Front View
1 OLED screen
2 Quick Touch Border
(right side, tap only)
3 Quick Touch Border
(bottom, tap and slide)
NOTE: When you turn on the frame or tap the Quick Touch Borders, the screen icons appear and LED lights
turn on at touch-sensitive points along the Quick Touch Borders.
To use the Quick Touch Borders, see
See the Extended user guide
www.kodak.com/go/digitalframesupport
3
4
4 LED lights
5 Memory card slot - SD, SDHC, MMC, MS, xD
page
4.
www.kodak.com/go/digitalframesupport
1
2
4
5
1
Advertisement
Table of Contents
Related Manuals for Kodak OLED Wireless Frame
Summary of Contents for Kodak OLED Wireless Frame
-
Page 1: Front View
NOTE: When you turn on the frame or tap the Quick Touch Borders, the screen icons appear and LED lights turn on at touch-sensitive points along the Quick Touch Borders. To use the Quick Touch Borders, see See the Extended user guide www.kodak.com/go/digitalframesupport 4 LED lights 5 Memory card slot - SD, SDHC, MMC, MS, xD page... -
Page 2: Back/Side View
Back/Side View 1 USB connector (to computer) 2 USB connector (to camera/USB device) 3 Audio In 4 Audio Out 5 DC-In (12V) 6 Volume 7 Power 8 Speakers www.kodak.com/go/easysharecenter... -
Page 3: Getting Started
Getting started Attaching the power cable Your power cable may look different from the one pictured. Use the plug that accommodates your type of power outlet. Turning on your frame www.kodak.com/go/digitalframesupport Power button- press and hold for 2 seconds, then release. - Page 4 Tap lights next to buttons (No sliding here) Home Play slide show Done Close ** Tap below arrows to move the highlight one picture, menu, or item at a time. www.kodak.com/go/easysharecenter *Quick Touch Borders...
-
Page 5: Setting Your Language
After you set your language, your frame scans for available wireless networks. See Connecting to your wireless network, page Enjoying your pictures immediately! www.kodak.com/go/digitalframesupport Slide (or tap below slider arrows) on the bottom border to highlight your language, then tap Save. -
Page 6: Inserting A Memory Card
To remove a card, push in the card to release it. IMPORTANT: Do not insert a micro or mini memory card without an adapter. USB devices: camera, flash drive, card reader, etc. (sold separately) www.kodak.com/go/easysharecenter... -
Page 7: Setting Up For Wireless Operation
1 First time—If this is the first time you turned on your frame, tap OK after you set your language (page The Scanning for available wireless networks screen appears. www.kodak.com/go/digitalframesupport page 22. Or open KODAK EASYSHARE Digital Display page 11) and click Tools → Wireless Troubleshooter. - Page 8 (with the highest % signal strength) is usually listed first and highlighted. Or, to select another network, slide or tap below the arrows to highlight a network, then tap OK. → → Settings Network (page www.kodak.com/go/easysharecenter → Scan for below. 14).
- Page 9 The person who set up your network can provide you with this information. Congratulations! You have successfully connected to your network. Return to this screen later to verify your network and frame connections. See 3 If you haven’t done so already, install KODAK EASYSHARE Digital Display Software (see page 10) so your frame can display wireless content properly.
-
Page 10: Installing The Software
The CD that was packaged with your frame contains two applications that work well independently, but also work together for the best experience with your frame: KODAK EASYSHARE Digital Display Software between your frame and computer, and set up your frame for access to KODAK Gallery and Web content KODAK EASYSHARE Software IMPORTANT: We recommend that you install both. -
Page 11: Using The Software
When prompted, take a few minutes to electronically register your frame and software for exclusive tips and offers. To register later, visit www.kodak.com/go/register. Using the software Install the software that was packaged with your frame you want your frame to connect to wirelessly. Then double-click the EASYSHARE Digital Display Software icon Click Help in the menu bar for more information on using the software. - Page 12 Setting up access to Gallery and Web content On your computer, use EASYSHARE Digital Display Software to Web content such as your KODAK Gallery account, frequently changing RSS (Really Simple Syndication) photo feeds, music, or videos. 1 Make sure your computer is connected to the Internet.
