2. Pin Definitions
Name No.
EN 41
GND 42
Notice:
For peripheral pin configurations, please refer to
2.3 Strapping Pins
ESP32-S2 has three strapping pins: GPIO0, GPIO45, GPIO46. The pin-pin mapping between ESP32-S2 and the
module is as follows, which can be seen in Chapter
• GPIO0 = IO0
• GPIO45 = IO45
• GPIO46 = IO46
Software can read the values of corresponding bits from register "GPIO_STRAPPING".
During the chip's system reset (power-on-reset, RTC watchdog reset, brownout reset, analog super watchdog
reset, and crystal clock glitch detection reset), the latches of the strapping pins sample the voltage level as strapping
bits of "0" or "1", and hold these bits until the chip is powered down or shut down.
IO0, IO45 and IO46 are connected to the internal pull-up/pull-down. If they are unconnected or the connected
external circuit is high-impedance, the internal weak pull-up/pull-down will determine the default input level of these
strapping pins.
To change the strapping bit values, users can apply the external pull-down/pull-up resistances, or use the host
MCU's GPIOs to control the voltage level of these pins when powering on ESP32-S2.
After reset, the strapping pins work as normal-function pins.
Refer to Table 3 for a detailed boot-mode configuration of the strapping pins.
Pin
2
IO45
Pin
IO0
IO46
Pin
IO46
Espressif Systems
Type Function
High: on, enables the chip.
I
Low: off, the chip powers off.
Note: Do not leave the EN pin floating.
P Ground
ESP32-S2 User
5
Table 3: Strapping Pins
VDD_SPI Voltage
Default
Pull-down
Booting Mode
Default
Pull-up
Pull-down
Enabling/Disabling ROM Code Print During Booting
Default
Pull-down
Submit Documentation Feedback
Manual.
Schematics:
1
3.3 V
0
SPI Boot
1
Don't-care
Enabled
See the fourth note
6
ESP32-S2-WROOM & ESP32-S2-WROOM-I User Manual V0.5
1.8 V
1
Download Boot
0
0
3 4
Disabled
See the fourth note
