool down inlet.
  • Page 43 Foreword/Starting your electric vehicle Checking Charging Status When charging the high voltage battery, the charge level can be checked from outside the vehicle. For more details, refer to ‘Charge Indicator Lamp for Electric Vehicle’ in this chapter. How to Disconnect DC Charger 1.

  • Page 44: Portable Charge

    Portable charge ORG3EVQ011075 ORG3EVQ011075 4. Press the button (1) on the front of ONE1Q011087L ONE1Q011087L the control box for 2 to 8 seconds (1) Code and Plug (Code set) to adjust the charge level. (Refer to (2) Control Box charging cable type and example for setting the charge level.) (3) Charging Cable and Charging Connector...
  • Page 45 Foreword/Starting your electric vehicle à Example for setting the ICCB charge level The example is only for reference and may vary according to the surrounding environment. Outlet current ICCB charge level Control box display window 14-16 A 12 A 13-12 A 10 A 11-10 A 9-8 A...
  • Page 46 How to Connect Portable Charger (ICCB: In-Cable Control Box) OJKEVQ011041 OJKEVQ011041 5. Push the charging door where the triangle symbol (1) is located to open. ORG3EVQ011074L ORG3EVQ011074L The charging door opens only when 1. Connect the plug to a household the vehicle is unlocked.
  • Page 47 Foreword/Starting your electric vehicle Information Locking Charging Cable Select ‘EV → Charging Connector Locking Mode’ in the infotainment. The charging connector will lock to the inlet depending upon the locking mode selected within the infotainment. • Always mode : The connector locks when the charging connector is plugged into the charging inlet.
  • Page 48 Checking Charging Status Information When charging the high voltage battery, Even though charging is possible with the charge level can be checked from the Start/Stop button in the ON/START outside the vehicle. position, for you safety, start charging when the Start/Stop button is in the For more details, refer to ‘Charge OFF position and the vehicle shifted to P Indicator Lamp for Electric Vehicle’...
  • Page 49 Foreword/Starting your electric vehicle Charging Status Indicator Lamp for Portable Charger OJKEVQ011067 OJKEVQ011067 Indicator Details POWER On: Power on On: Charge CHARGE Blink: Current limit due to high plug temperature or high internal temperature FAULT Blink: Charging interrupted 1-44...
  • Page 50 Indicator Details On: Error while charging/ Error during self-diagnosis Error code Item Cause Control Pilot Vehicle communication error communication Current leakage Leakage Charger error Plug overtemperature warning Plug temperature Plug temperature failure Charger error Overcurrent Charging overcurrent warning Charger overheating Internal temperature Charger error...
  • Page 51 Foreword/Starting your electric vehicle Indicator Details 12 A 10 A CHARGE LEVEL * The control box The charging current changes whenever the button (1) is pressed for less than 1 sec with the charger plugged into an electrical outlet but not the vehicle. ORG3EVQ011075 ORG3EVQ011075 1-46...
  • Page 52 • Plug connected to an electric outlet • ICCB (In-Cable Control Box) failure (POWER Green ON) We recommend that you contact an We recommend that you contact an authorized retailer of Genesis Branded authorized retailer of Genesis Branded products. products. OJKEVQ011070...
  • Page 53 2 seconds or longer to clear inlet. the error. We recommend that you contact an Information authorized retailer of Genesis Branded products. To prevent charging cable theft, the charging connector cannot be disconnected from the inlet when the doors are locked or the charging connector is in the ‘Locking while charging’...
  • Page 54 Information Some connectors installed in public charging stations stop charging by pressing the charge release button while charging is locked, and the connector can be disconnected. ORG3EVQ011087L ORG3EVQ011087L 3. Disconnect the plug from the household electric outlet. Do not pull the cable when disconnecting the plug.
  • Page 55 • Keep the normal charging connector or plug terminal free of foreign substances. • Use the portable charger that is certified by Genesis Branded Vehicle. • Do not step on the cable or cord. Do not pull the cable or cord and do not twist or •...

  • Page 56: Charging The Electric Vehicle (Abrupt Stop)

    5. If the vehicle does not charge when charged with another normally working charger, we recommend that you contact an authorized retailer of Genesis Branded products for inspection. 6. If charging fails and the service warning light ( ) is lit in the cluster, we recommend that you contact an authorized retailer of Genesis Branded products.

  • Page 57: Driving Electric Vehicle

    Foreword/Starting your electric vehicle DRIVING ELECTRIC VEHICLE How to start the vehicle 1. Holding the smart key, sit in the driver’s seat. 2. Fasten the seat belt before starting the vehicle. 3. Make sure to engage the parking brake. 4. Turn OFF all electrical devices. 5.

  • Page 58: How To Shut Off The Vehicle

    How to shut off the vehicle Virtual engine sound system 1. Hold down the brake pedal while the The Virtual Engine Sound System (VESS) vehicle is stopped. generates sound for pedestrians to hear because there is no sound while the 2.

  • Page 59: Distance To Empty

    Foreword/Starting your electric vehicle Distance to empty When destination is not set • On average, a vehicle can drive about 455 km (283 miles). • Under certain circumstances where the air conditioner/heater is ON, the distance to empty is impacted, resulting in a possible distance range from 300 km (186 miles).

  • Page 60: Tips For Improving Distance To Empty

    Tips for improving distance to • Distance to empty that is displayed on the instrument cluster after empty completing a recharge may vary • If you operate the air conditioner / significantly depending on previous heater too much, the driving battery operating patterns.

  • Page 61: Energy Information

    Foreword/Starting your electric vehicle Energy information Electric energy economy history OJKEVQ012033L OJKEVQ012033L OJKEVQ012047L OJKEVQ012047L It is possible to check the history of In order to check the current energy electric energy economy with the date consumption for each system of the and distance of previous driving.

  • Page 62: Power/Charge Gauge

    Power/Charge Gauge State of charge (SOC) gauge for high voltage battery OJKEVQ011035 OJKEVQ011035 OJKEV042014L OJKEV042014L OJKEVQ011036 OJKEVQ011036 The Power/Charge Gauge shows the OJKEV042015L OJKEV042015L energy consumption and recovery status • The SOC gauge shows the charging of the electric motor. status of the high voltage battery.

  • Page 63: Warning And Indicator Lights (Related To Electric Vehicle)

    - Blinking : Emergency driving. When the ready indicator goes OFF or blinks, there is a problem with the system. In this case, we recommend that you have your vehicle inspected by an authorized retailer of Genesis Branded products. Service Warning Light OJKEVQ011056 OJKEVQ011056 1.
  • Page 64 In this case, drive safely and we limitation of the vehicle power. recommend that you have your vehicle inspected by an authorized retailer of Genesis Branded products. The operation of the brake pedal may be more difficult than normal and the braking distance can increase.

  • Page 65: Lcd Display Messages

    Foreword/Starting your electric vehicle LCD display messages Unplug vehicle to start Shift to P to charge OOSEV040498L OOSEV040498L This message is displayed when you ORG3EVQ011117L ORG3EVQ011117L start the vehicle without unplugging the This message is displayed if you connect charging cable. Unplug the charging the charging cable without the gear in cable, and then turn on the vehicle.
  • Page 66 If the same problem occurs when charging cable or genuine Genesis charging the vehicle with a normally portable charger, we recommend that operating AC charger or genuine Genesis you have your vehicle inspected by an portable charger, we recommend that authorized retailer of Genesis Branded you have your vehicle inspected by an products.
  • Page 67 The warning light on the instrument you have the vehicle inspected by an cluster ( ) will turn on simultaneously. authorized retailer of Genesis Branded The vehicle’s power will be reduced to products. minimize the energy consumption of the high voltage battery. Charge the battery Low EV battery/Low battery immediately.
  • Page 68 Charging the battery before driving helps temperature decreases increase power. NOTICE If these warning messages still display even after the ambient temperature has increased, we recommend that you have the vehicle inspected by an authorized retailer of Genesis Branded products. 1-63...
  • Page 69 Genesis Branded - The high voltage battery level is too products and have the vehicle inspected. low or voltage is decreasing...

  • Page 70: Aux. Battery Saver

    Aux. Battery Saver+ WARNING The Aux. Battery Saver+ is a function that When this function is activating the monitors the charging status of the 12 V indicator lamp will illuminate and high auxiliary battery. If the auxiliary battery voltage electricity will be flowing into level is low, the main high voltage battery the vehicle.

  • Page 71: Safety Precautions For Electric Vehicle

    WARNING deprtment or an authorized retailer • When a vehicle accident occurs and of Genesis Branded products. the high voltage battery is damaged, harmful gas and electrolytes may leak. Be careful not to touch the leaked liquid.
  • Page 72 WARNING WARNING OJKEVQ011044 OJKEVQ011044 OJKEVQ011045 OJKEVQ011045 • If you tow the vehicle while the 2WD: rear, AWD: front/rear wheels are touching the ground, the vehicle motor may generate electricity OJKEV081016L OJKEV081016L and the motor components may be [1]: Dollies damaged or a fire may occur. •...

  • Page 73: Other Precautions For Electric Vehicle

    • We recommend that you use or install WARNING genuine Genesis part or the equivalent Never disconnect the high voltage (of the genuine part) specified for your cut-off switch except in an emergency vehicle.

  • Page 74: Vehicle Information

    2. Vehicle information Exterior overview (I) ...................2-2 Exterior overview (II) ..................2-3 Interior overview (I) ..................2-4 Interior overview (II) ..................2-5 Instrument panel overview (I) ................2-6 Instrument panel overview (II) ................2-7 Instrument panel overview (III) ................ 2-8 Motor compartment ..................2-9 Dimensions .......................2-10 Electric vehicle specifications ................2-10 Bulb wattage .....................2-11...

  • Page 75: Exterior Overview (I)

    Vehicle information EXTERIOR OVERVIEW (I) The actual shape may differ from the illustration. OJKEV011001 OJKEV011001 1. Hood ............5-48 5. Panorama sunroof ........ 5-44 2. Headlamp ..........9-48 6. Front windshield wiper blades ..... 9-17 3. Tires and wheels ........9-24 7.

  • Page 76: Exterior Overview (Ii)

    EXTERIOR OVERVIEW (II) The actual shape may differ from the illustration. OJKEV012002L OJKEV012002L 1. Door ............5-15 6. Rear window wiper blades ....9-19 2. Rear combination lamp......9-51 7. Antenna ..........5-122 3. Tailgate ........... 5-51 8. Rear view camera ......... 7-121 4.

  • Page 77: Interior Overview (I)

    Vehicle information INTERIOR OVERVIEW (I) Left-hand drive Left-hand drive The actual shape may differ from the illustration. OJKEV011003 OJKEV011003 1. Inside door handle ......... 5-16 9. DBC (Downhill Brake Control) button ............ 6-47 2. Integrated memory system ....5-26 10. ESC (Electronic Stability Control) OFF 3.

  • Page 78: Interior Overview (Ii)

    INTERIOR OVERVIEW (II) Right-hand drive Right-hand drive The actual shape may differ from the illustration. OJKEV012003R OJKEV012003R 1. Inside door handle ......... 5-16 9. DBC (Downhill Brake Control) button ............ 6-47 2. Integrated memory system ....5-26 10. ESC (Electronic Stability Control) OFF 3.

  • Page 79: Instrument Panel Overview (I)

    Vehicle information INSTRUMENT PANEL OVERVIEW (I) Left-hand drive Left-hand drive The actual shape may differ from the illustration. OJKEV011004 OJKEV011004 1. Instrument cluster ........4-4 13. Wireless charging system pad .....5-114 2. Horn ............5-31 14. Cup holder ........... 5-110 3.

  • Page 80: Instrument Panel Overview (Ii)

    INSTRUMENT PANEL OVERVIEW (II) Right-hand drive Right-hand drive The actual shape may differ from the illustration. OJKEV012004R OJKEV012004R 1. Instrument cluster ........4-4 13. Wireless charging system pad .....5-114 2. Horn ............5-31 14. Cup holder ........... 5-110 3. Driver’s front air bag ......3-54 15.

  • Page 81: Instrument Panel Overview (Iii)

    Vehicle information INSTRUMENT PANEL OVERVIEW (III) The actual shape may differ from the illustration. OJKEV011005 OJKEV011005 1. Audio remote control buttons .... 5-122 6. Wiper and washer control lever...5-80 2. Bluetooth® hands-free phone 7. LCD display control ......4-30 button ........... 5-124 8.

  • Page 82: Motor Compartment

    MOTOR COMPARTMENT The actual motor compartment in the vehicle may differ from the illustration. OJKEV092001L OJKEV092001L 1. Coolant reservoir ........9-12 5. Cabin air filter ........9-15 2. Brake fluid reservoir ......9-13 6. Front trunk ..........5-49 3. Windshield washer fluid reservoir ..9-14 7.

  • Page 83: Dimensions

    Vehicle information DIMENSIONS Items mm (in) Overall length 4,715 (185.6) Overall width 1,910 (75.2) Overall height 1,625 (64.0) /1,630 (64.2) Tire size Front Rear Tread 235/55 R19 1,647 (64.8) 1,661 (65.4) 265/45 R20 1,643 (64.7) 1,657 (65.2) Wheelbase 2,875 (113.2) for 265/45 R 20 tire *1 : for 235/55 R 19 tire...

  • Page 84: Bulb Wattage

    BULB WATTAGE Light bulb Bulb type Wattage Headlamp High Turn signal lamp Front Position lamp Daytime Running Lamp (DRL) Puddle lamp Side repeater lamp Stop lamp Tail lamp Turn signal lamp Rear Backup lamp License plate lamp Fog lamp High mounted stop lamp Map lamp Room lamp (without sunroof) Personal lamp (with sunroof)

  • Page 85: Tires And Wheels

    Vehicle information TIRES AND WHEELS Inflation pressure kPa (psi) Wheel Maximum Wheel bolt torque Items Tire size Normal load size load [kgf·m (lbf·ft, N·m)] Front Rear Front Rear 235/55 R19 8.0J x 19 (33) (39) (36) (41) Full size 14~16 tire (101~116, 137~157) 265/45R20...

  • Page 86: Load And Speed Capacity Tires (For Europe)

    Type B R-134a Compressor lubricant 180 g (6.3 oz.) POE RB100EV We recommend that you contact an authorized retailer of Genesis Branded products dealer for more details. VEHICLE WEIGHT AND LUGGAGE VOLUME Gross vehicle weight Luggage volume 2,845 kg (6,272 Ibs.) 503 ℓ...

  • Page 87: Recommended Lubricants And Capacities

    Vehicle information RECOMMENDED LUBRICANTS AND CAPACITIES To help achieve proper vehicle performance and durability, use only lubricants of the proper quality. These lubricants and fluids are recommended for use in your vehicle. Lubricant Volume Classification Front 2.9 ℓ (3.2 US qt.) Reduction HK ATF 65 SP4M-1 gear fluid...

  • Page 88: Vehicle Identification Number (Vin)

    VEHICLE IDENTIFICATION VEHICLE CERTIFICATION NUMBER (VIN) LABEL Frame number Frame number OJKEV011023 OJKEV011023 OJKEV011020 OJKEV011020 The vehicle identification number (VIN) The vehicle certification label attached is the number used in registering your on the driver’s (or front passenger’s) vehicle and in all legal matters pertaining side center pillar gives the vehicle to its ownership, etc.

  • Page 89: Tire Specification And Pressure Label

    Vehicle information TIRE SPECIFICATION AND MOTOR NUMBER PRESSURE LABEL OJKEV011021 OJKEV011021 OJKEV011025L OJKEV011025L The tires supplied on your new vehicle are chosen to provide the best performance for normal driving. The tire label located on the driver’s side center pillar gives the tire pressures recommended for your vehicle.

  • Page 90: Air Conditioner Compressor Label

    AIR CONDITIONER REFRIGERANT LABEL (IF COMPRESSOR LABEL EQUIPPED) ORG3EVQ011137L ORG3EVQ011137L OJKEV051121 OJKEV051121 A compressor label informs you the type You can find out which air conditioning of compressor your vehicle is equipped refrigerant is applied to your vehicle on with such as model (1), serial number (2), the label located inside of the hood.

  • Page 91: Declaration Of Conformity

    Directive a period of 3 years from the date of 1995/5/EC. product purchase. Further information including the manufacturer’s declaration of conformity is available on Genesis Branded Vehicle web site as follows; http://service.hyundai-motor.com 2-18...

  • Page 92: Safety System

    3. Safety system Important safety precautions ................3-3 Always wear your seat belt ..................3-3 Restrain all children ......................3-3 Air bag hazards ......................3-3 Driver distraction ......................3-3 Control your speed .......................3-3 Keep your vehicle in safe condition ................3-3 Seats ........................3-4 Safety precautions ....................... 3-7 Front seats ........................3-8 Rear seats ........................3-15 Headrest........................
  • Page 93 Air bag - supplemental restraint system ............3-51 Where are the air bags? .....................3-54 How does the air bag system operate?..............3-59 What to expect after an air bag inflates ..............3-62 Do not install a Child Restraint System on the front passenger seat .....3-63 Why didn’t my air bag go off in a collision? .............

  • Page 94: Important Safety Precautions

    IMPORTANT SAFETY PRECAUTIONS You will find many safety precautions Drivers can become distracted when and recommendations throughout this they take their eyes and attention off section, and throughout this manual. the road or their hands off the wheel to The safety precautions in this section are focus on activities other than driving.

  • Page 95: Seats

    Safety system SEATS OJKEV032001L OJKEV032001L Front seat (5) Seatback bolster (1) Seat sliding forward or rearward/ (6) Comfortable stretch Seat cushion tilt/ (7) Seat warmer/Air ventilation seat Seat cushion height (8) Headrest (2) Seatback angle (9) Walk-in seat switch (3) Seat cushion extension/ (10) Rear adjustment Seat cushion support (4) Lumbar support...
  • Page 96 OJKEV032002L OJKEV032002L Rear seat (13) Armrest (11) Seatback angle (Manual) (14) Seat warmer (12) Headrest (15) Seatback remote folding lever...
  • Page 97 Safety system OJKEV032004L OJKEV032004L Infotainment system Select ‘Setup -> Vehicle Settings -> Seat’ from the Settings menu in the infotainment system screen, you may use various convenience functions. • Seat position change alert: Seat change information is displayed. • Seat switch and movement alert: Detailed information of the seat switch and image is displayed when the switch is touched or the switch is moved.

  • Page 98: Safety Precautions

    WARNING Information The information provided may differ To reduce the risk of serious injury or depending on which functions are death from an inflating air bag, take the applicable to your vehicle. following precautions: • Adjust the driver’s seat as far to the Safety precautions rear as possible while maintaining the ability to control the vehicle.

  • Page 99: Front Seats

    Safety system Front seats CAUTION The front seat can be adjusted by using To prevent injury: the control switches located on the • Do not adjust your seat while outside of the seat cushion. Before wearing your seat belt. Moving the driving, adjust the seat to the proper seat cushion forward may cause position so that you can easily control...
  • Page 100 Forward and rearward adjustment Seat cushion tilt/height adjustment OJKEV031005 OJKEV031005 OJKEV031009 OJKEV031009 Seat cushion tilt (1) To move the seat forward or rearward: 1. Push the control switch forward or To change the angle of the front part of rearward. the seat cushion: 2.
  • Page 101 Safety system Seatback angle adjustment Seat belts must be snug against your hips and chest to work properly. When the seatback is reclined, the shoulder belt cannot do its job because it will not be snug against your chest. Instead, it will be in front of you.
  • Page 102 Seat cushion support adjustment Lumbar support (if equipped) (if equipped) OJKEV031010 OJKEV031010 To adjust the lumbar support: OJKEV031007 OJKEV031007 To adjust cushion support: 1. Press the front portion of the switch (1) to increase support or the rear 1. Push the control switch up to increase portion of the switch (2) to decrease cushion support or down to decrease support.
  • Page 103 Safety system Seat bolster adjustment (if equipped) Ergo-motion seat (if equipped) OJKEV032013L OJKEV032013L OJKEV031011 OJKEV031011 To adjust seat bolster: 1. Push the adjustment lever clockwise, the seatback bolster will be adjusted inward. Push the switch counterclockwise, the seatback bolster will be adjusted outward. 2.
  • Page 104 Comfortable stretch Smart posture assist Comfortable stretch is a function that After driving for an hour, Smart posture helps relieve fatigue of the driver’s pelvis assist automatically adjusts the pelvis and lower back due to driving. and back portion of the driver's seat to assist the driver’s posture.
  • Page 105 Safety system Walk-in switch (if equipped) Seatback pocket OJKEV031019 OJKEV031019 OJKEV031018 OJKEV031018 The rear seat passenger may use the The seatback pocket is provided on the switches to control the front passenger back of the front seatbacks. seat. • Sliding forward or rearward: CAUTION Press the switch (1) or (2) to move Do not put heavy or sharp objects in the...

  • Page 106: Rear Seats

    Rear seats - When returning the rear seatback from a folded to an upright position, hold the seatback and WARNING return it slowly. Ensure that the seatback is completely locked into Take the following precautions: its upright position by pushing •...
  • Page 107 Safety system NOTICE Folding the rear seats The rear seatbacks can be folded to To prevent damage to the vehicle: facilitate carrying long items or to • Rear seat belts increase the luggage capacity of the Before folding the seatback, insert vehicle.
  • Page 108 OJKEV031028 OJKEV031028 OJKEV031026 OJKEV031026 5. To use the rear seat, lift and unfold the seatback to the upright position by pulling up the folding lever. Push the seatback firmly until it clicks into place. Make sure the seatback is locked in place. 6.

  • Page 109: Headrest

    Safety system Headrest Armrest The vehicle’s front and rear seats have adjustable headrests. The headrests provide comfort for passengers, but more importantly they are designed to help protect passengers from whiplash and other neck and spinal injuries during an accident, especially in a rear impact collision.
  • Page 110 Front seat headrests WARNING OJKEV032021L OJKEV032021L OJX1039115 OJX1039115 The driver’s and front passenger’s seats When sitting on the rear seat, do not are equipped with adjustable headrests adjust the height of the headrest to the for the passengers safety and comfort. lowest position.
  • Page 111 Safety system OJKEV031016 OJKEV031016 OJKEV031014 OJKEV031014 Forward and rearward adjustment Removal The headrest may be adjusted forward To remove the headrest: to 3 different positions by pulling the 1. Recline the seatback (2) with the headrest forward to the desired detent. seatback angle switch (1).
  • Page 112 Rear seat headrests OJKEV031017 OJKEV031017 Reinstall OJKEV031021 OJKEV031021 To reinstall the headrest : The rear seats are equipped with headrests in all the seating positions for 1. Recline the seatback. the passenger’s safety and comfort. 2. Put the headrest poles (2) into the holes while pressing the release button (1).
  • Page 113 Safety system OJKEV032022L OJKEV032022L Removal/Reinstallation To remove the headrest: 1. Raise the headrest as far as it can go. 2. Press the headrest release button (1) while pulling the headrest up (2). To reinstall the headrest: 1. Put the headrest poles into the holes (3) while pressing the release button (1).

  • Page 114: Seat Warmers

    SEAT WARMERS (IF EQUIPPED) Use the heater and seat warmers when Information it is cold. • The seat warmer temperature is lowered automatically after a certain Front seat warmers time to prevent low temperature burn. Press from the climate control screen to adjust the temperature again.

  • Page 115: Rear Seat Warmers

    Safety system Rear seat warmers Operating rear seat warmer from front seat OJKEV032031L OJKEV032031L With the READY indicator on, press OJKEV032079L OJKEV032079L the seat warmer button on the center console to select the desired temperature level. • The temperature can be set to HIGH/ MEDIUM/LOW.
  • Page 116 3. Press to raise and to lower the CAUTION temperature. • Do not place any heavy, bumpy, and • Press and hold to turn sharp objects on the seat. It may off the seat warmer, or press damage the seat warmer. multiple times until the seat warmer •...

  • Page 117: Air Ventilation Seats

    Safety system AIR VENTILATION SEATS Use the air conditioner with the seat Information ventilators when it is hot. • The vehicle speed and driving time influences the fan speed if the seat Front air ventilation seats ventilator is set to ‘HIGH’. (For example, the fan speed is raised when the vehicle drives faster) •...
  • Page 118 CAUTION • Do not replace the seat cover. It may damage the seat ventilator. • Do not place any heavy, bumpy, and sharp objects on the seat. It may damage the seat ventilator. • Do not use organic solvents such as thinner, benzene, alcohol, or gasoline to clean the seats.

  • Page 119: Seat Belts

    Safety system SEAT BELTS This section describes how to use the • Never wear a seat belt over fragile seat belts properly. It also describes objects. If there is a sudden stop or some of the things not to do when using impact, the seat belt can damage it.

  • Page 120: Seat Belt Warning Light

    Seat belt warning light Front passenger’s seat belt warning Driver’s seat belt warning As a reminder to the front passenger, the front passenger’s seat belt warning light will illuminate for approximately 6 seconds each time the Start/Stop button is in the ON position regardless of belt fastening.
  • Page 121 Safety system Rear center seatbelt Rear passenger’s seat belt warning (if equipped) With the Start/Stop button in the ON position, if the rear center seat passenger’s seat belt is not fastened, the corresponding seat belt warning light will illuminate for 70 seconds. But, if the seatbelt is fastened after 6 seconds, the corresponding seat belt warning light will immediately turn off.

