- Page 1 domnick hunter Non-Cycling Refrigerated Dryer Models DNC200 - DNC1200 User Guide Rev. D...
-
Page 2: Table Of Contents
DNC200 - DNC1200 USER GUIDE Contents Transport / Inspection Environmental & Location Considerations Dryer Installation Plumbing the Air Lines Electrical Connections Controls - Standard on all models Start Up Procedures When Operating Dryer Routine Maintenance Maintenance Schedule Maintenance Procedures Troubleshooting / Service Refrigerant Charging Procedure Technical Data Spare Parts List... -
Page 3: Transport / Inspection
DNC200 - DNC1200 USER GUIDE Transport / Inspection Before unpacking/uncrating your new dryer, inspect the carton/crate for damage. Note any damage on the freight bill. File notice of concealed damage if: there are any dents in the cabinets there is any sign of oil on the skid or floor the refrigerant gauge shows NO pressure (Upper right side –... -
Page 4: Electrical Connections
Air piping must be supported independently of the dryer. • A properly sized Parker pre-filter must be installed ahead of the dryer to maintain optimal performance and warranty validation. It should be installed as close to the dryer as possible. Any piping between the pre-filter and inlet of the dryer must be stainless steel, copper, galvanized, aluminum or other non-corroding material. -
Page 5: Controls - Standard On All Models
DNC200 - DNC1200 USER GUIDE Controls - Standard on all models • Dryer ON/OFF Switch • Dryer POWER Light • HIGH REFRIGERANT PRESSURE ALARM • LOW REFRIGERANT PRESSURE ALARM • DEWPOINT TEMPERATURE INDICATOR • Adjustable time drain module mounted directly on drain solenoid 5 - Rev. -
Page 6: Start Up Procedures
DNC200 - DNC1200 USER GUIDE Start Up Procedures There should be NO air flow through the dryer before or during start-up. It is recommended that the dryer be installed with bypass piping to better service the unit. Inlet & outlet valves to the dryer should be closed with the by-pass valve open. -
Page 7: Routine Maintenance
Remove any debris immediately. • The strainer should be checked weekly. Pre-filtration per installation instructions: Parker pre-filter should be installed directly upstream from the dryer. • The pre-filter should be changed every 6-12 months to prevent dryer fouling and •... -
Page 8: Maintenance Schedule
DNC200 - DNC1200 USER GUIDE Maintenance Schedule The maintenance chart below indicates the components that should be checked while per- forming routine maintenance on the dryer. The chart also indicates how often a specific check should be performed. Description of Service Required Service recommended every: Component Operation... -
Page 9: Troubleshooting / Service
DNC200 - DNC1200 USER GUIDE Troubleshooting / Service Description Cause Remedy 1) Refrigerant leak 1) Locate leak. Repair & recharge. refrigerant 2) Low pressure switch defective 2) Replace pressure º 3) Increase ambient temperature 3) Ambient below 41 alarm High 1) Condenser dirty/blocked 1) Clean condenser refrigerant... -
Page 10: Technical Data
DNC200 - DNC1200 USER GUIDE Technical Data TECHNICAL DATA Electrical Compressor Fan motor Dryer Model V / Ph / Hz Fuse DNC200 230/1/60 12.2 230/1/60 12.1 17.0 230/3/60 11.6 DNC250 460/3/60 575/3/60 230/1/60 12.1 17.0 230/3/60 11.6 DNC325 460/3/60 575/3/60 230/3/60 11.6 DNC400... -
Page 11: Spare Parts List
DNC200 - DNC1200 USER GUIDE Spare Parts List MODEL Item DNC200 DNC250 DNC325 DNC400 DNC500 DNC700 DNC850 DNC1050 DNC1200 Replacement parts (DWG. # (DWG. # (DWG. # (DWG. # (DWG. # (DWG. # (DWG. # (DWG. # (DWG. # AD11511) AD11510) AD11509) AD11508) -
Page 12: Technical Specifications
DNC200 - DNC1200 USER GUIDE Technical Specifications 10.1 Air-Cooled Units Nominal Pipe Electrical Recommended Replacement Recommended Replacement Model Capacity Drain Size Supply Pre-Filter Element After-Filter Element (scfm) 2” 1/4” DNC200 230V/1PH/60Hz AO030GNFI 030AO AA030GNFI 030AA 230V/1PH/60Hz 2” 1/4” 230V/3PH/60Hz DNC250 AO035GNFI 035AO AA035GNFI... -
Page 13: Associated Drawings
DNC200 - DNC1200 USER GUIDE Associated Drawings REF: ADE11374 13 - Rev. D... - Page 14 DNC200 - DNC1200 USER GUIDE REF: ADE11374 14 - Rev. D...
- Page 15 DNC200 - DNC1200 USER GUIDE REF: ADE11374 15 - Rev. D...
- Page 16 DNC200 - DNC1200 USER GUIDE REF: ADE11374 16 - Rev. D...
- Page 17 DNC200 - DNC1200 USER GUIDE REF: ADE11374 17 - Rev. D...
-
Page 18: Exploded Views
DNC200 - DNC1200 USER GUIDE Exploded Views 18 - Rev. D... - Page 19 DNC200 - DNC1200 USER GUIDE 19 - Rev. D...
- Page 20 DNC200 - DNC1200 USER GUIDE 20 - Rev. D...
- Page 21 DNC200 - DNC1200 USER GUIDE 21 - Rev. D...
- Page 22 DNC200 - DNC1200 USER GUIDE 22 - Rev. D...
- Page 23 DNC200 - DNC1200 USER GUIDE 23 - Rev. D...
- Page 24 DNC200 - DNC1200 USER GUIDE 24 - Rev. D...
- Page 25 DNC200 - DNC1200 USER GUIDE 25 - Rev. D...
- Page 26 DNC200 - DNC1200 USER GUIDE 26 - Rev. D...
-
Page 27: Warranty Registration
IMPORTANT! Mail or Fax (716-685-1010) Today! Fold and Seal and your Service Warranty will be registered immediately. We are here to help. For more information on service or installation call the Service Department at 1-855-587-9323. Email to: fafwarranty@parker.com Model # Serial #... - Page 28 Colorado Springs, CO +31(0)75 655 50 00 719 531 5855 www.twinfilter.com www.velcon.com ©2014 Parker Hannifin Corporation. Product names are trademarks or registered trademarks of their respective companies DNC User Guide Rev. D Parker Hannifin Corporation Finite Airtek Filtration Division 4087 Walden Avenue...
