DEMO MANUAL DC1899A
PARTS LIST
ITEM QTY REFERENCE
Required Circuit Components
1 7 C1, C2, C3, C8, C9, C11, C14
2 2 C4, C5
3 2 C6, C7
4 0 C10, C12, C13, C15
5 2 D1, D2
6 4 D3, D5, D6, D8
7 2 D4, D7
8 1 D9
9 0 D10, D11, D12, D13
10 8 E1, E2, E3, E4, E5, E6, E7, E8
11 12 E9, E10, E11, E13-E16, E18-E22
12 5 JP1, JP2, JP3, JP6, JP7
13 2 JP4, JP5
14 8 J1, J2, J3, J4, J5, J6, J7, J8
15 4 Q1, Q2, Q3, Q4
16 0 Q5, Q6, Q7, Q8
17 2 RS1, RS2
18 0 RS3, RS4
19 4 R1, R3, R19, R20
20 2 R2, R4
21 6 R5, R6, R7, R8, R9, R10
22 2 R11, R15
23 2 R12, R16
24 2 R13, R17
25 2 R14, R18
26 0 R21, R25
27 0 R22, R26
28 1 R23
29 1 R24
DC1899A-A Assembly
2 1 U1
DC1899A-A Assembly
2 1 U1
6
PART DESCRIPTION
CAP., X7R, 0.1μF, 50V, 0603
CAP., X7R, 47nF, 50V, 0603
CAP., X7R, 15nF, 50V, 0603
CAP., ALUMINUM, 100μF 50V, OPT
DIODE, VOLTAGE SUPP. 19V 5%, SMA-DIODE
LED, SMT GREEN, J TYPE, LED-LN1351C-GREEN
LED, SMT RED, GW TYPE, LED-LN1261C-RED
DIODE, SWITCHING, SOD80
DIODE, CMHZ4706, SOD123
TP, 0.094"
TP, 0.064"
JMP, HD1X3, 0.079CC
JMP, HD2X4, 0.079CC
JACK, BANANA
MOSFET, N-CH, 30-V, SO8-POWERPAK
MOSFET, N-CH, 30-V, SiR158DP, SO8-POWERPAK
RES., CHIP, 0.005, 1/2W, 1%, 2010
RES., CHIP, 0.005, 1/2W, 1%, 2010, OPT
RES., CHIP, 10Ω, 1%, 0603
RES., CHIP, 47Ω, 1%, 0603
RES., CHIP, 3k, 1%, 0805
RES., CHIP, 20k, 1%, 0603
RES., CHIP, 137k, 1%, 0603
RES., CHIP, 49.9k, 1%, 0603
RES., CHIP, 28k, 1%, 0603
RES., CHIP, 10Ω, 0603
RES., CHIP, 0Ω, 0603
RES., CHIP, 470Ω, 1%, 0603
RES., CHIP, 41.2k, 1%, 0603
I.C. LTC4228IUFD-1, QFN28UFD
I.C. LTC4228IUFD-2, QFN28UFD
MANUFACTURER/PART NUMBER
AVX, 06035C104KAT
AVX, 06035C473KAT
AVX, 06035C153KAT
SANYO, 50CE100BS
VISHAY, SMAJ17A-E3
PANASONIC, LN1351C-TR
PANASONIC, LN1261C-TR
VISHAY, LS4148-GS18
OPT
MILL-MAX, 2501-2-00-80-00-00-07-0
MILL-MAX, 2308-2-00-80-00-00-07-0
SAMTEC, TMM-103-02-L-S
SAMTEC, TMM-104-02-L-D
KEYSTONE, 575-4
VISHAY, SiR158DP
OPT
VISHAY, WSL20105L000FEA
VISHAY, WSL20105L000FEA
VISHAY, CRCW060310R0FKEA
VISHAY, CRCW060347R0FKEA
VISHAY, CRCW08053K00FKEA
VISHAY, CRCW0060320K0FKEA
VISHAY, CRCW0603137KFKEA
VISHAY, CRCW060349K9FKEA
VISHAY, CRCW0060328K0FKEA
OPT
OPT
VISHAY, CRCW0603470RFKEA
VISHAY, CRCW0060341K2FKEA
LINEAR TECH., LTC4228IUFD-1
LINEAR TECH., LTC4228IUFD-2
