Summary of Contents for Hisense HDFS10HP
- Page 1 USER’S OPERATION MANUAL Before operating this unit, please read this manual thoroughly, and retain for future reference. HDFS10HP HDFS10HPB HDFS10HP* English...
- Page 3 TABLE OF CONTENTS SAFETY INFORMATION INTRODUCTION 14 PRODUCT DESCRIPTION 15 Technical information 16 INSTALLATION AND CONNECTION PREPARING THE 16 Selecting the room DRYER BEFORE 20 Adjusting the dryer feet FIRST USE 21 Changing the door opening direction 23 Draining the condensate 24 Connecting to the power mains 25 Moving and transport after installation 26 BEFORE USING THE APPLIANCE FOR THE FIRST TIME...
- Page 6 ELECTRICAL SAFETY...
- Page 13 Queensland Service Notes:In Queensland,the Authorized Service Person Musthold a Gas Work Authorization for hydrocarbon refrigerants to carry out servicingor repairs which involve removal of covers.
- Page 14 PRODUCT DESCRIPTION...
- Page 15 TECHNICAL INFORMATION (DEPENDING ON THE MODEL) Rating plate with basic information about the dryer is ftted on the front wall of the dryer door opening (see chapter DESCRIPTION OF THE DRYER >> << Width 595 mm Height 845mm Dryer depth (a) 640 mm Depth with door closed 670 mm...
- Page 23 During drying, the screen will display a prompt indicating the condensate water tank is full and should be emptied.
- Page 30 SWITCHING ON THE DRYER Connect the dryer to the power mains by plugging in the power cord. any other use.) The light in the dryer drum may only be replaced by the manufacturer, a service technician or an authorized person. Before first use, configure the preferences of Language, Country and Region, Time Zone and User agreement according to the boot navigation and user’s actual needs.
- Page 31 2. Select the time zone 3. Confirm whether network configuration is necessary 3.1 Skip network configuration, and set system date and time Note: After skipping network configuration, you can subsequently set the network again under System Settings 3.2 If network configuration is not skipped, the network can be connected as prompted on the screen.
- Page 32 CONTROL PANEL This device is controlled by a touchscreen + a rotary knob; program selection can be realized by touching the touchscreen or rotating the knob; the Power and Start/Pause buttons can be pressed by touching the touchscreen. Power Setting Options Knob Touch screen Start/Pause...
- Page 33 POWER startup is not supported. Press the Power button; the screen will turn on and the dryer will enter standby mode. When the dryer is in standby mode, or after the screen displays the program end interface, long press In standby mode, or in the program end interface or Wash & Dry retry reminder interface, if no START/PAUSE Press this key to start/pause the program.
- Page 34 Program Table End mode Program Type of laundry Rated Capacity Just in Manual (kg) Time This program is suitable for thicker, non-sensitive cotton laundry. Cotton It will be completely dry after the drying program ends. Synthetics This program is suitable for synthetics. This program is suitable for highly delicate laundry made of Delicates program ends.
- Page 35 STEP 4: SELECTING ADDITIONAL SETTINGS AND FUNCTIONS The settings of most programs are adjustable: Slide up or down in the program display area on the parameters, press Start key to start running the selected program. Touch the selected program time to change the Level and Target settings, and to set additional functions such as the Anti Crease, Night Dry and Steam.
- Page 36 Additional functions t s i Anti Crease If the laundry cannot be timely taken out after drying, the "Anti Crease" function can be selected. The drum will rotate intermittently to prevent crease of clothes. Press any button or open the machine door to exit the Anti Crease mode. If no operation is performed, the program will end automatically after the default maximum duration of 12 h.
- Page 37 Child Lock This is a safety feature. To enable this function, press the Child Lock icon. When the icon lights up, it indicates the Child Lock function is enabled. Press the Child Lock icon for 3s to unlock this function. •...
- Page 38 Mute This option can be used to turn on/off the prompt tone of the machine. When it is turned off, all sounds of the machine except the alarm tone will be disabled. Settings press this icon to enter the Settings interface, where you can set General, System Volume, Screen Brightness, WLAN, Energy Saving, User Program, APP and Pairing, System Upgrade, etc.
- Page 39 WASH & DRY DESCRIPTION ，...
- Page 40 TABLE Program AI Dry Allergy Care Bedding HIGH Baby Care Sportswear SMART Shirts Cotton Synthetics Delicates Power Towels Denim Duvet HIGH Ion Refresh Rack Dry Wool TIME DRY Time Dry Warm Dry Cool Air Note: When the Steam function is added, the maximum rated capacity changes to 3 shirts under the Shirts program, and to 1 Kg under other programs.
- Page 41 STEP 5: PROGRAM DISPLAY AND END During program operation, the display screen will show information such as time left. automatically adjusted based on such factors as type and amount of laundry, dry level and ambient temperature. within 10min, the dryer will shut down automatically. Report: Click it to view the energy consumption and time used of this drying.
- Page 45 The dust and dirt in the metal fins of the heat exchanger can be cleaned with vacuum cleaner soft brush Access to the heat exchanger is possible, when the heat pump filter is removed as is described in the chapter »Cleaning the heat pump filter«. Without pressing, gently move the brush attachment only in the direction of the metal fins from top to bottom.
- Page 46 The screen will display a prompt indicating the condensate water tank is full and should be emptied.
- Page 47 ADD WATER FOR THE STEAM FUNCTION AND CLEAN THE FILTER MESH The Steam function can be selected under some programs. It is needed to guarantee that water in the the screen displays a prompt indicating a lack of water during use, please use a container...
- Page 50 The dryer do not operate...
- Page 53 When you contact a service centre, please state your dryer type (1). Type, code/ID, model, and serial number are indicated on the back of the dryer.
- Page 54 PROGRAM TABLE The table indicates the power consumption and duration for drying of a test batch of laundry with various loads that go through spinning at various speeds, in compliance with EN 61121. The following requirements apply to the programs specified below. Inlet air temperature Room temperature Inlet air humidity...
- Page 57 Connecting your appliance to the application ConnectLife 1.ConnectLife ConnectLife is a smart home platform that connects people, devices, and services. The ConnectLife application includes advanced digital services and carefree solutions that allow users to monitor and control appliances, receive notifications from a smartphone, and update software (supported features vary depending on your appliance and your region/country).
- Page 58 2.4 Unpairing 1) On the appliance side: A. Click on the "Settings" button in the top right corner of the dropdown menu to enter the "Settings" page. B. Click on "App and Pairing" to enter the pairing page. C. Click on "Unbind" to unbind the connected account. D.
