Simmonsigns PASSAFE Installation Manual

The Simmonsigns PASSAFE is a demountable post system ideal for
vulnerable sites or where posts need to be removed for wide loads etc.
It comes pre-wired for use with other 24 volt Simmonsigns products
and offers a quick change post facility as well as enhanced driver
safety. It is important that the foundation is prepared correctly to ensure
the structural integrity of the system should the post be impacted.
Excavation equipment.
Spirit level
Concrete mix
2 x 17mm AF spanner
19mm af socket
Small electrical screwdriver
1. The PASSAFE is supplied with a 24 volt 10 Amp supply module
which operates from a standard 240 volt supply. The 10 amp supply
can be used to power several 24 volt products totalling no more than
10 amps. This is sufficient to run two bollards, two Invinca 600mm
LED illuminated signs and one CENTRENOL or one MODUCIC
centre Island units over a cable distance of 50m (using 2.5mm
conductor size). This makes it ideal for use in centre island locations.
2. For maximum safety the 24 volt supply module should be mounted
away from the traffic threshold, but near a convenient fused 240 volt
supply. This could be in an existing lighting column or in a mini pillar.
24 volt cables are then run into the traffic zone presenting lower risk
to road users.
3. A typical wiring scheme for a centre island installation is shown
overleaf.
4. Referring to installation drawing (overleaf). Note that the Passafe
duct is ORANGE.
5. The PASSAFE foundation duct is engineered to be planted into
a foundation hole measuring 800mm x 800mm wide by 559mm
deep. For the purpose of drainage, the base of the hole should be
compacted hard core preferably in free draining ground.
6. Take the assembled foundation duct (as supplied) and place in the
bottom of the excavated hole with the Traffic flow indicators correctly
aligned. This ORIENTATION is VERY IMPORTANT
7. Once the orientation of the duct is set, feed in necessary ducting and
cable using appropriate 50mm and 100mm knife knock outs. NOTE:
the centre Ø50.00mm knockouts can be simply hammered out using a
ball pain or claw hammer. The outer annular may need to be scribed
through with a blade. The ducting should suit the proposed wiring plan.
Keep in mind a 25 metre supply cable is provided with the PASSAFE.
8. After ducting, check the duct orientation has not moved.
9. Next, taking note of the finished ground level indicators on the
foundation cover plate, level up using a spirit level. The foundation
cover plate clearly indicates the finished ground level with the text
reading "Ground level". This should be set level with any kerb tops or
the desired finished site level and levelled using a spirit level.