  • Page 122: Seat Belt Restraint System

    Seat belt restraint system Lap/shoulder belt WARNING ORS031126 ORS031126 To fasten your seat belt: Pull it out of the retractor and insert the ORS031127 ORS031127 metal tab (1) into the buckle (2). There Improperly positioned seat belts may will be an audible “click” when the tab increase the risk of serious injury locks into the buckle.
  • Page 123 Safety system NOTICE If you are not able to smoothly pull enough of the seat belt out from the retractor, firmly pull the seat belt out and release it. After release, you will be able to pull the belt out smoothly. Height adjustment You can adjust the height of the shoulder belt anchor to one of the four different...
  • Page 124 Rear center seatbelt Pre-tensioner seat belt (3-point rear center seat belt) OJKEV031078 OJKEV031078 Your vehicle is equipped with driver’s and ORS031048 ORS031048 front passenger’s and rear passengers 1. Take out the buckle, which is stored Pre-tensioner Seat Belts (Retractor between the seat/seatback cushions. Pre-tensioner).
  • Page 125 (4) Rear Retractor pre-tensioner (if equipped) CAUTION Body work on the front area of the vehicle may damage the pre-tensioner seat belt system. Therefore, we recommend the system to be serviced by an authorized retailer of Genesis Branded products. 3-34...

  • Page 126: Pre-Active Seat Belt (Psb)

    SRS control passenger, Pre-Active Seat Belt system module be inspected by an authorized operates as below. retailer of Genesis Branded products as • Full retraction soon as possible. The seat belt is tightened when: - Emergency braking situation occurs...

  • Page 127: Additional Seat Belt Safety Precautions

    Genesis Branded products if the warning or accident. If you are in an accident message comes on while the vehicle is while pregnant, we recommend you in motion.
  • Page 128 Larger children WARNING Children under age 13 and who are ALWAYS properly restrain infants and too large for a booster seat should small children in a Child Restraint always occupy the rear seat and use the System appropriate for the child’s available lap/shoulder belts.

  • Page 129: Care Of Seat Belts

    This should be done even if no damage is • NEVER ride with a reclined seatback visible. We recommend that you consult when the vehicle is moving. an authorized retailer of Genesis Branded • Riding with a reclined seatback products. increases your chance of serious or fatal injuries in the event of a collision or sudden stop.

  • Page 130: Child Restraint System (Crs)

    • After an accident, we recommend a can be used instead of Child Restraint retailer of Genesis Branded products System differs among countries, so to check the Child Restraint System, you should be aware of the specific...

  • Page 131: Selecting A Child Restraint System (Crs)

    Safety system Selecting a Child Restraint System (CRS) When selecting a Child Restraint System for your child, always: • Make sure the Child Restraint System has a label certifying that it meets applicable Safety Standards of your country. A Child Restraint System may only be installed if it was approved in accordance with the requirements of OJKEV031042...
  • Page 132 Booster seats A booster seat is a Child Restraint System designed to improve the fit of the vehicle’s seat belt system. A booster seat positions the seat belt so that it fits properly over the stronger parts of your child’s body. Keep your children in booster seats until they are big enough to fit in a seat belt properly.

  • Page 133: Installing A Child Restraint System (Crs)

    Safety system Installing a Child Restraint • Make sure the Child Restraint System is firmly secured. After installing a System (CRS) Child Restraint System to the vehicle, push and pull the seat forward and WARNING from side-to-side to verify that it is securely attached to the seat.
  • Page 134 Suitability of each seating position for belted & ISOFIX Child Restraint Systems according to UN regulation (for Europe) (Information for vehicle users and CRS manufacturers) • Yes: Suitable for fitment of the designated category of CRS • No: Not suitable for fitment of the designated category of CRS •...
  • Page 135 Safety system Seat number Position in the vehicle Seating positions Front left Front center Front right Second row left Second row center Second row right OJKEV032087L OJKEV032087L Ã If the vehicle headrest prevents proper installation of a CRS, the headrest of the seating position shall be readjusted or entirely removed.
  • Page 136 Suitability of each seating position for belted & ISOFIX Child Restraint Systems according to UN regulations (except Europe) (Information for vehicle users and CRS manufacturers) • Yes: Suitable for fitment of the designated category of CRS • No: Not suitable for fitment of the designated category of CRS •...
  • Page 137 Safety system Seat number Position in the vehicle Seating positions Front left Front center Front right Second row left Second row center Second row right OJKEV032087L OJKEV032087L Ã If the vehicle headrest prevents proper installation of a CRS, the headrest of the seating position shall be readjusted or entirely removed.
  • Page 138 ISOFIX anchorage and top-tether WARNING anchorage (ISOFIX anchorage Do not attempt to install a Child system) for children Restraint System using ISOFIX The ISOFIX system holds a Child anchorages in the rear center Restraint System during driving and in seating position. There are no ISOFIX an accident.
  • Page 139 Safety system 3. Place the Child Restraint System on Securing a Child Restraint System the vehicle seat, then attach the seat seat with “Top-tether Anchorage” to the ISOFIX anchorages according to system the instructions provided by the Child Restraint System manufacturer. 4.
  • Page 140 Securing a Child Restraint System WARNING with a lap/shoulder belt Take the following precautions when When not using the ISOFIX system, all installing the top-tether: Child Restraint Systems must be secured • Read and follow all installation to a rear seat with the lap part of a lap/ instructions provided with your Child shoulder belt.
  • Page 141 Safety system ORS031122 ORS031122 ORS031125 ORS031125 3. Remove as much slack from the belt 2. Fasten the lap/shoulder belt latch into the buckle. Listen for the distinct as possible by pushing down on the “click” sound. Child Restraint System while feeding the shoulder belt back into the retractor.

  • Page 142: Air Bag - Supplemental Restraint System

    AIR BAG - SUPPLEMENTAL RESTRAINT SYSTEM Left-hand drive The actual air bags in the vehicle may differ from the illustration. OJKEV032003L OJKEV032003L 1. Driver’s front air bag 5. Driver’s knee air bag 2. Passenger’s front air bag 6. Front center side air bag 3.
  • Page 143 Safety system Right-hand drive The actual air bags in the vehicle may differ from the illustration. OJKEV032003R OJKEV032003R 1. Driver’s front air bag 5. Driver’s knee air bag 2. Passenger’s front air bag 6. Front center side air bag 3. Side air bag 7.
  • Page 144 The vehicles are equipped with a Supplemental Air Bag System for the driver’s seat and front passenger’s seats. The front air bags are designed to supplement the three-point seat belts. For these air bags to provide protection, the seat belts must be worn at all times when driving. You can be severely injured or killed in an accident if you are not wearing a seat belt.

  • Page 145: Where Are The Air Bags

    Safety system Where are the air bags? The SRS consists of air bags which are located in the center of the steering Driver’s and passenger’s front air wheel, in the driver’s side lower crash bags pad below the steering wheel, and the passenger’s side front panel pad above the glove box.
  • Page 146 OJKEV032088L OJKEV032088L OJKEV032089L OJKEV032089L Passenger’s front air bag ON/OFF switch To reactivate the passenger’s front air (if equipped) bag: The purpose of the switch is to disable Insert the key or a similar rigid device the passenger’s front air bag in order into the passenger’s front air bag ON/ to transport occupants who are at OFF switch and turn it to the ON position.
  • Page 147 ON/OFF switch is set to the OFF position. • We recommend that an authorized OJKEV031055 OJKEV031055 retailer of Genesis Branded products inspect the passenger’s front air bag ON/OFF switch and the SRS air bag system as soon as possible. OJKEV031057...
  • Page 148 Genesis Branded products. • Seat belts must be worn at all times to help keep occupants positioned properly.
  • Page 149 • Do not attempt to open or repair severity. the side curtain air bags yourself. If necessary, we recommend that the air bag be inspected by an authorized retailer of Genesis Branded products. 3-58...

  • Page 150: How Does The Air Bag System Operate

    How does the air bag system Information operate? Front passenger’s air bag ON/OFF lamp is located on the overhead console. The SRSCM (Supplemental Restraint System Control Module) continually monitors all SRS components while the Start/Stop button is ON to determine if a crash impact is severe enough to require air bag deployment or pre-tensioner seat belt deployment.
  • Page 151 We recommend that an authorized protect the occupants from serious retailer of Genesis Branded products physical injury. inspect the SRS as soon as possible if • Generally, air bags are designed to any of these conditions occur.
  • Page 152 • In addition to inflating in serious side Driver’s front air bag (1) Driver’s front air bag (1) collisions, vehicles equipped with a rollover sensor, side and/or curtain air bags and front center side air bag will inflate if the sensing system detects a rollover.

  • Page 153: What To Expect After An Air Bag Inflates

    • We recommend that an authorized retailer of Genesis Branded products WARNING replace the air bag immediately after To prevent objects from becoming deployment. Air bags are designed to dangerous projectiles when the be used only once.

  • Page 154: Do Not Install A Child Restraint System On The Front Passenger Seat

    Do not install a Child Restraint Noise and smoke from inflating air System on the front passenger seat When the air bags inflate, they make a loud noise and may produce smoke and powder in the air inside of the vehicle. This is normal and is a result of the ignition of the air bag inflator.

  • Page 155: Why Didn't My Air Bag Go Off In A Collision

    To ensure correct function of the airbag system, we recommend to replace the bumper with genuine Genesis part or the equivalent (of the genuine part) specified for your vehicle. • Press the Start/Stop button to the OFF or ACC position and wait for 3...
  • Page 156 OJKEV031085 OJKEV031085 (A): SRS control module/Rollover sensor (D): Side impact sensor (Acceleration) (B): Front impact sensor (E): Side impact sensor (Acceleration) (C): Side impact sensor (Pressure) 3-65...
  • Page 157 Safety system Air bag inflation conditions Side and curtain air bags and the front center side air bag are designed to inflate when an impact is detected by side collision sensors depending on the severity of impact resulting from a side impact collision.
  • Page 158 Air bag non-inflation conditions OJKEV031067 OJKEV031067 Front air bags may not inflate in side OJKEV031070 OJKEV031070 impact collisions, because occupants In certain low-speed collisions the air move in the direction of the collision, bags may not deploy. The air bags are and thus in side impacts, front air bag designed not to deploy in such cases deployment would not provide additional...
  • Page 159 Safety system Information With rollover sensor The side and curtain air bags and the front center side air bag may inflate in a rollover situation, when it is detected by the rollover sensor. Information Without rollover sensor OJKEV031073 OJKEV031073 The side and/or curtain air bags and the Just before impact, drivers often brake front center side air bag may inflate when heavily.

  • Page 160: Srs Care

    • Do not place objects over or near retailer of Genesis Branded products. the air bag modules on the steering We recommend any work on the SRS wheel, instrument panel, and the system, such as removing, installing, front passenger’s panel above the...

  • Page 161: Additional Safety Precautions

    Safety system Additional safety precautions Air bag warning labels Passengers should not move out of or change seats while the vehicle is moving. A passenger who is not wearing a seat belt during a crash or emergency stop can be thrown against the inside of the vehicle, against other occupants, or be ejected from the vehicle.

  • Page 162: Active Hood Lift System

    We recommend that the system be repaired by an authorized retailer of Genesis Branded products. • If you change or repair the front bumper, we recommend that the system be checked by an authorized retailer of Genesis Branded products.

  • Page 163: System Limitation

    Safety system System limitation OJKEV032095L OJKEV032095L OJKEV032092L OJKEV032092L OJKEV032096L OJKEV032096L The system will not activate when: OJKEV032093L OJKEV032093L • On side collisions, rear collision, and rollover accident. The vehicle can detect only frontal collision. • The front bumper is damaged or modified.

  • Page 164: System Malfunction

    This warning message means that the protection of pedestrians by the active hood lift system is not working properly. If the warning message is displayed, we recommend that the system be checked as soon as possible by an authorized retailer of Genesis Branded products. 3-73...

  • Page 165: Instrument Cluster

    4. Instrument cluster Instrument cluster .................... 4-4 Instrument panel illumination ..................4-5 Gauges and meters ..................... 4-6 Speedometer ......................4-6 Power/charge gauge ....................4-6 State of charge (SOC) gauge for high voltage battery ..........4-7 Outside temperature gauge ..................4-8 Odometer ........................4-8 Distance to empty ....................
  • Page 166 Electronic Stability Control (ESC) OFF indicator light ........... 4-18 Immobilizer indicator light ..................4-19 Turn signal indicator light ..................4-19 High beam indicator light ..................4-19 Low beam indicator light ..................4-19 Light ON indicator light ...................4-20 Rear fog indicator light ....................4-20 Intelligent Front-Lighting System indicator light ..........4-20 High Beam Assist indicator light ................4-20 AUTO HOLD indicator light ..................4-20...
  • Page 167 4. Instrument cluster Charging door open ....................4-25 Charging stopped. Check the charger/Charging interrupted. Check the charger ........................4-25 Charging stopped. Check the cable connection/Charging interrupted. Please check the cable connection ..................4-26 Check regenerative brakes..................4-26 Low EV battery/Low battery ...................4-26 Charge immediately. Power limited ............... 4-27 Power limited due to low EV battery temperature.

  • Page 168: Instrument Cluster

    Instrument cluster INSTRUMENT CLUSTER The actual cluster in the vehicle may differ from the illustration. For more information, refer to “Gauges and meters” section in this chapter. OJKEV042001L/OJKEV042002L OJKEV042001L/OJKEV042002L 1. Speedometer 5. LCD display 2. Power/Charge gauge 6. Battery SOC (State of Charge) gauge 3.

  • Page 169: Instrument Panel Illumination

    Instrument cluster control Instrument panel illumination (if equipped) OJKEV042004L OJKEV042004L • The brightness of the instrument panel illumination is displayed. • If the brightness reaches the OJKEV041003 OJKEV041003 maximum or minimum level, a chime When the vehicle’s position lights or will sound.

  • Page 170: Gauges And Meters

    Instrument cluster Gauges and meters Power/charge gauge Speedometer OJKEV041012 OJKEV041012 OJKEV041026 OJKEV041026 OJKEV041013 OJKEV041013 The Power/Charge Gauge shows the OJKEV042026L OJKEV042026L energy consumption and recovery status of the electric motor. • POWER: It shows discharging status of the electric motor when vehicle is accelerating or driving on a uphill road.

  • Page 171: State Of Charge (Soc) Gauge For High Voltage Battery

    State of charge (SOC) gauge for high voltage battery OJKEVQ011055 OJKEVQ011055 OJKEV042014L OJKEV042014L OJKEVQ011056 OJKEVQ011056 1. When the remaining battery is lower than 10 % on the SOC gauge, the OJKEV042015L OJKEV042015L warning light ( ) turns ON to alert •...

  • Page 172: Outside Temperature Gauge

    Instrument cluster Outside temperature gauge Odometer OJKEV041010 OJKEV041010 OJKEV041005 OJKEV041005 OJKEV041011 OJKEV041011 OJKEV041006 OJKEV041006 Gauge accuracy for outside air The odometer indicates the total temperature is 1°C (1°F). distance that the vehicle has been driven and should be used to determine Note that the temperature indicated when periodic maintenance should be on the LCD display may not change...

  • Page 173: Distance To Empty

    Distance to empty Information • If the vehicle is not on level ground or the battery power has been interrupted, the distance to empty function may not operate correctly. • The distance to empty may differ from the actual driving distance as it is an estimate of the available driving distance.

  • Page 174: Reduction Gear Shift Indicator

    Instrument cluster Automatic reset Regenerative braking level indicator To automatically reset the average energy economy, select between 'After Ignition' or 'After Recharging' from the Settings menu in the infotainment system screen. Information For 8-inch instrument cluster, you can check the energy economy in the Utility view on the cluster.

  • Page 175: Warning And Indicator Lights

    In this case, we recommend that indicator light is ON. you have your vehicle inspected by an • When the power is limited for the authorized retailer of Genesis Branded safety of the high-powered parts of products. an electric vehicle, the power down indicator light illuminates.

  • Page 176: Charging Indicator Light

    • When the warning light turns ON, If this occurs, we recommend that charge the battery immediately. you have the vehicle inspected by an authorized retailer of Genesis Branded products. Seat belt warning light Regenerative brake warning light This warning light informs the driver that the seat belt is not fastened.

  • Page 177: Parking Brake & Brake Fluid Warning Light

    If a brake fluid leak is found, or if the warning light remains on, or if the brakes do not operate properly, do not drive the vehicle. We recommend that you have the vehicle inspected by an authorized retailer of Genesis Branded products. 4-13...

  • Page 178: Anti-Lock Brake System (Abs) Warning Light

    ABS. retailer of Genesis Branded products as soon as possible. If this occurs, we recommend that you have the vehicle inspected by an...

  • Page 179: Motor Driven Power Steering (Mdps) Warning Light

    If this occurs, we recommend that If this occurs, we recommend that you have the vehicle inspected by an you have the vehicle inspected by an authorized retailer of Genesis Branded authorized retailer of Genesis Branded products. products. Master warning light...

  • Page 180: Low Tire Pressure Warning Light

    The warning light will If this occurs, we recommend that you have the vehicle inspected by an illuminate on the cluster. authorized retailer of Genesis Branded • Forward Collision-Avoidance Assist products as soon as possible. will turn off when ESC is turned off by pressing and holding the ESC For more details, refer to “Tire Pressure...

  • Page 181: Lane Safety Indicator Light

    LED headlight. If this occurs, we recommend that you have the vehicle inspected by an If this occurs, we recommend that authorized retailer of Genesis Branded you have the vehicle inspected by an products. authorized retailer of Genesis Branded products.

  • Page 182: Icy Road Warning Light

    If this occurs, we recommend that Warning function from the Settings you have the vehicle inspected by an menu in the infotainment system screen. authorized retailer of Genesis Branded Select: products. - Setup → Vehicle Settings → Cluster → Content Selection → Icy Road Warning This indicator light blinks: While ESC is operating.

  • Page 183: Immobilizer Indicator Light

    If this occurs, we recommend that This indicator light illuminates: you have the vehicle inspected by an • When the headlamps are on and in authorized retailer of Genesis Branded the high beam position products. • When the turn signal lever is pulled into the Flash-to-Pass position.

  • Page 184: Light On Indicator Light

    For more details, refer to “Intelligent If this occurs, we recommend that Front-Lighting System” section in you have the vehicle inspected by an chapter 5. authorized retailer of Genesis Branded products. For more details, refer to “Electronic Parking Brake (EPB)” section in chapter 4-20...

  • Page 185: Lcd Display Messages

    Start/Stop button, we This message is displayed if the washer recommend that you have the vehicle fluid level in the reservoir is nearly empty. inspected by an authorized retailer of Have the washer fluid reservoir refilled. Genesis Branded products. 4-21...

  • Page 186: Press Start Button With Key

    You need to replace the fuse with a new Genesis Branded products. one before starting the vehicle. If that is not possible, you can start the Door, Hood, Tailgate open indicator vehicle by pressing the Start/Stop button for 10 seconds in the ACC position.

  • Page 187: Low Tire Pressure

    Low tire pressure Wiper OJKEV042020L OJKEV042020L OJKEV042054L OJKEV042054L This warning message is displayed if the tire pressure is low. The corresponding tire on the vehicle will be illuminated. For more details, refer to “Tire Pressure Monitoring System (TPMS)” section in chapter 8.

  • Page 188: Check Haptic Steering Wheel System

    We recommend that you have the vehicle inspected by an authorized retailer of Genesis Branded products. Check headlight (if equipped) This message is displayed if the headlights are not operating properly. A ORG3EVQ011117L ORG3EVQ011117L lamp may need to be replaced.

  • Page 189: Unplug Vehicle To Start

    AC or DC charger and charging cable. If the same problem occurs when charging the vehicle with a normally operating AC charger or genuine Genesis portable charger, we recommend that OJKEV042057L OJKEV042057L you have your vehicle inspected by an...

  • Page 190: Charging Stopped. Check The Cable Connection/Charging Interrupted. Please Check The Cable Connection

    In this case, we recommend that charging connector is not correctly you have the vehicle inspected by an connected to the charging inlet authorized retailer of Genesis Branded products. In this case, separate the charging connector and re-connect it and check...

  • Page 191: Charge Immediately. Power Limited

    Charging the battery before driving helps immediately. increase power. NOTICE If these warning messages are still displayed even after the ambient temperature has increased, we recommend that you have the vehicle inspected by an authorized retailer of Genesis Branded products. 4-27...

  • Page 192: Ev Battery Overheated! Stop Vehicle/Battery Overheated! Stop Safely

    Instrument cluster EV Battery Overheated! Stop Power limited vehicle/Battery overheated! Stop safely ORG3EVQ011003L ORG3EVQ011003L This warning message is displayed: OJKEV042060L OJKEV042060L • When the power is limited for the This warning message is displayed to safety of the high-powered parts of an protect battery and electric vehicle electric vehicle.

  • Page 193: Stop Vehicle And Check Power Supply/Stop Safely And Check Power Supply

    Genesis Branded by an authorized retailer of Genesis products. Branded products. Check virtual engine sound system OJKEV042062L...

  • Page 194: Lcd Display

    Instrument cluster LCD DISPLAY LCD display control OJKEV041021 OJKEV041021 The LCD display modes can be changed by using the control switches. Switch Operation Function Press MODE button for changing View modes UP, DOWN switch for changing items in Utility view and Press Option menu Press...

  • Page 195: Driving Assist View

    Driving Assist view OJKEV042047L OJKEV042047L Driving Assist, Turn by Turn, Utility view OJKEV041023 OJKEV041023 modes are displayed in the center of the The status of Smart Cruise Control, Lane instrument cluster. Following Assist, Highway Driving Assist, etc., is displayed when Driving Assist view is selected.

  • Page 196: Utility View

    Instrument cluster Utility view Information In the Utility view, using the (UP, The vehicle must be driven for a minimum DOWN) switch, you may change through of 300 meters (0.19 miles) since the last items in the following order. ignition key cycle before the driving 8-inch information is recalculated.
  • Page 197 8-inch Information The vehicle must be driven for a minimum of 300 meters (0.19 miles) since the last ignition key cycle before the accumulated driving information is recalculated. OJKEV042065L OJKEV042065L 12.3-inch 3D OJWEV041033L OJWEV041033L Tire pressure The tire pressure of each tire is displayed. For more details, refer to “Tire Pressure Monitoring System (TPMS)”...
  • Page 198 Instrument cluster Select contents/Contents configuration You can select the items to be displayed in Utility view. OJKEV041038 OJKEV041038 Energy flow/Driving force distribution (if equipped) • The electric vehicle system informs OJK040050L OJK040050L the drivers its energy flow in various 1. Press and hold the OK switch on the operating modes.

  • Page 199: Option Menu

    Option menu Press the OK switch to enter Option menu. WARNING To avoid driver distractions, do not adjust the setting while driving which may lead to an accident. Information ORG3EV041039 ORG3EV041039 Driving assist information The information provided may differ The current operation conditions of depending on which functions are Manual Speed Limit Assist, Smart Cruise applicable to your vehicle.
  • Page 200 Instrument cluster Service messages Head-up display (if equipped) OJKEV042041L OJKEV042041L OJKEV042043L OJKEV042043L When Service Messages menu is When Head-Up Display menu is selected, selected, press the OK switch on the press the OK switch on the steering steering wheel to check vehicle warning wheel.

  • Page 201: Speed Unit

    3D instrument cluster (for 12.3- Speed unit (if equipped) inch 3D cluster) 3D cluster setting To use the 3D cluster, press the Start/ Stop button to the ON position, and then select 'Setup → Vehicle Settings → 3D cluster depth → Medium/Light' in infotainment system screen.
  • Page 202 Instrument cluster - The driver is winking or wearing an Information eye patch on one eye • When your face gets too close or far to - The driver’s face is covered the instrument cluster, or the camera partially by a mask, muffler, hijab, on the instrument cluster is blocked by etc.
  • Page 203 NOTICE WARNING • You should not use the 3D cluster if you or any of your family members or relatives has a history of epilepsy, convulsions, etc. Flashing or flickering lights or specific or regular patterns shown on the cluster may stimulate epilepsy, convulsions, etc.

  • Page 204: Vehicle Settings (Infotainment System)

    Instrument cluster VEHICLE SETTINGS (INFOTAINMENT SYSTEM) Setting your vehicle OJKEV042024L OJKEV042024L Vehicle Settings in the infotainment OJKEV041025 OJKEV041025 system provides user options for a 1. Press the SETUP button on the head variety of settings including door lock/ unit of the infotainment system. unlock features, convenience features, driver assistance settings, etc.

