Legend Symbols - Schellenberg TIMER PLUS Manual

Compatible with most exchange frames with a 50 x 50 mm
cutout according to DIN 49075� An adapter from the respec-
tive manufacturer is required� The timer switch features an
automatic changeover between daylight savings and standard
time� During the clock change the internal clock will be set
ahead or back by 1 hour�

LEGEND SYMBOLS
