Simmonsigns Solar Pulsa Installation Manual

SOLAR PULSA
Safety first
Wiring should be carried out in accordance with
current regulations by qualified engineers.
Ensure correct equipment is used to mount
components.
Tools required
5mm Security Allen key
6mm Security Allen key
13mm A/F Combination Spanner
13mm A/F Socket & Ratchet
3mm Spade End screwdriver
Solar Pulsa Post Installation
Install the post in line with the manufacturers
guidelines, taking into account the type of soil,
Solar Panel Installation
1) Place the pre-wired solar panel assembly onto
the top of the post passing the cable down the
post and into the base section.
2) Fix the panel spigot assembly to the post top
using its 4 No M10 socket set screws. Ensuring
that in the UK, the panel faces true south
3) Tighten the 4 No M10 socket set screws.
Battery & Regulator Assembly
1) Remove the battery and carrier from the
wooden board.
2) Secure the wooden board into the base of the
column using an M8 full nut and penny washer.
3) Replace the battery and carrier onto the
wooden board.
Simmonsigns Limited reserves the right to alter or improve this guide without prior notice.
simmonsigns.co.uk
+44 (0)7841 052 022
+44 (0)1952 293 333
sales@simmonsigns.co.uk
Telford Shropshire
TF3 3AS
Solar Pulsa
Installation Guide
Install the Pulsa
1) Drill a Ø14mm hole in the post at the required
height (2421mm from ground level to give a
height of 2100mm to the base of the Pulsa) -
ensure the hole is free from burrs and sharp
edges.
2) Pass the supply cable down the post to the
regulator assembly located in the base of the
post.
3) Fix the Pulsa to the post in accordance with the
standard Pulsa installation instructions found with
the Pulsa.
Connection
1) A qualified engineer should now make
connections to the regulator strictly in accordance
with the sunsaver operators manual supplied.
2) Once the above instruction has been completed,
the Smart Pulsa should then flash twice. A
calendar file can now be uploaded
3) Please ensure the Solar panel is placed with clear
line of sight to the sun, all year round.
Note: Failure to follow these instructions may
result in premature failure of the product.
Product Weights
SMART Pulsa
Solar Panel 15 kg
PULSA 6.25 kg
Battery Assembly 9.26 kg
Windage Information
Please see diagrams overleaf for general arrangement and
dimensions.
GPRS Pulsa
23 kg
6.25 kg
9.26 kg
Doc Ref: IG122
Issue Date: Apr 2019
Issue Number: 5