  • Page 205: Convenience Features

    5. Convenience features Accessing your vehicle ..................5-5 Using smart key ......................5-5 Smart key precautions ....................5-9 Replacing the battery ....................5-10 Immobilizer system ..................... 5-11 Fingerprint authentication system ..............5-12 Fingerprint authentication system settings ..............5-12 Fingerprint authentication system operation ............5-13 Limitations of the system ..................
  • Page 206 Mirrors ......................5-34 Inside rearview mirror ....................5-34 Outside rearview mirrors ...................5-35 Reverse parking aid ....................5-37 Windows ......................5-39 Power windows ......................5-41 Panorama sunroof................... 5-44 Power sunshade ......................5-44 Tilt open/close ......................5-45 Slide open/close ......................5-45 Automatic reversal ....................5-46 Resetting the sunroof ....................5-47 Sunroof open warning ....................
  • Page 207 5. Convenience features Interior lights ....................5-69 Interior lamp AUTO cut ..................... 5-69 Front lamps ........................ 5-69 Rear lamps ........................5-70 Vanity mirror lamp ......................5-70 Glove box lamp ......................5-70 Door handle lamp/Mood lamp/Door courtesy lamp ..........5-71 Luggage compartment lamp ..................5-71 Puddle lamp .........................5-71 Welcome system ......................
  • Page 208 Climate control additional features ..............5-104 Auto defogging system .................... 5-104 Auto dehumidify ....................... 5-105 Recirculating air when washer fluid is used ............5-106 Auto. Controls That Use Climate Control Settings (for driver’s seat) ....5-106 Storage compartment ...................5-108 Center console storage .................... 5-108 Glove box ........................

  • Page 209: Accessing Your Vehicle

    OJKEV052230L OJKEV052230L 4. Make sure the doors are locked by Your Genesis Branded Vehicle uses a pulling the door handle. Smart Key, which you can use to lock or unlock the driver and passenger doors or the rear tailgate.
  • Page 210 Convenience features Note that you cannot lock your vehicle Unlocking your vehicle using the door handle touch sensor if any of the following occur: • The Smart Key is in the vehicle. • The Start/Stop button is in ACC or ON position.
  • Page 211 Opening the tailgate Information • The outside rearview mirror will unfold if ‘Enable on Door Unlock’ is selected from the Settings menu in the infotainment system screen. Select: - Setup → Vehicle Settings → Lights → Welcome Mirror/Light → Enable on Door Unlock •...
  • Page 212 Convenience features Remotely starting vehicle (if Remotely moving vehicle forward or equipped) backward (if equipped) You can start the vehicle using the With the smart key, the driver can move Remote Start button (4) on the smart key. the vehicle forward or backward using the Forward or Backward button (5, 6) on To start the vehicle remotely: the smart key.

  • Page 213: Smart Key Precautions

    To remove the mechanical key from the remaining keys to your authorized smart key FOB: retailer of Genesis Branded products or tow the vehicle, if necessary. Smart key precautions The smart key may not work if any of the following occur: •...

  • Page 214: Replacing The Battery

    If you suspect your smart key might have sustained some damage, or you feel your smart key is not working correctly, it is recommended that you contact an authorized retailer of Genesis Branded products. OJKEV051004 OJKEV051004 WARNING 1. Place a soft cloth over the groove (A),...

  • Page 215: Immobilizer System

    If the system repeatedly does not recognize the coding of the key, it is recommended that you contact an authorized retailer of Genesis Branded products. Do not attempt to alter this system or add other devices to it. Electrical problems could result that may make your vehicle inoperable.
  • Page 216 Convenience features FINGERPRINT AUTHENTICATION SYSTEM (IF EQUIPPED) Fingerprint authentication system allows 6. When the fingerprint enrollment the driver to have access to personal process is completed in the vehicle, information, unlock profile and exit valet the status is displayed on the mode with a enrolled fingerprint.

  • Page 217: Fingerprint Authentication System

    CAUTION Fingerprint linked Characteristic features Do not participate in duplicating your Personal fingerprint with anyone. Use with a information acess fingerprint without Profile unlock NOTICE a password Valet mode exit Touch the fingerprint authentication sensor gently. Fingerprint For detailed information, scan the QR authentication attempts with excessive code in the separately supplied simple force may fail.

  • Page 218: Fingerprint Authentication System Settings

    • When you visit an authorized retailer of Genesis Branded products to repair parts due to fingerprint authorization system or related part failure, your registered fingerprint might be deleted.

  • Page 219: Door Locks

    DOOR LOCKS Operating door locks from Using smart key outside the vehicle Using mechanical key OJKEV051001 OJKEV051001 Lock Touch the touch sensor on the front OJKEV051013 OJKEV051013 outside door handle (the engraved part) [A]: Lock, [B]: Unlock while carrying the Smart Key with you or After pulling the door handle (1), turn the press the Door Lock button on the Smart key (2) toward the front of the vehicle to...

  • Page 220: Operating Door Locks From Inside The Vehicle

    Convenience features Operating door locks from inside Information the vehicle • In cold and wet climates, door lock With the door handle and door mechanisms may not work properly due to freezing conditions. • If the door is locked/unlocked multiple times in rapid succession with either the vehicle key or door lock switch, the system may stop operating temporarily...
  • Page 221 Using the door lock/unlock switch OJKEV051017 OJKEV051017 Rear door OJKEV051015 OJKEV051015 When the lock switch (1) is pressed (door indicator light ON), all the vehicle doors will lock. When the unlock switch (2) is pressed, all the vehicle doors will unlock. Information If all doors are locked with the rear door lock switch, and the electronic child safety...
  • Page 222 Convenience features In case of an emergency WARNING • The doors should always be fully closed and locked while the vehicle is in motion. If the doors are unlocked, the risk of being thrown from the vehicle in a crash is increased.

  • Page 223: Deadlocks

    Automatic door lock and unlock CAUTION features Opening a door when something is Your vehicle is equipped with features approaching may cause damage or that will automatically lock or unlock injury. Be careful when opening doors your vehicle based on settings you select and watch for vehicles, motorcycles, in the infotainment system screen.

  • Page 224: Child-Protector Rear Door Locks

    Convenience features Child-protector rear door locks Electronic child safety lock (if (if equipped) equipped) OJKEV052018L OJKEV052018L OJKEV051019 OJKEV051019 The child safety lock is provided to help When the electronic child safety lock prevent children seated in the rear from button is pressed and the indicator accidentally opening the rear doors.
  • Page 225 If children accidentally opens the rear Genesis Branded products. door while the vehicle is in motion, they could fall out of the vehicle. Electronic Safe Exit Assist (if equipped with...

  • Page 226: Theft-Alarm System

    Convenience features THEFT-ALARM SYSTEM This system helps to protect your vehicle Information and valuables. The horn will sound and • Do not lock the doors until all the hazard warning lights will blink passengers have left the vehicle. If the continuously if any of the following remaining passenger leaves the vehicle occur:...

  • Page 227: Advanced Rear Occupant Alert (Roa)

    25 seconds. Also, manual. a text message is sent to members of Genesis Connected Services (if available). If the system continues to detect a movement, the alert operates up to 8 times.

  • Page 228: System Precautions

    Convenience features System precautions Information • The second alert is available for vehicles equipped with the ROA sensor. • Rear Occupant Alert also activates when movement is detected in the cargo area. • The second alert is activated only after the prior activation of the first alert.
  • Page 229 Declaration of Conformity WARNING The radio frequency components (ROA Even if your vehicle is equipped with Radar Sensor) complies: Advanced Rear Occupant Alert (ROA), - For Europe and CE certified countries always make sure to check the rear seat before you leave the vehicle. Advanced Rear Occupant Alert (ROA) may not operate when: •...

  • Page 230: Integrated Memory System

    • If the battery is disconnected, the memory settings will be erased. • If integrated memory system does not operate normally, we recommend that you have the system inspected by an authorized retailer of Genesis Branded products. Storing memory positions OJKEV051022 OJKEV051022 1.

  • Page 231: Recalling Memory Positions

    Recalling memory positions Resetting the system 1. Shift to P (Park) while the Start/Stop Take the following procedures to reset button is in the ON position. integrated memory system, when it does not operate properly. 2. Press the desired memory button (1 or 2).

  • Page 232: Seat Easy Access

    Convenience features NOTICE • Entering the vehicle: The driver’s seat, steering wheel and • While integrated memory system seat bolster will move as follows when is being reset, if the resetting the Start/Stop button is pressed to the and notification sound stops ACC, ON or START position or while incompletely, restart the resetting carrying the smart key, the driver’s...

  • Page 233: Steering Wheel

    • When you operate the steering wheel recommend that you take the vehicle in low temperatures, abnormal noise to an authorized retailer of Genesis may occur. If the temperature rises, the Branded products and have the system noise will disappear. This is a normal checked as soon as possible.

  • Page 234: Tilt/Telescopic Steering

    Convenience features Tilt/Telescopic steering Information When adjusting the steering wheel to a Sometimes the lock release lever may not comfortable position, adjust the steering engage completely. This may occur when wheel so that it points toward your chest, the gears of the locking mechanism do not not toward your face.

  • Page 235: Horn

    Do not strike the horn severely to authorized retailer of Genesis Branded operate it, or hit it with your fist. Do not products. press on the horn with a sharp-pointed object.

  • Page 236: Heated Steering Wheel

    Convenience features Heated steering wheel Automatic Controls Linked to Climate Control Settings (if equipped) The heated steering wheel automatically controls the steering wheel temperature depending on the ambient temperature when READY indicator is on. To use this feature, it must be enabled from the Settings menu in the infotainment system screen.
  • Page 237 NOTICE • Do not install any cover or accessory on the steering wheel. The cover or accessory could cause damage to the heated steering wheel system. • Do not strike the steering wheel grip surface with sharp objects. It may damage the heating element in the steering wheel.

  • Page 238: Mirrors

    Convenience features MIRRORS Inside rearview mirror Electric Chromic Mirror (ECM) Before driving your vehicle, check to see that your inside rearview mirror is properly positioned. Adjust the rearview mirror so that the view through the rear window is properly centered. WARNING Make sure your line of sight is not obstructed.

  • Page 239: Outside Rearview Mirrors

    Outside rearview mirrors WARNING Do not adjust or fold the outside rearview mirrors while driving. This may cause loss of vehicle control resulting in an accident. NOTICE • Do not scrape ice off the mirror face; this may damage the surface of the glass.
  • Page 240 Convenience features Adjusting the rearview mirrors Folding the rearview mirrors OJKEV051028 OJKEV051028 OJKEV051029 OJKEV051029 Adjusting the rearview mirrors: The rearview mirrors can be folded or unfolded by pressing the button. 1. When the START/STOP button is in the ACC, ON or START position, press Infotainment system setting either the L (Left side) or R (Right side) button (1) to select the rearview mirror...

  • Page 241: Reverse Parking Aid

    NOTICE Reverse parking aid (if equipped) • The electric type outside rearview mirror operates even though the Start/Stop button is in the OFF position. However, to prevent unnecessary battery discharge, do not adjust the mirrors longer than necessary while the READY indicator is off.
  • Page 242 Convenience features Resetting reverse parking aid user settings Reverse parking aid user settings mode mode To change the outside rearview mirror You may change the angle of the outside angle back to the basic angle, shift the rearview mirror if it is difficult to see gear to R (Reverse), and adjust the mirror the rear view with the basic downward angle higher than when the gear is in P...

  • Page 243: Windows

    WINDOWS Left-hand drive • Front • Rear OJKEV051032 OJKEV051032 (1) Driver’s door power window switch (4) Rear door (right) power window switch (2) Front passenger’s door power window switch (5) Window opening and closing (3) Rear door (left) power window switch (6) Automatic power window (7) Power window lock switch 5-39...
  • Page 244 Convenience features Right-hand drive • Front • Rear OJKEV052032R OJKEV052032R (1) Driver’s door power window switch (4) Rear door (left) power window switch (2) Front passenger’s door power (5) Window opening and closing window switch (6) Automatic power window (3) Rear door (right) power window (7) Power window lock switch switch 5-40...

  • Page 245: Power Windows

    To close: authorized retailer of Genesis Branded products. Pull the window switch up to the first detent position (5). Release the window switch when you want the window to WARNING stop.
  • Page 246 Convenience features Automatic reverse WARNING Make sure body parts or other objects are safely out of the way before closing the windows to avoid injuries or vehicle damage. Objects less than 4 mm (0.16 in.) in diameter caught between the window glass and the upper window channel may not be detected by the automatic reverse window and the window will...
  • Page 247 • Press the door lock button for more WARNING than 3 seconds. The doors will lock Do not allow children to play with the and the windows will move up as long power windows. Keep the driver’s as you press the door lock button. door power window lock button in the •...

  • Page 248: Panorama Sunroof

    Convenience features PANORAMA SUNROOF (IF EQUIPPED) Power sunshade If your vehicle is equipped with a sunroof, you can slide or tilt your sunroof with the sunroof switch located on the overhead console. OJKEV052236L OJKEV052236L Use the power sunshade to block direct sunlight coming through the sunroof OJKEV052235L OJKEV052235L...

  • Page 249: Tilt Open/Close

    Tilt open/close Slide open/close OJKEV052238L OJKEV052238L OJKEV052237L OJKEV052237L • Push the sunroof switch upward, the • Push the sunroof switch rearward to sunroof glass tilts open. However, if the first detent position, the sunroof the power sunshade is closed, the glass opens.

  • Page 250: Automatic Reversal

    Convenience features NOTICE Automatic reversal • Do not continue to push the sunroof switch after the sunroof is fully opened, closed, or tilted. Damage to the sunroof motor could occur. • Continuous operations such as slide open/close, tilt open/close, etc. may cause the motor or sunroof system to malfunction.

  • Page 251: Resetting The Sunroof

    Resetting the sunroof 3. Release the switch when the power sunshade and sunroof glass are fully closed. 4. Push the switch forward until the power sunshade and sunroof glass move slightly. Then release the switch. 5. Once again push and hold the sunroof switch forward until the power sunshade and sunroof glass slide open and close.

  • Page 252: Sunroof Open Warning

    Convenience features EXTERIOR FEATURES Sunroof open warning Hood Opening the hood OJKEV051220 OJKEV051220 If the driver turns off the vehicle when OJKEV051042 OJKEV051042 the sunroof is not fully closed, the 1. Park the vehicle and set the parking warning chime will sound for several brake.
  • Page 253 Front trunk Closing the hood Opening the front trunk 1. Before closing the hood, check in and around the vehicle compartment to ensure the following: - Any tools or other loose objects are removed from the motor compartment area or hood opening area - All glove, rags, or other combustible material is removed...

  • Page 254: Front Trunk

    Convenience features • Do not spray water in the front WARNING trunk. Vehicle driving system may • NEVER make an attempt to get inside get damaged since the front trunk the front trunk. It will cause a fatal is located at the center of motor injury.

  • Page 255: Power Tailgate

    NOTICE Power tailgate (IF EQUIPPED) Power tailgate operating conditions • Do not close or open the tailgate manually. This may cause damage The power tailgate operates when to the power tailgate. If it is the gear is in P (Park) with the READY necessary to close or open the indicator on.
  • Page 256 3 km/h (1.8 vehicle inspected by an authorized mph), a warning will sound 10 times. retailer of Genesis Branded products. Immediately park the vehicle at a safe Do not operate the power tailgate place, close the tailgate, and check under the following conditions.
  • Page 257 Power tailgate open/close button (Outside Operating the power tailgate the power tailgate) Power tailgate open/close button (Smart key, Instrument panel) OJKEV051045 OJKEV051045 When the tailgate is closed, press the OJKEV052240L OJKEV052240L power tailgate open/close button to open the tailgate. If the vehicle is locked, press the power tailgate open/close button with the smart key in your possession.
  • Page 258 Convenience features Power tailgate open/close button (Inside Automatic reverse the power tailgate) During power tailgate operation if the power tailgate senses any obstacle, the tailgate will stop or will fully open. The automatic reverse feature may not operate properly, or it may operate unexpectedly under the following circumstances: •...
  • Page 259 User height setting Setting the power tailgate 1. Position the tailgate manually to the To use each feature, you must select the height you prefer. opening speed or opening height from the settings menu. Deselect the settings 2. Press the power tailgate open/close when you do not want to use the feature.
  • Page 260 Genesis Branded products. • When the 12-volt battery is recharged Emergency tailgate safety release • When the 12-volt battery is reinstalled after removal or replacement •...
  • Page 261 WARNING • For emergencies, be fully aware of the location of the emergency tailgate safety release latch in the vehicle and how to open the tailgate if you are accidentally locked in the luggage compartment. • No one, including animals, should be allowed to occupy the luggage compartment of the vehicle at any time.

  • Page 262: Smart Tailgate

    Convenience features Smart tailgate Information The smart tailgate will NOT operate when: • A door is not locked or closed. • The smart key is detected within 15 seconds from when the doors were closed and locked. • The smart key is detected within 15 seconds after the doors are closed and locked, and within 1.5 m (60 in.) from the front door handles.
  • Page 263 • If you press the door unlock button Information (2), the smart tailgate will be Do not approach the detecting area if you deactivated temporarily. But, if you do do not want the tailgate to open. If you not open any door for 30 seconds, the have unintentionally entered the detecting smart tailgate will be activated again.
  • Page 264 Convenience features Detecting area Information • Smart tailgate may not operate properly if any of the following occur: - The smart key is close to a radio transmitter such as a radio station or an airport which can interfere with normal operation of the transmitter.

  • Page 265: Charging Door

    Charging door Closing the charging door Opening the charging door OJKEVQ011042 OJKEVQ011042 1. After recharging, install the charging OJKEVQ011041 OJKEVQ011041 inlet cover. 1. Depress the brake pedal and apply the parking brake. 2. Close the charging door until it is latched securely.

  • Page 266: Head-Up Display (Hud)

    Convenience features HEAD-UP DISPLAY (HUD) (IF EQUIPPED) Head-up display information OJKEV052056L OJKEV052056L The Head-Up Display is an optional OJKEV052058L OJKEV052058L feature that allows the driver to view (1) Turn by Turn (TBT) navigation information projected onto a transparent information screen while still keeping your eyes (2) Traffic signs or speed limit safely on the road ahead while driving.

  • Page 267: Precautions While Using The Head-Up Display

    Precautions while using the • For your safety, make sure to stop the vehicle before adjusting the settings. head-up display • Do not tint the front windshield glass • It may sometimes be difficult to read or add other types of metallic coating. information on the Head-Up Display in Otherwise, the Head-Up Display the following situations.

  • Page 268: Exterior Lights

    Convenience features EXTERIOR LIGHTS Lighting control Daytime Running Light (DRL) The Daytime Running Lights (DRL) can To operate the lights, turn the knob at make it easier for others to see the front the end of the control lever to one of the of your vehicle during the day, especially following positions: after dawn and before sunset.
  • Page 269 NOTICE Headlamp ( • Do not cover or spill anything on the sensor (1) located at the upper end of the windshield glass. • Do not clean the sensor using a window cleaner, the cleanser may leave a light film which could interfere with sensor operation.

  • Page 270: High Beam Operation

    Convenience features High beam operation Turn signals and lane change signals OJKEV052267L OJKEV052267L To turn on the high beam headlamp, OJKEV051073 OJKEV051073 push the lever away from you. The lever To signal a turn, push down on the lever will return to its original position. for a left turn or up for a right turn in position (A).

  • Page 271: Rear Fog Lamp

    Rear fog lamp Headlamp delay function If the Start/Stop button is in the ACC position or the OFF position with the headlamps ON, the headlamps (and/ or position lamps) remain on for about 5 minutes. However, if the driver’s door is opened and closed, the headlamps are turned off after 15 seconds.

  • Page 272: Headlight Leveling Device

    When the gear is in R (Reverse), the inspected by an authorized retailer reverse lamp turns on and the reverse of Genesis Branded products. Do not guide lamp at the back of the vehicle attempt to inspect or replace the wiring lights the floor.

  • Page 273: Interior Lights

    INTERIOR LIGHTS Front lamps WARNING Front map lamp ( Do not use the interior lights when driving in the dark. The interior lights may obscure your view and cause an accident. NOTICE Do not use the interior lights for extended periods when the vehicle is turned off or the battery will discharge.

  • Page 274: Rear Lamps

    Convenience features Rear lamps Vanity mirror lamp OJKEV051079 OJKEV051079 ORS051274 ORS051274 Opening the lid of the vanity mirror will [A]: Room lamp (without sunroof) automatically turn on the mirror lamp. • Touch the icon to turn either lamp on Glove box lamp or off.

  • Page 275: Door Handle Lamp/Mood Lamp/Door Courtesy Lamp

    Door handle lamp/Mood lamp/ Puddle lamp Door courtesy lamp (if equipped) Welcome light OJKEV051081 OJKEV051081 OJKEV051083 OJKEV051083 • Door handle lamp (A): When all doors (and tailgate) are closed and locked, the puddle lamp will turn on The lamp turns on when the position for 15 seconds if the door is unlocked by lamps are on.

  • Page 276: Welcome System

    Convenience features Welcome system Headlamp and position lamp When the light switch is ON, and all the doors (and tailgate) are closed and locked, the headlamp and position lamp will turn on for approximately 15 seconds if the door unlock button is pressed on the smart key.

  • Page 277: Intelligent Front-Lighting System (Ifs)

    INTELLIGENT FRONT-LIGHTING SYSTEM (IFS) (IF EQUIPPED) Intelligent Front-Lighting System Intelligent Front-Lighting System secures a clear view for the driver with the high operation beam on while driving at night. Operating conditions Intelligent Front-Lighting System settings OJKEV051075 OJKEV051075 1. Place the headlamp switch in the AUTO position.

  • Page 278: Intelligent Front-Lighting System Malfunction And Limitations

    After System may not work in areas with bright the message disappears, AFS and streetlights. warning lights will illuminate on the cluster. We recommend that the system be inspected by an authorized retailer of Genesis Branded products. 5-74...
  • Page 279 Intelligent Front-Lighting System Limitations of Intelligent Front- disabled Lighting System Intelligent Front-Lighting System may not work properly in the following situations: • Light from a vehicle is not detected because of lamp damage, or because it is hidden from sight, etc. •...
  • Page 280 • When the system does not operate retailer of Genesis Branded products. normally, switch the headlamp position manually between high • Pay extreme caution to keep the beam and low beam.

  • Page 281: High Beam Assist (Hba)

    HIGH BEAM ASSIST (HBA) (IF EQUIPPED) NOTICE • Always keep the front view camera in good condition to maintain optimal performance of High Beam Assist. • For more details on the precautions of the front view camera, refer to “Forward Collision-Avoidance Assist (FCA)”...

  • Page 282: High Beam Assist Operation

    Convenience features High Beam Assist operation • When High Beam Assist is operating, high beam switches to low beam if Display and control any of the following conditions occur: • After selecting ‘High Beam Assist’ - When the headlamp of an in the Settings menu, High Beam oncoming vehicle is detected.

  • Page 283: High Beam Assist Malfunction And Limitations

    We recommend that the function be inspected by an authorized retailer of Genesis Branded Information products. For more details on the limitations of the Limitations of High Beam Assist Front View Camera, refer to “Forward...

  • Page 284: Wipers And Washers

    Convenience features WIPERS AND WASHERS Front windshield wipers Operates as follows when the Start/Stop button is in the ON position. MIST (1x): For a single wiping cycle, push the lever upward (or downward) and release. The wipers will operate continuously if the lever is held in this position.
  • Page 285 AUTO (Automatic) control WARNING To avoid personal injury from the windshield wipers, when the READY indicator is on and the windshield wiper switch is placed in the AUTO mode: • Do not touch the upper end of the windshield glass facing the rain sensor.

  • Page 286: Front Windshield Washers

    Convenience features Front windshield washers WARNING When the outside temperature is below freezing, ALWAYS warm the windshield using the defroster to help prevent the washer fluid from freezing on the windshield and obscuring your vision which could result in an accident and serious injury or death.

  • Page 287: Rear Window Wiper And Washer

    Rear window wiper and washer OJKEV051088 OJKEV051088 Push the lever away from you to spray OJKEV052251L OJKEV052251L rear washer fluid and to run the rear wipers 1~3 cycles. The spray and wiper operation will continue until you release the lever. Auto rear wiper The rear wiper will operate while the vehicle is in reverse with the front wiper...

  • Page 288: Automatic Climate Control System

    Convenience features AUTOMATIC CLIMATE CONTROL SYSTEM Front seat OJKEV052100L/OJKEV051101 OJKEV052100L/OJKEV051101 [A] Front seat control 11. Rear window defroster 12. A/C (air conditioning) 1. Driver’s temperature control 13. Rear control 2. Passenger’s temperature control 14. Driver’s seat climate control 3. Fan speed control 15.
  • Page 289 Rear seat (if equipped) OJKEV052102L OJKEV052102L 1. Fan speed control 4. AUTO (automatic control) 2. Temperature control 5. Mode selection 3. OFF (system off) Information Temperature and Mode selection (air flow direction) can be controlled from the rear seat. However, if ‘Setup → Vehicle Settings → Climate → Climate Features → Lock the Rear Climate Control’...

  • Page 290: Automatic Temperature Control Mode

    Convenience features Automatic temperature control 3. Turn the temperature control knob to the desired temperature. If the mode temperature is set to the lowest The Automatic Climate Control System setting (Lo), the air conditioning is controlled by setting the desired system will operate continuously.

