ASSEMBLY INSTRUCTIONS:
Item No: TT13061
1.
Place the lamp base on a level surface.
2.
Screw the socket assembly (A) into the base.
3.
Screw the threaded rod (B) into socket assembly (A).
4.
Adjust the knurl nut (C) onto the threaded rod (B).
This can be used to raise the shade a little if necessary.
5.
Place the shade (D) over threaded rod (B), and tighten
with the finial (E) securing the shade in place.
6.
Insert bulbs into the bulb socket.
Recommended (2) maximum 60 WATT Type "A" Bulbs
or (2) maximum 13WATT CFL Bulbs
(Bulbs not included)
Cleaning of your lamp.
Unplug lamp, wipe with a damp cloth.
Do not use abrasives
*SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
Made in China
FOR RETURN SHIPPING PURPOSES:
PLEASE RETAIN ORIGINAL PACKAGING
TO MINIMIZE DAMAGE.
Revision – 04/09/13
E
D
C
B
A