-
Page 13: Verifying Computer/Device Connections
2 Tap Done to close the window and return to the Home screen. Your frame can now access the content on your host computer, wirelessly. Your computer appears as a picture source icon www.kodak.com/go/digitalframesupport Setting up for wireless operation (page... -
Page 14: Doing More With Your Frame
Viewing the Home screen/Web content Start at the Home screen to: access your pictures, videos, and music. play slide shows of Web content (KODAK Gallery, Flickr, FrameChannel RSS feeds) you set up (see page 12) and preloaded ones such as weather, sports, news, etc. - Page 15 Music (see page 19). KODAK Gallery—appears if you set up access to KODAK Gallery (see your Gallery albums and My Friends’ Albums. This icon ( shared pictures with you at the Gallery! See Web media—list of Flickr and FrameChannel RSS photo feeds you set up (see page 12).
-
Page 16: Accessing Your Pictures And Videos
2 Slide or tap below the arrows to highlight a picture source, then: (Play slide show) to start a slide show of the pictures in the highlighted source. Or, tap OK to view thumbnails, folders, etc. 18). www.kodak.com/go/easysharecenter (Pictures and Videos). (page 6). The label and icon indicate (page (page... -
Page 17: Viewing Pictures And Videos
– To play a whole folder of images, highlight the folder then tap show). – To play a video from thumbnails view, highlight a video thumbnail ( (Play slide show). www.kodak.com/go/digitalframesupport Doing more with your frame page (Pictures and Videos). Slide to highlight a picture source, (Thumbnails). - Page 18 NOTE: My Slide show plays automatically when you turn on your frame. The My Slide show icon ( appears on the Pictures and Videos screen as a picture source (see (Play slide show). → Save as My Slide show www.kodak.com/go/easysharecenter → OK. Tap Yes to page 16).
-
Page 19: Selecting Multiple Pictures
3 Slide right/left to go to the previous or next song, or select All, then tap Play. 4 Adjust the volume with the Volume button on top of the frame. NOTE: Music plays automatically when a memory card or USB device with music on it is connected. www.kodak.com/go/digitalframesupport (page 17), tap Select All. -
Page 20: Automatically Receiving My Friends' Albums
Your wireless frame uses the Picture Mail feature to automatically notify you ( when a friend shares pictures with you at the KODAK Gallery. Play a slide show of the new pictures, right on your frame, even before you see the email on your computer! -
Page 21: Learning More About Your Frame
To see the shared pictures later: 1 When the notice slide to choose Dismiss. 2 To see the new pictures, tap (KODAK Gallery), then tap OK. 3 With My Friends’ Albums highlighted, tap OK. 4 Highlight a marked album Purchase frame accessories, including decorative... - Page 22 Install the software that came with your frame (see Make sure your frame is connected to your wireless network (see page 13). For more possible causes/solutions, see Troubleshooting in the extended user guide at www.kodak.com/go/digitalframesupport. www.kodak.com/go/easysharecenter for updates. see page 8 to enter your page...
- Page 23 NOTE: NOTE: Pictures may take a longer time to display when: the picture/video files Touch border doesn’t work. www.kodak.com/go/digitalframesupport Make sure the power cable that was included with your frame is connected securely (see page Press and hold the power button for 2 seconds, then release (see page Unplug the power cable, wait 5 seconds, reconnect the cable.
- Page 24 (20 cm) for 2.4 GHz operations between the radiator and your body. This transmitter must not be collocated or operated in conjunction with any other antenna or transmitter. The use of an accessory that is not recommended by Kodak may cause fire, electric shock, or injury. For approved accessories, visit www.kodak/go/accessories.
-
Page 25: Limited Warranty
Warranty service will include all labor as well as any necessary adjustments and/or replacement parts. If Kodak is unable to repair or replace a Product, Kodak will, at its option, refund the purchase price paid for the Product provided the Product has been returned to Kodak along with proof of the purchase price paid. - Page 26 Kodak (such as adapters and cables), or claims made after the duration of this warranty. Kodak makes no other express or implied warranty for this product, and disclaims the implied warranties of merchantability and fitness for a particular purpose. In the event that the exclusion of any implied warranty is ineffective under the law, the duration of the implied warranty will be one year from the purchase date or such longer period as required by law.
- Page 27 Appendix FCC compliance and advisory KODAK OLED Wireless Frame, model OL7620 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 28 Appendix Hereby, Eastman Kodak Company declares that this Kodak product is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. This digital picture frame (OL7620) transmits in 10 dBm. In France, the power level is limited to 10dBm in outdoor environments, per regulations.
- Page 29 An independent license for such use is required. For details, visit http://mp3licensing.com. Eastman Kodak Company Rochester, New York 14650 © Eastman Kodak Company, 2008 Kodak and EasyShare are trademarks of Eastman Kodak Company. 4H5031_en www.kodak.com/go/digitalframesupport...