  • Page 291: Manual Temperature Control Mode

    Manual temperature control Information mode The heating and cooling system can be controlled manually by selecting functions other than AUTO. In this case, the system works sequentially according to the order of the functions selected. When selecting any other functions except AUTO while using automatic operation, the functions not selected will be controlled automatically.
  • Page 292 Convenience features Mode selection OJKEV052105L OJKEV052105L Rear seat mode selection OJKEV052103L OJKEV052103L • Press the button to select the direction of the air flow to the desired position. • You may select 2 modes at the same time. OJKEV051104 OJKEV051104 [A]: Front seat control, [B]: Rear seat control Front seat mode selection •...
  • Page 293 OJKEV052125L [A]: Left-hand drive Air flow direction The mode selection Icon or button controls the direction of the air flow through the ventilation system. 5-89...
  • Page 294 Convenience features OJKEV052126R [B]: Right-hand drive Air flow direction The mode selection Icon or button controls the direction of the air flow through the ventilation system. 5-90...
  • Page 295 • Front seat • Rear seat Defrost (A, D) Face-level (E) Most of the air flow is directed to the Air flow is directed toward the upper windshield. body and face. Face-level (B, D, E) Floor-level (F) Air flow is directed toward the upper Most of the air flow is directed to the body and face.
  • Page 296 Convenience features Front windshield defroster Instrument panel vents OJKEV051107 OJKEV051107 OJKEV051108 OJKEV051108 Defrost-level (A, D) Press the button, and the indicator light will illuminate and the windshield defroster indicator will appear on the climate control information screen. Most of the air flow is directed to the windshield with a small amount of air directed to the side window defrosters.
  • Page 297 Temperature control SYNC OJKEV051110 OJKEV051110 OJKEV051112 OJKEV051112 Adjusting the temperature and air flow direction equally Press SYNC (indicator light ON), the rear seat’s temperature and air flow direction will be adjusted same as the driver’s control. You can also turn the SYNC function on or off by touching the air flow direction of the driver’s seat and the passenger seat at the same time on the...
  • Page 298 Convenience features Air intake control Information Operating the system primarily in Fresh mode is recommended. Use Recirculation mode temporarily only when needed. Prolonged operation of the heater in Recirculation mode and without the air conditioning ON can cause fogging of the windshield.
  • Page 299 Fan speed control Information To help improve microphone voice input sound, fan speed may automatically slow down for a couple of minutes when you activate voice recognition or hands free. NOTICE Operating the fan when the Start/Stop button is in the ON position could cause the battery to discharge.
  • Page 300 Convenience features Driver only HEAT button OJKEV052223L OJKEV052223L OJKEV052118L OJKEV052118L If you touch the DRIVER ONLY icon Touch CLIMATE icon in the climate ) and the indicator light control panel. The climate information illuminates in the infotainment climate screen will appear on the infotainment control screen, cold air mostly blows screen.

  • Page 301: System Operation

    System operation OFF mode Cooling / Ventilation 1. Select the Face Level ( ) mode. 2. Set the air intake control to fresh or recirculation mode. 3. Set the temperature control to the desired position. 4. Set the fan speed control to the desired speed.
  • Page 302 Convenience features Air conditioning system operation tips Air conditioning • If the vehicle has been parked in Your Genesis Branded Vehicle air direct sunlight during hot weather, conditioning system is filled with R-134a open the windows for a short time or R-1234yf refrigerant.

  • Page 303: System Maintenance

    We recommend that the cabin air filter be replaced by an authorized retailer of Genesis Branded products according to WARNING the maintenance schedule. If the vehicle is being driven in severe conditions such...
  • Page 304 Convenience features WARNING Vehicles equipped with R-1234yf Since the refrigerant is mildly flammable and operated at high pressure, the air conditioning system should only be serviced by trained and certified technicians. It is important that the correct type and amount of oil and refrigerant are used.

  • Page 305: Windshield Defrosting And Defogging

    WINDSHIELD DEFROSTING AND DEFOGGING NOTICE WARNING If the vehicle temperature is still cold Windshield heating after starting, then a brief vehicle warm Do not use the position during up period may be required for the cooling operation in extremely humid vented air flow to become warm or hot.

  • Page 306: To Defrost Outside Windshield

    Convenience features To defrost outside windshield Defogging logic To reduce the probability of fogging up the inside of the windshield, the air intake or air conditioning are controlled automatically according to certain conditions such as positions. To cancel or reset the defogging logic, do the following.

  • Page 307: Rear Window Defroster

    Rear window defroster Information • If there is heavy accumulation of snow NOTICE on the rear window, brush it off before operating the rear defroster. To prevent damage to the rear window defroster conducting elements bonded • The rear window defroster to the inside surface of the rear window, automatically turns off after never use sharp instruments or window...

  • Page 308: Climate Control Additional Features

    Convenience features CLIMATE CONTROL ADDITIONAL FEATURES When the Auto Defogging Auto defogging system System operates, the indicator will illuminate. If a high amount of humidity is detected in the vehicle, the Auto Defogging System will be enabled. The following steps will be performed automatically: •...

  • Page 309: Auto Dehumidify

    NOTICE Turning the Auto Defogging System ON or OFF Do not remove the sensor cover located Climate control system on the upper end of the windshield glass. Press the front windshield defroster button for 3 seconds when the Start/Stop Damage to system parts could occur button is in the ON position.

  • Page 310: Recirculating Air When Washer Fluid Is Used

    Convenience features Recirculating air when washer Auto. Controls That Use Climate fluid is used Control Settings (for driver’s seat) Recirculation mode automatically activates to reduce any objectionable The temperature of the driver’s seat scent of the washer fluid from entering warmer, air ventilated seat and heated the cabin when the windshield washer is steering wheel is automatically...
  • Page 311 Operating Condition Recirculation mode plus (if equipped) • Type of road: Freeway, highway, expressway • To prevent the inflow of polluted air into the vehicle when passing • Vehicle status: One or more of the through a tunnel, this function windows are opened or fresh mode is automatically closes the windows and selected...

  • Page 312: Storage Compartment

    Convenience features STORAGE COMPARTMENT Center console storage WARNING Never store cigarette lighters, propane cylinders, or other flammable/explosive materials in the vehicle. These items may catch fire and/or explode if the vehicle is exposed to hot temperatures for extended periods. WARNING ALWAYS keep the storage compartment covers closed securely while driving.

  • Page 313: Sunglass Holder

    Sunglass holder (if equipped) Mobile phone holder OJKEV052254L OJKEV052254L OJKEV051090 OJKEV051090 To open: Store your phone or other small items while driving. Push and release the cover and the holder will slowly open. Place your NOTICE sunglasses in the compartment door with the lenses facing out.

  • Page 314: Interior Features

    Convenience features INTERIOR FEATURES Cup holder WARNING • Avoid abrupt starting and braking when the cup holder is in use to prevent spilling your drink. If hot liquid spills, you could be burned. Such a burn to the driver could cause loss of vehicle control resulting in an accident.

  • Page 315: Ashtray

    Ashtray (if equipped) Sunvisor OJKEV052255L OJKEV052255L ORS051275 ORS051275 To open cover: To use the sunvisor, pull it downward. Press the cover and it will slowly open. To use the sunvisor to block the sun from the side window, pull it downward, release it from the bracket (1) and swing To clean the ashtray: it to the side (2) towards the window.

  • Page 316: Power Outlet

    Convenience features Power outlet WARNING Avoid electrical shocks. Do not place your fingers or foreign objects (pin, etc.) into a power outlet or touch the power outlet with a wet hand. NOTICE To prevent damage to the power outlets: • Use the power outlet only when the READY indicator is on and remove OJKEV051093 OJKEV051093...

  • Page 317: Usb Charger

    USB charger (if equipped) • A smart phone or a tablet PC may get warmer during the re-charging process. It does not indicate any malfunction with the charging system. • A smart phone or a tablet PC, which adopts a different re-charging method, may not be properly re- charged.

  • Page 318: Wireless Smart Phone Charging System

    Convenience features Wireless smart phone charging 3. The indicator light is orange when the smart phone is charging. The indicator system (if equipped) light will turn blue when phone charging is complete. Information Remove other items, including the smart key, from the wireless charging unit. If not, the wireless charging process may be interrupted.
  • Page 319 • If the smart phone has a thick cover, Information the wireless charging may not be • The wireless smart phone charging possible. system may not support certain smart • If the smart phone is not completely phones, which are not verified for the contacting the charging pad, wireless Qi specification ( ).

  • Page 320: Clock

    Convenience features Clock WARNING The clock can be set from the infotainment system. For detailed information, scan the QR code in a separately supplied simple manual. WARNING Do not attempt to adjust the clock while driving. Doing so may result in distracted driving which may lead to an accident involving personal injury or OJKEV051200...
  • Page 321 • Ensure to remove a protective mat in place. To avoid any interference film attached on the carpet with pedal operation, Genesis Branded before attaching a floor mat on Vehicle recommends that the Genesis the front floor carpet. Otherwise,...

  • Page 322: Rear Side Window Sunshades

    2. Hang the sunshade on both sides of contact your authorized retailer of the hook (B). If the sunshade is hung Genesis Branded products to obtain a on one side of the hook, the sunshade luggage net. may be wrinkled.

  • Page 323: Cargo Security Screen

    When the cargo security screen is not in Cargo security screen (if use: equipped) 1. Pull the cargo security screen rearward and up to release it from the guides. 2. The cargo security screen will automatically slide back in. Information The cargo security screen may not automatically slide back in if the cargo security screen is not fully pulled out.
  • Page 324 Convenience features Removing the cargo security screen OJKEV052258L OJKEV052258L 2. Push in the guide pin. OJKEV052259L OJKEV052259L 1. Push one side of the cargo screen inward to compress the spring and release the screen from the vehicle. 2. While the spring is compressed, pull out the cargo security screen.

  • Page 325: Exterior Features

    Avoid sudden accessory and are available at your local starts, braking, sharp turns, abrupt retailer of Genesis Branded products. maneuvers or high speeds that may result in loss of vehicle control or rollover resulting in an accident.

  • Page 326: Infotainment System

    Convenience features INFOTAINMENT SYSTEM NOTICE Antenna • If you install an aftermarket HID head lamp, your vehicle’s audio and electronic devices may not function properly. • Prevent chemicals such as perfume, cosmetic oil, sun cream, hand cleaner, and air freshener from contacting the interior parts because they may cause damage or discoloration.

  • Page 327: Infotainment System

    Infotainment system VOLUME (VOL + / VOL -) (1) • Rotate the VOLUME scroll up to increase volume. • Rotate the VOLUME scroll down to decrease volume. SEEK/PRESET ( ) (2) If the SEEK/PRESET switch is pressed up or down and held for 0.8 second or more, it will function in the following modes: RADIO mode •...

  • Page 328: Bluetooth® Wireless Technology

    Convenience features Bluetooth® Wireless Technology Lexicon premium sound system (if equipped) CAUTION Lexicon premium sound system is equipped with speaker grills made of stainless steel. The grill surface can be heated when the vehicle is exposed to hot weather for a long period of time. Keep away from the speaker grill when it is hot.

  • Page 329: Driving Your Vehicle

    6. Driving your vehicle Before driving ....................6-4 Before entering the vehicle ..................6-4 Before starting ......................6-4 Start/Stop button ....................6-5 Start/Stop button positions ..................6-6 Starting the vehicle ...................... 6-7 Turning off the vehicle ....................6-8 Remote start ....................... 6-9 Reduction gear ....................6-10 Reduction gear operation ..................
  • Page 330 Braking system ....................6-29 Power-assist brakes ....................6-29 Disc brakes wear indicator ..................6-30 High performance brake ................... 6-30 Electronic Parking Brake (EPB) .................. 6-31 Auto Hold ........................6-35 Brake Disc Cleaning ....................6-38 Anti-lock Brake System (ABS) ..................6-39 Electronic Stability Control (ESC) ................6-40 Vehicle Stability Management (VSM) ..............
  • Page 331 Special driving conditions ................6-64 Hazardous driving conditions .................. 6-64 Rocking the vehicle ....................6-64 Smooth cornering ..................... 6-65 Driving at night ......................6-65 Driving in the rain ...................... 6-65 Driving in flooded areas .................... 6-66 Highway driving ......................6-66 Reducing the risk of a rollover ...................6-67 Winter driving ....................6-68 Snow or icy conditions ....................

  • Page 332: Before Driving

    Driving your vehicle BEFORE DRIVING Before entering the vehicle WARNING • Be sure all windows, outside mirror(s), To reduce the risk of SERIOUS INJURY or and outside lights are clean and DEATH, take the following precautions: unobstructed. • ALWAYS wear your seat belt. All •...

  • Page 333: Start/Stop Button

    START/STOP BUTTON WARNING • NEVER press the Start/Stop button while the vehicle is in motion except in an emergency. This will result in the vehicle turning off and loss of power assist for the steering and brake systems. This may lead to loss of directional control and braking function, which could cause an accident.

  • Page 334: Start/Stop Button Positions

    Driving your vehicle Start/Stop button positions Button Action Notes Position To turn off the vehicle, press the Start/ If the steering wheel is not locked Stop button with the vehicle shifted to properly when you open the driver’s P (Park). door, the warning chime will sound.

  • Page 335: Starting The Vehicle

    Starting the vehicle Starting the vehicle 1. Always carry the smart key with you. 2. Make sure the parking brake is WARNING applied. • Always wear appropriate shoes when 3. Make sure the gear is in P (Park). operating your vehicle. Unsuitable 4.

  • Page 336: Turning Off The Vehicle

    Driving your vehicle NOTICE Emergency starting To prevent damage to the vehicle: Do not press the Start/Stop button for more than 10 seconds except when the stop lamp fuse is blown. When the stop lamp fuse is blown, you cannot normally start the vehicle. Replace the fuse with a new one.

  • Page 337: Remote Start

    Remote start (if equipped) To start the vehicle remotely: 1. Press the door lock button within 10 m (32 feet) from the vehicle. 2. Press the remote start ( ) button for over 2 seconds within 4 seconds after locking the doors. 3.

  • Page 338: Reduction Gear

    Driving your vehicle REDUCTION GEAR Reduction gear operation Depress the brake pedal whenever rotating the shift dial to change gear or selecting P. WARNING To reduce the risk of serious injury or death: • ALWAYS check the surrounding areas near your vehicle for people, OJKEV061005 OJKEV061005 especially children, before shifting a...
  • Page 339 Rotary shifter/Rotary gear shift dial Information P (Park) For vehicles equipped with the Electronic Always come to a complete stop before Parking Brake (EPB), EPB engages shifting into P (Park). automatically when the gear is shifted to P (Park). Automatic gear shift to P (Park) The gear is automatically shifted to P (Park), and the Electronic Parking Brake (EPB) applies automatically under the...
  • Page 340 Driving your vehicle R (Reverse) N (Neutral) Use this position to drive the vehicle rearward. OJKEV061008 OJKEV061008 To shift the gear to N (Neutral), rotate the shift dial clockwise from R (Reverse) or OJKEV061007 OJKEV061007 counterclockwise from D (Drive) while To shift the gear to R (Reverse), rotate depressing the brake pedal.
  • Page 341 To stay in N (Neutral) when vehicle is 4. Press and hold the OK button on the steering wheel for more than 1 second. 5. When the message ‘Vehicle will stay in (N). Change gear to cancel’ (or ‘N will stay engaged when the vehicle is Off’) will appear on the cluster LCD display, press the Start/Stop button while...
  • Page 342 Driving your vehicle D (Drive) When the battery is discharged This is the normal driving position. You cannot shift gears, when the battery is discharged. It automatically activates the regenerative braking system according In emergencies, do the following to shift to the road conditions.

  • Page 343: Lcd Display Messages (Cluster)

    LCD display messages (cluster) Shift-lock system Press brake pedal to change gear For your safety, your vehicle has a shiftlock system which prevents shifting the gear from P (Park) or N (Neutral) into R (Reverse) or D (Drive) unless the brake pedal is depressed.
  • Page 344 P We recommend that you have the (Park) position. vehicle inspected by an authorized retailer of Genesis Branded products. We recommend that you have the vehicle inspected by an authorized Rotary shifter stuck/Rotary gear retailer of Genesis Branded products.

  • Page 345: Good Driving Practices

    P (Park) to the roadway, do not steer sharply. keep the vehicle from moving. Instead, slow down before pulling back into the travel lanes. • Genesis Branded Vehicle recommends you to follow all posted speed limits. 6-17...

  • Page 346: Regenerative Braking System (Paddle Shifter)

    Driving your vehicle REGENERATIVE BRAKING SYSTEM (PADDLE SHIFTER) Regenerative braking system operates • Pull and hold the left paddle shift the paddle shift lever to control the ) for over 0.5 seconds to keep regenerative braking intensity of the raising the regenerative braking vehicle.

  • Page 347: Regenerative Braking System Limitations

    Regenerative braking system One Pedal Driving limitations One pedal driving operates the paddle shift lever while coasting to control Regenerative braking intensity cannot be the intensity of regenerative braking. changed using the paddle shift lever in It assists the driver to stop the vehicle the following situations: without depressing the brake.
  • Page 348 Driving your vehicle Automatic engagement of EPB CAUTION Use one pedal driving function to bring • The vehicle may not come to a stop the vehicle to a stop and automatically although the one pedal driving engage the electronic parking brake function is active, depending on the (EPB).

  • Page 349: Using I-Pedal

    Using i-PEDAL CAUTION i-PEDAL assists the driver to accelerate, • Depending on the vehicle and road decelerate, and stop the vehicle with condition, the vehicle may not come only the accelerator pedal. to a stop although the i-PEDAL function is active. Check for the Turning on/off the i-PEDAL surroundings and depress the brake pedal to control the vehicle speed.

  • Page 350: Smart Recuperation System

    Driving your vehicle SMART RECUPERATION SYSTEM The smart recuperation system recognizes vehicle-to-vehicle distance, road gradient, and speed cameras and controls the regenerative braking level while coasting. It reduces unnecessary depressing of pedals to improve fuel efficiency and driver convenience. Information •...

  • Page 351: Smart Recuperation System Operating Condition

    Smart recuperation system Smart recuperation level operating condition settings When the regenerative braking level is displayed as AUTO and the vehicle speed is above 10 km/h, the system will automatically control the regenerative braking level under the following conditions. - The road gradient changes - Distance from the vehicle ahead reduces or increases - Speed of the vehicle ahead reduces or...

  • Page 352: Pausing Smart Recuperation System

    Driving your vehicle Pausing smart recuperation Smart recuperation intensity setting system Regenerative braking intensity of the smart recuperation system can The smart recuperation system is be adjusted to match the driver’s temporarily turned off in the following preference. Adjust the braking intensity conditions.

  • Page 353: System Warning Due To Sensor Problems

    If the warning message is still displayed after the sensors are cleaned, visit an authorized retailer of Genesis Branded products for inspection. 6-25...
  • Page 354 If the sensor is smart recuperation system cannot exposed to physical impacts, visit an react to pedestrians, vehicles making authorized retailor of Genesis Branded a sudden stop and vehicles coming products for inspection. from the opposite lane.
  • Page 355 Precautions for vehicle recognition Precautions on the curves • The front sensors may suddenly recognize the foregoing vehicle when the smart recuperation system reacts slowly, or the vehicle is going through the end of a slope or curve. In this case, the regenerative braking intensity is increased and the vehicle may slow down.
  • Page 356 Driving your vehicle Precautions on the slope Precautions for shifting lanes OJKEV061018 OJKEV061018 OJKEV061040 OJKEV061040 • When the vehicle is coasting through • If a vehicle on the next lane is moving the end of a slope or where the into the front of your vehicle, the front gradient is changing, the front sensors sensors can only recognize the vehicle...

  • Page 357: Braking System

    BRAKING SYSTEM Power-assist brakes • When descending down a long or steep hill, use the paddle shifter to Your vehicle has power-assisted brakes increase the regeneration braking that adjust automatically through normal level in order to decrease your usage. speed without using the brake In the event of a vehicle power failure, pedal excessively.

  • Page 358: Disc Brakes Wear Indicator

    Driving your vehicle Disc brakes wear indicator High performance brake When your brake pads are worn and new For vehicles equipped with the High pads are required, you will hear a high Performance Brake (large diameter pitched warning sound from your front monoblock brakes with enhanced or rear brakes.

  • Page 359: Electronic Parking Brake (Epb)

    Make sure the Parking Brake warning that you have the system checked by an light comes on. authorized retailer of Genesis Branded products. EPB (Electronic Parking Brake) may be automatically applied when: • Requested by other systems •...
  • Page 360 • Gear in N (Neutral) you have the system checked by With the vehicle in the ready (READY) an authorized retailer of Genesis mode, depress the brake pedal and Branded products. shift out of N (Neutral) to R (Reverse) •...
  • Page 361 Warning messages • NEVER allow anyone who is unfamiliar with the vehicle to touch the EPB switch. If EPB is released unintentionally, serious injury may occur. • Only release EPB when you are seated inside the vehicle with your foot firmly on the brake pedal. CAUTION In winter, the Electronic Parking Brake (EPB) related device may freeze and...
  • Page 362 ON position, this indicates that the EPB may have malfunctioned. If this occurs, we recommend that you have the system checked by an authorized retailer of Genesis Branded products. The EPB warning light may illuminate when the ESC indicator comes on to...

  • Page 363: Auto Hold

    AUTO HOLD switch. authorized retailer of Genesis Branded The white AUTO HOLD indicator will products by loading the vehicle on a come on and the system will be in the flatbed tow truck and have the system standby position.
  • Page 364 Driving your vehicle To cancel: OJKEV061026 OJKEV061026 [A]: White, [B]: Green OJKEV061027 OJKEV061027 2. When you stop the vehicle completely [A]: OFF by depressing the brake pedal, Auto 1. Depress and hold the brake pedal. Hold maintains the brake pressure 2.
  • Page 365 10 minutes properly. - The vehicle is standing on a steep We recommend that you contact an slope authorized retailer of Genesis Branded products. - The vehicle moved several times In these cases, the Parking Brake Warning messages warning light comes on, the AUTO...

  • Page 366: Brake Disc Cleaning

    Driving your vehicle Brake Disc Cleaning Use the Brake Disc Cleaning function if noise is generated when depressing the brake while driving or if the brake disc gets rusty. It helps reduce the noise and rust. Regenerative braking is restrained while Brake Disc Cleaning is operated, which may lower the electric energy efficiency.

  • Page 367: Anti-Lock Brake System (Abs)

    Anti-lock Brake System (ABS) Using ABS To obtain the maximum benefit from your ABS in an emergency situation, WARNING do not attempt to modulate your brake Anti-Lock Braking System (ABS) or pressure and do not try to pump your Electronic Stability Control (ESC) brakes.

  • Page 368: Electronic Stability Control (Esc)

    ABS system. We recommend intended path. It is not a substitute for that you contact an authorized retailer safe driving practices. Always adjust your of Genesis Branded products as soon as speed and driving to the road conditions. possible. 6-40...
  • Page 369 ESC OFF condition WARNING To cancel ESC operation: Never drive too fast for the road conditions when cornering. ESC will not prevent accidents. • State 1 Excessive speed in turns, abrupt maneuvers, and hydroplaning on wet Press the ESC OFF button briefly. The surfaces can result in severe accidents.
  • Page 370 • Do not allow wheel(s) of one axle to retailer of Genesis Branded products as spin excessively while the ESC, ABS, soon as possible. and Parking Brake warning lights The ESC OFF indicator light comes on are displayed.

  • Page 371: Vehicle Stability Management (Vsm)

    Vehicle Stability Management VSM operation (VSM) When operating Vehicle Stability Management is a When you apply your brakes under function of the Electronic Stability conditions which may activate ESC, you Control (ESC) system. It helps the vehicle may hear sounds from the brakes, or feel stay stable when accelerating or braking a corresponding sensation in the brake suddenly on wet, slippery and rough...

  • Page 372: Trailer Stability Assist (Tsa)

    - Uneven road we recommend that the vehicle be checked by an authorized retailer of When the Trailer stability assist system Genesis Branded products as soon as detects sway, the front brakes are possible. applied automatically. If it is not enough...

  • Page 373: Hill-Start Assist Control (Hac)

    Hill-Start Assist Control (HAC) Emergency Stop Signal (ESS) Hill-Start Assist Control helps prevent Emergency Stop Signal alerts the driver the vehicle from rolling backwards behind by blinking the stop lights, while when starting a vehicle from a stop sharply and severely braking. on a hill.

  • Page 374: Multi-Collision Brake (Mcb)

    Driving your vehicle Multi-Collision Brake (MCB) System off Multi-Collision Brake is canceled in the Multi-Collision Brake controls the brake following situations: automatically in the event of an accident where the air bag deploys to reduce the - The accelerator pedal is depressed risk of additional accidents that may over a certain level.

  • Page 375: Brake Assistant System (Bas)

    Brake Assistant System (BAS) Downhill Brake Control (DBC) The Brake Assistant System provides additional pressure when the brake pedal is momentarily and strongly depressed in a situation sudden braking is required while driving. The Brake Assistant System reduces the time for ABS(Anti-Lock Brake System) control to enter and consequently reduces the braking distance, by providing additional pressure up to the...
  • Page 376 System during activation. If this occurs, Downhill Brake Control malfunction is deactivated. We recommend that the system be inspected by an authorized retailer of Genesis Branded Yellow light on products as soon as possible. 6-48...
  • Page 377 Information • Downhill Brake Control may not deactivate on steep inclines even though the brake pedal or accelerator pedal is depressed. • Downhill Brake Control may not always maintain vehicle speed at a certain speed. • Downhill Brake Control does not operate when: OJK060067L OJK060067L...

