ASSEMBLY INSTRUCTIONS:

Item No: TC11173

1. Place the base (A) on a level surface.

2. Insert the harp (E) until it sits firmly into the saddle (D).

3. Adjust the knurl nut (F) on harp (E).

This can be used to raise the shade a little if necessary.

4. Place the shade (G) over the end of the harp (E) and

tighten the finial (H) securing the shade in place.

5. Insert the bulb into the bulb socket.

Recommended (1) maximum 75 WATT Type "A" Bulb

Or (1) maximum 18WATT CFL Bulb

(Bulb not included)

Cleaning of your lamp.

Unplug lamp, wipe with a damp cloth.

Do not use abrasives

*SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.

Made in China

FOR RETURN SHIPPING PURPOSES:

PLEASE RETAIN ORIGINAL

PACKAGING TO MINIMIZE DAMAGE.

Revision – 04/16/12

Table of Contents

Do you have a question about the TC11173 and is the answer not in the manual?

Page 1 FOR RETURN SHIPPING PURPOSES: ASSEMBLY INSTRUCTIONS: PLEASE RETAIN ORIGINAL Item No: TC11173 PACKAGING TO MINIMIZE DAMAGE. 1. Place the base (A) on a level surface. 2. Insert the harp (E) until it sits firmly into the saddle (D). 3. Adjust the knurl nut (F) on harp (E).
