Lifetime SPEED SHIFT 90680 Assembly Instructions Manual

SPEED SHIFT
BASKETBALL SYSTEM
MODEL 90680
BEFORE ASSEMBLY:
• Decide how you would like to fi ll your base
(sand is recommended)
• At least 2 adults recommended for setup
WATCH
3D ANIMATION
OF THE FULL ASSEMBLY
SCAN THE
CODE
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY
TOOLS REQUIRED
1/2" (≈13 mm), 7/16" (≈11 mm),
9/16" (≈14 mm), 3/4" (≈19 mm)
(2 each)
(1)
(1)
QUESTIONS? CONTACT LIFETIME
Dial 1-800-225-3865
7:00 am–5:00 pm (M–F) MST
and 9:00 am–1:00 pm (Sat) MST
®
OR SEARCH
1215506
(1)
(1)
375 lb (≈170kg)
(1)
®
CUSTOMER SERVICE:
Live Chat:
www.lifetime.com/customerservice
(click on the "Live Chat" tab)
ASSEMBLY INSTRUCTIONS
Pour le français, voir la page 2. Para el español, ver la página 3.
3/16" (≈5 mm)
(2, included)
For Customer Service in Mainland
Europe and the United Kingdom,
E-mail: cs@lifetimeproducts.eu
TABLE OF CONTENTS
Icon Legend................................4
Warnings & Notices.....................5
Pole Assembly............................6
Pole-to-Base Assembly..............10
(1)
Backboard-to-Rim Assembly......14
Backboard-to-Pole Assembly......18
Parts Identifi er.........................i-iv
Handle Assembly......................22
Final Assembly.........................28
(1)
Maintenance............................32
Warning Sticker........................35
Registration........................36
Warranty................................37
Model Number: 90680
Product ID:
