Keyspan USB Serial Adapter Software v2.x for Mac OS X User Manual

7.1.cx.04 - Final Cut Pro

This Configuration Example assumes that you have already done the following:
7.installed the Keyspan serial port hardware and software
8.installed the Final Cut Pro software
9.connected your video deck hardware to a Keyspan serial port.
If you have not performed any of the steps mentioned above, please do so before proceeding.
Step 1
-
Check the Keyspan Serial Assistant
Before proceeding, you should check to see if the Keyspan serial port is installed correctly.
Keyspan Serial Assistant
To do this, open the
Keyspan Serial Assistant
open the
If your Keyspan hardware and software are installed correctly, the 'Serial Ports' text box will
show an icon of your Keyspan serial product. If you do not see an icon of your Keyspan serial
Keyspan Tech Support
product , contact
Click on the TRIANGLE to the left of your Keyspan icon. This will display the names of the
serial port(s) on that Keyspan product as shown below:
Note the the serial port name in the
in the Final Cut Pro software later.
Note: If you have a Keyspan product that has more than one serial
port, note the serial port name of the serial port that your Palm is con-
nected to. Typically, the last 2 letters indicate the port number on
your Keyspan hardware (ie P1 = port 1, P2 = port 2, etc.)
Step 2 -
Setup the Final Cut Pro Software.
Launch Final Cut Pro.
Under the Final Cut Pro menu, select Audio/Video Settings. (see below)
(located in your Applications folder). When you
.
for further information.
*** IMPORTANT ***
Keyspan Serial Assistant
Rev 2006aug07 Page 35
. We will be selecting this port name