  • Page 378: Good Braking Practices

    Start/Stop button to the to do so and we recommend that you call OFF position. an authorized retailer of Genesis Branded Vehicles parked with the parking brake products for assistance. not applied or not fully engaged may...

  • Page 379: All Wheel Drive (Awd)

    ALL WHEEL DRIVE (AWD) (IF EQUIPPED) NOTICE When All Wheel Drive (AWD) is activated, driving forces are distributed • Do not drive in water if the water appropriately to front and rear wheels. level is higher than the bottom of the It could improve driving performance by vehicle.
  • Page 380 If the AWD ( ) warning light stays on the instrument cluster, your vehicle may have a malfunction with the AWD system. Whenever the AWD ( ) warning light illuminates we recommend that the vehicle be inspected by an authorized retailer of Genesis Branded products as soon as possible. 6-52...
  • Page 381 Driving in sand or mud For safe AWD operation Before driving • Maintain slow and constant speed. • Use tire chains driving in mud if • Make sure all passengers are wearing necessary. seat belts. • Keep sufficient distance between your •...

  • Page 382: Emergency Precautions

    Driving your vehicle WARNING WARNING Do not drive across the contour of steep Do not grab the inside of the steering hills. A slight change in the wheel angle wheel when you are driving off-road. can destabilize the vehicle, or a stable You may hurt your arm by a sudden vehicle may lose stability if the vehicle steering maneuver or from steering...
  • Page 383 Dynamometer testing WARNING An AWD vehicle must be tested on a special four wheel chassis dynamometer. OJKEV062061L OJKEV062061L Never start or run the vehicle while OJKEV062054 OJKEV062054 an AWD vehicle is raised on a jack. [A]: Roll tester (Speedometer), The vehicle can slip or roll off of a jack [B]: Temporary free roller causing serious injury or death to you or An AWD vehicle should not be tested...

  • Page 384: Electronic Control Suspension

    Check Electronic Suspension When Electronic Control Suspension is not working properly, this warning message will appear on the cluster LCD display. If this occurs, we recommend that the system be inspected by an authorized retailer of Genesis Branded products. 6-56...

  • Page 385: Electronically Controlled Suspension With Road Preview

    Information We recommend that the system be inspected by an authorized retailer of Genesis Branded products when: • The windshield glass is replaced. • The front view camera or cover gets OJKEV051076 OJKEV051076 damaged or replaced.

  • Page 386: System Malfunction

    LCD display. If this occurs, we recommend that the system be inspected by an authorized retailer of Genesis Branded products. NOTICE If the battery level is high or low, Electronically Controlled Suspension with Road Preview may not work temporarily to protect the system.

  • Page 387: Drive Mode Integrated Control System

    DRIVE MODE INTEGRATED CONTROL SYSTEM (IF EQUIPPED) Selecting drive mode ECO, COMFORT, SPORT mode features Drive mode may be selected according ECO mode to the driver's preference or road condition. ECO mode is a driving mode that helps improve energy efficiency by limiting Changing drive mode (ECO, maximum vehicle power (torque), COMFORT, SPORT)
  • Page 388 Driving your vehicle SPORT mode SPORT mode is a driving mode that provides sporty but firm riding by making the motor response more quickly, making the steering wheel heavier and driving the vehicle with all four wheels (AWD). In SPORT mode, the energy efficiency may decrease.

  • Page 389: Drive Modes Characteristic

    Drive modes characteristic The characteristic of each components varies according to which drive mode is selected. Drive mode COMFORT SPORT TERRAIN High electric COMFORT Sporty driving SNOW, MUD, Characteristics energy driving mode mode SAND efficiency mode Button activation Press Press Press Press Indicator on the...

  • Page 390: Selecting Multi Terrain Mode

    Driving your vehicle Selecting multi terrain mode OJK060045 OJK060045 Push (1) the DRIVE/TERRAIN switch OJKEV061030 OJKEV061030 to change from Drive mode to Multi Multi terrain mode may be selected terrain mode. After the switch is pushed, according to the driver's preference or push the DRIVE/TERRAIN switch up road condition.

  • Page 391: Boost Mode

    If this occurs, we recommend that the control the vehicle when using Boost system be inspected by an authorized mode. retailer of Genesis Branded products. • Do not attempt dangerous driving while using Boost mode. Boost Mode limitations Boost mode will turn off during operation...

  • Page 392: Special Driving Conditions

    Driving your vehicle SPECIAL DRIVING CONDITIONS Hazardous driving conditions Rocking the vehicle When hazardous driving elements If it is necessary to rock the vehicle to are encountered such as water, snow, free it from snow, sand, or mud, first turn ice, mud and sand, take the following the steering wheel right and left to clear precautions:...

  • Page 393: Smooth Cornering

    NOTICE Driving in the rain If you are still stuck after rocking the Rain and wet roads can make driving vehicle a few times, have the vehicle dangerous. Here are a few things to pulled out by a tow vehicle to avoid consider when driving in the rain or on motor overheating, possible damage slick pavement:...

  • Page 394: Driving In Flooded Areas

    Driving your vehicle Highway driving Hydroplaning Tires If the road is wet enough and you are going fast enough, your vehicle may Adjust the tire inflation, as specified. have little or no contact with the road Under-inflation may overheat or damage surface and actually ride on the water.

  • Page 395: Reducing The Risk Of A Rollover

    Reducing the risk of a rollover WARNING Your multi-purpose passenger vehicle is Utility vehicles have a significantly defined as a Sports Utility Vehicle (SUV). higher rollover rate than other types of SUV’s have higher ground clearance vehicles. To prevent rollovers or loss of and a narrower track to make them control: capable of performing in a wide variety...

  • Page 396: Winter Driving

    Driving your vehicle WINTER DRIVING The severe weather conditions of winter quickly wear out tires and cause other problems. To minimize winter driving problems, you should take the following suggestions: Snow or icy conditions You need to keep sufficient distance between your vehicle and the vehicle in front of you.
  • Page 397 Summer tires Tire chains (Auto sock) • Summer tires are used to maximize the driving performance on dry roads. • If the temperature is below 7°C (44°F) or you are driving on snowy or icy roads, the summer tires lose their brake performance and traction as the tire grip weakens significantly.
  • Page 398 Driving your vehicle Chain Installation WARNING When installing tire chains, follow the The use of AutoSock (fabric snow chain) manufacturer’s instructions and mount may adversely affect vehicle handling: them as tightly possible. Drive slowly • Drive less than 30 km/h (20 mph) (less than 30 km/h (20 mph)) with or the chain manufacturer’s chains installed.

  • Page 399: Winter Precautions

    When there is the risk that your level be checked by an authorized parking brake may freeze, temporarily retailer of Genesis Branded products or apply it with the gear in P (Park). Also, in a service station. block the rear wheels in advance, so the vehicle may not roll.
  • Page 400 Driving your vehicle Do not let your parking brake freeze Carry emergency equipment Under some conditions your parking In accordance with weather conditions, brake can freeze in the engaged position. you should carry appropriate emergency This is most likely to happen when there equipment, while driving.

  • Page 401: Trailer Towing

    Ask an authorized retailer of laden mass of the vehicle may be Genesis Branded products for further exceeded by not more than 10% or 100 details before towing. kg (220.4 lbs), whichever value is lower.

  • Page 402: If You Decide To Pull A Trailer

    OOSH069129L OOSH069129L to consult an authorized retailer What is the maximum safe weight of a of Genesis Branded products for trailer? It should never weigh more than further information on additional the maximum trailer weight with trailer requirements such as a towing kit, etc.
  • Page 403 Tongue load WARNING Take the following precautions: • Never load a trailer with more weight in the rear than in the front. The front should be loaded with approximately 60% of the total trailer load; the rear should be loaded with approximately 40% of the total trailer load.
  • Page 404 Driving your vehicle Reference weight and distance hen towing a trailer Without ltem trailer With trailer package package With brake 1,800 (3,970) system Maximum trailer weight kg (Ibs.) Without brake 750 (1653) system Maximum permissible static vertical load on the coupling device 180 (397) kg (Ibs.) Recommended distance from rear wheel...

  • Page 405: Trailer Towing Equipment

    It’s important to have the correct hitch • A Genesis Branded Vehicle trailer equipment. Crosswinds, large trucks hitch accessory is available at an going by, and rough roads are a few authorized retailer of Genesis Branded reasons why you’ll need the right hitch.

  • Page 406: Driving With A Trailer

    Driving your vehicle Driving with a trailer Safety chains You should always attach chains between Towing a trailer requires a certain your vehicle and your trailer. amount of experience. Before setting out for the open road, you must get to Instructions about safety chains may know your trailer.
  • Page 407 Consult an road signs, trees, or other objects. Avoid authorized retailer of Genesis Branded jerky or sudden maneuvers. Signal well in products for assistance. advance.
  • Page 408 Driving your vehicle NOTICE Parking on hills Generally, if you have a trailer attached To prevent motor overheating: to your vehicle, you should not park your • If you tow a trailer with the maximum vehicle on a hill. gross vehicle weight and maximum trailer weight, it can cause the However, if you ever have to park your motor to overheat.

  • Page 409: Maintenance When Towing A Trailer

    Maintenance when towing a Driving the vehicle after it has been parked on a hill trailer 1. With the gear in P (Park), apply your Your vehicle will need service more brakes and hold the brake pedal down often when you regularly pull a trailer. while you: Important items to pay particular attention to include reduction gear fluid,...

  • Page 410: Vehicle Weight

    Driving your vehicle VEHICLE WEIGHT Two labels on your driver’s door sill show GAWR (Gross Axle Weight Rating) how much weight your vehicle was This is the maximum allowable weight designed to carry: the Tire and Loading that can be carried by a single axle (front Information Label and the Certification or rear).

  • Page 411: Driver Assistance System

    7. Driver assistance system Due to the infotainment software update, the description of each function of the driver assistance system may differ from the owner’s manual. In this case, for detailed information on updates, scan the QR code in the separately supplied simple manual.

  • Page 412: Forward Collision-Avoidance Assist (Fca) (If

    Driver assistance system FORWARD COLLISION–AVOIDANCE ASSIST (FCA) (IF EQUIPPED) Junction Turning function OJKEV071082 OJKEV071082 Forward Collision-Avoidance Assist is OJKEV071083 OJKEV071083 designed to help detect and monitor the Junction Turning function can help avoid vehicle ahead or help detect a pedestrian a collision with an oncoming vehicle in or cyclist in the roadway and warn the an adjacent lane when turning left (left-...
  • Page 413 Lane-Change Oncoming function (if Lane-Change Side function (if equipped) equipped) OJKEV071086 OJKEV071086 OJKEV071087 OJKEV071087 [A]: Oncoming vehicle [A]: Front-side vehicle Lane-Change Oncoming function helps Lane-Change Side function helps avoid avoid a collision with an oncoming a collision with the vehicle ahead in vehicle when changing lanes by assisting the next lane when changing lanes by the driver’s steering.
  • Page 414 Driver assistance system Evasive Steering Assist function (if Detecting sensor equipped) OJKEV051076 OJKEV051076 OJKEV071198 OJKEV071198 • Driver steering assist Evasive Steering Assist function helps avoid a collision with a vehicle, pedestrian or cyclist ahead in the same lane. When a risk of collision is detected, Evasive Steering Assist function will warn the driver and if the driver steers to avoid collision it will...
  • Page 415 • Use only genuine parts to repair or that you have your vehicle inspected replace a damaged front radar cover. by an authorized retailer of Genesis Do not apply paint to the front radar Branded products. cover.
  • Page 416 Assist settings Settings menu. If the warning light Forward safety remains ON when Forward Collision- Avoidance Assist is on, we recommend that the vehicle be inspected by an authorized retailer of Genesis Branded products. Forward cross-traffic safety (if equipped) OJKEV072001L OJKEV072001L With the vehicle on, select or deselect ‘Driver assistance →...
  • Page 417 Warning timing CAUTION • If ‘Warning only’ is selected, braking or steering (if equipped) is not assisted. • The settings for Forward safety include ‘Basic function’, ‘Junction Turning’, ‘Lane-Change Oncoming’, ‘Lane-Change Side’ and ‘Evasive Steering Assist’ (if equipped). • If Forward safety is set to ‘Off’, Junction Crossing function will not operate even when ‘Forward OJKEV072003L...
  • Page 418 Driver assistance system Warning volume Information • If the vehicle is restarted, Warning timing and Warning volume will maintain the last setting. • If 'Off' is selected, the Warning volume of Forward Collision-Avoidance Assist will not turn off, but the volume will sound as 'Low'.
  • Page 419 Forward Collision-Avoidance Assist operation Basic function The basic function for Forward Collision- Avoidance Assist is to warn and help control the vehicle depending on the collision risk level: ‘Collision Warning’, ‘Emergency Braking’ and ‘Stopping vehicle and ending brake control’. OJKEV072006L OJKEV072006L Emergency braking •...
  • Page 420 Driver assistance system Junction Turning function Junction Turning function will warn and control the vehicle depending on the collision risk level: ‘Collision Warning’, ‘Emergency Braking’ and ‘Stopping vehicle and ending brake control’. OJKEV072007L OJKEV072007L Stopping vehicle and ending brake control •...
  • Page 421 OJKEV072260L OJKEV072260L OJKEV072007L OJKEV072007L Stopping vehicle and ending brake control [A]: Left-hand drive, [B]: Right-hand drive • When the vehicle is stopped due Emergency braking to emergency braking, the ‘Drive • To warn the driver that emergency carefully’ warning message will braking will be assisted, the appear on the cluster.
  • Page 422 Driver assistance system Junction Crossing function (if equipped) Junction Crossing function will warn and control the vehicle depending on collision risk level: ‘Collision Warning’, ‘Emergency Braking’ and ‘Stopping vehicle and ending brake control’ OJKEV072010L OJKEV072010L OJKEV072011L OJKEV072011L Emergency braking • To warn the driver that emergency braking will be assisted, the ‘Emergency braking’...
  • Page 423 Lane-Change Oncoming function (if equipped) Lane-Change Oncoming function will warn and control the vehicle depending on collision risk level: ‘Collision Warning’ and ‘Emergency Steering’ OJKEV072007L OJKEV072007L Stopping vehicle and ending brake control • When the vehicle is stopped due to emergency braking, the ‘Drive carefully’...
  • Page 424 Driver assistance system Lane-Change Side function (if equipped) Lane-Change Side function will warn and control the vehicle depending on collision risk level: ‘Collision Warning’ and ‘Emergency Steering’ OJKEV072228L OJKEV072228L [A]: Left-hand drive, [B]: Right-hand drive Emergency steering • To warn the driver that emergency steering will be assisted, the ‘Emergency steering’...
  • Page 425 Evasive Steering Assist function (if equipped) Evasive Steering Assist function will warn and control the vehicle with ‘Emergency steering’. OJKEV072015L OJKEV072015L OJKEV072016L OJKEV072016L Emergency steering • To warn the driver that emergency steering will be assisted, the ‘Emergency steering’ warning message will appear on the cluster, OJKEV072017L OJKEV072017L...
  • Page 426 Driver assistance system CAUTION • The steering wheel may turn automatically when emergency steering is operating. • Emergency steering will automatically cancel when risk factors disappear. If necessary, the driver must steer the vehicle. • Emergency steering may not operate or may cancel during operation if OJKEV072017L OJKEV072017L...
  • Page 427 • Depending on the road and driving WARNING conditions, Forward Collision- Take the following precautions when Avoidance Assist may warn the driver using Forward Collision-Avoidance late or may not warn the driver. Assist: • During Forward Collision-Avoidance • For your safety, only change the Assist operation, the vehicle may Settings after parking the vehicle at a stop suddenly injuring passengers...
  • Page 428 We Oncoming, Lane-Change Side and recommend that the vehicle be inspected Evasive Steering Assist will not assist by an authorized retailer of Genesis you with steering but only warn you Branded products. of a collision (if equipped).
  • Page 429 • The field of view of the front view inspected by an authorized retailer of camera is obstructed by sun glare Genesis Branded products. • Street light or light from an oncoming traffic is reflected on the wet road surface, such as a puddle on the road •...
  • Page 430 Driver assistance system • The surrounding is very dark, such as • A material is near that reflects very in a tunnel, etc. well on the front radar, such as a guardrail, nearby vehicle, etc. • The brightness changes suddenly, for example when entering or exiting a •...
  • Page 431 • Driving on an incline road, curved road, etc. • Driving through a roadside with trees or streetlights • The adverse road conditions cause excessive vehicle vibrations while driving • Your vehicle height is low or high due to heavy loads, abnormal tire pressure, etc.
  • Page 432 Driver assistance system • Driving on a highway (or motorway) • There are markings on the road near ramp or driving through a tollgate the lane or the markings on the road looks similar to the lane markings • Driving on a road where the guardrail or wall is in double structure •...
  • Page 433 WARNING • Driving on a curved road OJKEV071094 OJKEV071094 OJKEV071091 OJKEV071091 OJKEV071095 OJKEV071095 OJKEV071096 OJKEV071096 Forward Collision-Avoidance Assist may detect a vehicle, pedestrian or cyclist in the next lane or outside the OJKEV071092 OJKEV071092 OJKEV071093 OJKEV071093 lane when driving on a curved road. Forward Collision-Avoidance Assist may not detect other vehicles, If this occurs, Forward Collision-...
  • Page 434 Driver assistance system • Driving on an inclined road Forward Collision-Avoidance Assist may not detect other vehicles, pedestrians or cyclists in front of you while driving uphill or downhill, adversely affecting the performance of the sensors. This may result in unnecessary warning, braking assist or steering assist (if equipped) or no warning, braking assist or steering assist (if...
  • Page 435 • Changing lanes OJKEV071101 OJKEV071101 [A]: Your vehicle, OJKEV071100 OJKEV071100 [B]: Lane changing vehicle, [A]: Your vehicle, [C]: Same lane vehicle [B]: Lane changing vehicle When a vehicle in front of you When a vehicle moves into your lane merges out of the lane, Forward from an adjacent lane, it cannot Collision-Avoidance Assist may not be detected by the sensor until it...
  • Page 436 Driver assistance system • Detecting vehicle WARNING • When you are towing a trailer or another vehicle, turn off Forward Collision-Avoidance Assist for safety reasons. • Forward Collision-Avoidance Assist may operate if objects that are similar in shape or characteristics to vehicles, pedestrians and cyclists are detected.
  • Page 437 LANE KEEPING ASSIST (LKA) (IF EQUIPPED) Lane Keeping Assist settings Lane Keeping Assist is designed to help detect lane markings (or road edges) Lane safety while driving over a certain speed. Lane Keeping Assist will warn the driver if the vehicle leaves the lane without using the turn signal, or will automatically assist the driver’s steering to help prevent the...
  • Page 438 Driver assistance system Lane Keeping Assist operation Warning volume Turning Lane Keeping Assist On/Off OJKEV072261L OJKEV072261L With the vehicle on, select ‘Driver OJKEV071144 OJKEV071144 assistance → Warning volume’ or ‘Sound • For Europe → Driver assistance → Warning volume’ Whenever the vehicle is turned on, from the Settings menu to change the Lane Keeping Assist will always turn Warning volume to ‘High’, ‘Medium’,...
  • Page 439 Lane Keeping Assist will warn and help Lane Keeping Assist control the vehicle with Lane Departure • To warn the driver that the vehicle Warning and Lane Keeping Assist. is departing from the projected lane in front, the green indicator Warning and control light will blink on the cluster, and the steering wheel will make adjustments...
  • Page 440 Driver assistance system WARNING Information • For more details on instrument cluster • The steering wheel may not be settings, refer to “LCD display control” assisted if the steering wheel is held section in chapter 4. very tight or the steering wheel is steered over a certain degree.
  • Page 441 • The lane suddenly disappears, such as Genesis Branded products. at the intersection Limitations of Lane Keeping Assist • The lane (or road width) is very wide...
  • Page 442 Driver assistance system • You may not hear the warning WARNING sound of Lane Keeping Assist if the Take the following precautions when surrounding is noisy. using Lane Keeping Assist: • If you attach objects to the steering • The driver has the responsibility to wheel, steering may not be assisted safely drive and control the vehicle.
  • Page 443 BLIND-SPOT COLLISION-AVOIDANCE ASSIST (BCA) (IF EQUIPPED) Blind-Spot Collision-Avoidance Assist is designed to help detect and monitor approaching vehicles in the driver’s blind spot area and warn the driver of a possible collision with a warning message and audible warning. In addition, if there is a risk of collision when changing lanes or driving forward out of a parking space, Blind-Spot Collision-Avoidance Assist can help avoid...
  • Page 444 Driver assistance system Detecting sensor OJKEV071107 OJKEV071107 When you are driving forward out of a OJKEV051076 OJKEV051076 parking space, if Blind-Spot Collision- Avoidance Assist judges that there is a collision risk with an approaching vehicle in the blind spot, it can help avoid collision by applying the brake.
  • Page 445 Blind-spot safety Collision-Avoidance Assist may not operate properly. We recommend that the vehicle be inspected by an authorized retailer of Genesis Branded products. • If the detecting sensors have been replaced or repaired, we recommend that the vehicle be inspected by an authorized retailer of Genesis Branded products.
  • Page 446 Driver assistance system Warning timing OJKEV072230L OJKEV072230L When the vehicle is restarted with Blind- OJKEV072003L OJKEV072003L Spot Collision-Avoidance Assist off, the With the vehicle on, select ‘Driver ‘Blind-spot safety system is Off’ message assistance → Warning timing’ from the will appear on the cluster. Settings menu to change the initial If you change the setting from ‘Off’...
  • Page 447 Warning volume CAUTION • The setting of the Warning timing and Warning volume applies to all functions of Blind-Spot Collision- Avoidance Assist. • Even though ‘Normal (Standard)’ is selected for Warning timing, if a vehicle approaches at high speed, the warning may seem late. •...
  • Page 448 Driver assistance system Collision warning Collision-Avoidance Assist (while driving) • Collision warning will operate when the turn signal is turned on in the direction of the detected vehicle. • To warn the driver of a collision, the warning light on the outside rearview mirror and head-up display (if equipped) will blink.
  • Page 449 • Emergency braking will be assisted to CAUTION help prevent collision with the vehicle • Collision-avoidance assist will in the blind spot area. be cancelled under the following • Blind-Spot Collision-Avoidance Assist circumstances: will operate when your vehicle speed - your vehicle enters the next lane is below 3 km/h (2 mph) and the by a certain distance speed of the vehicle in the blind spot...
  • Page 450 Driver assistance system • Blind-Spot Collision-Avoidance Assist WARNING does not operate in all situations and Take the following precautions when cannot avoid all collisions. using Blind-Spot Collision-Avoidance • Blind-Spot Collision-Avoidance Assist: Assist may warn the driver late or • For your safety, only change the may not warn the driver depending Settings after parking the vehicle at a on the road and driving conditions.
  • Page 451 Genesis Branded products. for several seconds, and the master ) warning light will illuminate on the cluster. If this occurs, we recommend that the vehicle be inspected by an authorized retailer of Genesis Branded products. 7-41...
  • Page 452 • The temperature around the retailer of Genesis Branded products. detecting sensor is high or low due to surrounding environment. • The detecting sensor is blocked while driving near a vehicle, pillar, or wall.
  • Page 453 • The road pavement (or the peripheral • There is a curb or road edges without ground) abnormally contains metallic a lane components (for example, possibly • The vehicle in front is driving with one due to subway construction). side on the lane marking •...
  • Page 454 Driver assistance system Blind-Spot Collision-Avoidance Assist • Driving on an curved road may not operate properly, or it may operate unexpectedly when the following objects are detected: • A motorcycle or bicycle is detected • A vehicle such as a flat trailer is detected •...
  • Page 455 • Driving on an inclined road • Driving where the heights of the lanes are different OJKEV071113 OJKEV071113 Blind-Spot Collision-Avoidance OJKEV071115 OJKEV071115 Assist may not operate properly Blind-Spot Collision-Avoidance when driving on a slope. The Assist may not operate properly function may not detect the vehicle when driving where the heights of in the next lane or may incorrectly...
  • Page 456 Driver assistance system SAFE EXIT WARNING (SEW) (IF EQUIPPED) Detecting sensor OJKEV072285L OJKEV072285L After the vehicle stops, when an OJKEV071117 OJKEV071117 approaching vehicle from the rear area [1] : Rear corner radar is detected after a passenger opens Refer to the picture above for the the door, Safe Exit Warning will warn detailed location of the detecting the driver with a warning message and...

