Laser Safety - MICRO-EPSILON scanCONTROL 25 Series Assembly Instructions Manual

4.

Laser Safety

The scanCONTROL 25xx sensors operate with a semiconductor laser with a
wavelength of 658 nm (visible/red). Operation of the laser is indicated visually by the
LED on the sensor, see operating instructions Chap. 3.3.
When operating the scanCONTROL 25xx sensors, the relevant regulations according to
IEC 60825, Part 1 of 05/2014 and the applicable accident prevention regulations must
be followed. The laser warning labels for Germany have already been attached. For
other non German speaking countries, an IEC standard label is included in delivery and
the versions valid for the user's country must be attached before the device is put into
operation for the first time.
i
If both warning labels are covered over when the unit is installed, the user must
ensure that supplementary labels are attached.
Laser Class 2M
The sensors fall within laser class 2M (IIM). The laser is operated on a pulsed mode,
the maximum optical power is ≤ 8 mW.
Attach the following warning labels to the cover (front and rear side) of the sensor
housing.
Laser warning sign and laser label LLT25xx-25, LLT25xx-50, LLT25xx-100
COMPLIES WITH 21 CFR 1040.10 AND 1040.11
EXCEPT FOR CONFORMANCE WITH
IEC 60825-1 ED. 3., AS DESCRIBED IN
LASER NOTICE NO. 56, DATED MAY 8, 2019
scanCONTROL 25xx
Laser radiation. Close your eyes or immediately turn away if the
laser beam hits the eye. Irritation or injury of the eyes possible.
LASER RADIATION
DO NOT STARE INTO BEAM
OR EXPOSE USERS OF
TELESCOPE OPTICS
CLASS 2M LASER PRODUCT
IEC 60825-1: 2014
P ≤ 8 mW; P ≤ 8 mW; H ≤ 52 W/m²;
0 P
 = 658nm; F = 0...4 kHz; t = 1 µs...∞
Only for USA
i
Mark the laser area recognizable
and everlasting.
