Kodak Scanmate i1120 Quick Start

CLEANING THE CALIBRATION AREA
1. Remove dust and debris from this area by using a Stati-
cide wipe, a small brush or scanner cleaning swab. Be
careful not to scratch the glass or bend the white
tabs on the calibration guide.
2. Wipe the calibration guide with a Staticide wipe.
IMPORTANT:Staticide wipes and cleaning swabs contain
isopropanol which can cause eye irritation
and dry skin. Wash your hands with soap and
water after performing maintenance
procedures. Refer to the User's Guide for
MSDS acquisition.
3. Wipe the front and rear calibration guides again with an
almost-dry Staticide wipe to remove any streaks.
REPLACING THE FEED ROLLER ASSEMBLY
1. Remove the input tray by pulling it forward and lifting it
out of position. Set it aside.
2. Rotate the orange tab upward to release the feed roller
assembly.
3. Lift the feed roller assembly up and out of the
scanner.
4. Install the new feed roller assembly by aligning the shaft
end of the assembly in position.
5. With the orange tab in the upward position, snap the
feed roller assembly in place.
6. Rotate the orange tab down. If the tab is not in the down
position, you will not be able to reinstall the input tray.
7. Reinstall the input tray by locating and aligning the four
tabs on the input tray with the slots on the scanner.
8. When tabs and slots are in place, roll the input tray
toward the back of the scanner until it snaps into place.
SUPPLIES*
CAT No. Description
894 6097 Kodak ScanMate i1120 Pre-Separation
Pad
122 6034 Kodak ScanMate i1120 Feed Roller
Assembly
824 5862 Kodak ScanMate i1120 Scanner
Cleaning Swabs
853 5981 Kodak Digital Science Roller Cleaning
Pads (qty 24)
169 0783 Kodak Digital Science Transport
Cleaning Sheets (qty 50)
896 5519 Staticide Wipes for Kodak Scanners
(qty 144)
* Items are subject to change.
EASTMAN KODAK COMPANY
343 State Street
Rochester, New York 14650 USA
© Kodak, 2007
TM: Kodak, ScanMate and Digital Science
A-61603/Part No. 9E8503 January 2008
ScanMate i1120 Scanners
Quick Tips
www.kodak.com
Kodak Field Service:
1-800-356-3253
Kodak Technical Assistance:
1-800-822-1414
Kodak Professional Services:
1-800-525-6325