  • Page 457: Safe Exit Warning (Sew)

    Safe Exit Warning settings Setting features OJKEV072261L OJKEV072261L Warning volume With the vehicle on, select ‘Driver OJKEV072266L OJKEV072266L assistance → Warning volume’ or ‘Sound Safe Exit Warning → Driver assistance → Warning volume’ With the vehicle on, select ‘Driver from the Settings menu to change the assistance →...
  • Page 458 Driver assistance system Safe Exit Warning operation • Safe Exit Warning does not operate in all situations and cannot prevent Safe Exit Warning all collisions. • Safe Exit Warning may warn the driver late or may not warn the driver depending on the road and driving conditions.
  • Page 459 ) warning light will we recommend that the vehicle be illuminate on the cluster. If this occurs, inspected by an authorized retailer of we recommend that the vehicle be Genesis Branded products. inspected by an authorized retailer of Genesis Branded products. 7-49...
  • Page 460 3 seconds after the vehicle is inspected by an authorized retailer of started, or the rear corner radars are Genesis Branded products. initialized. WARNING • Even though the warning message does not appear on the cluster, Safe Exit Warning may not properly operate.
  • Page 461 SAFE EXIT ASSIST (SEA) (IF EQUIPPED) CAUTION • Warning timing may vary depending on the speed of the approaching vehicle. • Do not use Safe Exit Assist instead of the electronic child safety lock button. To protect rear seat passengers, use the electronic child safety lock button.
  • Page 462 Driver assistance system Safe Exit Assist settings Warning volume Safe Exit Assist OJKEV072261L OJKEV072261L With the vehicle on, select ‘Driver OJKEV072265L OJKEV072265L assistance → Warning volume’ or ‘Sound With the vehicle on, select ‘Driver → Driver assistance → Warning volume’ assistance →...
  • Page 463 Safe Exit Assist operation Safe Exit Assist linked with Electronic child safety lock Collision warning when exiting vehicle OTM070145L OTM070145L • When Electric child safety lock is OJKEV051027 OJKEV051027 operating and an approaching vehicle from the rear area is detected, the rear doors cannot be unlocked even if the driver tries to unlock the rear doors using the electronic child safety...
  • Page 464 Driver assistance system CAUTION WARNING If the driver presses the electronic Take the following precautions when child safety lock button again within using Safe Exit Assist: 10 seconds after the warning message • For your safety, change the Settings appears, Safe Exit Assist judges that after parking the vehicle at a safe the driver has unlocked the doors location.
  • Page 465 ) warning light will we recommend that the vehicle be illuminate on the cluster. If this occurs, inspected by an authorized retailer of we recommend that the vehicle be Genesis Branded products. inspected by an authorized retailer of Genesis Branded products. 7-55...
  • Page 466 3 seconds after the vehicle is inspected by an authorized retailer of started, or the rear corner radars are Genesis Branded products. initialized. WARNING • Even though the warning message does not appear on the cluster, Safe Exit Assist may not properly operate.
  • Page 467 MANUAL SPEED LIMIT ASSIST (MSLA) OJKEV071027 OJKEV071027 OJKEV071119 OJKEV071119 (1) Speed Limit indicator 2. Push the + switch up or - switch down, and release it at the desired speed. (2) Set speed Push the + switch up or - switch down You can set the speed limit when you do and hold it.
  • Page 468 Driver assistance system Temporarily pausing Manual Speed Limit Assist OJKEV071028 OJKEV071028 3. The set speed limit will be displayed on the cluster. OJKEV071120 OJKEV071120 If you would like to drive over the Press the switch to temporarily preset speed limit, depress the pause the set speed limit.
  • Page 469 Resuming Manual Speed Limit Assist Turning off Manual Speed Limit Assist OJKEV071119 OJKEV071119 To resume Manual Speed Limit Assist OJKEV071118 OJKEV071118 after the function was paused, operate Press the Driving Assist ( ) button to the +, -, switch. turn Manual Speed Limit Assist off. The Speed Limit ( ) indicator will go If you push the + switch up or –...
  • Page 470 Driver assistance system INTELLIGENT SPEED LIMIT ASSIST (ISLA) (IF EQUIPPED) Intelligent Speed Limit Assist Intelligent Speed Limit Assist uses information from the detected road sign settings and navigation system to inform the Speed Limit driver of the speed limit and additional information of the current road.
  • Page 471 Intelligent Speed Limit Assist Speed Limit Offset operation Intelligent Speed Limit Assist will warn and control the vehicle by ‘Displaying speed limit’, ‘Warning overspeed’ and ‘Changing set speed’. Information Intelligent Speed Limit Assist warning and control are described based on the Offset adjust to '0'.
  • Page 472 Driver assistance system Displaying speed limit Warning overspeed OJKEV072031L OJKEV072031L OJKEV071032 OJKEV071032 Speed limit information is displayed on When driving at a speed higher than the the instrument cluster. displayed speed limit, the speed limit is displayed in red. Information Changing set speed •...

  • Page 473: Manual Speed Limit Assist (Msla)

    Intelligent Speed Limit Assist be inspected by an authorized retailer of may not operate properly. Genesis Branded products. Information • For more details on Manual Speed Limit Assist operation, refer to “Manual Speed Limit Assist (MSLA)”...
  • Page 474 • The distance between the vehicle and we recommend that the vehicle be inspected by an authorized retailer of the road signs is too far Genesis Branded products. • The vehicle encounters illuminant road signs WARNING • Intelligent Speed Limit Assist...
  • Page 475 • The minimum speed limit sign is on WARNING the road • Intelligent Speed Limit Assist is a • The brightness changes suddenly, for supplemental function that helps the example when entering or exiting a driver to comply with the speed limit tunnel or passing under a bridge on the road, and may not display the •...

  • Page 476: Driver Attention Warning (Daw)

    Driver assistance system DRIVER ATTENTION WARNING (DAW) (IF EQUIPPED) Driver Attention Warning settings Basic function Driver Attention Warning can help Driver Attention Warning determine the driver's attention level by analyzing driving pattern and driving time while the vehicle is driven. Driver Attention Warning will recommend a break when the driver’s attention level falls below a certain level.
  • Page 477 Leading vehicle departure alert Warning timing OJKEV072037L OJKEV072037L OJKEV072003L OJKEV072003L • If ‘Leading vehicle departure alert’ is With the vehicle on, select ‘Driver selected, the function will inform the assistance → Warning timing’ from the driver when a detected vehicle in front Settings menu to change the initial departs from a stop.
  • Page 478 Driver assistance system Driver Attention Warning WARNING operation For your safety, only change the Basic function Settings after parking the vehicle at a The basic function of Driver Attention safe location. Warning is to warn the driver ‘Consider taking a break’. CAUTION Taking a break •...
  • Page 479 • The driver has the responsibility to Genesis Branded products. safely drive and control the vehicle. CAUTION • Leading Vehicle Departure Alert is a supplemental function and may not alert the driver whenever the front vehicle departs from a stop.
  • Page 480 Driver assistance system Limitations of Driver Attention • When the vehicle ahead sharply steers Warning Driver Attention Warning may not work properly in the following situations: • The vehicle is driven violently • The vehicle intentionally crosses over lanes frequently •...
  • Page 481 • When a pedestrian or bicycle is • When driving at a tollgate or between you and the vehicle ahead intersection, etc. OJKEV071124 OJKEV071124 OJKEV071126 OJKEV071126 If there is a pedestrian(s) or bicycle(s) If you pass a tollgate or intersection in between you and the vehicle in with lots of vehicles or you drive front, Leading Vehicle Departure Alert...

  • Page 482: Forward Attention Warning (Faw)

    Driver assistance system FORWARD ATTENTION WARNING (FAW) (IF EQUIPPED) Forward Attention Warning can warn the driver to help prevent the driver from being distracted while using the interior view camera installed in the instrument cluster. Forward Attention Warning settings Setting features OJKEV072003L OJKEV072003L Warning timing...
  • Page 483 Forward Attention Warning WARNING operation If any other system’s warning message Operating conditions is displayed or audible warning Forward Attention Warning will operate is generated, Forward Attention when the following conditions are Warning's warning message may not be displayed and audible warning may not satisfied: be generated.
  • Page 484 Forward cluster. If this occurs, we recommend Attention Warning is able to detect the that the vehicle be inspected by an driver’s face, the function will operate authorized retailer of Genesis Branded properly. products. 7-74...
  • Page 485 • When cleaning the instrument CAUTION cluster or camera, wipe with a soft and clean cloth to prevent damages on the surface of the cluster or camera lens. In addition, you should not use sharp tools near the cluster or camera, or use chemicals to clean the cluster or camera.
  • Page 486 Driver assistance system Limitations of Forward Attention • The driver is improperly positioned in Warning the driver's seat so that the driver’s face is not detected Forward Attention Warning may be • The driver is too tall or short limited or may not operate properly in the following circumstances: •...
  • Page 487 BLIND-SPOT VIEW MONITOR (BVM) (IF EQUIPPED) Detecting sensor OJKEV071194 OJKEV071194 OJKEV071128 OJKEV071128 [A], [B]: Wide-side view camera Refer to the picture above for the detailed location of the detecting sensors. Blind-Spot View Monitor settings Setting features Blind-Spot View With the vehicle on, select ‘Driver OJKEV071195 OJKEV071195 assistance →...
  • Page 488 Genesis Brand products. WARNING • The image shown on the cluster may differ from the actual distance of the object.
  • Page 489 SMART CRUISE CONTROL (SCC) (IF EQUIPPED) Smart Cruise Control is designed to Detecting sensor help detect the vehicle ahead and help maintain the desired speed and minimum distance between the vehicle ahead. Overtaking Acceleration Assist While Smart Cruise Control is operating, if the function judges that the driver is determined to overtake the vehicle in front, acceleration will be assisted.
  • Page 490 Driver assistance system Smart Cruise Control settings Driving Style settings (if equipped) Smart Cruise Control OJKEV072039L OJKEV072039L With the vehicle on, select ‘Driver OJKEV072210L OJKEV072210L assistance → Driving convenience → SCC With the vehicle on, select ‘Driver (Smart Cruise Control)’ from the Settings assistance →...
  • Page 491 Smart Cruise Control operation Warning volume Operating conditions for basic function Basic function Smart Cruise Control operates when the following conditions are satisfied. • The gear is in D (Drive) • Your vehicle speed is within the operating speed range - 10-200 km/h (5-120 mph): when there is no vehicle in front OJKEV072261L...
  • Page 492 Driver assistance system Operating conditions for Turning on Smart Cruise Control Acceleration Assist Overtaking Acceleration Assist operates when the turn signal indicator is turned on to the left (left-hand drive) or turned on to the right (right-hand drive) while Smart Cruise Control is operating, and the following conditions are satisfied: •...
  • Page 493 Setting vehicle distance Increasing set speed OJKEV071129 OJKEV071129 OJKEV071130 OJKEV071130 Each time the button is pressed, the • Push the + switch up and release headway changes as follows: it immediately. The set speed will increase by 1 km/h (1 mph) each time the switch is operated in this manner.
  • Page 494 Driver assistance system Decreasing set speed Resuming Smart Cruise Control OJKEV071133 OJKEV071133 OJKEV071131 OJKEV071131 To resume Smart Cruise Control after the • Push the - switch down and release function was cancelled, operate the +, - it immediately. The set speed will switch.
  • Page 495 Turning off Smart Cruise Control Displaying operating status You can see the status of the Smart Cruise Control operation in the Driving Assist view on the cluster. Refer to “View Modes” section in chapter 4. Smart Cruise Control will be displayed as below depending on the status of the function.
  • Page 496 Driver assistance system WARNING Information • The distance of the front vehicle on the Be careful when accelerating cluster is displayed according to the temporarily, because the speed and actual distance between your vehicle distance is not controlled automatically and the vehicle ahead. even if there is a vehicle in front of you.
  • Page 497 Temporarily cancelling Smart Cruise WARNING Control When Smart Cruise Control is temporarily cancelled, distance with the front vehicle will not be maintained. Always have your eyes on the road while driving, and if necessary, depress the brake pedal to reduce your driving speed in order to maintain a safe distance.
  • Page 498 Driver assistance system In traffic situation Warning road conditions ahead OJKEV072240L OJKEV072240L OJKEV072241L OJKEV072241L In traffic, your vehicle will stop if the In the following situation, the ‘Watch for vehicle ahead of you stops. Also, if the surrounding vehicles’ warning message vehicle ahead of you starts moving, your will appear on the cluster, and an audible vehicle will start as well.
  • Page 499 Collision warning WARNING Take the following precautions when using Smart Cruise Control: • Smart Cruise Control does not substitute for proper and safe driving. It is the responsibility of the driver to always check the speed and distance to the vehicle ahead. •...
  • Page 500 Driver assistance system • When maintaining distance with • Vehicles moving in front of you with the vehicle ahead, if the front a frequent lane change may cause vehicle disappears, Smart Cruise a delay in Smart Cruise Control Control may suddenly accelerate to reaction or may cause Smart Cruise the set speed.
  • Page 501 Genesis • You may hear a sound when the brake Branded products. is controlled by Smart Cruise Control.
  • Page 502 Driver assistance system Smart Cruise Control disabled Limitations of Smart Cruise Control Smart Cruise Control may not operate properly, or it may operate unexpectedly under the following circumstances: • The detecting sensor or the surroundings are contaminated or damaged • Washer fluid is continuously sprayed, or the wiper is on •...
  • Page 503 • Only part of the vehicle is detected • The vehicle in front is bent out of shape • The vehicle in front has no tail lights, tail lights are located unusually, etc. • The front vehicle’s speed is fast or slow •...
  • Page 504 Driver assistance system • Driving on a curved road • Driving on an inclined road OJKEV071091 OJKEV071091 OJKEV071097 OJKEV071097 On curves, Smart Cruise Control may During uphill or downhill driving, the not detect a vehicle in the same lane, Smart Cruise Control may not detect and may accelerate to the set speed.
  • Page 505 • Changing lanes • Situations when detecting are limited OJKEV071136 OJKEV071136 OJKEV071100 OJKEV071100 OJKEV071102 OJKEV071102 [A]: Your vehicle, [B]: Lane changing vehicle In the following cases, some vehicles, When a vehicle moves into your lane pedestrians or animals in your lane from an adjacent lane, it cannot be cannot be detected by the sensor: detected by the sensor until it is in the...
  • Page 506 Driver assistance system - Narrow vehicles, such as motorcycles or bicycles - Special vehicles - Animals and pedestrians Adjust your vehicle speed by depressing the brake pedal according to the road and driving conditions ahead. In the following cases, the vehicle in front cannot be detected by the sensor: OJKEV071138...

  • Page 507: Navigation-Based Smart Cruise Control (Nscc)

    NAVIGATION-BASED SMART CRUISE CONTROL (NSCC) (IF EQUIPPED) Navigation-based Smart Cruise Navigation-based Smart Cruise Control can help drive at a certain speed Control settings according to the road conditions when driving on highways (or motorways) by using road information from the navigation system while Smart Cruise Control is operating.
  • Page 508 Driver assistance system Navigation-based Smart Cruise Control operation Operating conditions Navigation-based Smart Cruise Control is ready to operate if all of the following conditions are satisfied: • Smart Cruise Control is operating • Driving on main roads of highways (or motorways) OJKEV071048 OJKEV071048...
  • Page 509 Highway Curve Zone Auto Slowdown WARNING • Depending on the curve ahead on the highway (or motorway), the vehicle will decelerate, and after passing the curve, the vehicle will accelerate to Smart Cruise Control set speed. • Vehicle deceleration time may differ depending on the vehicle speed and the degree of the curve on the road.
  • Page 510 Driver assistance system Limitations of Navigation-based • If Highway Set Speed Auto Change function has changed to the standby Smart Cruise Control state by depressing the brake pedal Navigation-based Smart Cruise Control or pressing the switch on the may not operate properly under the steering wheel, press the switch following circumstances:...
  • Page 511 • The driver goes off course the route set in the navigation • The route to the destination is changed or cancelled by resetting the navigation • The vehicle enters a service station or rest area • Android Auto or Car Play is operating •...
  • Page 512 Driver assistance system OJKEV072283L OJKEV072283L OJKEV072284L OJKEV072284L [1]: Set route, [2]: Branch line, [3]: Driving route, [1]: Driving route, [2]: Branch line, [4]: Main road, [5]: Curved road section [3]: Curved road section, [4]: Main road • When there is a difference between •...
  • Page 513 • If the driver accelerates and WARNING releases the accelerator pedal while • Navigation-based Smart Cruise Navigation-based Smart Cruise Control is not a substitute for safe Control is operating, the vehicle may driving practices, but a convenience not decelerate sufficiently or may function.
  • Page 514 Driver assistance system LANE FOLLOWING ASSIST (LFA) (IF EQUIPPED) Lane Following Assist settings Lane Following Assist is designed to help detect lane markings and/or vehicles on Warning volume the road, and assists the driver’s steering to help center the vehicle in the lane. Detecting sensor OJKEV072261L OJKEV072261L...
  • Page 515 Lane Following Assist operation Lane Following Assist Turning Lane Following Assist On/ OJKEV071049 OJKEV071049 If the vehicle ahead and/or both lane markings are detected and your vehicle OJKEV071144 OJKEV071144 speed is below 200 km/h (120 mph), the With the vehicle on, shortly press the green indicator light illuminates on Lane Driving Assist button located on the...
  • Page 516 Driver assistance system Hands-off warning OJKEV072244L OJKEV072244L If the driver still does not have their OJKEV072022L OJKEV072022L hands on the steering wheel after the If the driver takes their hands off the hands-off warning, the ‘LFA (Lane steering wheel for several seconds, the Following Assist) cancelled’...
  • Page 517 Genesis Branded products. theme selected from the settings menu. Limitations of Lane Following Assist • If lane markings are not detected,...
  • Page 518 Driver assistance system HIGHWAY DRIVING ASSIST (HDA) (IF EQUIPPED) Basic function Highway Lane Change Assist (if equipped) Highway Driving Assist is designed to Highway Lane Change Assist function do the following while driving on the helps change lanes to the direction the highway: driver slightly moves the turn signal switch if the function judges that lane...
  • Page 519 Detecting sensor CAUTION For more details on the precautions of the detecting sensors, refer to “Forward Collision-Avoidance Assist (FCA)” section in this chapter. Highway Driving Assist settings OJKEV051076 OJKEV051076 OJKEV072050L OJKEV072050L With the vehicle on, select or deselect ‘Driver assistance → Driving convenience’ from the Settings menu to set whether to use each function.
  • Page 520 • If there is a problem with the functions, the settings cannot be changed. We recommend that the vehicle be inspected by an authorized retailer of Genesis Branded products. OJKEV072261L OJKEV072261L • If the vehicle is restarted, the functions Warning volume will maintain the last setting.

  • Page 521: Highway Driving Assist (Hda)

    Highway Driving Assist Information operation • For more details on the display refer Basic function to “Smart Cruise Control (SCC)” and Displaying operating status “Lane Following Assist (LFA)” sections in this chapter. You can see the status of the Highway •...
  • Page 522 Driver assistance system Restarting after stopping Hands-off warning OJKEV072240L OJKEV072240L OJKEV072022L OJKEV072022L When Highway Driving Assist is If the driver takes their hands off the steering wheel for several seconds, the operating, your vehicle will stop if the vehicle ahead of you stops. Also, if the ‘Keep hands on steering wheel’...
  • Page 523 Driving speed limit Driving to one side within lane (if equipped) OJKEV072249L OJKEV072249L When Highway Driving Assist is OJKEV071149 OJKEV071149 When vehicle speed is above 60 km/h cancelled by the hands-off warning, The driving speed will be limited. (40 mph), if a vehicle around you is driving at a close distance, your vehicle While Driving Speed Limit function will control steering in the opposite...
  • Page 524 Driver assistance system Information • Driving Speed Limit helps you drive below 60 km/h (40 mph). At this time, the vehicle decelerates due to the vehicle ahead. After the vehicle has decelerated, it cannot automatically accelerate. • Driving Speed Limit will cancel in the following circumstances: - When the driver grabs the steering OJKEV072250L...
  • Page 525 Information • While Lane Change Assist function is turned on (indicator on), Lane Following Assist will not cancel even if the turn signal indicator or hazard warning flasher is operating. • Lane Change Assist function turns off automatically when driven in the following road conditions: - One driving lane OJKEV072251L...
  • Page 526 Driver assistance system Highway Lane Change Assist operating Information Turn signal lever Turn signal lever • Highway Lane Change Assist operates when the turn signal lever is positioned at A. If the turn signal lever is released to the center (1) before stepping on the lane, Highway Lane Change Assist cancels.
  • Page 527 • Highway lane change assist does not Highway Lane Change Assist standby operate on the entrance or exit of the Highway Lane Change Assist function highway. will be in the standby state when one of the ready state condition is not satisfied, or when entering or driving on one of the following roads: •...
  • Page 528 Driver assistance system - Highway Lane Change Assist WARNING function is off (The function turns • While the function is operating, the off when the function is turned off function will cancel if one of the from the settings menu, when the following occurs: road changes to a one-way road, when there is a intersection or...
  • Page 529 We recommend - Driving on roads that Highway that the vehicle be inspected by an Driving Assist does not operate, authorized retailer of Genesis Branded such as a rest area, intersection, products junction, etc. - The navigation does not operate...
  • Page 530 Driver assistance system • If the vehicle is driven at high speed • GPS signals are blocked in areas such above a certain speed at a curve, as a tunnel your vehicle may drive to one side or • The driver goes off course or the may depart from the driving lane.
  • Page 531 REAR VIEW MONITOR (RVM) (IF EQUIPPED) Rear View Monitor settings Rear View Monitor shows the area behind the vehicle to assist you when Warning volume parking or backing up. Detecting sensor OJKEV072263L OJKEV072263L With the vehicle on, select 'Driver assistance → Warning volume → Parking OJKEV071152 OJKEV071152 safety priority' or 'Sound →...
  • Page 532 Driver assistance system Rear View Parking Guide Lines Camera settings If ‘Rear view reference lines (Rear View Parking Guide Lines)’ is selected, the rear view parking guide lines and rear top view guide lines will be displayed at the left side of the infotaintment system screen.
  • Page 533 Rear View Monitor operation Rear View function Parking/View button OJKEV072154L OJKEV072154L Operating conditions OJKEV071153 OJKEV071153 Press the Parking/View button (1) to turn • Shift the gear to R (Reverse), the on Rear View Monitor. image will appear on the screen. •...
  • Page 534 Driver assistance system Operating conditions Extended Rear View function Press the Parking/View button (1) while Extended Rear View function maintains the gear is in D (Drive) or N (Neutral), showing the rear view when the gear is R the driving rear view will appear on the (Reverse), N (Neutral) or D (Drive).
  • Page 535 When Rear View Monitor is not working properly, or the screen flickers, or the camera image does not display properly, we recommend that the vehicle be inspected by an authorized retailer of Genesis Branded products. WARNING OJKEV072156L OJKEV072156L • The rear view camera does not...
  • Page 536 Driver assistance system SURROUND VIEW MONITOR (SVM) (IF EQUIPPED) Surround view Monitor settings Surround View Monitor can assist in parking by allowing the driver to see Warning volume around the vehicle. Detecting sensor OJKEV072263L OJKEV072263L With the vehicle on, select 'Driver assistance →...

  • Page 537: Parking Safety

    Camera settings Rear View Parking Guide Lines When the ‘Rear view reference lines (Rear View Parking Guide Lines)’ is selected, parking guidance is displayed in the rear view. Information The horizontal guideline shows the distance of 0.5 m (1.6 ft.), 1 m (3.3 ft.) and 2.3 m (7.6 ft.) from the vehicle.
  • Page 538 Driver assistance system Surround View Monitor • The gear is in N (Neutral) or D (Drive), and vehicle speed is 15 km/h (9 mph) operation or less. • The Parking/View button (1) is pressed, while the gear is in N (Neutral) or D (Drive), and vehicle speed is 15 km/h (9 mph) or less.
  • Page 539 Rear view Rear View while driving The driver can check the rear view on the screen while driving. The rear view while driving consist of a rear view while driving and a rear wide view while driving. Also, you can change the view mode you want to select by pressing the view button (2) on the infotainment system screen.
  • Page 540 • The image shown on the screen may Genesis Branded products. differ from the actual distance of the object. Make sure to directly check Limitations of Surround View the vehicle's surroundings for safety.

