Installation & Operation Manual
Self-Generating Steam Jacketed
ECT-6, ECT-10 and ECT-12
Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury
or death. Read the installation, operating and maintenance instructions thoroughly before installing or
Manual 10132 Rev 2 (08/22)
$21.00
Counter Tilting Kettles
servicing this equipment.
CROWN FOOD SERVICE EQUIPMENT
70 Oakdale Road, Downsview (Toronto) Ontario, Canada, M3N 1V9
Telephone: 919-762-1000
Model ECT-6
WARNING
A Middleby Company
www.crownsteamgroup.com
IMPORTANT FOR FUTURE REFERENCE
Please complete this information and retain this
manual for the life of the equipment:
Model #: ___________________________
Serial #: ___________________________
Date Purchased: _____________________
Self-Generating Steam Jacketed
Counter Tilting Kettles
M
S
ANUAL
ECTION
CO
Advertisement
Table of Contents
Related Manuals for Crown ECT-6
Summary of Contents for Crown ECT-6
- Page 1 Date Purchased: _____________________ Installation & Operation Manual Self-Generating Steam Jacketed Counter Tilting Kettles ECT-6, ECT-10 and ECT-12 Model ECT-6 WARNING Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury or death. Read the installation, operating and maintenance instructions thoroughly before installing or servicing this equipment.
-
Page 2: Safety
This manual should be retained for future reference. It is recommended that this manual be read thoroughly and that all instructions be followed carefully. Copyright © 2022 by Crown. All rights reserved. Published in the United States of America. PAGE OF 24 INSTALLATION &... -
Page 3: Table Of Contents
Self-Generating Steam Jacketed Counter Tilting Kettles Table of Contents RETAIN THIS MANUAL FOR FUTURE REFERENCE. Table of Contents Safety ............................ 2 Service Connections ......................4 Introduction ........................... 5 Installation ..........................6 Operation ..........................7 Cleaning ..........................8 Maintenabce ......................... 9 Troubleshooting ........................ -
Page 4: Service Connections
33.3 31.5 28.9 18.3 16.7 14.5 11.5 [86 kg] (76 mm) (51 mm) As continued product improvement is a policy of Crown, specifications are subject to change without notice. PAGE OF 24 INSTALLATION & OPERATION MANUAL 10132 REV 2 (08/22) -
Page 5: Introduction
Introduction Description Models ECT-6 (6 gallon capacity) and ECT-10 (10 gallon capacity) and ECT-12 (12 gallon capacity) electrically powered, self-contained, countertop, tilting kettles. Each model has a jacket of double-wall construction forming a sealed reservoir around the lower two-thirds of the kettle. The reservoir is charged with distilled water and anti-freeze solution. -
Page 6: Installation
Self-Generating Steam Jacketed Counter Tilting Kettles NSTALLATION Installation NPACKING IMMEDIATELY INSPECT FOR SHIPPING DAMAGE Immediately after unpacking the steamer, check for possible shipping damage. If the steamer is found to be damaged, save the packaging material and contact the carrier within 15 days of delivery. Installation Instructions 1. -
Page 7: Operation
Self-Generating Steam Jacketed Counter Tilting Kettles PERATION Operation Operating Instructions WARNING The safety relief valve may discharge large amounts of steam and/or hot water. Keep away from the discharge tube at all times. Warn others in the area so they will not be startled by the sound. 1. -
Page 8: Cleaning
Cleaning Self-Generating Steam Jacketed Counter Tilting Kettles Cleaning WARNING Disconnect the power supply to the appliance before cleaning or servicing. WARNING Never spray water into electric controls or components! CAUTION The equipment and its parts are hot. Use care when operating, cleaning and servicing. CAUTION Do not use cleaning agents that are corrosive. -
Page 9: Maintenabce
Self-Generating Steam Jacketed Counter Tilting Kettles Maintenance Maintenance Daily 1. Ensure there is adequate vacuum in the kettle jacket before operating. 2. Ensure that the appliance and controls are not damaged and that it can be safely operated. 3. Ensure the work area of the operator is not slippery and is clear of debris so as to provide a safe workplace. 4. -
Page 10: Troubleshooting
2. At exterior rear of kettle jacket remove nut from Air Vent. 3. Insert funnel into Air Vent opening and slowly add the indicated amount of distilled water for: Model Amount of Distilled Water ECT-6 Add 50 oz. (1.5 litres) ECT-10 and ECT-12 Add 100 oz. (3 litres) 4. -
Page 11: Appendix A, Material Safety Data Sheet
Self-Generating Steam Jacketed Counter Tilting Kettles Material Safety Data Sheets Appendix ‘A’ INSTALLATION & OPERATION MANUAL 10132 REV 2 (08/22) PAGE OF24... - Page 12 Material Safety Data Sheets Self-Generating Steam Jacketed Counter Tilting Kettles PAGE OF 24 INSTALLATION & OPERATION MANUAL 10132 REV 2 (08/22)
- Page 13 Self-Generating Steam Jacketed Counter Tilting Kettles Material Safety Data Sheets INSTALLATION & OPERATION MANUAL 10132 REV 2 (08/22) PAGE OF24...
- Page 14 Material Safety Data Sheets Self-Generating Steam Jacketed Counter Tilting Kettles PAGE OF 24 INSTALLATION & OPERATION MANUAL 10132 REV 2 (08/22)
- Page 15 Self-Generating Steam Jacketed Counter Tilting Kettles Material Safety Data Sheets INSTALLATION & OPERATION MANUAL 10132 REV 2 (08/22) PAGE OF24...
- Page 16 Material Safety Data Sheets Self-Generating Steam Jacketed Counter Tilting Kettles PAGE OF 24 INSTALLATION & OPERATION MANUAL 10132 REV 2 (08/22)
- Page 17 Self-Generating Steam Jacketed Counter Tilting Kettles Material Safety Data Sheets INSTALLATION & OPERATION MANUAL 10132 REV 2 (08/22) PAGE OF24...
- Page 18 Material Safety Data Sheets Self-Generating Steam Jacketed Counter Tilting Kettles PAGE OF 24 INSTALLATION & OPERATION MANUAL 10132 REV 2 (08/22)
- Page 19 Self-Generating Steam Jacketed Counter Tilting Kettles Material Safety Data Sheets INSTALLATION & OPERATION MANUAL 10132 REV 2 (08/22) PAGE OF24...
- Page 20 Material Safety Data Sheets Self-Generating Steam Jacketed Counter Tilting Kettles PAGE OF 24 INSTALLATION & OPERATION MANUAL 10132 REV 2 (08/22)
- Page 21 Self-Generating Steam Jacketed Counter Tilting Kettles Notes INSTALLATION & OPERATION MANUAL 10132 REV 2 (08/22) PAGE OF24...
- Page 22 Self-Generating Steam Jacketed Counter Tilting Kettles Notes PAGE OF 24 INSTALLATION & OPERATION MANUAL 10132 REV 2 (08/22)
- Page 23 Self-Generating Steam Jacketed Counter Tilting Kettles Notes INSTALLATION & OPERATION MANUAL 10132 REV 2 (08/22) PAGE OF24...
- Page 24 STEAM JACKETED COUNTER TILTING KETTLES A product with the Crown name incorporates the best in durability and low maintenance. We all recognize, however, that replacement parts and occasional professional service may be necessary to extend the useful life of this appliance.
