4. Electrical Characteristics
4.1 Current Consumption Characteristics
With the use of advanced power-management technologies, the module can switch between different power
modes. For details on different power modes, please refer to Section RTC and Low-Power Management in
S2 User Manual.
Work mode
Active (RF working)
Note:
• The current consumption measurements are taken with a 3.3 V supply at 25 °C of ambient temperature at the RF
port. All transmitters' measurements are based on a 50% duty cycle.
• The current consumption figures for in RX mode are for cases when the peripherals are disabled and the CPU idle.
Work mode
Modem-sleep
Light-sleep
Deep-sleep
Power off
Note:
• The current consumption figures in Modem-sleep mode are for cases where the CPU is powered on and the cache
idle.
• When Wi-Fi is enabled, the chip switches between Active and Modem-sleep modes. Therefore, current consump-
tion changes accordingly.
• In Modem-sleep mode, the CPU frequency changes automatically. The frequency depends on the CPU load and
the peripherals used.
• During Deep-sleep, when the ULP co-processor is powered on, peripherals such as GPIO and I²C are able to
operate.
• The "ULP sensor-monitored pattern" refers to the mode where the ULP coprocessor or the sensor works periodi-
cally. When touch sensors work with a duty cycle of 1%, the typical current consumption is 7 µA.
Espressif Systems
Table 7: Current Consumption Depending on RF Modes
802.11b, 20 MHz, 1 Mbps, @ 22.31dBm
802.11g, 20 MHz, 54 Mbps, @ 25.00dBm
TX
802.11n, 20 MHz, MCS7, @ 24.23dBm
802.11n, 40 MHz, MCS7, @ 22.86 dBm
802.11b/g/n, 20 MHz
RX
802.11n, 40 MHz
Table 8: Current Consumption Depending on Work Modes
Description
240 MHz
The CPU is
160 MHz
powered on
Normal speed: 80 MHz
The ULP co-processor is powered on.
ULP sensor-monitored pattern
RTC timer + RTC memory
RTC timer only
CHIP_PU is set to low level, the chip is powered off.
