  • Page 1 GlobalSat LT-10 Series User Manual Version: 0.9 USGlobalSat Incorporated GlobalSat WorldCom Corporation 14740 Yorba Court, Chino, CA 91710 16F., No. 186, Jian 1 Rd., Zhonghe Dist., Tel: 888.323.8720 / Fax: 909.597.8532 New Taipei City 23553, Taiwan sales@usglobalsat.com Tel: 886.2.8226.3799/ Fax: 886.2.8226.3899 lora@globalsat.com.tw...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. Warning ............................3 2. Welcome ............................4 3. Introduction ............................. 5 3.1 Introduction .........................5 3.2 LED Indicators ......................6 4. Device Operation ..........................6 4.1 Device Charging ......................6 4.2 Switch On/Off ......................7 4.3 Parameter Settings via Android App ................8 4.4 Firmware Upgrade via Android App ................

  • Page 3: Warning

    Indemnification: User agrees to defend, indemnify and hold harmless GlobalSat WorldCom Corp. and USGlobalSat, Inc., its officers, directors, employees and agents against and from any third party claims, actions, damages or demands, including but not limited to, reasonable legal and accounting fees, resulting from user's use or misuse of this product, violation of these Terms, or any activities related to this product, or from user's violations of the rights of any other user of this product.

  • Page 4: Welcome

    2. Welcome Thank you for purchasing the GlobalSat LT-10. The LT-10 is a light animal ear tag tracking device. We appreciate your purchase of a GlobalSat WorldCom Product!

  • Page 5: Introduction

    3. Introduction 3.1 Introduction The LT-10 is a solar LoRaWAN tracker designed for range animal use. The high ® performance solar cell can provide sufficient power for continuous LoRa transmission. They are the size of a standard management tag reusable GPS ear tag is powered using a battery and integrated solar cell.

  • Page 6: Led Indicators

    3. Introduction (Continued) 3.2 LED Indicators LoRa LED Blink Red 2 times State Data transmitting BLE LED Blink Red 2 times Blink Red 1 time Blink Red 1 time (100ms on,100ms off) per seconds per 5 seconds State LT-10 is able to do BLE LT-10 is searching for LT-10 is connected by advertising.

  • Page 7: Switch On/Off

    4.2 Switch On/Off 1. To turn the device “ON”, please take a proper magnet under device’s LED for 4 seconds as picture above. Then it would blink Red 3 times (100ms on, 100ms off). There are two kinds of behavior as following table when the device is on. Operation mode Low battery mode Take magnet under device’s LED for 1...

  • Page 8: Parameter Settings Via Android App

    1. Install LT-10 App as the following link and QR code. iOS version: http://d.3appstore.com/b9lj?utm_source=fir&utm_medium=qr Android version: https://play.google.com/store/apps/details?id=tw.com.globalsat.lt10 It would have icon as following. We use Android App’s operation as an example for chapter 4.3 and 4.4. 2. Make sure you turn on BLE for mobile device and open LT-10 App.
  • Page 9 5. Click Scan button, it will search for LT-10 device and click it which you would like to do settings as the following left picture. After pairing with the device, it would get settings. 6. Then FW version, LoRa MAC, device battery level, App Version would be shown at the bottom of menu.
  • Page 10 7. When entering into LoRaWAN settings, you could modify Join Mode, DevAddr, AppSKey, NwkSKey, Tx_Band etc. Please adjust these settings according to network server’s settings carefully. Otherwise, it will cause network server connection issue. After modifying all the settings, click Apply button to write all these settings to the device.
  • Page 11 8. You could also adjust tracker’s settings by modifying some parameters in GPS/ Operation Mode/Other Setting and click Apply button to write your settings to device.
  • Page 12 9. In case if you have the wrong settings and would like to return to factory default settings, please click Restore button as the following left picture. However, you will lose all values customizations.

  • Page 13: Firmware Upgrade Via Android App

    4.4 Firmware Upgrade via Android/iOS App I. Put firmware file to mobile phone 1. Connect your Android mobile phone and drop the firmware zip file (for example, F-0LR-49-2111181_dfu.zip) to a proper location, for example, the folder of SD card’s ‘Download’.
  • Page 14 II. Upgrade Firmware via Android App 1. Make sure you turn on BLE for mobile device and open LT-10 App. 2. Turn on device by putting magnetic under device’s LED for 4 seconds, it would blink Red 3 times. 3. Putting magnetic under device’s LED for 2 seconds till you see Red LED blink twice. Then move magnetic to be far from device.
  • Page 15 5. Click ‘Firmware Upgrade’ to start firmware upgrade. Then click Select button and click the firmware zip file which folder you ever drop under ‘Download’, for example, F-0LR-49-2111181_dfu.zip. 6. Click Apply button. Then click Confirm button to run Firmware upgrade process.
  • Page 16 7. When finishing firmware upgrade, it will show Upload complete as the following picture. Click Confirm to exit it.

  • Page 17: Safety Information

    Avoid direct prolonged exposure to sunlight and high temperatures to avoid the potential over-heating of the battery of this product, which may cause damage.  Please do not attempt to repair this device yourself, contact GlobalSat or USGlobalSat for Technical Support. ...
  • Page 18 GlobalSat/ USGlobalSat and becomes GlobalSat/ USGlobalSat’s property. If a defect arises and a valid claim is received by GlobalSat/ USGlobalSat after the first one hundred and eighty (180) days of Warranty period, a shipping and handling charge may apply to any repair or exchange...
  • Page 19 This Limited Warranty applies only to the hardware product manufactured by or for GlobalSat that can be identified by the “GlobalSat” trademark, trade name, or logo annexed to it. The Limited Warranty does not apply to any non-GlobalSat hardware product or any software, even if packaged or sold with the GlobalSat hardware.
  • Page 20 (i) by sending the unit to GlobalSat/ USGlobalSat location, where service is performed at the location, or (ii) by sending the unit to an authorized GlobalSat/ USGlobalSat supplier (iii) by sending you new or refurbished customer-installable replacement product or parts to enable you to service or exchange your own product (“RMA service”).
  • Page 21 GlobalSat/ USGlobalSat in a timely manner. When providing RMA service requiring the return of the original product or part, GlobalSat/ USGlobalSat may require credit card authorization as security for the retail price of the replacement product or part and applicable shipping costs.