  • Page 541: Rear Cross-Traffic Collision-Avoidance Assist (Rcca)

    REAR CROSS-TRAFFIC COLLISION-AVOIDANCE ASSIST (RCCA) (IF EQUIPPED) Detecting sensor Rear Cross-Traffic Collision-Avoidance Assist is designed to help detect vehicles approaching from the left and right side while your vehicle is reversing. When a vehicle is detected, the system will warn the driver that a collision is imminent with a visual and audible warning.
  • Page 542 Driver assistance system Rear Cross-Traffic Collision- Avoidance Assist settings Rear cross-traffic safety OJKEV072003L OJKEV072003L Warning timing With the vehicle on, select ‘Driver assistance → Warning timing’ from the OJKEV072064L OJKEV072064L Settings menu to change the initial With the vehicle on, select ‘Driver warning activation time for Rear Cross- assistance →...
  • Page 543 CAUTION • The setting of the Warning timing and Warning volume applies to all functions of Rear Cross-Traffic Collision-Avoidance Assist. • Even though ‘ Normal (Standard)’ is selected for Warning timing, if the vehicles from the left and right side approaches at high speed, the warning may seem late.
  • Page 544 Driver assistance system Rear Cross-Traffic Collision- Collision warning Avoidance Assist operation • To warn the driver of an approaching vehicle from the rear left/right side of Rear Cross-Traffic Collision-Avoidance your vehicle, the warning light on the Assist will warn and control the vehicle outside rearview mirror will blink and depending on collision risk level: a warning will appear on the cluster.
  • Page 545 Emergency braking • Rear Cross-Traffic Collision-Avoidance Assist will operate when all the following conditions are satisfied: - The gear is shifted to R (Reverse) - Vehicle speed is below 8 km/h (5 mph) - The approaching vehicle is within approximately 1.5 m (5 ft.) from the left and right side of your vehicle - The speed of the vehicle approaching from the left and right...
  • Page 546 Driver assistance system Stopping vehicle and ending brake WARNING control Take the following precautions when using Rear Cross-Traffic Collision- Avoidance Assist: • For your safety, only change the Settings after parking the vehicle at a safe location. • If any other system’s warning message is displayed or audible warning is generated, Rear Cross- Traffic Collision-Avoidance Assist’s...
  • Page 547 • The ESC (Electronic Stability Control) inspected by an authorized retailer of warning light is on Genesis Branded products. • ESC (Electronic Stability Control) is engaged in a different function Information If braking is assisted by Rear Cross-...
  • Page 548 Assist will operate properly when such foreign material or trailer, etc., is removed. If Rear Cross-Traffic Collision-Avoidance Assist does not operate properly after it is removed, we recommend that the vehicle be inspected by an authorized retailer of Genesis Branded products. 7-138...
  • Page 549 Limitations of Rear Cross-Traffic WARNING Collision-Avoidance Assist • Even though the warning message Rear Cross-Traffic Collision-Avoidance does not appear on the cluster, Rear Assist may not operate properly, or it Cross-Traffic Collision-Avoidance may operate unexpectedly under the Assist may not operate properly. following circumstances: •...
  • Page 550 Driver assistance system • When the vehicle is in a complex WARNING parking environment • Driving near a vehicle or structure OJKEV071161 OJKEV071161 OJKEV071160 OJKEV071160 Rear Cross-Traffic Collision- [A]: Structure Avoidance Assist may detect Rear Cross-Traffic Collision- vehicles which are parking or pulling out near your vehicle (example, a Avoidance Assist may be limited when driving near a vehicle or...
  • Page 551 • When the vehicle is parked • When the vehicle is on or near a diagonally slope OJKEV071162 OJKEV071162 OJKEV071163 OJKEV071163 Rear Cross-Traffic Collision- Rear Cross-Traffic Collision- Avoidance Assist may be limited Avoidance Assist may be limited when backing up diagonally, when the vehicle is on a uphill or and may not detect the vehicle downhill slope, or near it, and may...
  • Page 552 Driver assistance system • Pulling into the parking space where • When the vehicle is parked rearward there is a structure OJKEV071165 OJKEV071165 OJKEV071164 OJKEV071164 Rear Cross-Traffic Collision- [A]: Structure, [B]: Wall Avoidance Assist may detect vehicles passing by behind you when parking Rear Cross-Traffic Collision- in reverse into a parking space.

  • Page 553: Forward/Reverse Parking Distance Warning (Pdw)

    FORWARD/REVERSE PARKING DISTANCE WARNING (PDW) (IF EQUIPPED) Forward/Reverse Parking Forward/Reverse Parking Distance Warning can help warn the driver if an Distance Warning settings obstacle is detected within a certain Warning volume distance when the vehicle is moving forward or in reverse at low speeds. Detecting sensor OJKEV072262L OJKEV072262L...
  • Page 554 Driver assistance system Parking Distance Warning Auto On Forward Parking Distance Warning To use Parking Distance Warning Forward Parking Distance Warning will Auto On function, select ‘Driver operate under the following conditions. assistance → Parking safety → Auto PDW • The gear is shifted from R (Reverse) (Parking Distance Warning)’...
  • Page 555 Reverse Parking Distance Warning Warning indicator Reverse Parking Distance Warning will Distance Warning when operate under the following conditions. from object sound driving • The gear is shifted to R (Reverse). forward Information 60~100 cm Buzzer beeps Forward Parking Distance Warning (24~40 in.) intermittently operates when the vehicle’s speed is below...
  • Page 556 (snow, blockage’ warning message appears rain, or foreign material) is removed on the cluster. (including trailer, carrier, etc., from the rear bumper), we recommend that the vehicle be inspected by an authorized retailer of Genesis Branded products. OJKEV072189L OJKEV072189L 7-146...
  • Page 557 Limitations of Parking Distance • The following objects may not be Warning detected: - Sharp or slim objects, such as ropes, • Parking Distance Warning may not chains or small poles. operate properly when: - Narrow objects, such as corners of a - There is excessive moisture or frost square column on the sensor...
  • Page 558 It varies depending on the speed of the vehicle or the shape of a person, animal, or object. • If the Parking Distance Warning does not operate properly, we recommend that the vehicle be inspected by an authorized retailer of Genesis Branded products. 7-148...

  • Page 559: Reverse Parking Collision-Avoidance Assist (Pca) (If

    REVERSE PARKING COLLISION-AVOIDANCE ASSIST (PCA) (IF EQUIPPED) Reverse Parking Collision- Reverse Parking Collision-Avoidance Assist can warn the driver or assist with Avoidance Assist settings braking to help reduce the possibility of Parking safety collision with a pedestrian or an object With the vehicle on, select or deselect while driving at low speed.
  • Page 560 Driver assistance system Turning Reverse Parking Collision Information Avoidance Assist On/Off If you change the Warning timing, the Warning timing of other Driver Assistance systems may change. Warning volume OJKEV071168 OJKEV071168 Press and hold the Parking Safety ( button more than 2 seconds, ‘Active rear assist’...
  • Page 561 Reverse Parking Collision- Avoidance Assist operation Operating conditions If ‘Active rear assist’ or ‘Rear warning only’ is set from the Settings menu, Reverse Parking Collision-Avoidance Assist will be in the ready status when the following conditions are satisfied: • The tailgate is closed •...
  • Page 562 Reverse Parking Collision-Avoidance the camera lens clean. Assist will turn off automatically. We recommend that the vehicle be inspected by an authorized retailer of Genesis Branded products. OJKEV071167 OJKEV071167 [B]: Rear ultrasonic sensor The ultrasonic sensors detect objects around the vehicle. If the sensors are...
  • Page 563 Limitations of Reverse Parking Collision-Avoidance Assist Reverse Parking Collision-Avoidance Assist may not assist braking or warn the driver even if there are pedestrians or objects under the following circumstances: • Problems with vehicle - Any non-factory equipment or accessory is installed - Your vehicle is unstable due to an OJKEV072255L OJKEV072255L...
  • Page 564 Driver assistance system • Problems with the surroundings • Problems with pedestrian or object - The surrounding is very bright or - The pedestrians are difficult to very dark detect - Outside temperature is very high or - There is ground height difference very low between the vehicle and the pedestrian...
  • Page 565 • Problems with driving condition • Problems with the surroundings - The driver drives the vehicle - The pattern on the road is mistaken immediately after shifting to R for a pedestrian (Reverse) or D (Drive) - There is shadow or light reflecting - The driver accelerates or circles the on the ground vehicle...
  • Page 566 Driver assistance system • Reverse Parking Collision-Avoidance WARNING Assist may not operate properly Take the following precautions when or may operate unnecessarily using Reverse Parking Collision- depending on the road conditions Avoidance Assist: and the surroundings. • Always exercise extreme caution •...
  • Page 567 Reverse Parking Collision-Avoidance Assist may not operate properly if the wide angle cameras or the ultrasonic sensor(s) is forcibly moved out of proper alignment. We recommend that the vehicle be inspected by an authorized retailer of Genesis Branded products. 7-157...
  • Page 568 Driver assistance system REMOTE SMART PARKING ASSIST (RSPA) (IF EQUIPPED) Remote Smart Parking Assist uses Function Description vehicle sensors to help the driver park Parallel forward exit and exit parking spaces remotely from outside the vehicle by controlling the steering wheel, vehicle speed, and gearshifts Smart Exit Function...
  • Page 569 • If the detecting sensors need repair, we recommend that you have your vehicle inspected by an authorized retailer of Genesis Branded products. • Remote Smart Parking Assist may malfunction if the vehicle OJKEV071191 OJKEV071191...
  • Page 570 Driver assistance system Remote Smart Parking Assist settings Settings features OJKEV072262L OJKEV072262L Warning volume With the vehicle on, select ‘Driver assistance → Warning volume’ from the Settings menu to change the Warning volume to ‘High’, ‘Medium’, ‘Low’ or ‘Off’ for Remote Smart Parking Assist. Information •...
  • Page 571 Remote Smart Parking Assist operation Remote Smart Parking Assist button Parking/View button, Parking Safety button Smart key OJKEV071193 OJKEV071193 OJKEV071168 OJKEV071168 OJKEV071153 OJKEV071153 Location Name Symbol Description • Press and hold the Parking/View button to turn on Remote Smart Parking Assist. Also, Forward/ Reverse Parking Distance warning will automatically turn on.
  • Page 572 Driver assistance system Remote Operation Operating order Remote Operation functions in the following order: 1. Getting ready to remotely move forward and backward 2. Remotely moving forward and backward 1. Getting ready to remotely move forward OJKEV071174 OJKEV071174 and backward There are two ways to operate Remote Operation function.
  • Page 573 • 'Agree' must be selected on the (2) While Remote Operation function infotainment system screen and the is operating, if you do not infotainment system has to operate hold down the Forward ( ) or properly to use Remote Operation Backward ( ) button, the vehicle function.
  • Page 574 Driver assistance system CAUTION Information • Check that all smart keys are outside • When using Remote Operation the vehicle when using Remote function, make sure that all Operation function. passengers have gotten out of the vehicle. • Remote Operation function will operate only when the smart key is within 4 •...
  • Page 575 Remote Operation function operation How to turn off Remote Operation status function while operating • Press the Parking/View ( ) button Hazard while the infotainment system screen Operation Smart key LED warning guides the driver using method 2. status light •...
  • Page 576 Driver assistance system • The vehicle moves 7 m (22 ft.) while • Approximately 3 minutes and 50 the smart key is pressed with Remote seconds have past after Remote Operation function (maximum travel Operation function has started to distance per button press) operate •...
  • Page 577 Smart Parking, Remote Smart 2. Searching for parking space Parking Operating order Parking function operates in the following order: 1. Getting ready for parking 2. Searching for parking space 3. Select parking type and operating mode 4. Smart Parking 5. Remote Smart Parking OJKEV072218L OJKEV072218L (1) Slowly drive forward maintaining...
  • Page 578 Driver assistance system • Remote Smart Parking Assist Information searches parking lines or parking spaces that are next to parked vehicles. Remote Smart Parking Assist cannot search parking spaces in front or rear of the vehicle. • While searching for a parking space, when vehicle speed is above 20 km/h (12 mph), a message will appear on the infotainment system...
  • Page 579 3. Select parking type and operating mode CAUTION Before selecting the Parking type, the driver should check whether the parking space is suitable. If the searched parking space by Remote Smart Parking Assist is narrow or unsuitable for parking, do not select the Parking type and move the vehicle to search for another parking space.
  • Page 580 Driver assistance system 4. Smart Parking Information OJKEV072074L OJKEV072074L OJKEV072221L OJKEV072221L If Remote Smart Parking Assist cannot activate Remote Smart Parking function, only the Smart Parking guide will be displayed on the infotainment system screen. OJKEV072075L OJKEV072075L (1) Press the Parking/View ) button when the vehicle is stopped by depressing the brake pedal.
  • Page 581 (3) When the vehicle reaches the 5. Remote Smart Parking target parking position, a message will appear on the infotainment system screen to inform you that parking is complete. (4) If you need to change the vehicle’s position or location, manually complete parking your vehicle.
  • Page 582 Driver assistance system CAUTION Information • When operating Remote Smart • When using Remote Smart Parking Parking function, make sure all smart function, make sure that all keys are outside of the vehicle. passengers have gotten out of the vehicle. •...
  • Page 583 Parking function operation status • Smart Parking function Operation status Turn signal The turn signal of the parking direction blinks until the first reverse Under control is complete. • Remote Smart Parking function Operation status Smart key LED Hazard warning light Turn signal The turn signal of Green LED...
  • Page 584 Driver assistance system The function will pause in the How to turn off Parking function following conditions when: while operating • Smart Parking • Press the Parking/View ( ) button in the following stage: - There is a pedestrian, animal or object in the direction the vehicle is - Searching for parking space moving...
  • Page 585 The function will cancel in the • Remote Smart Parking following conditions when: - The steering wheel is steered • Smart Parking - The gear is shifted - The steering wheel is steered - Operating EPB while the vehicle is moving - The gear is shifted while the vehicle is moving...
  • Page 586 Driver assistance system Smart Exit 2. Checking space Operating order Smart Exit function operates in the following order: 1. Getting ready for exit 2. Checking space 3. Select exit direction 4. Smart Exit 1. Getting ready for exit OJKEV072223L OJKEV072223L (1) When the vehicle is stopped by depressing the brake pedal, the vehicle sensors will detect the...
  • Page 587 4. Smart Exit Information Due to abnormal performance of the ultrasonic sensor or the influence of the surroundings, Parking function may not be able to search for an exit space even if there is an exit space, or may search for a space that is not suitable for exiting.
  • Page 588 Driver assistance system How to turn off Smart function while Information operating • Smart Exit function will not operate if • Press the Parking/View ( ) button the door is open or the seat belt is not in the following stage: fastened.
  • Page 589 - The slope of the road exceeds the and we recommend that the vehicle be operational range inspected by an authorized retailer of Genesis Branded products. - The function was paused for more than 1 minute - The steering wheel, gearshift,...
  • Page 590 Driver assistance system OJKEV072276L OJKEV072276L OJKEV072277L OJKEV072277L Remote Smart Parking Assist cancelled Remote Smart Parking Assist standby When Remote Parking Assist is ‘Parking Assist Conditions Not Met’ operating, the function can be cancelled, message appears when Parking/View and the ‘Parking Assist Canceled’ ) button has been pressed and held warning message may appear regardless while Remote Smart Parking Assist is in...
  • Page 591 Limitations of Remote Smart Parking • The road surface is bumpy (curbstone, Assist speed bump, etc.) • The road is slippery In the following circumstances, Remote Smart Parking Assist performance to • The parking line is too thin or thick park or exit the vehicle may be limited, •...
  • Page 592 Driver assistance system Remote Smart Parking Assist may not • Parking on uneven road operate properly under the following circumstances: • Parking on inclines OJKEV071178 OJKEV071178 Remote Smart Parking Assist may cancel when the vehicle slips, or the vehicle cannot move due to OJKEV071177 OJKEV071177 road conditions such as pebbles or...
  • Page 593 • Parking near a pillar • Parking diagonal OJKEV071180 OJKEV071180 OJKEV071184 OJKEV071184 Remote Smart Parking Assist Remote Smart Parking Assist does not performance may reduce or collision provide diagonal parking. Even if your with an obstacle may occur when vehicle was able to enter the parking there is a narrow object, circular pillar, space, do not use Remote Smart square pillar, or a pillar surrounded...
  • Page 594 We recommend that the vehicle be inspected by an authorized retailer of Genesis Branded Products. • Noise may be heard when braking occurs by Remote Smart Parking Assist or when the brake pedal is depressed by the driver.
  • Page 595 DECLARATION OF CONFORMITY (IF EQUIPPED) Front radar For Australia The radio frequency components (Front Radar) complies: For Europe and CE certified countries OANATEL287 OANATEL287 For United Arab Emirates OANATEL288 OANATEL288 For Brazil OANATEL285 OANATEL285 OANATEL289 OANATEL289 7-185...
  • Page 596 Driver assistance system For Serbia For Ukraine OANATEL290 OANATEL290 OANATEL292 OANATEL292 For Moldova For Oman OANATEL293 OANATEL293 For Israel OANATEL291 OANATEL291 OANATEL294 OANATEL294 7-186...
  • Page 597 For Mexico For Singapore OANATEL295 OANATEL295 OANATEL298 OANATEL298 For Jordan For Russia OANATEL296 OANATEL296 For Malaysia OANATEL299 OANATEL299 OANATEL297 OANATEL297 7-187...
  • Page 598 Driver assistance system Front corner radar/Rear corner For Indonesia radar The radio frequency components (Front Corner Radar/Rear Corner Radar) OANATEL056 OANATEL056 complies: For Taiwan For Malaysia OANATEL057 OANATEL057 For Singapore OANATEL058 OANATEL058 OANATEL055 OANATEL055 7-188...
  • Page 599 For Brazil For Jordan OANATEL062 OANATEL062 United Arab Emirates OANATEL399 OANATEL399 For Mexico OANATEL063 OANATEL063 Ghana OANATEL064 OANATEL064 OANATEL059 OANATEL059 For Ukraine OANATEL060 OANATEL060 7-189...
  • Page 600 Driver assistance system Serbia and Montenegro For Europe and CE certified countries OANATEL066 OANATEL066 Republic of South Africa OANATEL116 OANATEL116 For Paraguay OANATEL065 OANATEL065 OANATEL117 OANATEL117 7-190...
  • Page 601 For Thailand For Morocco OANATEL401 OANATEL401 For Australia OANATEL320 OANATEL320 For Israel OANATEL327 OANATEL327 For United Kingdom OANATEL400 OANATEL400 OANATEL362 OANATEL362 7-191...
  • Page 602 8. Emergency situations Hazard warning flasher..................8-2 In case of an emergency while driving ............8-2 If the vehicle stalls while driving .................8-2 If the vehicle stalls at a crossroad or crossing ............8-2 If you have a flat tire while driving ................8-3 If the vehicle will not start ................

  • Page 603: Emergency Situations

    • Turn on your hazard warning flasher. • Try to start the vehicle again. If your vehicle will not start, we recommend that you contact an authorized retailer of Genesis Branded products or seek OJKEV081001 OJKEV081001 other qualified assistance. The hazard warning flasher serves as...

  • Page 604: If You Have A Flat Tire While Driving

    IF THE VEHICLE WILL NOT START If you have a flat tire while driving Confirm the EV battery is not low on the charge gauge If a tire goes flat while you are driving: • Take your foot off the accelerator •...

  • Page 605: Jump Starting (12 V Battery)

    Emergency situations JUMP STARTING (12 V BATTERY) Jump starting can be dangerous if done If acid gets into your eyes, flush your incorrectly. Follow the jump starting eyes with clean water for at least 15 procedure in this section to avoid serious minutes and get immediate medical injury or damage to your vehicle.
  • Page 606 Jump starting procedure WARNING • Keep sparks away from the battery as 1. Position the vehicles close enough the explosive gas is generated by the that the jumper cables will reach, but sparks while the battery is running. do not allow the vehicles to touch. •...
  • Page 607 (-) checked by an authorized retailer of chassis ground of your vehicle (4). Genesis Branded products. Do not allow the jumper cables to contact anything except the correct battery or jumper terminals or the correct ground.
  • Page 608 NOTICE Disconnect the jumper cables in the exact reverse order you connected them: To prevent damage to your vehicle: 1. Disconnect the jumper cable from the • Only use a 12-volt power supply black, negative (-) chassis ground of (battery or jumper system) to jump your vehicle (4).

  • Page 609: Tire Pressure Monitoring System (Tpms)

    Emergency situations TIRE PRESSURE MONITORING SYSTEM (TPMS) Check tire pressure OJKEV081005 OJKEV081005 OJKEV082007L OJKEV082007L • You can check the tire pressure in the Utility view on the cluster. Refer to the “View Modes” section in chapter 4. • Tire pressure is displayed after a few minutes of driving after initial vehicle start up.

  • Page 610: Tire Pressure Monitoring System

    Genesis Branded products. failure. 1. The Low Tire Pressure Telltale/TPMS Under-inflation also reduces fuel...

  • Page 611: Low Tire Pressure Warning Light

    Emergency situations Low tire pressure If you cannot reach a service station or warning light if the tire cannot hold the newly added air, replace the low pressure tire with the spare tire (if equipped). Low tire pressure position and The Low Tire Pressure Telltale will remain tire pressure telltale on and the TPMS Malfunction Indicator...

  • Page 612: Tpms (Tire Pressure Monitoring System) Malfunction Indicator

    The TPMS Malfunction Indicator be repaired by an authorized retailer of will illuminate after it blinks for Genesis Branded products as soon as approximately one minute when there possible or replace the flat tire with the is a problem with the Tire Pressure spare tire (if equipped).
  • Page 613 If the indicators do not extinguish after a WARNING few minutes we recommend to consult Tampering with, modifying, or disabling an authorized retailer of Genesis Branded the Tire Pressure Monitoring System products. (TPMS) components may interfere Each wheel is equipped with a tire with the system’s ability to warn the...

  • Page 614: If You Have A Flat Tire (With Tire Mobility Kit)

    For this reason, you should avoid abrupt of Genesis Branded products or the steering or other driving maneuvers, equivalent approved for your vehicle as especially if the vehicle is heavily loaded soon as possible.

  • Page 615: Notes On The Safe Use Of The Tire Mobility Kit

    We recommend to contact the nearest authorized retailer of Genesis Branded • Long time exposure to the sealant products if the tire cannot be made may cause damage to bodily tissue roadworthy with the tire mobility kit.

  • Page 616: Components Of The Tire Mobility Kit

    Components of the Tire Mobility Kit OJKEV081023 OJKEV081023 1. Speed restriction label 7. ON/OFF switch 2. Sealant bottle and label with speed 8. Pressure gauge for displaying the tire restriction inflation pressure 3. Filling hose from sealant bottle to 9. Button for reducing the tire inflation wheel pressure 4.

  • Page 617: Using The Tire Mobility Kit When A Tire Is Flat

    Emergency situations WARNING Sealant • Keep out of reach of children. • Avoid contact with eyes. • Do not swallow. Using the Tire Mobility Kit When a tire is flat OJKEV081012 OJKEV081012 CAUTION 1. Shake the sealant bottle (2). OJKEV081024 OJKEV081024 Detach the speed restriction label from OJKEV081013...
  • Page 618 CAUTION Securely install the sealant filling hose to the valve. If not, sealant may flow backward, possibly clogging the filling hose. 6. Make sure the compressor turns off by pressing [O] of the main switch (7). OTM080024 OTM080024 3. Connect the sealant bottle (2) and compressor (6).
  • Page 619 Emergency situations Do not exceed a speed of 80 km/h (50 CAUTION mph). If possible, do not fall below a Tire pressure speed of 20 km/h (12 mph). Do not attempt to drive your vehicle if While driving, if you experience any the tire pressure is below 200 kPa (29 unusual vibration, ride disturbance or psi).

  • Page 620: How To Adjust Tire Pressure

    We recommend that you get this done at an The pressure gauge may show higher than authorized retailer of Genesis Branded actual reading when the compressor is products. running. To get an accurate tire pressure, the compressor needs to be turned off.
  • Page 621 Emergency situations 4. Adjust the tire inflation pressure to the Information recomended tire inflation. • The pressure gauge may show With the Vehicle is ON higher than actual reading when the indicator ON), proceed as compressor is running. To get an follows.

  • Page 622: Towing

    OJKEV081016L OJKEV081016L [1]: Dollies If emergency towing is necessary, we recommend having it done by an authorized retailer of Genesis Branded products or a commercial tow-truck service. Proper lifting and towing procedures are necessary to prevent damage to the vehicle. The use of wheel dollies or flatbed is recommended.

  • Page 623: Removable Towing Hook

    • Do not tow the vehicle with any be towed by an authorized retailer wheels on the ground as this may of Genesis Branded products or a cause damage to the vehicle. commercial tow-truck service.Only use the tow hook to move short distances or to lift the vehicle before towing.

  • Page 624: Emergency Commodity

    EMERGENCY COMMODITY (IF EQUIPPED) First aid kit Your vehicle is equipped with emergency commodities to help you respond to Supplies for use in giving first aid such emergency situation. as scissors, bandage and adhesive tape, etc., are provided. Fire extinguisher Triangle reflector NOTICE Place the triangle reflector on the road...
  • Page 625 For your safety we recommend to call the fire station and or contact an authorized retailer of Genesis Branded products. • When the fire spread to the high voltage battery, the additional fire may occur. In this situation, be sure to accompany a fire truck when the vehicle is being towed.
  • Page 626 PAN-EUROPEAN ECALL SYSTEM (IF EQUIPPED) The vehicle is equipped with a device* connected with the Pan-European eCall system for making emergency call to response teams. The Pan-European eCall system is an automatic emergency call service made in event of a traffic accident or other** accidents on the roads of Europe.
  • Page 627 Emergency situations Once the data which is stored in the Pan-European eCall system is delivered to the rescue center to assist the driver and passengers with proper rescue operations, the data will be deleted after rescue operation is completed. Description of the ecall in-vehicle system Antenna SOS Button Emergency...
  • Page 628 Information on data processing (1) Directive 95/46/EC of the European Parliament and of the Council of Any processing of personal data 24 October 1995 on the protection through the 112-based eCall in-vehicle of individuals with regard to the system shall comply with the personal processing of personal data and on data protection rules provided for in the free movement of such data (OJ L...

