Activating The Bluetooth Connection; Displaying The Firmware Version; Operation Via The App - DP -control III Installation & Operating Manual

6.3.5 Activating the Bluetooth connection

1. Press the turn/push button for a minimum of 5 seconds.
ð The Bluetooth connection symbol flashes. [ð Section 6.2.2, Page 25]
While the Bluetooth connection symbol flashes, the control unit can be connected to a
wireless device.
An existing connection is displayed by a continuously lit Bluetooth connection symbol on the
screen.
If no connection is established, the flashing Bluetooth connection symbol extinguishes after
some time.

6.3.6 Displaying the firmware version

Every time the pressure booster system is re-started the firmware version is displayed for a
short time. [ð Section 6.2.5, Page 26]
To have the firmware version displayed without re-starting the pressure booster system,
proceed as follows.
1. Turn the turn/push button to select the Locking/unlocking the screen symbol. Then
press the turn/push button.
ð The symbol flashes.
2. Turn the turn/push button to select the Servicing required symbol.
ð The firmware version is displayed on the bottom left and bottom right.

6.4 Operation via the app

Further configurations can only be made via the DP-Control app.
The app is available in the App Store or Google Play.
29 / 76