  • Page 629: Pan-European Ecall System

    Emergency situations Pan-European eCall System The 112-based eCall in-vehicle system is designed in such a way as to ensure that data in the system internal memory is automatically and continuously removed. The vehicle location data is constantly overwritten in the internal memory of the system so as always to keep maximum of the last three up-to-date locations of the vehicle necessary for the normal...

  • Page 630: Pan-European Ecall System

    Automatic accident reporting System operation in the Connection with the Public Emergency services event of a traffic accident Safety Answering Point (PSAP) OJKEV082028L OJKEV082028L The Pan-European eCall device automatically makes an emergency call to the Public Safety Answering Point (PSAP) for proper rescuing operations in event of vehicle accident.
  • Page 631 Emergency situations Manual accident reporting OJKEV082029L OJKEV082029L The driver or passenger manually can make an emergency call in the Public Safety Answering Point (PSAP), by pressing SOS button to call the necessary emergency services. A call to the emergency services through the Pan-European eCall system can be cancelled by pressing the SOS button again only before the call connection.
  • Page 632 Pan- European eCall system. We recommend to have the Pan-European eCall system checked at an authorized retailer of Genesis Branded products. Otherwise correct operation of the Pan- European eCall system device, installed in your vehicle is not guaranteed.
  • Page 633 9. Maintenance Motor compartment ..................9-3 Maintenance services ..................9-4 Owner’s responsibility ....................9-4 Owner maintenance precautions................9-4 Owner maintenance ..................9-5 Owner maintenance schedule ................... 9-6 Scheduled maintenance services ..............9-7 Normal maintenance schedule .................. 9-8 Maintenance under severe usage conditions ............9-10 Explanation of scheduled maintenance items ..........9-11 Coolant ......................
  • Page 634 Tires and wheels ..................... 9-24 Tire care ........................9-24 Recommended cold tire inflation pressures ............9-24 Check tire inflation pressure ..................9-25 Tire rotation ........................9-26 Wheel alignment and tire balance ................9-26 Tire replacement ......................9-27 Wheel replacement ....................9-28 Tire traction ........................9-28 Tire maintenance .......................9-28 Tire sidewall labeling ....................9-28 Low aspect ratio tires ....................

  • Page 635: Motor Compartment

    MOTOR COMPARTMENT The actual motor compartment in the vehicle may differ from the illustration. OJKEV092001L OJKEV092001L 1. Coolant reservoir 5. Cabin air filter 2. Brake fluid reservoir 6. Front trunk 3. Windshield washer fluid reservoir 7. Jump-start negative (chassis) terminal 4.

  • Page 636: Maintenance Services

    Genesis Branded Vehicle in addition, violate conditions of the limited order to provide you with a high level of warranties covering the vehicle.

  • Page 637: Owner Maintenance

    Performing maintenance work on a by the owner or an authorized retailer vehicle can be dangerous. If you lack of Genesis Branded products at the sufficient knowledge and experience frequencies indicated to help ensure or the proper tools and equipment...

  • Page 638: Owner Maintenance Schedule

    Maintenance Owner maintenance schedule At least monthly: When you stop for charging: • Check coolant level in the coolant reservoir. • Check the coolant level in the coolant reservoir. • Check the operation of all exterior lights, including the stoplights, turn •...

  • Page 639: Scheduled Maintenance Services

    SCHEDULED MAINTENANCE SERVICES Follow Normal Maintenance Schedule if the vehicle is usually operated where none of the following conditions apply. If any of the following conditions apply, you must follow the Maintenance Under Severe Usage Conditions. • Repeatedly driving short distance of less than 8 km (5 miles) in normal temperature or less than 16 km (10 miles) in freezing temperature •...
  • Page 640 Maintenance...

  • Page 642: Maintenance Under Severe Usage Conditions

    Maintenance Maintenance under severe usage conditions The following items must be serviced more frequently on cars mainly used under severe driving conditions. Refer to the chart below for the appropriate maintenance intervals. R: Replace I: Inspect and if necessary, adjust, correct, clean or replace Maintenance Driving Maintenance item...

  • Page 643: Explanation Of Scheduled Maintenance Items

    Replace any damaged parts. calipers for any fluid leakage. For more information on checking the Coolant pads or lining wear limit, refer to the Genesis Branded Vehicle web site. The coolant should be changed at the intervals specified in the maintenance (http:service.hyundai-motor.com) schedule.

  • Page 644: Coolant

    If the coolant is low, we recommend to have the vehicle inspected by an authorized retailer of Genesis Branded products. Use only designated coolant water for electric vehicles, adding other types...

  • Page 645: Brake Fluid

    Capacities” section in chapter 2). wear of the brake linings. If the fluid level is excessively low, we recommend that the brake system be checked by an authorized retailer of Genesis Branded products. WARNING If the brake system requires frequent additions of fluid this could indicate a leak in the brake system.

  • Page 646: Reduction Gear Fluid

    Genesis Branded products. OJKEV091004 OJKEV091004 Check the fluid level in the washer fluid reservoir and add fluid if necessary. Plain water may be used if washer fluid is not available.

  • Page 647: Cabin Air Filter

    CABIN AIR FILTER Filter inspection The cabin air filter should be replaced according to the Maintenance Schedule. If the vehicle is operated in severely air- polluted cities or on dusty rough roads for a long period, it should be inspected more frequently and replaced sooner.
  • Page 648 Maintenance NOTICE Motor compartment (if equipped) OJKEV091008 OJKEV091008 OHI078055 OHI078055 1. Remove the cover covering the cabin Install a new cabin air filter in the air filter by pushing out the retainer correct direction with the arrow symbol clip with a slim tool. (↓) facing downwards, to prevent noise and reduce effectiveness.

  • Page 649: Wiper Blades

    WIPER BLADES Blade inspection Blade replacement Contamination of either the windshield When the wipers no longer clean or the wiper blades with foreign matter adequately, the blades may be worn or can reduce the effectiveness of the cracked, and require replacement. windshield wipers.
  • Page 650 Maintenance ORG3EV091035 ORG3EV091035 ORG3EV091037 ORG3EV091037 3. Lift up the wiper blade clip (1). Then 5. Remove the wiper blade from the lift up the wiper blade (2). wiper arm (5). 6. Install the new blade assembly in the reverse order of removal. 7.
  • Page 651 5. Rotate back the blade assembly so that it aligns with the wiper arm. To prevent damage to the wiper arms or other components, we recommend that you have the wiper blades replaced by an authorized retailer of Genesis Branded products. 9-19...

  • Page 652: Battery (12 Volt)

    Maintenance BATTERY (12 VOLT) • When lifting a plastic-cased battery, WARNING excessive pressure on the case may To prevent SERIOUS INJURY or DEATH cause battery acid to leak. Lift with a to you or bystanders, always follow battery carrier or with your hands on these precautions when working near opposite corners.

  • Page 653: For Best Battery Service

    For best battery service Battery replacement OJKEV091010 OJKEV091010 OJKEV091009 OJKEV091009 • Keep the battery securely mounted. When replacing the battery, disconnect negative (-) cable (1) and remove positive • Keep the battery top clean and dry. (+) battery fuse box (2). Reassemble in •...

  • Page 654: Battery Capacity Label

    Ã The actual battery label in the vehicle DEATH from explosions or acid burns: may differ from the illustration. • Before performing maintenance or 1. AGM60R-DIN(12v) : The Genesis recharging the battery, turn off all Branded Vehicle model name of accessories and stop the vehicle.

  • Page 655: Reset Items

    • We recommend that you use An inappropriately disposed batteries for replacement from battery can be harmful to the an authorized retailer of Genesis environment and human health. Branded products. Dispose of the battery according to your local law(s) or regulation.

  • Page 656: Tire Care

    Maintenance TIRES AND WHEELS Tire care WARNING For proper maintenance, safety, and Tire failure may cause loss of vehicle maximum electric energy economy, you control resulting in an accident. To must always maintain recommended reduce risk of SERIOUS INJURY or tire inflation pressures and stay within DEATH, take the following precautions: the load limits and weight distribution...

  • Page 657: Check Tire Inflation Pressure

    Recheck the tire Genesis Branded products. pressure with the tire gauge. Be sure • Over-inflation produces a harsh ride, to put the valve caps back on the valve excessive wear at the center of the stems.

  • Page 658: Tire Rotation

    Maintenance Tire rotation Information To equalize tread wear, Genesis Branded The outside and inside of the Vehicle recommends that the tires be unsymmetrical tire is distinguishable. rotated according to the maintenance When installing an unsymmetrical tire, be schedule or sooner if irregular wear sure to install the side marked “outside”...

  • Page 659: Tire Replacement

    • Tires degrade over time, even when they are not being used. Regardless of the remaining tread, Genesis Branded Vehicle recommends that tires be replaced after six (6) years of normal service. • Heat caused by hot climates or...

  • Page 660: Wheel Replacement

    Maintenance Tire sidewall labeling WARNING This information identifies and describes The original tire should be repaired or the fundamental characteristics of replaced as soon as possible to avoid the tire and also provides the tire failure of the spare (if equipped) and identification number (TIN) for safety loss of vehicle control resulting in an standard certification.
  • Page 661 Tire speed ratings Example tire size designation: (These numbers are provided as an The chart below lists many of the example only; your tire size designator different speed ratings currently being could vary depending on your vehicle.) used for passenger vehicle tires. The speed rating is part of the tire size 265/45 R20 101H designation on the sidewall of the tire.
  • Page 662 Genesis vehicles be used. You may find on a specified government test course. the marking “GOE” (Genesis Original For example, a tire graded 150 would Equipment) embossed on the tire wear one-and-a-half times (1½) as well...

  • Page 663: Low Aspect Ratio Tires

    Or, we WARNING recommend that have you to contact The temperature grade for this tire is an authorized retailer of Genesis established for a tire that is properly Branded products. inflated and not overloaded. Excessive • Inspect the tire condition and...

  • Page 664: Fuses

    If the replacement fuse blows, this indicates an electrical problem. Avoid using the system involved. We recommend that you immediately consult an authorized retailer of Genesis Branded products. WARNING NEVER replace a fuse with anything but another fuse of the same rating.

  • Page 665: Instrument Panel Fuse Replacement

    If it fits loosely, we recommend that you consult an authorized retailer of Genesis Branded products. In an emergency, if you do not have a spare fuse, use a fuse of the same...

  • Page 666: Motor Compartment Panel Fuse Replacement

    If the multi fuse or midi fuse is blown, compartment fuse panel. we recommend that you consult an authorized retailer of Genesis Branded 5. Push in a new fuse of the same rating, products. and make sure it fits tightly in the clips.

  • Page 667: Fuse/Relay Panel Description

    Fuse/relay panel description Information Instrument panel fuse panel Not all fuse panel descriptions in this manual may be applicable to your vehicle; the information is accurate at the time of printing. When you inspect the fuse box on your vehicle, refer to the fuse box label. OJKEV091018 OJKEV091018 Inside the fuse/relay box cover, you can...
  • Page 668 Maintenance Instrument panel fuse panel Fuse Symbol Circuit Protected Fuse Name Rating Overhead Console, Electro Chromic Mirror, Inverter (Rear) Driver/Passenger Power Seat Module, Smart Phone Wireless Charger, Rear Seat Warmer Control MODULE9 MODULE Module, Fingerprint Recognition Device, Rear Air Ventilation Seat Control Module, AMP, Data Link Connector, A/V &...
  • Page 669 Instrument panel fuse panel Fuse Symbol Circuit Protected Fuse Name Rating Head-Up Display, Instrument Cluster CLUSTER CLUSTER IBU2 SRS Control Module A/BAG2 PRESAFETY PRESAFETY Pre-Active Seat Belt Unit SEAT BELT SEAT BELT3 Rear Corner Radar LH/RH, ECS Unit, Crash Pad Switch, Front View Camera MODULE8 MODULE...
  • Page 670 Maintenance Instrument panel fuse panel Fuse Symbol Circuit Protected Fuse Name Rating Sunroof Control Unit (Master) S/ROOF Driver Power Seat Module, Driver Power Seat 1 DRV P/SEAT DRV1 Switch Driver Door Module, Driver/Passenger Power Outside Mirror, Power Tailgate Module, Driver/ Passenger Power Seat Switch, Driver/Passenger MODULE2 MODULE...
  • Page 671 Motor compartment fuse panel Information Not all fuse panel descriptions in this manual may be applicable to your vehicle; the information is accurate at the time of printing. When you inspect the fuse panel in your vehicle, refer to the fuse panel label.
  • Page 672 Maintenance Motor compartment fuse panel Fuse Symbol Circuit Protected Type Fuse Name Rating 100A MDPS Unit MDPS1 255A ICCU MINE P/R Junction Block (Fuse - S1, S2, S3, S4, 150A F1, F2, F3, F4, F5), PCB Block (Fuse - S1, S2, S3, S4) Front Wiper Motor FR WIPER...
  • Page 673 Motor compartment fuse panel Fuse Symbol Circuit Protected Type Fuse Name Rating Electronic Water Pump (BSA #1) EWP1 ICCU, VCMS VCU1 VCU2 Electronic Water Pump (BSA #2) EWP2 PCB Block (Horn Relay) HORN Inverter (Front) EPCU1 EPCU MICRO RLY.5 B/ALARM PCB Block (IG3 #2 Relay) IG3 8 E-SHIFTER2...
  • Page 674 Maintenance Tailgate fuse panel (Rear sub Information junction block) Not all fuse panel descriptions in this manual may be applicable to your vehicle; the information is accurate at the time of printing. When you inspect the fuse panel in your vehicle, refer to the fuse panel label.
  • Page 675 Rear junction block Fuse Fuse Name Symbol Circuit Protected Rating ICU Junction Block(IPS2, IPS5, IPS6, Fuse : F22, F29, F30, F37, F38, F46, F47) CHILD LOCK Child Lock/Unlock Relay Passenger Safety Power Window Module (LHD), Driver Safety P/WIN RH Power Window Module (RHD), Rear Power Window Module RH PRESAFETY S/ PRESAFETY...
  • Page 676 Maintenance Tailgate fuse panel (Battery junction Information block) Not all fuse panel descriptions in this manual may be applicable to your vehicle; the information is accurate at the time of printing. When you inspect the fuse panel in your vehicle, refer to the fuse panel label.
  • Page 677 Battery junction block Fuse Fuse Name Symbol Circuit Protected Rating TRAILER Trailer Connector ICU Junction Block (IPS1, IPS3, IPS4, IPS7, Short/ Long Term Load Latch Relay, Fuse : F50) ICU Junction Block (Fuse : F26, F33, F36, F34, F41, F42, F43, F44) ICU Junction Block (Fuse : F27, F31, F45) Rear Junction Block (Fuse : F3, F6, F9, F12, F14, F16, 100A...

  • Page 678: Light Bulbs

    Maintenance LIGHT BULBS We recommend that have Consult an Information - Headlamp authorized retailer of Genesis Branded desiccant products to replace most vehicle light bulbs. It is difficult to replace vehicle This vehicle is equipped with desiccant to light bulbs because other parts of the...
  • Page 679 Traffic Change (for Europe) Genesis Branded products. The low beam light distribution is • The position lamp may not turn on asymmetric. If you go abroad to a country...

  • Page 680: Headlamp, Position Lamp, Turn Signal Lamp, Daytime Running Light (Drl) Replacement

    Genesis Branded products. (Horizontal line passing through The LED lamps cannot be replaced as center of head lamps) on the screen.
  • Page 681 Aiming point OJKEV092043L OJKEV092043L H1: Height between the head lamp bulb center and ground (Low beam) H2: Height between the head lamp bulb center and ground (High beam) W1: Distance between the two head lamp bulbs centers (Low beam) W2: Distance between the two head lamp bulbs centers (High beam) Vehicle condition Without driver 852 (33.5)
  • Page 682 Maintenance Headlamp low beam Based on 10m screen Based on 10m screen OJK090047L OJK090047L [1]: Vertical line of the left headlamp bulb center [2]: Car axis [3]: Vertical line of the right headlamp bulb center [4]: Horizontal line of headlamp bulb center [5]: cut-off line of left headlamp [6]: cut-off elbow of left headlamp [7]: distance between vertical line and cut-off elbow of left headlamp →...

  • Page 683: Puddle Lamp Replacement

    If the LED lamp does not operate, we recommend that the system be inspected by an authorized retailer of Genesis Branded products. The LED lamps cannot be replaced as a single unit because it is an integrated unit. The LED lamps has to be replaced with the unit.

  • Page 684: High Mounted Stop Lamp Replacement

    If the LED lamp (1) does not operate, inspected by an authorized retailer of we recommend that the system be Genesis Branded products. inspected by an authorized retailer of Genesis Branded products. The LED lamps cannot be replaced as...

  • Page 685: Front Trunk Lamp Replacement

    If the LED lamp (1) does not operate, we recommend that the system be inspected by an authorized retailer of Genesis Branded products. The LED lamps cannot be replaced as a single unit because it is an integrated unit. The LED lamps has to be replaced with the unit.
  • Page 686 [G]: Tailgate lamp If the LED lamp does not operate, we recommend that the system be inspected by an authorized retailer of Genesis Branded products. The LED lamps cannot be replaced as a single unit because it is an integrated OJKEV091041 OJKEV091041 unit.

  • Page 687: Appearance Care

    APPEARANCE CARE Exterior care Insects, tar, tree sap, bird droppings, industrial pollution and similar deposits can damage your vehicle’s finish if not NOTICE removed immediately. If you park your vehicle near a stainless Even prompt washing with plain water steel sign or glass facade building, the may not completely remove all these vehicle’s exterior plastic parts such deposits.
  • Page 688 Maintenance NOTICE NOTICE • Do not use strong soap, chemical Matte paint finish vehicle (if equipped) detergents or hot water, and do not Automatic car wash which uses rotating wash the vehicle in direct sunlight brushes should not be used as this can or when the body of the vehicle is damage the surface of your vehicle.
  • Page 689 Genesis Branded paint deterioration. products. Take extreme care, as it is difficult to restore the quality after the repair.
  • Page 690 By using the most advanced design with dirt; trapped water in these areas and construction practices to combat can cause rusting. corrosion, GENESIS produces vehicles of the highest quality. However, this is only WARNING part of the job. To achieve the long-term...
  • Page 691 High-corrosion areas To help prevent corrosion If you live in an area where your vehicle is Keep your vehicle clean regularly exposed to corrosive materials, The best way to prevent corrosion is corrosion protection is particularly to keep your vehicle clean and free of important.

  • Page 692: Interior Care

    Maintenance NOTICE Keep your garage dry Don’t park your vehicle in a damp, • Never allow water or other liquids poorly ventilated garage. This creates to come in contact with electrical/ a favorable environment for corrosion. electronic components inside the This is particularly true if you wash your vehicle as this may damage them.
  • Page 693 NOTICE • Caring for the leather seats - Vacuum the seat periodically to Using anything but recommended remove dust and sand on the seat. It cleaners and procedures may affect the will prevent abrasion or damage of fabric’s appearance and fire-resistant the leather and maintain its quality.
  • Page 694 Therefore, you should immediately have replaced the damaged interior wooden trim. We recommend that you contact an authorized Retailer of Genesis Branded Products. • Forged wood is an eco-friendly wooden trim made from recycled wood chips. Due to these material...
  • Page 695 Index...
  • Page 696 Index Accessing your vehicle ..................5-5 Immobilizer system ..................5-11 Replacing the battery..................5-10 Smart key precautions ..................5-9 Using smart key....................5-5 Active hood lift system ..................3-71 System activation .................... 3-71 System limitation .................... 3-72 System malfunction ..................3-73 Active noise control-road ..................6-63 System malfunction ..................
  • Page 697 Automatic climate control system ...............5-84 Automatic temperature control mode.............. 5-86 Manual temperature control mode ..............5-87 System maintenance ..................5-99 System operation ..................... 5-97 Battery (12 volt) ....................9-20 12V Battery recharging ................... 9-22 Battery capacity label ..................9-22 Battery replacement ..................9-21 For best battery service ...................
  • Page 698 Index Good braking practices ................... 6-50 High performance brake .................. 6-30 Hill-Start Assist Control (HAC) ..............6-45 Multi-Collision Brake (MCB) ................ 6-46 Power-assist brakes ..................6-29 Trailer Stability Assist (TSA) ................6-44 Vehicle Stability Management (VSM) ............6-43 Bulb wattage ......................2-11 Cabin air filter ......................9-15 Filter inspection ....................
  • Page 699 Door locks ......................5-15 Automatic door lock and unlock features ............5-19 Child-protector rear door locks ............... 5-20 Deadlocks ......................5-19 Electronic child safety lock ................5-20 Operating door locks from inside the vehicle ..........5-16 Operating door locks from outside the vehicle ..........5-15 Drive mode integrated control system ..............6-59 Drive modes characteristic ................
  • Page 700 Index EV mode ........................1-9 Charging and climate ..................1-11 Energy information ..................1-10 EV mode screen ....................1-9 EV settings ...................... 1-19 Nearby charging stations ................. 1-19 Next departure ....................1-10 Vehicle to load (V2L) ..................1-13 Electric vehicle ......................1-6 Battery Information ...................
  • Page 701 Fingerprint authentication system................5-12 Fingerprint authentication system operation ........... 5-13 Fingerprint authentication system settings ............5-12 Limitations of the system ................5-14 When purchasing a used vehicle ..............5-14 Forward Attention Warning (FAW) ..............7-72 Forward Attention Warning malfunction and limitations ....... 7-74 Forward Attention Warning operation .............
  • Page 702 Index If the vehicle will not start ..................8-3 If you have a flat tire (with Tire Mobility Kit) ............8-13 Components of the Tire Mobility Kit .............. 8-15 How to adjust tire pressure ................8-19 Introduction ..................... 8-13 Notes on the safe use of the Tire Mobility Kit ..........8-14 Using the Tire Mobility Kit When a tire is flat ..........
  • Page 703 Intelligent Front-Lighting System (IFS) ..............5-73 Intelligent Front-Lighting System malfunction and limitations...... 5-74 Intelligent Front-Lighting System operation ........... 5-73 Intelligent Front-Lighting System settings............5-73 Intelligent Speed Limit Assist (ISLA) ..............7-60 Intelligent Speed Limit Assist malfunction and limitations ......7-63 Intelligent Speed Limit Assist operation ............7-61 Intelligent Speed Limit Assist settings ............
  • Page 704 Index Lane Following Assist (LFA) ................7-104 Lane Following Assist malfunction and limitations........7-107 Lane Following Assist operation ..............7-105 Lane Following Assist settings..............7-104 Lane Keeping Assist (LKA) ................7-27 Lane Keeping Assist malfunction and limitations .......... 7-31 Lane Keeping Assist operation ............... 7-28 Lane Keeping Assist settings .................
  • Page 705 Mirrors .........................5-34 Inside rearview mirror ..................5-34 Outside rearview mirrors................. 5-35 Reverse parking aid ..................5-37 Motor compartment ....................9-3 Motor compartment ....................2-9 Motor number ......................2-16 Navigation-based Smart Cruise Control (NSCC) ..........7-97 Limitations of Navigation-based Smart Cruise Control........ 7-100 Navigation-based Smart Cruise Control operation ......... 7-98 Navigation-based Smart Cruise Control settings ..........
  • Page 706 Index Rear View Monitor (RVM) ................7-121 Rear View Monitor malfunction and limitations........... 7-125 Rear View Monitor operation ................ 7-123 Rear View Monitor settings................7-121 Recommended lubricants and capacities .............2-14 Reduction gear .....................6-10 Good driving practices ..................6-17 LCD display messages (cluster) ..............6-15 Reduction gear operation ................
  • Page 707 Safety precautions for electric vehicle ..............1-66 High voltage cut-off switch ................1-68 If an accident occurs..................1-66 Other precautions for electric vehicle ............. 1-68 Scheduled charging ....................1-27 AC charge ......................1-32 Charging precautions ..................1-27 DC charge ......................1-36 Disconnecting charging connector in emergency ........... 1-32 Electric charging label ..................
  • Page 708 Index Smart recuperation system ...................6-22 Front sensors (Front radar) ................6-24 Pausing smart recuperation system ..............6-24 Precautions for smart recuperation system ............. 6-25 Smart recuperation level settings ..............6-23 Smart recuperation system on/off ..............6-22 Smart recuperation system operating condition ..........6-23 System warning due to sensor problems ............
  • Page 709 Theft-alarm system ....................5-22 Tire Pressure Monitoring System (TPMS) ............8-8 Changing a tire with TPMS ................8-11 Check tire pressure .................... 8-8 Low tire pressure position and tire pressure telltale........8-10 Low tire pressure warning light ..............8-10 Tire pressure monitoring system ............... 8-9 TPMS (Tire Pressure Monitoring System) malfunction indicator ....
  • Page 710 Index Vehicle certification label ..................2-15 Vehicle Identification Number (VIN) ..............2-15 Vehicle settings (infotainment system) ..............4-40 Setting your vehicle ..................4-40 Vehicle weight .....................6-82 Overloading ..................... 6-82 Vehicle weight and luggage volume ..............2-13 Washer fluid ......................9-14 Windows ......................5-39 Power windows ....................5-41 Windshield defrosting and defogging ..............5-101 Defogging logic .....................

Table of Contents

Save PDF
